Page 1: Air Conditioner
AIR CONDITIONER Multi : 2rooms type 3rooms type 4rooms type DESIGN & TECHNICAL MANUAL AU  G07LVLA AR  G07LLTA ARG18LLTA AS  G07LJCA INDOOR AU  G09LVLA AR  G09LLTA AR  G18LLTB AS  G09LJCA AU  G12LVLA AR ...
Page 2 1. INDOOR UNIT COMPACT WALL MOUNTED TYPE: CASSETTE TYPE: ASG07LJCA AUG07LVLA ASG09LJCA AUG09LVLA ASG12LJCA AUG12LVLA AUG14LVLA ASG07LUCA AUG18LVLA ASG09LUCA AUG12LVLB ASG12LUCA AUG14LVLB ASG14LUCA AUG18LVLB ASG07LMCA SLIM DUCT TYPE: ASG09LMCA ARG07LLTA ASG12LMCA ARG09LLTA ASG14LMCA ARG12LLTA ARG14LLTA ASG18LFCA ARG18LLTA ASG24LFCA ARG12LLTB ASG24LFCC ARG14LLTB ARG18LLTB FLOOR TYPE:...
Page 3: Table Of Contents
CONTENTS 1. INDOOR UNIT FEATURES ......................01-01 1-1. INDOOR UNIT ...................... 01-01 1-1-1. COMPACT CASSETTE TYPE ..............01-01 1-1-2. SLIM DUCT TYPE ..................01-02 1-1-3. WALL MOUNTED TYPE ................01-03 1-1-4. FLOOR / CEILING TYPE ................01-07 1-1-5. FLOOR TYPE ....................01-08 1-2.
Page 4: Indoor Unit
CONTENTS 1. INDOOR UNIT FAN PERFORMANCE CURVE ............. 01-108 7-1. SLIM DUCT TYPE ..................... 01-108 AIRFLOW ....................... 01-118 NOISE LEVEL CURVE ................01-120 9-1. COMPACT CASSETTE TYPE ................. 01-120 9-2. SLIM DUCT TYPE ..................... 01-123 9-3. WALL MOUNTED TYPE .................. 01-126 9-4.
Page 5: Compact Cassette Type
FEATURES 1-1. INDOOR UNIT 1-1-1. COMPACT CASSETTE TYPE  G07LVLA, AU  G09LVLA, AU  G12LVLA, „ „ MODELS : AU AU  G14LVLA, AU  G18LVLA, AU  G12LVLB, AU  G14LVLB, AU  G18LVLB „ „ FEATURES „ Quiet quality „...
Page 6: Slim Duct Type
1-1-2. SLIM DUCT TYPE  G07LLTA, AR  G09LLTA, AR  G12LLTA, „ „ MODELS : AR AR  G14LLTA, AR  G18LLTA, AR  G12LLTB, AR  G14LLTB, AR  G18LLTB Slim design and wide range of static pressure for flexible installation. „...
Page 7: Wall Mounted Type
1-1-3. WALL MOUNTED TYPE AS  G07LJCA, AS  G09LJCA, AS  G12LJCA „ „ MODELS : Compact and Stylish design indoor unit „ „ FEATURES „ „ High density heat transfer tube Easy maintenance arrangement Removable & washable panel Ø5 Making the tube thin: →5...
Page 8 AS  G07LUCA, AS  G09LUCA, AS  G12LUCA, „ „ MODELS : AS  G14LUCA „ „ FEATURES „ Thin & Slim design Thin and slim design is realized by Ø5mm heat exchanger and high efficiency wind blower. H282 X W870 X D185 185mm Big open panel and High density multi path heat exchanger Large intake...
Page 9 AS  G07LMCA, AS  G09LMCA, AS  G12LMCA, „ „ MODELS : AS  G14LMCA „ „ FEATURES High efficient compact design z More comfortable airflow „ „ Quiet operation INDOOR UNIT Airflow mode can be set in 4 steps and more detailed airflow setting is possible. 21dB only at cooling operation (22dB at heating operation).
Page 10  G18LFCA, AS  G24LFCA, AS  G24LFCC „ „ MODELS : AS Simple & Elegant Appearance Design „ „ FEATURES „ Compact & Slim design 998 mm “ Vertical airflow” provides powerful floor level heating „ (24/30) Outside air conditions: 2 C 60% Operation contents: Heating Set temperature (Max set temp)
Page 11: Floor / Ceiling Type
1-1-4. FLOOR / CEILING TYPE  G14LVTA, AB  G18LVTA, „ „ MODELS : AB AB  G18LVTB „ „ FEATURES „ Flexible installation Example for floor installation Example for ceiling installation „ Easy installation Main work settings can be done easily from the remote controller at installation Main work settings Setting by wireless or wired remote controller...
