Bluebird BP30 Manual

Barcode controller
Hide thumbs Also See for BP30:

Advertisement

Quick Links

Download this manual See also: User Manual
Barcode Controller
Scenario & Manual
BP30/BM180, EF400/EF500
Bluebird, inc.
ver : 1.3

Advertisement

loading
Need help?

Need help?

Do you have a question about the BP30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bluebird BP30

Summary of Contents for Bluebird BP30

  • Page 1 Barcode Controller Scenario & Manual BP30/BM180, EF400/EF500 Bluebird, inc. ver : 1.3...
  • Page 2 Contents 1. Introduction 2. BarcodeController working scenario(Chart) 3. BarcodeController working scenario(Details) 4. Exception 5. Information...
  • Page 3 1. Introduction - 1 Purpose  BarcodeController is an Android service that allows App to use Barcode module on • Android OS based devices. This document is a summary of scenario and program development to support the user • on building application that uses barcode with BarcodeController. Information ...
  • Page 4 1. Introduction - 2 Term definition  app : • Android application that communicates with BarcodeController. The users actually uses this application. BarcodeController : • Middleware(Android service) that allows application to use Barcode Module. DataWedgeMode : • Function that allows to read in barcode data without building additional application. Read-in value goes into text window of current screen where the cursor is on.
  • Page 5 1. Introduction - 2 Term definition  Profile : • Database that sets function details of Barcode module. Changeable on BBSettings app on device. Sequence number : • The value to distinguish each intend when application send Intent to BarcodeController. When BarcodeController returns the result to app (ACTION_BARCODE_REQUEST_SUCCESS/FAILED), this value is save in Intent.
  • Page 6 2.1 BarcodeController Operation scenario BarcodeController User App ACTION_BARCODE_CALLBACK_REQUEST_SUCCESS ACTION_BARCODE_OPEN EXTRA_INT_DATA3 : Sequence num EXTRA_INT_DATA3 : Sequence num ACTION_BARCODE_CALLBACK_REQUEST_FAILED EXTRA_INT_DATA2 : 에러ID EXTRA_INT_DATA3 : Sequence num ACTION_BARCODE_SET_TRIGGER EXTRA_INT_DATA2 : trigger value(1:on / 0:off) ACTION_BARCODE_CALLBACK_DECODING_ EXTRA_INT_DATA3 : Sequence num DATA EXTRA_BARCODE_DECODING_DATA : Barcode read data(byte[]) EXTRA_INT_DATA3 : Sequence num ACTION_BARCODE_CALLBACK_REQUEST_FAILED...
  • Page 7 3.1 Specific Scenario Barcode Open  Opens Barcode module. Function that allows Barcode module and use app to communicate. • If module Open is successful, handle value will be transferred through • ACTION_BARCODE_CALLBACK_REQUEST_SUCCESS. If the Module fails to open, it will return ACTION_BARCODE_CALLBACK_REQUEST_FAILED Intent. •...
  • Page 8 3.2 Specific Scenario Barcode Set Trigger  Function that delivers trigger command to Barcode module and sets beam to on/off and sets barcode read to standby mode. • If the Intent is used, EXTRA_INT_DATA2 should be sent as 0 or 1.(0:trigger off / 1:trigger on) •...
  • Page 9 3.3 Specific Scenario Barcode Decoding Timeout  Intent that BarcodeController transfers to application if valid barcode read is not tried for Decoding Timeout • period(default: 5 seconds). ( ACTION_BARCODE_CALLBACK_REQUEST_FAILED). ACTION_BARCODE_SET_TRIGGER(EXTRA:1)  ACTION_BARCODE_CALLBACK_REQUEST_FAILED(-6) Put extra : Name ExtraName Type EXTRA_HANDLE EXTRA_HANDLE EXTRA_INT_ERROR_ID EXTRA_INT_DATA2 EXTRA_INT_SEQUENCE_ID...
