Item
Data connection
*2
Data size
*2
Connection
Ship position information
Using GPS
Latitude
Longitude
Temperature information: Internal temperature information
HPA
IF
Modem
Error information
Error
Warning
*1: FELCOM 500 only
*2: No display if No permission is shown for Data connection.
Description
Displays data communication status. --- (Not avail-
able), No permission (No connection permission),
Not connected, Connected (in green). The status of
all groups is shown if logged in as Administrator.
"Connected" if one or more groups is connected; "Not
connected" if no groups are connected.
Displays packet traffic volume of group affiliated with
the PC currently in use. If logged in as Administrator,
the packet volume for all groups/PPPoE sessions is
shown. If there is no satellite acquired "---" appears.
Displays Streaming IP packet session volume. The
total for all groups is shown if logged in as Adminis-
trator.
Displays GPS in use.
Internal, External, No fix (GPS data invalid), No data
(no GPS data)
Displays ship latitude. If no GPS data, [_°_'_"] is dis-
played.
Displays ship longitude. If no GPS data, [_°_'_"] is
displayed.
Temperature of the HPA board in the Antenna Unit.
If no information, [---] is displayed.
Temperature of the IF board in the Communication
Unit. If no information, [---] is displayed.
Temperature of the modem board in the Communi-
cation Unit. If no information, [---] is displayed.
Active Error count.
Active Warning count.
5. WEB SOFTWARE
5-5