Page 12: Floor Type
1-1-5. FLOOR TYPE  G09LVCA, AG  G12LVCA, AG  G14LVCA „ „ MODELS : AG „ „ FEATURES 2-Fan & Wide airflow „ Heating Prevents cold Window Cooling Prevents cold air draft from from falling window at operation at operation at stable at stable start...
Page 13: Line Up
1-2. LINE UP „ „ MODELS INDOOR UNIT AUG07LVLA , AUG09LVLA ARG07LLTA ARG18LLTA AUG12LVLA, AUG14LVLA ARG09LLTA ARG18LLTB AUG18LVLA, AUG12LVLB ARG12LLTA AUG14LVLB, AUG18LVLB ARG14LLTA ARG12LLTB ARG14LLTB ASG07LJCA ASG07LUCA ASG07LMCA ASG09LJCA ASG09LUCA ASG09LMCA ASG12LJCA ASG12LUCA ASG12LMCA ASG14LUCA ASG14LMCA ASG18LFCA ABG14LVTA AGG09LVCA ASG24LFCA ABG18LVTA AGG12LVCA ASG24LFCC...
Page 14 „ „ INDOOR UNIT CONNECTION PATTERNS „ 2 Rooms AOG14LAC2 room 1 room 2 total AOG18LAC2 room 1 room 2 total Notes) 7: 7000Btu/h, 9: 9000Btu/h, 12: 12000Btu/h, 14: 14000Btu/h models Where "14" means "Wall Mounted type" only models. Other types of indoor units cannot be connected. „...
Page 15 „ 4 Rooms AOG30LAT4 room 1 room 2 room 3 room 4 total 1 2 Notes) 7: 7000Btu/h, 9: 9000Btu/h, 12: 12000Btu/h, 14: 14000Btu/h, 18: 18000Btu/h, 24: 24000Btu/h models 1: Connection of "ARG09L+ARG09L+ARG09L+ASG18L " is not available. All types other than this combination can be connected. 2: Connection of "ARG09L+ARG09L+ARG12L+ASG18L "...
Page 16: Remote Controller
REMOTE CONTROLLER 2-1. WIRELESS REMOTE CONTROLLER „ „ MODEL : AR-RAH2E / AR-RAH1E „ „ FEATURES ● 4 mode timer setup available (ON / OFF / PROGRAM / SLEEP). ● Can be used jointly with wired remote controllers . ● Easy to change custom code (Max.4 custom codes) by button operation.
Page 17 „ „ [Wall mounted(LF) , Floor/Ceiling type ] FUNCTIONS MODE button Selects the operating mode (AUTO, COOL, DRY, FAN, HEAT). /Start / end R.C. custom code change. (Max. 4 custom codes) 10°C HEAT button SET TEMP. button ( ▲ / ▼ ) Sets the indoor temp./ Sets R.C.
Page 18 „ „ FUNCTIONS [ Compact cassette, Wall mounted ( LJ ) , Floor type ] MODE button Selects the operating mode (AUTO, COOL, DRY, FAN, HEAT). /Start / end R.C. custom code change. (Max. 4 custom codes) 10°C HEAT button SET TEMP.
Page 19: System Diagram
„ „ SYSTEM DIAGRAM ● Control signal might not be recognized in following cases: (i) A curtain or a wall, etc. exists between transmitter and receiver. (ii) There is an instant-start type (inverter type, etc.) fluorescent lamp Signal receiver Signal transmitter in the room.
Page 20: Packing List
„ „ PACKING LIST Name and shape Quantity Application Remote controller holder Use as remote controller holder Tapping screw For remote controller holder installation Battery For remote controller [ 1.5V (R03 / AAA) ] „ „ SPECIFICATIONS Dimensions [H x W x D]: (mm) 170 x 56 x 19 Weight : (g) 85 [w/o batteries]...
Page 21 „ „ MODEL : AR-REA2E „ „ FEATURES 5 mode timer setup available (ON / OFF / WEEKLY / PROGRAM /  „ SLEEP). Easy operation.  „ Easy to change custom code (Max. 4 custom codes) by button  „...
Page 22 „ „ FUNCTIONS [Wall mounted (LU) type] Signal Transmitter MODE button FAN button 10 °C HEAT button ECONOMY button SWING button OUTDOOR UNIT TEMP. button LOW NOISE button SET button POWERFUL button TIMER SETTING button WEEKLY button Start / Stop SEND button button ON/OFF button...
