Page 1: Camera Installation
TruVision Series 3 IP Camera Installation Guide P/N 1073188-EN • REV E • ISS 22SEP17... - Page 2 Copyright © 2017 United Technologies Corporation. Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and Trade names used in this document may be trademarks or registered trademarks of the manufacturers or patents vendors of the respective products.
- Page 3 (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. Contact information For contact information, see www.interlogix.com or www.utcfssecurityproducts.eu.
-
Page 5: Table Of Contents
Content Introduction 1 Product overview 1 Installation 3 Installation environment 3 Package contents 4 Cable requirements 20 Camera description 20 Setting up the camera 28 Accessing the SD card 28 Mounting the IP fixed lens bullet camera 29 Mounting the IP VF lens bullet camera and the IP motorized lens bullet camera (without the supplied back box) 30 Mounting the IP VF lens dome camera and IP motorized lens dome camera 36... - Page 6 TruVision IP fixed lens dome 57 TruVision IP wedge cameras 57 TruVision IP turret cameras 58 Pin definitions 59 Installation Guide...
-
Page 7: Introduction
Introduction Product overview This is the installation guide for TruVision Series 3 IP camera models: IP fixed lens bullet camera: TVB-5301 (2MPX Bullet, 4 mm lens) TVB-5302 (4MPX Bullet, 4 mm lens) IP VF lens bullet camera: TVB-5303 (2MPX Bullet, 2.8 to 12 mm VF lens) ... - Page 8 IP motorized lens dome camera: TVD-5305 (2MPX Dome, 2.8-12 mm VF Motorized lens) TVD-5306 (4MPX Dome, 2.8-12 mm VF Motorized lens) IP wedge camera: TVW-5301 (2MPX Wedge, 2.0 mm lens, Gray) TVW-5302 (2MPX Wedge, 2.8 mm lens, Gray) ...
-
Page 9: Installation
Installation This section provides information on how to install the cameras. Installation environment When installing your product, consider these factors: • Electrical: Install electrical wiring carefully. It should be done by qualified service personnel. Always use a proper PoE switch or a 12 VDC UL listed Class 2 or CE certified power supply to power the camera. -
Page 10: Package Contents
be used for an extended period of time, put on the lens cap to protect the sensors from dirt. Package contents Check the package and contents for visible damage. If any components are damaged or missing, do not attempt to use the unit;... - Page 11 Water joint: Provides water 12 VDC connector: resistance to network cable Two terminal connector connector. with positive and negative indicators. Installation manual: CD with manuals and TruVision Device Manager: Equipment and Battery Disposal sheets: Installation Guide...
- Page 12 IP VF lens bullet camera Camera: Drill template: Screws: Drywall anchor 7.5 × 24.5 mm (4 pcs) Drill Template Screw Hole A: for cables routed through the wall Screw hole 1: for integrative bracket Screw hole 2: for conduit back box M4 ×...
- Page 13 Video test cable: Back box: Screws: M4.8 × 8 (4 pcs) Torx wrench: Installation manual: CD with manuals and TruVision Device Manager: Equipment and Battery Disposal sheets: Installation Guide...
- Page 14 IP motorized lens bullet camera Camera: Drill template: Screws: Drywall anchor 7.5 × 24.5 mm (4 pcs) Drill Template Screw Hole A: for cables routed through the wall Screw hole 1: for integrative bracket Screw hole 2: for conduit back box M4 ×...
- Page 15 Water joint: Provides water 12 VDC connector: resistance to network cable Two terminal connector connector. with positive and negative indicators. Screws: M4.8 × 8 (4 pcs) Torx wrench: Installation manual: CD with manuals and TruVision Device Manager: Equipment and Battery Disposal sheets: Installation Guide...
- Page 16 IP fixed lens dome camera Camera: Template: Screws: Drywall anchor 7.5 × 24.5 mm (3 pcs) Drill Template Screw Hole A: for cables routed through the ceiling screw hole 1: for Mounting Base M4 × 25 mm (3 pcs) Water joint: Provides water 12 VDC connector: resistance to network cable Two terminal connector...
- Page 17 Screws: 4 × 75 mm (3 pcs) Torx wrench: Installation manual: CD with manuals and TruVision Device Manager: Equipment and Battery Disposal sheets: Installation Guide...
- Page 18 IP VF lens dome camera Camera: Drill template: Screws: Drywall anchor 7.5 × 24.5 mm (4 pcs) Screw M4 × 25 mm (4 pcs) Screws: M4 × 9 (3 pcs) Mounting adaptor plate: Water joint: Provides water 12 VDC connector: resistance to network cable Two terminal connector connector.
