- Page 1 PlayStation 3 Setup (NB16WV-02)
- Page 2 Playstation 3 Setup There are two ways of allowing your Playstation 3 to communicate with the internet. One is through port forwarding and the other is through the DMZ feature. Port forwarding will enable specified ports on the router to get access to your Playstation 3 to communicate with the internet as if they were directly connected by allowing access through.
- Page 3 Setting the Playstation 3 as the DMZ Host http://192.168.20.1 1. Navigate to in a web browser. 2. Enter admin as both the username and password then click Login. 3. Click on Switch to advanced view option at the bottom right hand side of the screen.
- Page 4 4. Select the Forwarding Rules menu then click the Miscellaneous option. 5. Enter the static IP address of the PlayStation in the DMZ Host IP Address field. In this example, 192.168.20.100 is the IP address of the PlayStation. 6. Click on the Save/Apply button. 7.
- Page 5 Adding Port Forwarding Rules for Playstation 3 http://192.168.20.1 1. Navigate to in a web browser. 2. Enter admin as both the username and password then click Login. 3. Click on Switch to advanced view option at the bottom right hand side of the screen.
- Page 6 4. Select the Forwarding Rules menu then click the Port Forwarding option. 5. Enter the port number or port range into the Service Port field. The ports for Playstation 3 are: 80, 443, 3478, 3479, 3480, 3658, 5223 and 8080 6.
- Page 7 Rebooting the NB16WV 1. In the Advanced View, select the Toolbox menu then click the Reboot option. 2. Click OK when prompted to confirm.
