Page 1: User Manual
TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual P/N 1072794B-EN • REV 1.0 • ISS 17JUN14... - Page 2 Copyright © 2014 United Technologies Corporation. Interlogix is part of UTC Building & Industrial Systems, a unit of United Technologies Corporation. All rights reserved. Trademarks and Trade names used in this document may be trademarks or patents registered trademarks of the manufacturers or vendors of the respective products.
-
Page 3: Table Of Contents
Set the camera ID 15 Set the sync mode 16 Select the language 17 Reset camera settings 17 Specifications 18 Dimensions 18 Menu tree 19 TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 4: Product Overview
Program the camera settings as much as possible before mounting the camera. Take appropriate safety precautions while completing programming after installation. • Always use a 12 VDC or 24 VAC UL listed Class 2 power supply to power the camera. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 5: Product Description
8. Outlet hole 3. Base 9. Power supply and video BNC cables 4. OSD control button 10. Composite video BNC cable 5. Lens 11. Focus adjustment 6. IR LED (only for TVD-7125VE-2) 12. Zoom adjustment TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 6: Installation
1. Prepare the mounting surface. 2. Remove the dome cover. 3. Secure the camera to the mounting surface with screws. 4. Remove the IR LED cover to adjust the lens and the viewing angle. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 7: Connect The Cables
4. Adjust the lens to obtain the appropriate angle of view and the optimum focus. Tighten the focus lock lever. 5. Replace the IR LED and dome covers on the camera. 6. Secure the dome cover with screws. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... - Page 8 Note: Ensure that the screws highlighted above with a “ ” have been tightened securely to prevent water seepage. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual...
-
Page 9: Programming
Press the center of the button to display the Setup Menu. If the selected item has its own menu, press the button to enter a submenu. Access the Setup Menu The Setup Menu provides access to the camera configuration options. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... - Page 10 6. To exit the Setup Menu and return to normal camera operation mode, move the cursor to Exit at the bottom of the screen and press Enter. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual...
-
Page 11: Save Changes
0 and 255. Set the shutter/AGC In the Setup Menu, go to Shutter/AGC and select the required light control option, Manual or Autoiris. Auto is default. The Manual or Auto menu appears: TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... - Page 12 1/1000, 1/2000, 1/4000 or 1/10000. AGC: Set the gain level. A higher gain compensates for a brighter scene but noise increases. Manual AGC can be set to 6, 12, 18, 24, 30, 36, 42 or 44.8 TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual...
-
Page 13: Set The White Balance
Level UP: Press Enter to increase the WB level. Level DOWN: Press Enter to decrease the WB level. Push Lock Press Enter to automatically adjust the white balance to the environment and lock it at this value. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 14: Set The Backlight Compensation (Blc)
Dynamic Range). It is used when there are both bright and dark areas in the picture. It helps improve the contrast between objects. In the Setup Menu, go to and select the desired luminance and contrast parameters. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 15: Set The Motion Detection
Use this function to mask out selected areas of the image. Up to eight privacy mask areas can be configured, each by size and location on-screen. Note: Only four privacy mask areas can be set when motion detection is enabled. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 16: Set The Day/Night Mode
B/W. ON mode maintains the same color signal in B/W so that the video signal provides better compatibility with certain color equipment. OFF mode removes the color burst signal B/W video and increase the total TV lines. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 17: Set The Image Noise Reduction
(Y). Set the camera ID In the Setup Menu, go to Camera ID and press Enter to display the menu. The camera ID displayed on-screen can have up to 40 characters. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 18: Set The Sync Mode
In live view mode push the OSD control button to the right for two seconds. Repeat the operation to switch it back from the line lock to internal synchronization. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 19: Select The Language
Portuguese, German, and French. Reset camera settings Use this menu to reset the camera settings to factory default. In the Setup Menu, go to Camera Reset and press Enter. Factory default settings are immediately restored. TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 20: Specifications
168 mA 243 mA Power consumption 4.0 W (max.) 5.9 W (max.) Operating temperature -30 to +60 °C (-22 to +140 °F) Weight 800 g (1.76 lbs) Dimensions (Units of measurement = mm) TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual... -
Page 21: Menu Tree
Menu tree TruVision TVD-7120VE-2 / TVD-7125VE-2 Camera User Manual...