Page 23 „ „ MODEL: AR-REB1E „ „ FEATURES 4 mode timer setup available (ON / OFF / PROGRAM / SLEEP).  „ Easy operation.  „ Easy to change custom code (Max. 4 custom codes) by button  „ operation. „ Simple function setting Setting of the air conditioner selection function is performed by remote controller.
Page 24 „ „ FUNCTIONS [Wall mounted (LM) type] ① Signal Transmitter ② 10 °C HEAT button ③ MODE button ④ ECONOMY button ⑤ OUTDOOR UNIT LOW NOISE button ⑥ ON TIMER button ⑦ OFF TIMER button ⑧ CLOCK ADJUST button ⑨ POWERFUL button ⑩...
Page 25 „ „ SYSTEM DIAGRAM (AR-REA2E, AR-REB1E) ● Control signal may not be recognized in following cases: (i) A curtain or a wall, etc. exists between transmitter and receiver. (ii) There is an instant-start type (inverter type, etc.) fluorescent lampin the room. ●...
Page 26 „ „ PACKING LIST Name and shape Quantity Application Remote controller holder Use as remote controller holder Tapping screw For remote controller holder installation Battery For remote controller [ 1.5V (R03 / AAA) ] „ „ SPECIFICATIONS Dimensions [H x W x D]: (mm) 205 x 61 x 17 Weight : (g) 122 [w/o batteries]...
Page 27: Wired Remote Controller [ For Slim Duct Type ]
[ For Slim duct type ] 2-2. WIRED REMOTE CONTROLLER ● Various timer setup available (ON / OFF / WEEKLY). „ „ FEATURES ● Equipped with weekly timer as standard function. (Start / Stop function is twice per day for a week) ●...
Page 28 „ „ FUNCTIONS START/STOP button Pressed to start and stop operation. SET TEMP. button Selects the setting temperature. Display MODE button Selects the operating mode ( AUTO , COOL , DRY , , HEAT FAN button , MED Selects the fan speed ( AUTO , HIGH , QUIET Vertical air flow direction and swing button...
Page 29: Electrical Wiring
„ „ SYSTEM DIAGRAM z 2 remote controllers „ 1 remote controller Indoor unit Indoor unit A , B , C : Remote controller cable. 500m ; B+C 500m < < Primary Secondary Remote controller Remote controllers „ „ ELECTRICAL WIRING z 2 remote controllers „...
Page 30 „ „ INSTALLATION „ Connection Pattern Note: Connection pattern is different according to type of Indoor unit. Indoor unit types Connection Pattern Compact Cassette type Slim Duct type Pattern A Floor / Ceiling type Pattern B Wall Mounted type Pattern C Floor type „...
Page 31 „ Pattern C 1) Modify the remote controller cable as per below methods. ● Use a tool to cut off the terminal on the end of the remote controller cable and then remove the insulation from the cut end of the cable as shown in Fig. ●...
Page 32: Wiring Specifications
„ „ PACKING LIST Name and shape Quantity Application Operating manual Installation manual For connecting the remote controller Remote controller cable (10m) For installing the remote controller Screw (M4 x 16mm) To tie the remote controller and cables Cable tie For connecting the remote controller cable to the Connecting cable *1 Wall mounted type indoor unit...
Page 33: Wired Remote Controller (Optional Parts)
2-3. WIRED REMOTE CONTROLLER (Optional parts) : UTY-RVN  M „ „ MODEL ● Large and full-dot liquid crystal screen ● Screen with backlight can be seen even in the dark ● Wide and large keys easy to press, user-intuitive arrow key „...
Page 34: Main Functions
„ „ MAIN FUNCTIONS „ Auto off timer ● The indoor unit automatically turns Ex) At interval time hour (17:00 to 24:00) to prevent off after a set time has passed. forgetting to turn off ● The time interval for which auto off Set interval time hour (17:00 to 24:00) works can be set.
Page 35 22°C 10:00 12:00 14:00 17:00 20:00 23:59 Time Setting menu in „ Weekly timer function remote controller ● Not only time setting On/Off, but also setting of the operation mode and set temperature can be set by Weekly timer function. Two types of settings: Weekly 1 and Weekly 2 for summer and winter are possible.
Page 36 „ „ FUNCTIONS 1 Display panel (with backlight) 6 Screen switch button (Right) 2 Screen switch button (Left) 7 Power indicator 3 Menu button 8 On / Off button 4 Cancel button 9 Enter button 5 Cursor button - (01-32) -...
Page 37 „ „ SYSTEM DIAGRAM z 2 remote controllers „ 1 remote controller Indoor unit Indoor unit A , B , C : Remote controller cable. Secon- Primary dary Remote controller Remote controllers „ „ ELECTRICAL WIRING z 2 remote controllers „...
