Contents
Chapter 1 Quick Installation .................... 3
1.1 Layout ...................................................................................... 3
1.2 CPU setting .............................................................................. 4
1.3 Jumpers .................................................................................... 4
1.4 Expansion Slots / Sockets ....................................................... 8
1.5 Connectors ............................................................................... 9
1.6 Form Factor ............................................................................ 16
Chapter 2 Overview ................................ 17
Chapter 3 Features ................................. 20
3.1 Motherboard Components Placement .................................. 20
3.2 Back Panel ............................................................................. 22
3.3 Block Diagram ....................................................................... 23
3.4 Specifications ......................................................................... 24
Chapter 4 Hardware Setup .................... 26
4.1 Before Installation ................................................................. 26
4.3 Install the Processor .............................................................. 31
4.4 Install Memory Modules ...................................................... 35
4.5 Install PCI Expansion Cards ................................................. 36
4.6 Usage of the AMR slot ......................................................... 38
4.7 Connect Devices and Power Supply ..................................... 38
WA133 Series Rev 1.2A
FB2A319301100
1
Advertisement
Table of Contents
Related Manuals for IWILL wa133
Summary of Contents for IWILL wa133
-
Page 1: Table Of Contents
4.3 Install the Processor .............. 31 4.4 Install Memory Modules ............35 4.5 Install PCI Expansion Cards ..........36 4.6 Usage of the AMR slot ............38 4.7 Connect Devices and Power Supply ........38 WA133 Series Rev 1.2A FB2A319301100... - Page 2 5.7 Power Management Setup ............ 66 5.8 PnP/ PCI Configurations ............69 5.9 PC Health Status ..............70 5.10 IWILL Smart Setting ............71 5.11 Load Fail-Safe Defaults ............73 5.12 Load Optimized Defaults ............ 74 5.13 Set Supervisor / User Password Setting ......74 5.14 Save &...
-
Page 3: Chapter 1 Quick Installation
Several easy installation steps will be described in this chapter to help the experienced users with quick installation. If you are a beginner, or need to know more about this product, please refer to Hardware Setup. 1.1 Layout WA133 Series... -
Page 4: Cpu Setting
700Mhz(100x7) Pentium III 533EB 1.60V, FCPGA 533Mhz(133x4) Pentium III 600EB 1.65V, FCPGA 600Mhz(133x4.5) Pentium III 667EB 1.65V, FCPGA 667Mhz(133x5) Pentium III 733EB 1.65V, FCPGA 733Mhz(133x5.5) 1.3 Jumpers JP1 (CMOS) Clear CMOS jumper JP2 SCSI Enabled / Disabled jumper WA133 Series... - Page 5 CPU automatically. In this case you need not go to BIOS to do setup. If you want to have some further setting, the CPU speed is setup using “IWILL Smart Setting”. This is found in the BIOS setup program by pressing <Del> during the boot up process.
- Page 6 This jumper is used to select the CPU core voltage. JP10 (VIO) VIO select jumper This jumper is used to select the VIO voltage. JP13 (AC 97) AC97 Codec Enabled / Disabled jumper This jumper is used to enable / disable the onboard audio CODEC. WA133 Series...
- Page 7 Chapter 1 Quick Installation JP15 (LAN) LAN Enabled / Disabled jumper (WA133-SN only) This jumper is used to enable / disable the onboard LAN chip. JP16 (FLASH) FLASH protect jumper This jumper is used to select the Flash ROM protected mode.
-
Page 8: Expansion Slots / Sockets
Single-Side Module Double-Side Module DM2 must be empty 1.DM1 must have a single-side module Single-Side Module 2.Must be the same or half memory size of DM1 Double-Side Module DM1 must be empty Total System Memory (Max 512 MB) WA133 Series... -
Page 9: Connectors
Chapter 1 Quick Installation J12—J17 (PCI 1—PCI 6) PCI expansion slots J27 (AMR) AMR Slot 1.5 Connectors J25 SCSI Channel 50-pin connector WA133 Series... - Page 10 Chapter 1 Quick Installation J28 (IDE0) Primary ATA/66 IDE channels J29 (IDE1) Secondary ATA/66 IDE channels J30 (FDC) Floppy connector J32 (COM2) This is an internal connector for COM2 port. WA133 Series...