  • Page 10 3.4 Specific Scenario Barcode Close  Intent : -> finished module activation through transfer close command to the barcode module. • If the closed process is completed, the program cannot use the barcode module until the module is re-opened using •...
  • Page 11 3.5 Specific Scenario Barcode Get Status  Description : Current barcode status value. • STATUS_CLOSE(0) / STATUS_OPEN(1) / STATUS_TRIGGER_ON(2) • ACTION_BARCODE_GET_STATUS  ACTION_BARCODE_CALLBACK_GET_STATUS Put extra : Name ExtraName Type EXTRA_HANDLE EXTRA_HANDLE EXTRA_INT_STATUS_ID EXTRA_INT_DATA2 EXTRA_INT_SEQUENCE_ID EXTRA_INT_DATA3 Example  …. BarcodeIntent.ACTION_BARCODE_GET_STATUS); String action = intent.getAction(); if(action.equals(BarcodeIntent.ACTION_BARCODE_CALLBACK_GET_STATUS)) intent.putExtra(“EXTRA_HANDLE”, handle);...
  • Page 12 3.6 Specific Scenario Barcode Set Parameter  The function set the Barcode specific value without BBSetting option. • The parameter has to be set using the standard registered values in BBAPI class • Values have to be set depending on the parameter •...
  • Page 13 3.7 Specific Scenario Barcode Get Parameter  The function can check the Barcode specific value. • Parameter have to set the registered values in BBAPI class • A parameter of values has to be set in BBAPI class. • ACTION_BARCODE_SET_PARAMETER  ACTION_BARCODE_CALLBACK_PARAMETER Put extra : Name ExtraName...
  • Page 14 3.8 Specific Scenario Barcode Preview  The function can Preview. • Method name • 1) public void onPreviewFrame(int fullLength, boolean option, int width, int height, byte[] data) Param Explain Type fullLength Data length option Option value Boolean width width height height data Data array...
  • Page 15 3.8 Specific Scenario Barcode Preview   Example private BarcodeRemoteServiceManager mRemoteServiceManager; //call stop capture mRemoteServiceManager.stopCapture(); protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); //get remoteService manager mRemoteServiceManager = (BarcodeRemoteServiceManager)getSystemService(Context.BARCODE_REMOTE_SERVICE //initialize callback mRemoteServiceManager.initialize(mRemoteCallback); //implement callback method private IBarcodeRemoteCallback mRemoteCallback = new IBarcodeRemoteCallback.Stub() { …...
  • Page 16 4. Exception If scan key is press on DataWedgeMode : On / Status : Close Mode  Delay occurs for 2~3 seconds until beam turns on since Trigger gets on after completion • of Open operation If attempts to symbology was made to while it is set as disabled on Profile ...
  • Page 17 5.1 Information Intent set  Name Type Content ACTION_BARCODE_OPEN String BarcodeIntent. ACTION_BARCODE_OPEN ACTION_BARCODE_CLOSE String BarcodeIntent. ACTION_BARCODE_CLOSE ACTION_BARCODE_SET_TRIGGER String BarcodeIntent. ACTION_BARCODE_SET_TRIGGER ACTION_BARCODE_CALLBACK_DECODING_DATA String BarcodeIntent. ACTION_BARCODE_CALLBACK_DECODING_DATA ACTION_BARCODE_CALLBACK_REQUEST_SUCCESS String BarcodeIntent. ACTION_BARCODE_CALLBACK_REQUEST_SUCCESS ACTION_BARCODE_CALLBACK_REQUEST_FAILED String BarcodeIntent. ACTION_BARCODE_CALLBACK_REQUEST_FAILED...
