USER'S MANUAL
9.35BT MOTORIZED TREADMILL
USER WEIGHT LIMITATION: 400lbs(180kgs).
SERIAL NUMBER (found on frame):
REV140129

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the smt-935bt and is the answer not in the manual?

Questions and answers

Related Manuals for Smooth Fitness smt-935bt

Summary of Contents for Smooth Fitness smt-935bt

  • Page 1 USER’S MANUAL 9.35BT MOTORIZED TREADMILL USER WEIGHT LIMITATION: 400lbs(180kgs). SERIAL NUMBER (found on frame): REV140129...
  • Page 2 .Children should be supervised to ensure that they do not play with the appliance.  If the supply cord is damaged, it must be replaced by the manufacturer or approved agent, with a Smooth Fitness OEM part.
  • Page 3 www.smoothfitness.com PRECAUTIONS Pour réparations futures ou questions connexes : Please staple your receipt and/or write in the name and phone number of the retail store where you purchased your treadmill. Name: ______________________________ Phone Number: ___________________ Receipt: ______________________ Précautions: AVERTISSEMENT : Pour réduire les risques de brûlures, d’incendie, de choc électrique ou de blessures aux personnes, lire les précautions importantes et l’information suivantes avant de se servir du tapis roulant.

  • Page 4: Power Requirements

    9.35 TREADMILL POWER REQUIREMENTS Power Requirements: IMPROPER CONNECTION OF THE EQUIPMENT GROUNDING CONNECTOR CAN RESULT IN THE RISK OF AN ELECTRIC SHOCK. CHECK WITH A QUALIFIED ELECTRICIAN OR SERVICE MAN IF YOU ARE IN DOUBT AS TO WHETHER THE PRODUCT IS PROPERLY GROUNDED. DO NOT MODIFY THE PLUG PROVIDED WITH THE PRODUCT, IF IT WILL NOT FIT THE OUTLET;...
  • Page 5 www.smoothfitness.com POWER REQUIREMENTS Alimentation : UN MAUVAIS BRANCHEMENT DU CONNECTEUR DE MISE À LA TERRE DE L’ÉQUIPEMENT POURRAIT PROVOQUER UN CHOC ÉLECTRIQUE. EN CAS DE DOUTE, CONSULTER UN ÉLECTRICIEN OU UN RÉPARATEUR QUALIFIÉ POUR SAVOIR SI LE PRODUIT EST CORRECTEMENT MIS À LA TERRE. NE PAS MODIFIER LA FICHE FOURNIE AVEC LE PRODUIT. SI ELLE N’ENTRE PAS DANS LA PRISE, FAIRE INSTALLER UNE PRISE APPROPRIÉE PAR UN ÉLECTRICIEN PROFESSIONNEL.

  • Page 6: Before You Begin

    9.35 TREADMILL BEFORE YOU BEGIN Open the boxes: Open the boxes of your new equipment. Inventory all parts included in the boxes, and Supplied Hardware lists on page 7 for a full count of the parts included. If you are missing any parts or have any questions contact us directly at 888-800-1167 Gather your tools: Before you begin, make sure that you have gathered all the necessary tools you may require to assemble the unit...

  • Page 7: Hardware Kit

    www.smoothfitness.com SUPPLIED COMPONENTS / SUPPLIED HARDWARE This list identifies the major components you will use to assemble this product. CONSOLE UPRIGHT CONSOLE ASSEMBLY MAIN FRAME Crossbar HARDWARE KIT Accessory tray AUDIO WIRE HARDWARE KIT M10x20 Hex socket M8x15 Hex socket head Washer M10 Washer M8 ∮...

  • Page 8: Complete Parts List

    9.35 TREADMILL COMPLETE PARTS LIST ITEM DESCRIPTION ITEM DESCRIPTION 935BT-1 Main frame 935BT-45 935BT-2 Incline frame 935BT-46 Fan fixing plate 935BT-3 Console frame 935BT-47 Speaker 935BT-4 Left console mast 935BT-48 Speaker hood 935BT-5 Right console mast 935BT-49 Speed key 935BT-6 Drive motor 935BT-50 Key panel...
  • Page 9 www.smoothfitness.com COMPLETE DIAGRAM Console Assembly Handle Pulse Handle Accessory tray Console Upright Motor Cover Running Belt Rear Roller Transportation Wheel End Cap...
  • Page 10 9.35 TREADMILL COMPLETE PARTS DIAGRAM 2...
  • Page 11 www.smoothfitness.com ASSEMBLY – PLEASE READ ALL STEPS BEFORE BEGINNING ASSEMBLY. STEP1: Assemble the Left and Right Uprights to Main Frame. NOTE: Make sure all wires are recessed into the frame. DO NOT trap or Pinch the Data Cables. DO NOT tighten the bolts until STEP3. 1.
  • Page 12 9.35 TREADMILL ASSEMBLY STEP2: Attach the Console to Left and Right Uprights NOTE: Make sure all wires are recessed into the frame. DO NOT trap or Pinch the Data Cables. DO NOT tighten the bolts until STEP3. 1. Connect the lower data cables(34) from the right upright to the upper data cables from the console(35) 2.