Page 38 „ „ INSTALLATION 1) Installation space. Unit : mm * Please secure enough space where a flat screwdriver to take off or more a case can be inserted. or more or more 220 or more* 2) Processing of the remote controller cable. Unit : mm 1.
Page 39 4) Installing the remote controller A. When attaching to switch box: (1) Seal the wiring hole of the remote controller cable. (2) Put a remote controller cable through the hole of the rear case. (3) Fix the rear case by securing it with attached screws (2 places). B.
Page 40 5) Connect the cable to the terminals on the front case. Fix the cable together with the sheath with the cable tie. Cut off the excess cable tie. Tightening torque Terminal screw 0.8 to 1.2N • m 1. 12V (Red) 2.
Page 41 „ Connection Pattern Note: Connection pattern is different according to type of Indoor unit. Indoor unit types Connection Pattern Compact Cassette type Slim Duct type Pattern A Floor / Ceiling type Pattern B Wall Mounted type Pattern C Floor type „...
Page 42 „ Pattern C 1) Modify the remote controller cable as per below methods. ● Use a tool to cut off the terminal on the end of the remote controller cable and then remove the insulation from the cut end of the cable as shown in Fig. ●...
Page 43 „ „ DIMENSIONS Unit : mm 33.5 21.3 Front View Side View Rear View „ „ PACKING LIST Name and shape Q'ty Summary Instruction book for operation Operating manual Instruction book for installation Installation manual For connecting the remote controller Remote controller cable For connecting the remote controller cable to the wall mounted type.
Page 44 „ „ PART (OPTIONAL) Wall mounted AS  G07LUCA AS  G07LMCA AS  G07LJCA AS  G09LUCA AS  G09LMCA AS  G09LJCA AS  G12LUCA AS  G12LMCA Model name AS  G12LJCA AS  G14LUCA AS  G14LMCA UTY-XCBXZ1 UTY-TWBXF UTY-XCBXZ2...
Page 45: Compact Cassette Type
SPECIFICATIONS 3-1. COMPACT CASSETTE TYPE AU  G12LVLA AU  G14LVLA AU  G18LVLA Model name AU  G07LVLA AU  G09LVLA AU  G12LVLB AU  G14LVLB AU  G18LVLB Power source 1ø 230V ~ 50Hz Available voltage range 198-264V Capacity 2.0kW Class...
Page 46: Slim Duct Type
3-2. SLIM DUCT TYPE AR  G12LLTA AR  G14LLTA AR  G18LLTA Model name AR  G07LLTA AR  G09LLTA AR  G12LLTB AR  G14LLTB AR  G18LLTB Power source 1ø 230V ~ 50Hz Available voltage range 198-264V Capacity 2.0kW Class 2.5kW Class...
Page 47: Wall Mounted Type
3-3. WALL MOUNTED TYPE Model name AS  G07LJCA AS  G09LJCA AS  G12LJCA Power source 1ø 230V ~ 50Hz Available voltage range 198-264V Capacity 2.0kW Class 2.5kW Class 3.5kW Class Input power Running current 0.13 0.15 0.19 High Cooling Quiet Airflow...
Page 48 Model name AS  G07LUCA AS  G09LUCA AS  G12LUCA AS  G14LUCA Power source 1ø 230V ~ 50Hz Available voltage range 198-264V Capacity 2.0kW Class 2.5kW Class 3.5kW Class 4.0kW Class Input power Running current 0.13 0.14 0.17 0.20 High Cooling...
Page 49 Model name AS  G07LMCA AS  G09LMCA AS  G12LMCA AS  G14LMCA Power source 1ø 230V ~ 50Hz Available voltage range 198-264V Capacity 2.0kW Class 2.5kW Class 3.5kW Class 4.0kW Class Input power Running current 0.13 0.15 0.19 0.25 High Cooling...
Page 50 Model name AS  G18LFCA AS  G24LFCA AS  G24LFCC Power source 1ø 230V ~ 50Hz Available voltage range 198-264V Capacity 5.0kW Class 7.0kW Class Input power Running current 0.33 0.53 High 1120 Cooling Quiet Airflow rate High 1100 Heating Quiet Type ×...
Page 51: Floor / Ceiling Type
3-4. FLOOR / CEILING TYPE AB  G18LVTA Model name AB  G14LVTA AB  G18LVTB Power source 1ø 230V ~ 50Hz Available voltage range 198-264V Capacity 4.0kW Class 5.0kW Class Input power Running current 0.21 0.36 High Cooling Quiet Airflow rate High...