  • Page 18 5.2 Information Error Id  Name realValue Type ERROR_DECODING_TIMEOUT Timeout period is passed after Trigger on ERROR_USE_TIMEOUT No Action is take after 30 seconds from last Action(except CLOSE) ERROR_BATTERY_LOW If barcode related Action has been made when battery is lower than ERROR_NOT_SUPPORTED Unsupportable API ERROR_NORMAL...
  • Page 19 5.3 Information Symbology ID  Name Name Name SYMBOLOGY_UPC_A SYMBOLOGY_ISBT128 SYMBOLOGY_KOREAN_POST SYMBOLOGY_UPC_E SYMBOLOGY_COMPOSITE_CC_C SYMBOLOGY_US_POSTNET SYMBOLOGY_UPC_E1 SYMBOLOGY_MATRIX2OF5 SYMBOLOGY_US_PLANET SYMBOLOGY_EAN8 SYMBOLOGY_DATAMATRIX SYMBOLOGY_UPC_A_PREAMBLE SYMBOLOGY_EAN13 SYMBOLOGY_MAXICODE SYMBOLOGY_UPC_A_TRANSMIT_CHECK_DIGIT SYMBOLOGY_BOOKLAND SYMBOLOGY_AZTECCODE SYMBOLOGY_UPC_E_PREAMBLE SYMBOLOGY_SUPPLEMENTAL_CODE SYMBOLOGY_MICROPDF SYMBOLOGY_UPC_E_TRANSMIT_CHECK_DIGIT SYMBOLOGY_CODE39 SYMBOLOGY_QRCODE SYMBOLOGY_UPC_E1_PREAMBLE SYMBOLOGY_CODE93 SYMBOLOGY_TRIOPTIC_CODE SYMBOLOGY_UPC_E1_TRANSMIT_CHECK_DIGIT SYMBOLOGY_CODE128 SYMBOLOGY_DISCRETE2OF5 SYMBOLOGY_EAN8_EXTEND SYMBOLOGY_INTERLEAVED2OF5 SYMBOLOGY_USPS4CB SYMBOLOGY_EAN_TRANSMIT_ISSN SYMBOLOGY_CODABAR SYMBOLOGY_AUSTRALIA_POST...
  • Page 20 5.4 Information Symbology ID  Name Name Name SYMBOLOGY_MATRIX2OF5_SUPPLEMENTAL_RE SYMBOLOGY_CODE39_CHECK_DIGIT SYMBOLOGY_CODE11_LENGTH_MIN DUNDANCY SYMBOLOGY_CODE39_TRANSMIT_CHECK_DIGIT SYMBOLOGY_CODE11_LENGTH_MAX SYMBOLOGY_MATRIX2OF5_CHECK_DIGIT SYMBOLOGY_MATRIX2OF5_TRANSMIT_CHECK_ SYMBOLOGY_CODE39_FULL_ASCII SYMBOLOGY_CODE11_CHECK_DIGIT DIGIT SYMBOLOGY_CODE11_TRANSMIT_CHECK_DIGI SYMBOLOGY_CODE93_LENGTH_MIN SYMBOLOGY_COMPOSITE_CC_AB SYMBOLOGY_CODE93_LENGTH_MAX SYMBOLOGY_MSI_LENGTH_MIN SYMBOLOGY_COMPOSITE_TLC_39 SYMBOLOGY_CODE128_LENGTH_MIN SYMBOLOGY_MSI_LENGTH_MAX SYMBOLOGY_COMPOSITE_UPC SYMBOLOGY_CODE128_LENGTH_MAX SYMBOLOGY_MSI_CHECK_DIGIT SYMBOLOGY_DATAMATRIX_INVERSE SYMBOLOGY_CODE128_EMULATION SYMBOLOGY_MSI_TRANSMIT_CHECK_DIGIT SYMBOLOGY_DATAMATRIX_ONLY SYMBOLOGY_INTERLEAVED2OF5_LENGTH_MIN SYMBOLOGY_MSI_CHECK_DIGIT_ALGORITHM SYMBOLOGY_DISCRETE2OF5_LENGTH_MIN SYMBOLOGY_INTERLEAVED2OF5_LENGTH_MAX SYMBOLOGY_GS1_LIMITED SYMBOLOGY_DISCRETE2OF5_LENGTH_MAX SYMBOLOGY_INTERLEAVED2OF5_CHECK_DIGIT SYMBOLOGY_GS1_LIMITED_SECURITY_LEVEL SYMBOLOGY_US_TRANSMIT_CHECK_DIGIT...
  • Page 21 5.5 Information Symbology ID  Name Name Name SYMBOLOGY_CONVERT_UPCE1_TO_A SYMBOLOGY_MICROQR SYMBOLOGY_CONVERT_CODE39_TO_32 SYMBOLOGY_HANXIN SYMBOLOGY_CONVERT_I2OF5_TO_EAN13 SYMBOLOGY_HANXIN_INVERSE SYMBOLOGY_CONVERT_GS1_TO_UPCEAN SYMBOLOGY_IATA SYMBOLOGY_GS1_DATABAR_EXPANDED SYMBOLOGY_EAN128 SYMBOLOGY_GS1_128_EMULATION_FOR_UCC_CO SYMBOLOGY_UPC_D MPOSITE_CODE SYMBOLOGY_INVERSE_1D SYMBOLOGY_GS1_DATABAR SYMBOLOGY_UPU_FICS_POSTAL SYMBOLOGY_SCANLET SYMBOLOGY_UPC_COMPOSITE_MODE SYMBOLOGY_CUECODE SYMBOLOGY_AZTEC_INVERSE SYMBOLOGY_SIGNATURE_CAPTURE SYMBOLOGY_SPECIFIC_REDUNDANCY_LEVEL SYMBOLOGY_AUSTRALIA_POST_FORMAT SYMBOLOGY_TRANSMIT_UK_POST_CHECK_DIGIT SYMBOLOGY_CODE32_PREFIX SYMBOLOGY_USER_SUPPLEMENTAL_1 SYMBOLOGY_USER_SUPPLEMENTAL_2...
  • Page 22 For more information www.mypidion.com Copyright © 2013 Bluebird Inc. All Rights Reserved.