  • Page 13: Step3: Crossbar Assembly

    www.smoothfitness.com ASSEMBLY STEP3: Crossbar Assembly 1) Align the crossbar with the bolt holes on the inside of the upright post. Make sure the two extrusions on the crossbar are facing towards the back of the treadmill 2) Secure the crossbar to the uprights using 4x M8*15mm bolts(67) and 4x M8 washers(86).
  • Page 14 9.35 TREADMILL ASSEMBLY STEP4: Assembly of the accessory tray to the cross bar 1. Attach the rubber spacers to both sides of the accessory tray 2. Place the accessory tray over the crossbar 3. Secure the tray to the crossbar using 8 x M4*15mm screws (85). Tighten all bolts and fasteners now...

  • Page 15: Power Switch

    www.smoothfitness.com ASSEMBLY STEP 5: 1) Turn the power switch on 2) Insert the Safety Key (56) into the Bottom Center of Console, prior to operation. Note:Your treadmill will not Function without the safety key. Power Switch Safety Key...

  • Page 16: Computer Operation

    9.35 TREADMILL COMPUTER OPERATION MySmooth Bluetooth Compatible This feature is optional and must be purchased separately. INTRODUCING MYSMOOTH VIRTUAL TABLET-BASED FITNESS CONTROLS, ALLOWING YOU TO IMMERSE THEMSELVES IN VIRTUAL OUTDOOR WORKOUT EXPERIENCES THROUGH FULL MOTION VIDOES AND INTERACTIVE CAPABILIATES BENEFITS: 1) The app is FREE.

  • Page 17: Storage And Maintenance

    www.smoothfitness.com Wireless Heart Rate WIRELESS CHEST BELT MONITOR Your product includes the pre‐installed receiver with console. The chest belt is included with the equipment. For sanitary reasons it is recommended not to share the chest belt with any other person. To purchase an additional chest belt from our website go to www.smoothfitness.com or call 1‐888‐800‐1167.
  • Page 18 9.35 TREADMILL COMPUTER OPERATION Computer Display Time 00:00-99:59 Min Speed 0.5-12.5 mile/h incline 0-15 Distance 0.00-99.9 mile Calories 0-999 KCAL Pulse 70-200 / Min Goal 0-100% 15-80 years Weight 88-400 lbs Level L1-L10 Mode P0-P26 C1-C4 Height 4.0-11.0ft Gender Male = M ,Female = F Target HR 50-190...
  • Page 19 www.smoothfitness.com COMPUTER OPERATION START: Press the “START “ button to begin your workout DOWN SLOW FAST PAUSE: Press the “STOP”button to pause the DOWN SLOW workout. FAST RESET: Press and hold the “STOP”button for a few seconds to reset the computer to the power up screen.
  • Page 20 9.35 TREADMILL COMPUTER OPERATION INCLINE BUTTONS Press the /buttons to choose the DOWN SLOW FAST incline or workout time according to the selected function (the selected function is flashing) QUICK SPEED BUTTONS: DOWN SLOW FAST Press the quick speed buttons to achieve the predetermined speed with the push of one button.
  • Page 21 www.smoothfitness.com COMPUTER OPERATION Displays the program selection Displays the completed or remaining distance in miles. Displays the current incline. Displays calories burned Displays hand grip and wireless heart rate reading SPEED GRAPH / INCLINE MATRIX Displays boththe speed and incline profile. Press select to toggle between both profiles. Displays the user profile selections(gender, weight, height, and age) Displays the program description Displays the time...
  • Page 22 9.35 TREADMILL COMPUTER OPERATION At first, the LCD will show U1, and will also display only factory default setting values for user Gender, Weight, Height, and Age. Press the Speed ─ / ┼ to choose the user number from 1 to 4 and press the Enter button to assign the user number shown.
  • Page 23 www.smoothfitness.com COMPUTER OPERATION Speed Specific Programs(Incline=0) Speed Weight Loss Speed Waves Speed Training Interval Speed Summit Endurance Training Interval Strength...
  • Page 24 9.35 TREADMILL COMPUTER OPERATION Speed Specific Programs(Incline=0) Country Run Graduating speed intervals...
  • Page 25 www.smoothfitness.com COMPUTER OPERATION Incline Specific Programs(Speed=0.5mph) Incline Weight Loss Rolling Hills Incline Training Interval Speed Waves Endurance Training Interval...
  • Page 26 9.35 TREADMILL COMPUTER OPERATION Incline Specific Programs(Speed=0.5mph) Strength Country hike Graduating Hills...
  • Page 27 www.smoothfitness.com COMPUTER OPERATION Speed and Incline Programs Valley Run SPEED INCLINE Crosstraining SPEED INCLINE Combination interval training SPEED INCLINE Cross country SPEED INCLINE Mountain jog SPEED INCLINE...
  • Page 28 9.35 TREADMILL COMPUTER OPERATION P23 TARGET HEART RATE This program is designed to interact with your heart rate based on a pre-set target rate. P23 THR Program Press Speed + / - until P23 is displayed in the computer window. Press select to confirm. Enter Time To enter the time press the speed + /- until preferred time is displayed.
  • Page 29 www.smoothfitness.com COMPUTER OPERATION P24 60% MAX HEART RATE This program is designed to interact with your heart rate based on 60% of you max heart rate using the 220-age-40%. P5 60% MHR Program Press Speed + / - until P24 is displayed in the computer window. Press select to confirm. Enter Time To enter the time press the speed + /- until preferred time is displayed.
  • Page 30 9.35 TREADMILL COMPUTER OPERATION The program will begin at 1mph. Adjust the speed by using the speed + or – button to a comfortable rate as the treadmill will adjust the incline to help you achieve the target heart rate. The computer will read your heart rate and compare it to the preset target rate and adjust the incline up one level if the actual heart rate is 6 or more beats below the preset target.
  • Page 31 www.smoothfitness.com COMPUTER OPERATION C1~C4 CUSTOM PROGRAMS This program is designed to allow you to create your own custom program. The program must be created prior to starting. C1 Custom Program Press Speed + / - until C1~C4 is displayed in the computer window. Press select to confirm. Enter Time To enter the time press the speed + /- until preferred time is displayed.