- Page 19 Plastic G3/4 cable adapter: Torx wrench: (mm) Equipment and Battery Installation manual: Disposal sheets: CD with manuals and TruVision Device Manager: Installation Guide...
- Page 20 IP motorized lens dome camera Camera: Drill template: Screws: Drywall anchor 7.5 × 24.5 mm (4 pcs) Screw M4 × 25 mm (4 pcs) Screws: M4 × 9 (3 pcs) Mounting adaptor plate: Water joint: Provides water 12 VDC connector: resistance to network cable Two terminal connector connector.
- Page 21 Torx wrench: Video test cable: Plastic G3/4 cable adapter: CD with manuals and TruVision Device Manager: (mm) Equipment and Battery Installation manual: Disposal sheets: Installation Guide...
- Page 22 IP wedge camera Camera: Camera drill template: Adapter plate drill template: Water joint: Provides water 12 VDC connector: resistance to network cable Two terminal connector connector. with positive and negative indicators. Lens adjustment tool: Adapter plate: Installation Guide...
- Page 23 Screws: M4 × 8 (2 pcs) Torx wrench: Screws: Equipment and Battery Disposal sheets: Drywall anchor 7.5 × 24.5 mm (3 pcs) Screw M4 × 25 mm (3 pcs) Installation manual: CD with Configuration manual and TruVision Device Finder: Installation Guide...
- Page 24 IP turret camera Camera: Water joint: Provides water 12 VDC connector: 2- resistance to network cable terminal connector connector. with positive and negative indicators. Camera drill template: Adapter plate: Screws: Screw PM6-32 × 10 (4 pcs, used to attach the Drywall anchor turret camera to a 2 7.5 ×...
- Page 25 Screw KM4 × 8 (4 pcs, used Screw PM4 × 8 (3pcs): to attach the adapter to the brackets) CD with Configuration Installation manual: manual and TruVision Device Finder: Equipment and Battery Disposal sheets: CAUTION: Use direct plug-in UL listed power supplies marked Class 2/CE certified or LPS (limited power source) of the required output rating as listed on the unit.
-
Page 26: Cable Requirements
Cable requirements For proper operation, adhere to the following cable and power requirements for the cameras. Category 5 cabling or better is recommended. All network cabling must be installed according to applicable codes and regulations. Camera description Figure 1: IP fixed lens bullet camera Adjustable bracket Sunshield... - Page 27 Figure 2: IP VF bullet camera Sunshield Reset button Front cover 10. Audio I/O Lens adjustment 11. Alarm I/O IR LEDs 12. 12 VDC power Lens 13. Ethernet RJ45 PoE port Waterproof film 14. Aux power output (12 VDC, 50 mA) Base 15.
- Page 28 Figure 3: IP motorized lens bullet camera Sunshield Reset button Front cover 10. Audio I/O Lens adjustment 11. Alarm I/O IR LEDs 12. 12 VDC power Lens 13. Ethernet RJ45 PoE port Waterproof film 14. Back box Base SD/SDHC/SDXC slot Installation Guide...
- Page 29 Figure 4: IP VF lens dome camera Housing cover Aux power output (12 VDC, 50 mA) Dome liner Ethernet RJ45 PoE port Lens 12 VDC power Mounting plate adapter 10. Audio I/O Reset button 11. Alarm I/O SD/SDHC/SDXC slot 12. Analog video output (BNC) Installation Guide...
- Page 30 Figure 5: IP motorized lens dome camera Housing cover Video test cable connection Dome liner Ethernet RJ45 PoE port Lens 12 VDC power Mounting plate adapter 10. Audio I/O Reset button 11. Alarm I/O SD/SDHC/SDXC slot Installation Guide...
- Page 31 Figure 6: IP fixed lens dome camera Base Analog video output (BNC) IR LEDs Ethernet RJ45 PoE port Lens 10. Alarm I/O Dome liner 11. Audio I/O Housing cover 12. Aux power output SD/SDHC/SDXC slot (12 VDC, 50 mA) Reset button 13.
- Page 32 Figure 7: IP wedge camera Housing cover Audio output and alarm Lens Reset button SD/SDHC/SDXC slot Microphone Ethernet RJ45 PoE port Adapter plate 12 VDC power Installation Guide...
- Page 33 Figure 8: IP turret camera Trim ring Lens assembly Housing 12 VDC power Base Ethernet RJ45 PoE port Installation Guide...