Page 52: Floor Type
3-5. FLOOR TYPE Model name AG  G09LVCA AG  G12LVCA AG  G14LVCA Power source 1ø 230V ~ 50Hz Available voltage range 198-264V Capacity 2.5kW Class 3.5kW Class 4.0kW Class Input power Running current 0.15 0.18 0.20 High Cooling Quiet Airflow rate...
Page 53: Dimensions
DIMENSIONS 4-1. COMPACT CASSETTE TYPE  G07LVLA, AU  G09LVLA, AU  G12LVLA, „ „ MODELS : AU AU  G14LVLA, AU  G18LVLA, AU  G12LVLB, AU  G14LVLB, AU  G18LVLB Unit : mm • Cassette grille mounting state 530: Hanging bolt position op view Be sure to leave...
Page 54: Installation Place
„ „ INSTALLATION PLACE Unit : mm Strong and durable ceiling or more 1000 1000 or more or more 1800 or more Obstruction Floor H (The maximum height from floor to ceiling) Unit: mm Model name AU  G07 AU  G09 AU ...
Page 55: Slim Duct Type
4-2. SLIM DUCT TYPE  G07LLTA, AR  G09LLTA, AR  G12LLTA, „ „ MODELS : AR AR  G14LLTA, AR  G12LLTB, AR  G14LLTB Unit : mm View A Rear view (Drain hose) Drain port 100 x 6 = 600 Side view Top view Front view...
Page 56  G18LLTA, „ „ MODEL : AR Unit : mm AR  G18LLTB Rear view View A (Drain hose) Drain port 100 x 8 = 800 Top view Side view Front view Bottom view AR  G18L Liquid ø 6.35 mm (ø 1/4 in.) ...
Page 57 Unit : mm „ „ INSTALLATION PLACE 300 or more Strong and durable ceiling 20 or more Indoor unit Left Right side side 20 or more Service access Ceiling or more or more Floor or less or less Left side Right side (PIPE side) Grille...
Page 58 Unit : mm „ „ MAINTENANCE SPACE Provide a service access for inspection purposes as shown below. Do not place any wiring or illumination in the service space, as they will impede service. Service access Unit Control or more Service space - (01-54) -...
Page 59: Wall Mounted Type
4-3. WALL MOUNTED TYPE  G07LJCA, AS  G09LJCA, AS  G12LJCA „ „ MODELS : AS Unit : mm 205 : Installed state 140 *1 145 *1 *1: Vertical flap is downward Outline of unit 353: Gas pipe ø 65 ø...
Page 60 „ „ INSTALLATION PLACE Unit : mm Outline of unit 48 or more 52 or more 100 or more 70 or more 1500 or more - (01-56) -...
Page 61  G07LUCA, AS  G09LUCA, AS  G12LUCA, „ „ MODELS : AS AS  G14LUCA 187: Installed state Outline of Unit Ø65 Ø65 for pipe inlet for pipe inlet AS  G07LU, AS  G09LU, AS  G14LU AS  G12LU Liquid ø...
Page 62 „ „ INSTALLATION PLACE - (01-58) -...
Page 63 „ „ G07LMCA, ASG09LMCA, ASG12LMCA, MODELS : AS ASG14LMCA (Unit : mm) AS  G07LM, AS  G09LM, AS  G14LM AS  G12LM Liquid ø 6.35 mm (1/4 in.) ø 6.35 mm (1/4 in.)  Refrigerant pipe flare connection ø...
Page 64 „ „ INSTALLATION PLACE (Unit : mm) - (01-60) -...
Page 65  G18LFCA, AS  G24LFCA, AS  G24LFCC „ „ MODELS : AS Unit : mm Unit center 18 x 11 hole 26 x 11 hole 26 x 11 hole 21 x 5: 14holes 18 x 11 hole 5 x 18: 14holes ø...
Page 66 „ „ INSTALLATION PLACE Unit : mm Outline of unit 52 or more 53 or more 80 or more 120 or more 1500 or more - (01-62) -...
Page 67: Floor / Ceiling Type
4-4. FLOOR / CEILING TYPE  G14LVTA, AB  G18LVTA, „ „ MODELS : AB AB  G18LVTB Rear view Side view (Drain hose) Bottom view Wall bracket Side of set 100 hole 50 hole 100 hole AB  G14L, AB  G18L Liquid ø...
Page 68 „ „ INSTALLATION PLACE Left Right 300 or more 300 or more Ceiling Left Right Indoor unit 150 or more 300 or more Ceiling 20 or more Obstruction Floor - (01-64) -...
Page 69: Floor Type
4-5. FLOOR TYPE  G09LVCA, AG  G12LVCA, AG  G14LVCA „ „ MODELS : AG Side view Front view „ „ INSTALLATION PLACE 100 or more 80 or more 80 or more 50 or more 150 or below from the floor - (01-65) -...