- Page 11 J39 (FCPU) & J40 (FAUX) & J41 (FSYS) There are three fan connectors on this motherboard. The J39 (FCPU) is designed to support CPU fan; the J41 (FSYS) is for system fan used and you can connect any auxiliary fan to the J40 (FAUX). WA133 Series...
- Page 12 This connector is composed of all the headers that may be connected to the front panel of the chassis. J45 (IR) This connector is designed for the SIR/FIR/CIR devices. WA133 Series...
- Page 13 J47 (WOM) This connector can be connected to MR card or internal modem card to provide the ability of power on by modem device. J48 (SMBUS) This connector provides the connectivity of SMBUS utilization. WA133 Series...
- Page 14 This connector only supports the digital LCD panel. An analog LCD panel comes with a 15-pin VGA connector can be used on the external VGA connector. J54 (CD_IN) The audio output can be transfered from CD-ROM to the audio system through this connector directly. WA133 Series...
- Page 15 Chapter 1 Quick Installation External COM1 connector External Parallel connector External PS/2 mouse & keyboard connector External Dual USB & RJ45 connector External VGA connector External Game / Line-in / Line-out / MIC connector WA133 Series...
-
Page 16: Form Factor
Chapter 1 Quick Installation 1.6 Form Factor WA133 Series... -
Page 17: Chapter 2 Overview
] Iwill SIDE-DU280 PCI Dual channel Ultra2 SCSI controller ] MR card Introduction The WA133-S series motherboard is the most flexible platform in today’s market based on the newest Intel® i810E chipset. A major advancement in chipset technology, the Intel®i810E WA133 Series... - Page 18 (Coppermine-256 <Pentium III> and Cumine-128 <Celeron>) without any headache. It can support the processors that packed as a PPGA or FCPGA type. In other words, no matter what kind of processors you have in PPGA or FCPGA , the WA133-S motherboard always provides you an adequate solution.
- Page 19 Hsin Chuang City, Taipei, Taiwan, R.O.C. Declare under sole responsibility that the WA133-S motherboard Meets the intent of Directive 89/336/ECC for Electromagnetic Compatibility. Compliance was demon- strated to the following specifications as listed in the official Journal of the European Communities:...
-
Page 20: Chapter 3 Features
Chapter 3 Features Chapter 3 Features This Iwill WA133-S / WA133-SN motherboard are well designed for the user. Who wants the most stable plat form, best performance/price ratio and convenience. 3.1 Motherboard Components Placement WA133 Series... - Page 21 11. SCSI Connector. 12. COM2 Header. 13. Multi-I/O Chip. 14. 32 bit/33MHz Bus Master PCI Slot. 15. Lan Chip 10/100M BaseT (WA133-SN only). 16. PTI header (Optional). 17. AMR Slot. 18. AC’97 V2.1 Audio CODEC. 19. Joystick, Midi Line out,Line in, Microphone In Connector.
-
Page 22: Back Panel
Chapter 3 Features 3.2 Back Panel WA133 Series... -
Page 23: Block Diagram
Chapter 3 Features 3.3 Block Diagram WA133 Series... -
Page 24: Specifications
Supports two high-speed 16550A serial ports Supports one SPP/ECP/EPP parallel port Supports one PS2 mouse port Supports one PS2 keyboard port Provides one Game/MIDI port to support two joysticks Supports FIR and CIR infrared communication Supports PS2 mouse and PS2 keyboard auto swapping WA133 Series... - Page 25 SCSI on board Build-in Advansys ASC3050 Ultra SCSI controller Supports the maximum Ultra SCSI bus data rate of 20 MB/sec LAN on board (WA133-SN only) Build-in Realtek RTL8139B Ethernet LAN controller (10Base-T/100Base-TX) Supports IEEE 802.3u Auto-Negotiation Supports Full-Duplex Flow Control (IEEE 802.3x)
-
Page 26: Chapter 4 Hardware Setup
To reset the CMOS data, you should turn off the computer first, take the JP1 jumper cap off pins 1-2, place onto pins 2-3, and then place back onto pins 1-2 again. Then, turn on your computer, press <Del> key during boot up and enter the BIOS setup program to re-set your preferences. WA133 Series... - Page 27 If you want to have some further setting, after you setting up these jum pers to assign the “Based External Frequency” you should enter BIO S setup program, select the proper CPU speed within “Iwill Smart Setting”page. The BIO S will display the proper options depends on these jum pers setting.
