Summary of Contents for NetComm AM5056
-
Page 2: Table Of Contents
Appendix A: Cable Connections ..........................13 RJ11 connector and cable ......................... 13 605 to RJ-11 adapter ......................... 13 USB cable ............................13 Appendix B: Registering your NetComm Product ....................14 Contact Information .......................... 14 Legal & Regulatory Information ......................14 Customer Information ........................14 Product Warranty .......................... -
Page 3: Introduction
Introduction Hassle-free installation for instant fastspeed connection, the NetComm Rave II 56K USB modem delivers unparalleled high speed, reliable performance and guarantees uninterrupted 56K connections. Powered packed with advanced features, it satisfies all your communication and telephony requirements. Installed in seconds, you do not require any external power supply and it offers USB Plug &... -
Page 4: Package Contents
Telephone extension cable 605 to RJ11adapter This Quick Install Guide and a Package Contents Note Check the contents of your package and, if any parts are missing or damaged, please contact your Dealer. NetComm Rave II 56K USB Modem YML722 Rev1 www.netcomm.com.au... -
Page 5: Step 1: Connecting The Modem To Your Computer
Connect one end of the telephone extension cable to the LINE jack on Modem and the other end to your Telephone Wall Socket. Connect the USB cable of the Modem to the USB port on your computer. This completes the modem connections. Please proceed to Step 2. YML722 Rev1 NetComm Rave II 56K USB Modem www.netcomm.com.au... -
Page 6: Step 2: Installing Your Modem Driver
1. Windows will detect that the Rave 56 USB has been connected and display the Add New Hardware Wizard. Click on Next. 2. Insert the NetComm Communications CD into your CD-ROM drive. 3. Select “Search for the best driver for your device. (Recommended)” and click on Next. -
Page 7: Installing Your Modem Driver - For Windows® 2000
CD-ROM drive). The installation procedure is similar to that of Windows 98 & Me. If you need detailed instructions for Windows 2000 installation please visit the support section of www.netcomm.com.au. YML722 Rev1 NetComm Rave II 56K USB Modem... -
Page 8: Installing Your Modem Driver - For Windows® Me
1. Start you PC and make sure your USB modem is connected. Windows will detect your new modem and display a New Hardware found screen. 2. Insert the NetComm Communications CD into your CD-ROM drive. 3. Windows will display the "Add New Hardware Wizard", select "Specify the location of the driver (Advanced)"... -
Page 9: Installing Your Modem Driver - For Windows® Xp
1. Please ensure that you have correctly installed Windows XP and your system is operating correctly. Make sure that you have connected the NetComm Rave USB modem to your PC as detailed Step 1. XP will automatically detect the new hardware and you will see this first screen. - Page 10 3. The windows drivers used are not digitally signed by Microsoft and the following message will be displayed, click" Continue Anyway" to proceed. 4. Windows XP will continue to install the NetComm driver and display the below message when finished, please click "Finish" to proceed.
-
Page 11: Step 3: Using The Rave Ii 56K Usb Modem
Windows application (Dial Up Networking, Hyperterminal, etc) that needs to use the modem. Software included with your modem. Send and receive faxes directly from your PC with Fax and Voice Software. Read manuals with Adobe Acrobat 4 Reader. YML722 Rev1 NetComm Rave II 56K USB Modem www.netcomm.com.au... -
Page 12: Specifications
Bell 212A, Bell 103 1 x RJ11 telephone sockets for Phone Data Compression Note: * V.92 feature is subjected to ISP support ** Requires software application support V.44, V.42bis, MNP 5 NetComm Rave II 56K USB Modem YML722 Rev1 www.netcomm.com.au... -
Page 13: Appendix A: Cable Connections
If you are unsure about which cable to use or which socket to connect it to, please refer to the hardware installation section in this manual. If you are still not sure about cable connections, please contact a professional computer technician or NetComm for further advice. RJ11 connector and cable An RJ-11 connector is the small, modular plug used for most analog telephones. -
Page 14: Appendix B: Registering Your Netcomm Product
NetComm Limited. NetComm Limited accepts no liability or responsibility, for consequences arising from the use of this product. NetComm Limited reserves the right to change the specifications and operating details of this product without notice. -
Page 15: Product Warranty
The cost of transporting product to and from NetComm's nominated premises is your responsibility; and, NetComm does not have any liability or responsibility under this warranty where any cost, loss, injury or damage of any kind, whether direct, indirect, consequential, incidental or otherwise arises out of events beyond NetComm's reasonable control.