Page 70: Wiring Diagrams
WIRING DIAGRAMS 5-1. COMPACT CASSETTE TYPE  G07LVLA, AU  G09LVLA, AU  G12LVLA, „ „ MODELS : AU AU  G14LVLA, AU  G18LVLA, AU  G12LVLB, AU  G14LVLB, AU  G18LVLB - (01-66) -...
Page 71: Slim Duct Type
5-2. SLIM DUCT TYPE  G07LLTA, AR  G09LLTA, AR  G12LLTA, „ „ MODELS : AR AR  G14LLTA, AR  G18LLTA, AR  G12LLTB, AR  G14LLTB, AR  G18LLTB THERMISTOR GRAY (PIPE TEMP.) GRAY BLACK THERMISTOR BLACK (ROOM TEMP.) LOUVER PRINTED...
Page 72: Wall Mounted Type
5-3. WALL MOUNTED TYPE  G07LJCA, AS  G09LJCA, AS  G12LJCA „ „ MODELS : AS - (01-68) -...
Page 73  G07LUCA, AS  G09LUCA, AS  G12LUCA, „ „ MODELS : AS AS  G14LUCA - (01-69) -...
Page 74 „ „ G07LMCA, ASG09LMCA, ASG12LMCA, MODELS : AS ASG14LMCA - (01-70) -...
Page 75  G18LFCA, AS  G24LFCA, AS  G24LFCC „ „ MODELS : AS - (01-71) -...
Page 76: Floor / Ceiling Type
5-4. FLOOR / CEILING TYPE  G14LVTA, AB  G18LVTA, „ „ MODELS : AB AB  G18LVTB - (01-72) -...
Page 77: Floor Type
5-5. FLOOR TYPE  G09LVCA, AG  G12LVCA, AG  G14LVCA „ „ MODELS : AG - (01-73) -...
Page 78: Air Velocity And Temperature Distributions
AIR VELOCITY AND TEMPERATURE DISTRIBUTIONS 6-1. COMPACT CASSETTE TYPE Conditions Fan speed: HIGH  G07LVLA, AU  G09LVLA „ „ MODELS : AU Operation mode: FAN „ Air velocity distribution Top view Vertical airflow direction louver: Up Unit : m/s 0.25 0.25 0.25...
Page 79 Reference data Conditions Fan speed: HIGH Operation mode: HEATING „ Air velocity distribution Vertical airflow direction louver: 4 WAY Side view Vertical airflow direction louver: Down Unit : m/s 0.25 0.25 „ Air temperature distribution Side view Vertical airflow direction louver: Down Unit : °C - (01-75) -...
Page 80 Conditions Fan speed: HIGH „ „ G12LVLA, AUG12LVLB MODELS : AU Operation mode: FAN „ Air velocity distribution Top view Vertical airflow direction louver: Up Unit : m/s 0.25 0.25 0.25 0.25 Side view Vertical airflow direction louver: Up Unit : m/s 0.25 0.25 - (01-76) -...
Page 81 Reference data Conditions Fan speed: HIGH Operation mode: HEATING Vertical airflow direction louver: 4 WAY „ Air velocity distribution Side view Vertical airflow direction louver: Down Unit : m/s 0.25 0.25 „ Air temperature distribution Side view Vertical airflow direction louver: Down Unit : °C - (01-77) -...
Page 82 Conditions Fan speed: HIGH  G14LVLA, AU  G14LVLB „ „ MODELS : AU Operation mode: FAN „ Air velocity distribution Top view Vertical airflow direction louver: Up Unit : m/s 0.25 0.25 0.25 0.25 Side view Vertical airflow direction louver: Up Unit : m/s 0.25 0.25...
Page 83 Reference data Conditions Fan speed: HIGH Operation mode: HEATING Vertical airflow direction louver: 4 WAY „ Air velocity distribution Side view Vertical airflow direction louver: Down Unit : m/s 0.25 „ Air temperature distribution Side view Vertical airflow direction louver: Down Unit : °C - (01-79) -...
Page 84 Conditions Fan speed: HIGH  G18LVLA, AU  G18LVLB „ „ MODELS : AU Operation mode: FAN „ Air velocity distribution Top view Vertical airflow direction louver: Up Unit : m/s 0.25 0.25 0.25 0.25 Side view Vertical airflow direction louver: Up Unit : m/s 0.25 0.25...
Page 85 Reference data Conditions Fan speed: HIGH Operation mode: HEATING „ Air velocity distribution Vertical airflow direction louver: 4 WAY Side view Vertical airflow direction louver: Down Unit : m/s 0.25 0.25 „ Air temperature distribution Side view Vertical airflow direction louver: Down Unit : °C - (01-81) -...
