www.mypidion.com
Handheld Mobile Computer
BP30
User's Manual
∙Please read the following warnings before using the product.
∙ S hapes and colors of the images shown in this manual may differ from the actual products.
∙ C ontents of the manuals may differ based on the software version of products or conditions of the wireless provider.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bluebird BP30
Summary of Contents for Bluebird BP30
- Page 1 Handheld Mobile Computer BP30 User's Manual ∙Please read the following warnings before using the product. ∙ S hapes and colors of the images shown in this manual may differ from the actual products. ∙ C ontents of the manuals may differ based on the software version of products or conditions of the wireless provider.
-
Page 2: Registered Trademark
• This user manual is protected by copyright. • This user manual has been created by the Bluebird Inc. We have done our best not to create typos, editing errors, and leaving out any information. Please understand if there are any inconveniences. - Page 3 Most compliance for this requirement is stated from the specification of the frequency generation portion of the device and not necessarily through additional testing. Hereby, Bluebird Inc. declares that this BP30 is in compliance with the essential requirements and other relevant provisions of directive 1999/5/EC.
-
Page 4: Table Of Contents
..........Warranty Certificate BP30 MANUAL... -
Page 5: Notice Before Using Device
• Do not paint your device. It can damage your screen or your device’s exterior. Also, the paint can peel off and it triggers allergies. If there is allergic reaction, please find medical advice. BP30 MANUAL... -
Page 6: Precautions Before Using Battery
2) A lithium ion battery pack shall be marked with the following or equivalent: “CAUTION: Risk of Fire and Burns. Do Not Open, Crush, Heat Above (50°C). Follow Manufacturer’s Instructions.” This wording or equivalent shall also be included in the instructions packaged with the battery pack. BP30 MANUAL... -
Page 7: About The Product
The images in this User’s Manual may not reflect the color and shape of the actual product. Please contact the Customer Care Center if you wish to purchase any additional or optional products. Battery Cover BP30 Main Body LCD Protect Film(Optional) Battery Adaptor (Optional) -
Page 8: Checking Names Of Parts
Power button Home button Cancel button Menu button Microphone Cradle I/O Connector Barcode Scan Window LED Flash Camera < Rear > Handstrap hole Battery lock Barcode Scan Button Battery cover Volume Up Volume Down MicroUSB Port Audio I/O Port BP30 MANUAL... -
Page 9: Buttons
2. Menu button Select the menu. 3. Home button Press to return to the Home screen. 4. Cancel button Tap to return to the previous screen. 5. Volume button Press to adjust the device volume. 6. PTT button PTT(Push-To-Talk) Function. BP30 MANUAL... -
Page 10: Learning Basics
Push the battery to the direction of the arrow. • Be careful not to damage your fingernails when you remove the back cover. • Do not bend or twist the back cover excessively. Doing so may damage the cover. WARNING BP30 MANUAL... - Page 11 Learning Basics Push down the battery cover. Replace the back cover. Turn the battery lock. • Only use the supplied adapter to charge your battery. WARNING BP30 MANUAL...
-
Page 12: Remove The Battery
Learning Basics 1-2 Removing the battery Turn the battery lock. Remove the battery cover. Pull out the battery. • Do not remove the battery before removing the charger. This may damage the device. WARNING BP30 MANUAL... -
Page 13: How Th Use Cards
Push the memory card into the slot until it locks in place. 2-2 Insert the MicroSD card Insert a memory card with the gold-coloured contacts facing downwards. Push the memory card into the slot until it locks in place. BP30 MANUAL... -
Page 14: Insert The Micro Sim Card(Optional)
Push the memory card into the slot until it locks in place. 2-4 Removing the card Push the card until it disengages from the device, and then pull it out. ∙ Do not insert a memory card into the Micro SIM card slot. WARNING BP30 MANUAL... -
Page 15: Charging The Battery
Charge the battery before using it for the first time. Use the charger to charge the battery. 3-1 Direct charging Plug the small end of the cable into the micro USB port on the device and plug the normal USB connector of cable into an charger. BP30 MANUAL... -
Page 16: Cradle Charging
∙ When the device's battery is low, it may warn you with a ring and a message. ∙ The charging time can vary depending on the environment. WARNING A new battery is only partially charged. Please charge fully before using. BP30 MANUAL... -
Page 17: Tuning On
Learning Basics 4. Tuning On ∙ T he [Power] button on the side. ∙ P ress the [Power] button shortly due to turn on. BP30 MANUAL... -
Page 18: Using The Barcode Reader
Press the [Scan] button either on the side. Then Start to scan barcodes. 2. Scanning Barcodes In order to scan accurately, you must scan with the correct angle 10cm away. Correct scanning Angle ∙ If you are using Barcodes with special programs, please contact the manufacturing company. WARNING BP30 MANUAL... -
Page 19: Card Reader
MSR card down in the direction of the arrow shows. MSR terminal is to the left. MSR can recognize the card in bi- directions. 2. NFC card reader If you touch the picture card as the payment is to NFC. BP30 MANUAL... -
Page 20: Device Specifications
Optional, 802.11 a/b/g/n (802.11n 2.4GHz and 5GHz) WPAN Radio Optional, Bluetooth Classs II V4.0 PAYMENT OPTIONS Optional, Integrated Magnetic Stripe Reader (MSR) Optional, Integrated contactless Card Reader ∙ Please ask your sales representative for the specs not listed above. WARNING BP30 MANUAL... -
Page 21: Q & A
Please contact to your service center. The BP30 won’t turn on. The program may be damaged. Please try resetting your device. If it still doesn’t work, Please contact the service center. -
Page 22: Service Center
• Do not intentionally damage the label on the product. • Damaged label may result in a disadvantage to the customer. • When you return the product to Bluebird for service, please put the product in a protective box. • Warranty will not be provided for any damage occurring during delivery. - Page 23 • Loss of product or other components (CD, diskette, manual, connecting cables, etc). WARNING • Damage to the product after 10 days of purchase, the product will either be exchanged or provided with after-sales service (note, returning of goods or repayment is not allowed). BP30 MANUAL...
-
Page 24: Warranty Certificate
1 year from purchase Warranty 1. Bluebird Inc. (hereinafter referred to as Bluebird) provides the warranty service for its products in compliance with the regulations on compensation for damage of customer. 2. Upon receiving a notification on a defect of its product within the range of warranty during the warranty period, Bluebird will repair or replace the defective product according to its warranty policy. - Page 25 W e ar e not open on Satur day, Sundays and National Holidays. Addr ess Customers service center, SSang-young IT twin tower B 703, Sangdaewon-dong 442-5, Joongwon-gu, Sungnam-si, K eonggi-do, K or ea Bluebir d constantly strives to bring utmost satisfaction to all our customers. BP30 MANUAL...