- Page 28 Chapter 4 Hardware Setup The table shows the proper setting for most of the processors in the market. The WA133-S is designed for Intel® Pentium® III and Celeron™ through a Socket 370 connector. CPU Model Vcore & Package JP3 JP3A “CPU Speed”...
- Page 29 Chapter 4 Hardware Setup 4.2.5 JP6 PS/2 power standby jumper (PS2_SB) The computer can be powered on through PS/2 keyboard or PS/2 mouse. In order to support this feature, the standby power must be provided to PS/2 ports. WA133 Series...
- Page 30 This jumper is used to enable / disable the onboard audio CODEC. The onboard audio CODEC must be disabled when using an ISA/PCI audio card or a primary AMR card. 4.2.9 JP15 LAN Enabled / Disabled jumper (LAN) (WS133-NS only) This jumper is used to enable / disable the onboard LAN chip. WA133 Series...
-
Page 31: Install The Processor
Do not leave JP16 without any cap. 4.3 Install the Processor ® The WA133-S motherboard provides one ZIF Socket 370 to support Pentium III and Celeron™ processors. T h e C P U sh o u ld h a v e a fa n a tta c h e d to it to p re v e n t o v er h ea tin g . If th is is n o t t h e c as e, t h e n pur c h as e a f a n b ef or e y o u t u r n o n y o ur s yst e m. - Page 32 The motherboard is provides a ZIF Socket 370. Step1: Locate the ZIF socket and open it by first pulling the lever of socket upward. Step2: Insert the CPU into the socket. Please keep the lever right angle when inserting CPU. WA133 Series...
- Page 33 Because the CPU has a corner pin for two of the four corners, the CPU will only fit in the orientation as shown. Step4: Push the lever down to close the socket. WA133 Series...
- Page 34 Be careful not to scrape the motherboard when mounting a clampstyle processor fan or else damage may occur to the motherboard. Step6: Push the clip of heatsink downward to hook the ear of socket firmly. Step7: Finally, attach the fan cable to the CPU fan header FCPU. WA133 Series...
-
Page 35: Install Memory Modules
Single-Side Module 2.Must be the same or half memory size of DM1 Double-Side Module DM1 must be empty Total System Memory (Max 512 MB) Step 1:Open latches of DIMM socket Step 2:Proofread the RAM module to the DIMM Socket WA133 Series... -
Page 36: Install Pci Expansion Cards
After installing the necessary software drivers, you can enjoy the features that expansion card provided. Step 1:Place the motherboard onto the Step 2:Secure the motherboard on the chassis chassis by fastening respective screws WA133 Series... - Page 37 Chapter 4 Hardware Setup Step 3:Insert the expansion card into the PCI socket Step 4:Secure the expansion card on the chassis by fastening the screw. WA133 Series...
-
Page 38: Usage Of The Amr Slot
AMR card. 4.7 Connect Devices and Power Supply All the connectors showed in this section are not jumpers, DO NOT PLACE JUMPER CAPS OVER THE PINS OF THEM. If you do so, you will damage the motherboard permanently. WA133 Series... - Page 39 A legacy ATA (IDE) drive can coexist with an Ultra ATA/66 drive. However, for the Ultra ATA/ 66 device to attain Ultra DMA 4 mode, an Ultra ATA/66 capable cable is required. Orient the red markings on the ribbon cable to pin1 of the connector WA133 Series...
- Page 40 QIC-80 floppy tape drive. After connecting the single end to the board, connect the two plugs on the other end to the floppy devices. Orient the red markings on the ribbon cable to pin1 of the connector WA133 Series...
- Page 41 That means if you plug the PS/2 keyboard into the mouse connector, it still can work without any trouble and vice versa. It i recommended that you turn off the computer before connecting or disconnecting keyboard and/or mouse. WA133 Series...
- Page 42 Line Out connector. Mic (Pink color) allows microphones to be connected for inputting voice. 4.7.3.8 Ethernet RJ45 Connector (for WA133-SN only) The RJ45 connector is optional at the time of purchase and is located on top of the USB connectors.