Page 86: Slim Duct Type With Auto Louver Grille Kit
6-2. SLIM DUCT TYPE with Auto louver grille kit  G07LLTA (UTD-GXSA-W) „ „ MODEL : AR Conditions Fan speed: HIGH Note: This data is measured installing the Auto louver grille kit(option). Operation mode: FAN „ Air velocity distribution Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver:...
Page 87 Reference Data Conditions Note: This data is measured installing the Auto louver grille kit(option). Fan speed: HIGH Operation mode: HEATING „ Air velocity distribution Unit: m/s Side view Vertical airflow direction louver: Down Horizontal airflow direction louver: Center „ Air temperature distribution Unit: °C Side view Vertical airflow direction louver:...
Page 88  G09LLTA (UTD-GXSA-W) „ „ MODEL : AR Conditions Fan speed: HIGH Note: This data is measured installing the Auto louver grille kit(option). Operation mode: FAN „ Air velocity distribution Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Unit: m/s Top view...
Page 89 Reference Data Conditions Note: This data is measured installing the Auto louver grille kit(option). Fan speed: HIGH Operation mode: HEATING „ Air velocity distribution Unit: m/s Side view Vertical airflow direction louver: Down Horizontal airflow direction louver: Center „ Air temperature distribution Unit: °C Side view Vertical airflow direction louver:...
Page 90  G12LLTA, AR  G12LLTB „ „ MODELS : AR Conditions Fan speed: HIGH (UTD-GXSA-W) Operation mode: FAN Note: This data is measured installing the Auto louver grille kit(option). „ Air velocity distribution Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Unit: m/s...
Page 91 Reference Data Conditions Note: This data is measured installing the Auto louver grille kit(option). Fan speed: HIGH Operation mode: HEATING „ Air velocity distribution Unit: m/s Side view Vertical airflow direction louver: Down Horizontal airflow direction louver: Center „ Air temperature distribution Unit: °C Side view Vertical airflow direction louver:...
Page 92: Vertical Airflow Direction Louver: Up Horizontal Airflow Direction Louver: Center
 G14LLTA, AR  G14LLTB „ „ MODELS : AR Conditions Fan speed: HIGH (UTD-GXSA-W) Operation mode: FAN Note: This data is measured installing the Auto louver grille kit(option). „ Air velocity distribution Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Unit: m/s...
Page 93 Reference Data Conditions Note: This data is measured installing the Auto louver grille kit(option). Fan speed: HIGH Operation mode: HEATING „ Air velocity distribution Unit: m/s Side view Vertical airflow direction louver: Down Horizontal airflow direction louver: Center „ Air temperature distribution Unit: °C Side view Vertical airflow direction louver:...
Page 94: Vertical Airflow Direction Louver: Up
 G18LLTA, AR  G18LLTB „ „ MODELS : AR Conditions Fan speed: HIGH (UTD-GXSB-W) Operation mode: FAN Note: This data is measured installing the Auto louver grille kit(option). „ Air velocity distribution Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Unit: m/s...
Page 95 Reference Data Conditions Note: This data is measured installing the Auto louver grille kit(option). Fan speed: HIGH „ Operation mode: HEATING Air velocity distribution Unit: m/s Side view Vertical airflow direction louver: Down Horizontal airflow direction louver: Center „ Air temperature distribution Unit: °C Side view Vertical airflow direction louver:...
Page 96: Wall Mounted Type
6-3. WALL MOUNTED TYPE Conditions Fan speed: HIGH  G07LJCA „ „ Operation mode: FAN MODEL : AS Unit : m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Right &...
Page 97 Conditions Fan speed: HIGH  G09LJCA „ „ Operation mode: FAN MODEL : AS Unit : m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Right & Left Side view Vertical airflow direction louver: Up...
Page 98 Conditions Fan speed: HIGH  G12LJCA „ „ Operation mode: FAN MODEL : AS Unit : m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Right & Left Side view Vertical airflow direction louver: Up...
Page 99: Horizontal Airflow Direction Louver: Right & Left
Conditions Fan speed: HIGH Operation mode: FAN  G07LUCA, AS  G09LUCA „ „ MODELS : AS Unit : m/s Top view Vertical airflow direction louver: Up 0.25 0.75 Horizontal airflow direction louver: Center Top view 0.25 0.75 Vertical airflow direction louver: Up Horizontal airflow direction 0.75...
Page 100: Horizontal Airflow Direction Louver: Center
Conditions Fan speed: HIGH  G12LUCA, AS  G14LUCA Operation mode: FAN „ „ MODELS : AS Unit : m/s Top view Vertical airflow direction louver: Up 0.25 0.75 Horizontal airflow direction louver: Center Top view 0.25 0.75 Vertical airflow direction louver: Up Horizontal airflow direction 0.75...