-
Page 34: Setting Up The Camera
Setting up the camera Note: If the light source where the camera is installed experiences rapid, wide variations in lighting, the camera may not operate as intended. To quickly put the camera into operation: Prepare the mounting surface. Mount the camera on the mounting surface using the appropriate hardware. -
Page 35: Mounting The Ip Fixed Lens Bullet Camera
Note: There is no Micro SD card slot in the mini fixed lens bullet and turret cameras. Mounting the IP fixed lens bullet camera Mount the camera on a ceiling or wall. To mount the IP fixed lens bullet camera: Use the supplied template to mark out the mounting area. -
Page 36: Mounting The Ip Vf Lens Bullet Camera And The Ip Motorized Lens Bullet Camera (Without The Supplied Back Box)
Loosen the large nut at the base of the mounting bracket to adjust the camera’s viewing angle. Pan direction: 0 to 360° adjustable Tilt direction: 0 to 90° adjustable Rotate direction: 0 to 360° adjustable Adjust the lens to the desired surveillance angle. Tighten the adjustable nuts to complete the installation. - Page 37 To route the cable harness through the mounting surface, cut a cable access hole in the mounting surface, referencing the letter “A” on the drill template. Skip this step if you want to route the cables on the surface. Secure the camera to the surface with the four mounting screws and drywall anchors.
- Page 38 To install the SD card: Rotate the screw that secures the sunshield counterclockwise to loosen it. Slide the sun shield so that the hole in the sunshield lines up with the screw head. Remove the sun shield. Remove the lens cover by rotating it counterclockwise.
- Page 39 Insert the SD card in the SD card slot. Reinstall the lens cover by rotating the assembly clockwise. Reinstall the sunshield. Installation Guide...
- Page 40 Rotate the sunshield screw clockwise to tighten it. To ensure that the camera maintains its IP66 rating, when rotating the lens cover clockwise align the red bar on the label of the lens cover with red bar on the label that is located on the camera housing.
- Page 41 To mount the IP VF lens bullet camera and the IP Motorized lens bullet camera with a back box: Use the supplied template to mark out the mounting area. Drill mounting holes in the surface using the holes labeled number “2” on the drill template. To route the cable harness through the mounting surface, cut a cable access hole in the mounting surface, referencing the letter “A”...
-
Page 42: Mounting The Ip Vf Lens Dome Camera And Ip Motorized Lens Dome Camera
Mounting the IP VF lens dome camera and IP motorized lens dome camera Note: For planning purposes, there are several cable routing options available: Route the interconnect cables through the mounting surface, straight out the back of the dome. –... - Page 43 To mount the IP VF lens dome camera and the IP motorized lens dome camera on a surface: Loosen the three Torx screws at the edge of the dome housing using the supplied Torx wrench. Torx screw Remove the dome housing and then remove the black plastic inner liner.
- Page 44 Drill the three screw holes on the ceiling in the mounting surface using with the supplied drill template. Use number “1” as reference. To route the cable harness through the mounting surface, cut a cable access hole in the mounting surface, referencing the letter “A”...
- Page 45 Connect the appropriate cables. To mount the IP VF lens dome camera and the IP Motorized lens dome camera on a single or double gang electrical box: Follow steps 1 to 3 in the section above, “To mount the IP VF lens dome camera and the IP motorized lens dome camera on a surface”.
- Page 46 Route the cables through the center of the adapter plate and connect the appropriate cables inside the electrical box. Attach the dome to the adapter plate. Connect the video output connector to the monitor. Connect the power connector to the power supply. Adjust the image and focus.
-
Page 47: Mounting The Ip Fixed Lens Dome Camera
Tilting Rotation Rotation Mounting the IP fixed lens dome camera To mount the IP fixed lens dome camera on a surface: Use the supplied template to mark out the mounting area. Drill mounting holes in the surface using the holes labeled number “1”... - Page 48 Drill Template Hole A: for cables routed through the ceiling screw hole 1: for Mounting Base Using the supplied Torx wrench, loosen the screws to remove the dome housing. Attach the dome on the mounting surface using the supplied hardware. Installation Guide...
- Page 49 Note: If required, route cables through the side opening of the mounting base. Loosen the tilt adjust screws (see image below) and adjust the tilt position of the lens assembly within a range of 75 degrees. Retighten the tilt adjust screws. Rotate the dome liner to adjust the pan position within a range of 355 degrees.
- Page 50 Tilt adjust screw (Optional) If using a micro SD card (not included): To remove the SD card, push the micro SD card forward. The micro SD card will spring out. Re-attach the dome housing and tighten the Torx screws. Installation Guide...