- Page 43 The CPU temperature can be monitored by a CPU inside thermal diode. If your CPU does not have this feature, purchase one temperature sensor and connect it to the Auxiliary Temperature Sensor Connector. Onboard System Temp Sensor. WA133 Series...
- Page 44 This 2-pin connector connects to the case-mounted IDE LED, which lights when the IDE devices connected to the primary / secondary IDE connectors are working. Reset Connector (RST) This 2-pin connector connects to the case-mounted reset button for rebooting your computer without having to turn off the power supply. WA133 Series...
- Page 45 When using a SIR/FIR devices, you need to enter the BIOS setup program and configure the “ART Mode Select” field as “IrDA”. b. When using a CIR device, the jumper cap of JP6 should be placed over 1-2 in order to use Consumer Infrared power up. WA133 Series...
- Page 46 For the external Modems, the Wake-On-Modem is detected through the COM port. b. You need to enable the “Wake Up by Ring/LAN” feature in the BIO setup program. c. Your system must have a ATX power supply with at least 720mA 5VSB power. WA133 Series...
- Page 47 Chapter 4 Hardware Setup 4.7.12 SMBUS connector J48 (SMBUS) This connector provides the connectivity of SMBUS utilization. WA133 Series...
- Page 48 15-pin VGA connector can be used on the external VGA connector. 4.7.15 Internal Audio Connector (CD_IN) This connect allow you to receive stereo audio input from such sound sources as a CD-ROM, TV tuner or MPEG card. WA133 Series...
-
Page 49: Atx Power Supply Connector
4. Connect the power cord into a power outlet that is equipped with a surge protector. 5. Many of the power supply support 110V/220V by a switch setting. Switch your power supply to the correct supply voltage (refer to the power supply’s manual). 6. Turn on your system in the following order: WA133 Series... -
Page 50: Asc3050 Ultra Scsi
Linux, Unixware and Solaris. Ultra SCSI connector supports an 8-bit, single-ended, and provides a 50-pin connector. The connector also supports the complete range of SCSI devices, including hard disk drives, CD- ROM drives, tape backup units, MOs, CD-ROMs, printers, and scanners. WA133 Series... -
Page 51: Chapter 5 Bios Setup
5.1.1 Upgrade BIOS The BIOS can be upgraded from a diskette with the Award Flash utility — AWDFLASH.EXE. The BIOS image file, and update utility are available from IWILL’s WEB site: www.iwill.net 5.1.2 Enter BIOS setup program Power-on the system by either pressing the Power-On button, or by using any of the power-on features provided by the motherboard. -
Page 52: Main Menu
The main menu allows you to select from several setup pages. Use the arrow keys to select among these pages and press <Enter> key to enter the sub-menu. A brief description of each highlighted selection appears at the bottom of the screen. WA133 Series... -
Page 53: Standard Cmos Features
“Manual” lets you set the remaining fields on this screen. Selects the type of fixed disk. Options Description Auto (*) BIOS automatically fills in the values for the cylinders, heads and sectors fields N o n e No disk drives are attached 5.3.3.3 Capacity Your disk drive size WA133 Series... - Page 54 Each time the BIOS detects a non-fatal error, the system will stop and display an error message No Errors The system will not stop for any errors that are detected All, But Keyboard The system will stop for any errors except keyboard error WA133 Series...
-
Page 55: Advanced Bios Features
Many disk diagnostic programs will attempt to access the boot sector table, which can cause the above warning message. If you run such a program, we recommend that you first disable the Virus Warning function beforehand. WA133 Series... -
Page 56: Cpu Internal Cache
5.4.7 First / Secondary / Third / Other Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. Options Floppy (*) LS/ZIP HDD-0 (**) SCSI (***) CD-ROM HDD-1 HDD-2 HDD-3 Disable WA133 Series... -
Page 57: Swap Floppy Drive
6 (*), 8, 10, 12, 15, 20, 24, 30 5.4.14 Typematic Delay (Msec) When enabled, typematic delay allows you to select the time delay between when the key is first pressed and when the acceleration begins. Options 250 msec (*), 500 msec, 750 msec, 1000 msec WA133 Series... -
Page 58: Advanced Chipset Features
5.5.1 SDRAM CAS Latency Time This controls the number of clocks between the SDRAM read command and the time that the data actually becomes available. Options 3 (*) WA133 Series... - Page 59 Disabled (*) 5.5.8 CPU Latency Timer Configuration options: Enabled Disabled (*) 5.5.9 Delayed Transaction When enabled, the south bridge ICH will supports the Delayed Transaction mechanism when it is the target of a PCI transaction. Options Enabled (*) Disabled WA133 Series...
