Furuno FELCOM 250 Operator's Manual page 121

How to delete extension numbers
You can delete a single extension number or all extension numbers.
1. Display the Extension screen.
2. Put a check [ ] in the check box at the left side of the extensions) to delete.
(Check as many numbers as desired.) To delete all extension numbers, put a
check in the [Number] checkbox at the top of the screen. This puts a checkmark
on all numbers.
3. Click the [Delete] button.
4. Click the [OK] button.
5. Click the [OK] button again.
How to set internal call routing
When a voice call (only 4kbps AMBE+2) is received, the call can be transferred to an
internal phone automatically. Follow the procedures to set up the internal call routing.
1. From the menu bar, click [Settings] - [PBX settings] - [Internal call routing].
2. To enable the internal call routing function, put a checkmark in the Enable/Disable
box. With no checkmark this function is deactivated, and a call is routed according
to "How to set incoming route" on page 6-2.
3. Select a guidance language; English or Japanese.
4. Set a timeout time between 10 seconds to 99 seconds. If nobody answers the
transferred call during the timeout time, this call is transferred again to phones
specified for incoming routing.
5. Click the [Apply] button to activate the internal call routing. The message "Setting
Completed." appears.
6. Click the [OK] button to erase the message.
When a voice call is received, the FELCOM 250/500 plays guidance to the calling par-
ty. Then, the calling party inputs an extension number. The call is then transferred to
that number.
Operation at calling side in the automatic transfer function
1) Call this vessel (AMBE+2). You are requested to dial extension number.
2) Dial extension number (4 digits). The extension number is called.
3) When the party answers, pick up the receiver.
4) Hang up the receiver after completing the call.
6. WEB FUNCTIONS
6-7