  • Page 32: Deck Lubrication

    The walking belt has been pre-lubricated at the factory. However, it is recommended that the walking deck be checked periodically for lubrication, to ensure optimal treadmill performance. Your treadmill should not have to be lubricated usually within 3 months. Smooth Fitness recommends lubricating the walking deck every 3 months Please visit www.smoothfitness.com for approved maintenance supplies...

  • Page 33: Maintenance

    www.smoothfitness.com MAINTENANCE To apply lubricant to the walking belt: 1. Position the walking belt so that the seam is located on top and in center of the walking board. 2. Insert the nozzle of the lubricant container under the belt 3.

  • Page 34: Important Steps

    9.35 TREADMILL IMPORTANT STEPS Warning: Before using this product, please consult your personal physician for a complete physical examination. Frequent and strenuous exercise should be approved by your doctor first. If any discomfort should result from your use of this product, stop exercising and consult your doctor.

  • Page 35: Muscle Chart

    www.smoothfitness.com MUSCLE CHART Targeted muscle groups: The exercise routine that is performed on this product will develop primarily lower body muscle groups. These muscle groups are shown in gray color on the chart below. MUSCLE GROUPS Shoulder muscles Calf muscles Pectoral muscles Trapezius muscles Bicep muscle...

  • Page 36: Stretching Routine

    9.35 TREADMILL STRETCHING ROUTINE Warm up and cool down: A successful exercise program consists of a warm-up, aerobic exercise, and a cool-down. Do the entire program at least two and preferably three times a week, resting for a day between workouts. After several months, you can increase your workouts to four or five times per week.

  • Page 37: Read Carefully The Following Before Using Your Treadmill

    www.smoothfitness.com STRETCHING ROUTINE Read carefully the following before using your treadmill  Always stretch your muscles before exercise program. Warm up slowly by walking at a slow incline. Increase workout intensity gradually until you reach your desired workout pace. Decrease workout intensity gradually to an easy walk, allowing your heart rate to decrease to a normal situation.

  • Page 38: Troubleshooting Guide

    9.35 TREADMILL TROUBLESHOOTING TROUBLE SHOOTING GUIDE: SYMPTOM CAUSE SOLUTION Place the safety key onto the operation Show E0 The Safety key is not in place position Check Speed sensor and 10-pin cable or Show E1 Speed signal error contact your retailer Check the 10-pin cable or contact your Show E2 Motor or motor drive system error...

  • Page 39: Limited Warranty

    Fitness may at its discretion, choose to provide any of following parts or repair options. In the event that a part is determined in need of replacement, upon receipt of the part by Smooth Fitness, Smooth Fitness may send out the part by UPS ground or another such carrier directly to the customer’s home.
  • Page 40 mooth Fitness 780 5 King of Prussia, PA 19406 Toll Free Customer Service: 1.888.800.1167 Website: www.smoothfitness.com...