- Page 60 This item controls RAS# active to precharge, and refresh to RAS# active delay ( in local memory clocks). Options Slow (*) Fast 5.5.16 RAS# Precharge Timing This item controls RAS# precharge (in local memory clocks). Options Slow (*) Fast WA133 Series...
-
Page 61: Integrated Peripherals
Use Mode 0 timing to access device Mode 1 Use Mode 1 timing to access device Mode 2 Use Mode 2 timing to access device Mode 3 Use Mode 3 timing to access device Mode 4 Use Mode 4 timing to access device WA133 Series... -
Page 62: Usb Controller
When enabled, the IDE controller will use the faster block mode to access devices. Options Enabled (*) Disabled 5.6.9 Power-On Function This field configures the Power-On mode of the system. This feature only supports PS/2 keyboard and PS/2 mouse. It does not work with USB keyboard or serial mouse. WA133 Series... -
Page 63: Onboard Fdc Controller
These fields configure the onboard serial ports. There are several port addresses and IRQ channels to select from. Options Description 3F8 / IRQ 4(*) Port address 3F8h, IRQ 4 2F8 / IRQ 3(*) Port address 2F8h, IRQ 3 3E8 / IRQ 4 Port address 3E8h, IRQ 4 WA133 Series... -
Page 64: Onboard Parallel Port
Disables parallel port 5.6.14 Parallel Port Mode This field configures the operating mode of an onboard parallel port. Ensure you know the specifications of your parallel port devices before selecting field. Options SPP (*) / EPP / ECP / ECP+EPP WA133 Series... - Page 65 330(*) Port address 330h Port address 300h Port address 290h 5.6.18 Midi Port IRQ This field configures the midi port IRQ. There are several IRQs to select from. Options Description 5 (*) Port address IRQ5 Port address IRQ10 WA133 Series...
-
Page 66: Power Management Setup
This field specifies the method that video subsystem used for power saving. Options Description V/H SYNC+Blank Turn off the vertical and horizontal synchronization ports and write blanks to the video buffer Blank Screen Writes blanks to the video buffer only DPMS (*) Initial display power management signaling with DPMS WA133 Series... -
Page 67: Video Off In Suspend
When Wake up by RING function is enabled, the PC can power-on through an external modem connected to your PC. This feature will be disabled if you turn off the system by pressing power button over 4 secs. WA133 Series... - Page 68 If enabled, timer restarts whenever the slave disk of the primary IDE channel is active. Options Enabled Disabled (*) 5.7.14.3 Secondary IDE 0 If enabled, timer restarts whenever the master disk of the secondary IDE channel is active. Options Enabled Disabled (*) 5.7.14.4 Secondary IDE 1 WA133 Series...
-
Page 69: Pnp/ Pci Configurations
Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system can not boot. Options Enabled Disabled (*) 5.8.3 Resources Controlled By WA133 Series... -
Page 70: Pc Health Status
5.8.5 PCI 1/PCI 5 IRQ Use PCI 2/PCI 6 IRQ Use PCI 3/Onboard LAN IRQ Use(WA133-SN only) PCI 4/Onboard SCSI IRQ Use These fields set how IRQ use is determined for each PCI slot. The default setting for each field is “Auto”... - Page 71 This item configures radiation emitted from the system. When enabled, system will release less radiation. Options Enabled Disabled (*) 5.10.3 CPU Speed Options CPU Speed:CPU External Frequency Ñ Ñ Ñ Ñ CPU Clock Ratio CPU / SDRAM Clock This field allows user to adjust the CPU external frequency. WA133 Series...
