- Page 1 TruVision High Definition TVI Dome Installation Guide TVD-2401/TVD-4401 TVD-2403/TVD-4403 P/N 1072939-EN • REV A • ISS 11MAR15...
-
Page 2: Table Of Contents
Content Product overview 3 Camera description 5 Installation 8 Programming 11 Menu 13 Specifications 14 Legal and Regulatory information 15 Installation Guide... -
Page 3: Product Overview
Product overview This is the Pocket Guide for TruVision High Definition TVI dome TVD-2401/TVD-4401 and TVD- 2403/TVD-4403. This guide describes a standard installation. Package contents: Camera with power 3 screws and 3 and video output anchors for wall or cables ceiling installation Template... - Page 4 • WEEE and Battery Disposal Installation Guide...
-
Page 5: Camera Description
Camera description TVD-2401/TVD-4401 Base Housing IR LED Power supply Lens TVI Video output cable (grey) Dome liner Installation Guide... - Page 6 TVD-2403/TVD-4403 Base Housing IR LED Power supply Lens TVI video output cable (grey) Dome liner CVBS video output cable (black) Installation Guide...
- Page 7 Note: Please check the camera output settings before setting up a system. The TVI video output can be only connected to DVR with TVI signal input. The CVBS output supports the standard monitor, test monitor, encoder and DVR. For TVD-2403/TVD-4403, you can connect the white and black line ends of the WDR switch cable to enable the Wide Dynamic Range function.
-
Page 8: Installation
Installation To install the camera on a ceiling: Using the template, place it level against the mounting surface and mark the position of the mounting holes. Drill Template Hole A: for cables routed through the ceiling screw hole 1: for Mounting Base Following all local codes, drill and prepare the mounting holes. - Page 9 Securely fasten the mounting base to the mounting surface with the screws. Using a 75 ohm coaxial video cable, connect the camera TVI video output and a TVI DVR, and connect a 12 VDC power supply to the camera power cable. Installation Guide...
- Page 10 Adjust the surveillance angle according to the figure below. Re-attach the housing to the base. Installation Guide...
-
Page 11: Programming
Programming Programming on TVI output: Programming on TVI output is available for TVD- 2403/TVD-4403 only. Once the camera hardware has been installed, you can configure the camera settings on the TVI DVR. Please select PTZ protocol as TruVision Coax and click menu button to call up the camera menu. - Page 12 Programming on CVBS output: Programming on CVBS output is available for TVD- 2403/TVD-4403 only. Programming on CVBS output, you need to connect a monitor and a TVS-C200 controller (purchase separately) as following system figure. The TVS-C200 has one male BNC output and a female output.
-
Page 13: Menu
Menu Installation Guide... -
Page 14: Specifications
Specifications Power supply 12 VDC Current TVD-2401/TVD-4401: Max. 300 mA TVD-2403/TVD-4403: Max.333 mA TVD-2401/TVD-4401: Power consumption Max. 3.5W TVD-2403/TVD-4403: Max. 4W Weight 345 g (0.76 lb.) Dimensions 111 x 82 mm (4.4 x 3.2 in. ) (Ø × L) Installation Guide... -
Page 15: Legal And Regulatory Information
Legal and Regulatory information Copyright: © 2015 United Technologies Corporation, Interlogix is part of UTC Building & Industrial Systems, a unit of United Technologies Corporation. All rights reserved. Trademarks and patents: Trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products. -
Page 16: Contact Information
For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info. Contact information: For contact information, see www.interlogix.com or www.utcfssecurityproducts.eu Installation Guide...