-
Page 51: Mounting The Ip Wedge Dome Camera
Mounting the IP wedge dome camera To mount the IP wedge dome camera on a surface: Use the supplied template (supplied) to mark out the mounting area. Drill mounting holes in the surface using the holes labeled number “1” on the drill template. To route the cable harness through the mounting surface, cut a cable access hole in the mounting surface, referencing the letter “A”... - Page 52 Note: If required, remove the knockout (A) on the side of the adapter plate to allow for cable access. Loosen the Torx screws with a Torx wrench (supplied) to remove the dome housing. Attach the camera base to the adapter plate or directly to the mounting surface.
- Page 53 Loosen the locking screw, located near the lens assembly using the Torx wrench. Align the Lens Adjustment Tool with the two small holes located on the camera assembly. Rotate (pan) the camera assembly using the Lens Adjustment Tool until the lens is positioned in the correct location.
-
Page 54: Mounting The Ip Turret Camera
Lens adjustment tool Tilt Rotation Re-attach the dome housing cover to the camera base. Mounting the IP turret camera To mount the IP turret camera on a surface: Use the supplied template (supplied) to mark out the mounting area. Drill mounting holes in the surface using the holes labeled number “1”... - Page 55 referencing the letter “A” on the drill template. Skip this step if you want to route the cables on the surface. Use the supplied adapter plate if installing the turret camera to a wall mount or other accessory. Fix the adapter plate to the accessory with three PM4X8 screws, referencing number “2”.
- Page 56 Trim ring Lens assembly There two options for routing the cables. Route the cables directly out of the bottom of the camera or through the side access point shown below. Remove one of the knockouts (using pliers) on the edge of the trim ring to provide cable access.
- Page 57 Adjust the lens. Loosen the locking screw using a Philips screw driver. Rotate the lens assembly to adjust the pan angle. Rotate the lens assembly to adjust the tilt angle. Tighten the locking screw to secure the lens at the desired surveillance angle.
- Page 58 Attach the trim ring to the camera and rotate it clockwise to secure it. Installation Guide...
-
Page 59: Using The Camera With A Recorder
Using the camera with TruVision Navigator A camera must be connected to an Interlogix NVR or hybrid DVR in order to be operated by TruVision Navigator. Please refer to the TruVision Navigator user manual for instructions on operating the camera with the TruVision Navigator. -
Page 60: Specifications
Specifications TruVision IP fixed lens bullet cameras Electrical Voltage input 12 VDC, PoE (IEEE 802.3af) Power consumption Max. 5 W Miscellaneous Connectors DC jack flying lead, RJ45 flying lead Operating temperature -30 to +60°C (-22 to +140°F) Dimensions 60 × 153 mm (2.3 × 6.0 in.) Weight 373 g (0.82 lb.) Environmental rating... -
Page 61: Truvision Ip Motorized Lens Bullet Cameras
Weight 800 g (1.76 lb.) Environmental rating IP67 TruVision IP motorized lens bullet cameras Electrical Voltage input 12 VDC, PoE (IEEE 802.3af) Power consumption Max. 7.5 W Miscellaneous Connectors DC jack flying lead, RJ45 flying lead Operating temperature -30 to +60°C (-22 to +140°F) Dimensions 105 ×... -
Page 62: Truvision Ip Motorized Lens Dome Cameras
Operating temperature -30 to +60°C (-22 to +140°F) Dimensions (L × W × H) 140 × 100 mm (5.51 × 3.94 in.) Weight 807 g (1.78 lb.) Environmental rating IP67 TruVision IP motorized lens dome cameras Electrical Voltage input 12 VDC, PoE (IEEE 802.3af) Power consumption Max. -
Page 63: Truvision Ip Fixed Lens Dome
TruVision IP fixed lens dome Electrical Voltage input 12 VDC, PoE (IEEE 802.3af) Power consumption Max. 5 W Miscellaneous Connectors DC jack flying lead, RJ45 flying lead Operating temperature -30 to +60°C (-22 to +140°F) Dimensions (L × W × H) 111 ×... -
Page 64: Truvision Ip Turret Cameras
TruVision IP turret cameras Electrical Voltage input 12 VDC, PoE (IEEE 802.3af) Power consumption Max. 5.5 W (Max. 7.5 W with IR on) Miscellaneous Connectors DC jack flying lead, RJ45 flying lead Operating temperature -30 to +60°C (-22 to +140°F) Dimensions (L ×... -
Page 65: Pin Definitions
Pin definitions There are eight wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of straight and crossover cable connection: Figure 9: Straight-through cable White/Orange White/Orange Orange Orange White-Green White-Green Blue Blue White/Blue... - Page 66 Please make sure your connected cables have the same pin assignment and color as above before deploying the cables in your network. Installation Guide...