- Page 72 150 / 113 MHz 150 MHz 113 MHz 153 / 115 MHz 153 MHz 115 MHz CPU Clock Ratio: Options 2/2.5/3/3.5/4/4.5/5/5.5/6/6.5/7/7.5/8 5.10.4 BIOS-ROM Flash Protect The main function of BIOS-ROM Flash Protect prevents the virus of computers to destory the WA133 Series...
-
Page 73: Load Fail-Safe Defaults
5.11 Load Fail-Safe Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Pressing ‘Y’ loads the BIOS default values for the most stable, minimal-performance system operations. 5.12 Load Optimized Defaults WA133 Series... -
Page 74: Set Supervisor / User Password Setting
Please keep your password in safe place. 5.14 Save & Exit Setup Saves current CMOS value and exit BIOS setup program. 5.15 Exit Without Saving Abandons all CMOS value changes and exits BIOS setup program. WA133 Series... -
Page 75: Chapter 6 Power Installer Cd
Power Installer CD 6.1 Software Installation The attached Power Installer CD contains all the necessary drivers, utilities for IWILL’s full range of motherboards. It provides an easy way for users to install the needed drivers without going through a complicated process. The Power Installer CD is able to auto-detect and display the drivers, utilities needed for your motherboard. - Page 76 This bootable Power Installer CD also allows you to boot up your system, even when the OS has not been installed. During the boot-up process, you can perform “IWILL Diskette Creator,” which will automatically make the driver diskettes you need.
- Page 77 You may just click on the Software Audio Driver shown on screen that needs to be installed, then follow the prompts to complete setup. 6.2.7 How to install Network Driver (WA133-SN only) You may just click on the Network Driver Installation Guide shown on screen . Please follow the istructions to install the network driver.
- Page 78 Chapter 6 Power Installer CD WA133 Series...
- Page 79 Chapter 6 Power Installer CD 6.2.11 How to use Onboard SCSI ASPI Utility (Windows NT only) You may just click on the Onboard SCSI ASPI Driver shown on screen then follow the prompts to complete setup. WA133 Series...
-
Page 80: Installing Operating Systems
98, and won’t transfer any existing system settings. Windows 98 will become your default operating system, and will use standard system settings. This procedure represents an entirely new installation of Windows, therefore you’ll need to reinstall any existing programs you may want to use. WA133 Series... - Page 81 4. Select “Boot Sequence” and change the default setting from A, C, SCSI to “CD- ROM, C, A” using Page Up /Page Down key, save, and reboot. 5. Place the Windows NT 4.0 CD-ROM in the drive, and boot from CD-ROM. 6. Follow all instructions to finish Windows NT installation. WA133 Series...
-
Page 82: Chapter 7 Scsi Software Installation
Enter the image number for the Power Installer CD from the list of bootable CDs displayed on the screen (or press the Esc key to boot from your hard disk). The following Iwill Bootable CD Diskette Creator 1.0 menu will appear on the screen: www.iwill.net... - Page 83 Enter the image number for the Power Installer CD from the list of bootable CDs displayed on the screen (or press the Esc key to boot from your hard disk). The following Iwill Bootable CD Diskette Creator 1.0 menu will appear on the screen: www.iwill.net...
- Page 84 Enter the image number for the Power Installer CD from the list of bootable CDs displayed on the screen (or press the Esc key to boot from your hard disk). The following Iwill Bootable CD Diskette Creator 1.0 menu will appear on the screen: www.iwill.net...
- Page 85 Type a driver diskette number or command letter followed by <Enter>: Step2: Type in 2), and press Enter to continue. The message appears on the screen. WA133-S / WA133-SN SCSI Device Driver 1) SCSI driver for WIN95 / 98 6) SCSI driver for OS / 2 2) SCSI driver for DOS / WIN 3.1...
-
Page 86: Scsi Software Installation On Windows
Select Make driver, and click on this item. Step3: The following IWILL Driver Diskette Maker menu will appear on the screen. Then you need to select WA133 onboard SCSI Driver, and please click on “Go” Button to make WA133 onboard SCSI Driver. - Page 87 Chapter 7 SCSI Software Installation Step4: The following WA133 Onboard SCSI Driver Diskette Maker menu will appear on the screen. Select your operating system, choose a 3.5” floppy disk drive, and insert a floppy diskette into that driver. WA133 Series...