Page 101 Conditions Fan speed: HIGH  G07LMCA „ „ Operation mode: FAN MODEL : AS Unit : m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Right & Left Side view Vertical airflow direction louver: Up...
Page 102 Conditions Fan speed: HIGH  G09LMCA „ „ Operation mode: FAN MODEL : AS Unit : m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Right & Left Side view Vertical airflow direction louver: Up...
Page 103 Conditions Fan speed: HIGH  G12LMCA „ „ Operation mode: FAN MODEL : AS Unit : m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Right & Left Side view Vertical airflow direction louver: Up...
Page 104 Conditions Fan speed: HIGH Operation mode: FAN  G14LMCA „ „ MODEL : AS Unit : m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Right & Left Side view Vertical airflow direction louver: Up...
Page 105 Conditions Fan speed: HIGH  G18LFCA „ „ Operation mode: FAN MODEL : AS Unit : m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Right & Left Side view Vertical airflow direction louver: Up...
Page 106 Conditions Fan speed: HIGH  G24LFCA, AS  G24LFCC „ „ MODELS : AS Operation mode: FAN Unit : m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Right &...
Page 107: Floor / Ceiling Type
6-4. FLOOR / CEILING TYPE Conditions Fan speed: HIGH  G14LVTA (UNDER CEILING) „ „ Operation mode: FAN MODEL : AB Unit : (m/s) Top view Vertical airflow direction louver: Up 0.25 Horizontal airflow direction louver: Center Unit : (m/s) 0.25 Top view Vertical airflow direction...
Page 108 Conditions Fan speed: HIGH  G14LVTA (FLOOR CONSOLE) „ „ MODEL : AB Operation mode: FAN Unit : (m/s) Top view Vertical airflow direction louver: Up 0.25 Horizontal airflow direction louver: Center Unit : (m/s) 0.25 Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Right &...
Page 109 Conditions Fan speed: HIGH  G18LVTA, AB  G18LVTB „ „ MODELS : AB Operation mode: FAN (UNDER CEILING) Unit : (m/s) Top view Vertical airflow direction louver: Up 0.25 Horizontal airflow direction louver: Center Unit : (m/s) 0.25 Top view Vertical airflow direction louver: Up Horizontal airflow direction...
Page 110 Conditions Fan speed: HIGH  G18LVTA, AB  G18LVTB „ „ MODELS : AB Operation mode: FAN (FLOOR CONSOLE) Unit : (m/s) Top view Vertical airflow direction louver: Up 0.25 Horizontal airflow direction louver: Center Unit : (m/s) 0.25 Top view Vertical airflow direction louver: Up Horizontal airflow direction...
Page 111: Floor Type
6-5. FLOOR TYPE „ „ G09LVCA, AGG12LVCA, AGG14LVCA MODELS : AG Conditions Unit : m/s Fan speed: HIGH Operation mode: FAN Fan select: UPPER & LOWER Top view Vertical airflow direction louver: Down Horizontal airflow direction louver: Center UPPER LOWER Unit : m/s Top view Vertical airflow direction...
Page 112: Fan Performance Curve
FAN PERFORMANCE CURVE 7-1. SLIM DUCT TYPE  G07LLTA „ „ MODEL : AR SP mode09 upper limit Hi (SP mode09) Quiet (SP mode09) SP mode09 lower limit Normal SP Hi (Normal SP) upper limit Quiet (Normal SP) Normal SP lower limit SP mode00 upper limit...
Page 113 „ Cooling Capacity Air Flow [m „ Heating Capacity Air Flow [m - (01-109) -...
Page 114  G09LLTA „ „ MODEL : AR SP mode09 upper limit Hi (SP mode09) Quiet (SP mode09) SP mode09 lower limit Normal SP Hi (Normal SP) upper limit SP mode00 upper limit Quiet (Normal SP) Hi (SP mode00) Quiet (SP mode00) Air Flow [m Available air flow rate range (High level) Hi (SP mode09)
Page 115 „ Cooling Capacity Air Flow [m „ Heating Capacity Air Flow [m - (01-111) -...
Page 116  G12LLTA, AR  G12LLTB „ „ MODELS : AR Hi (SP mode09) SP mode09 upper limit Quiet (SP mode09) SP mode09 lower limit Normal SP upper limit Hi (Normal SP) Quiet (Normal SP) Hi (SP mode00) SP mode00 upper limit Quiet (SP mode00) Air Flow [m Available air flow rate range (High level)
Page 117 „ Cooling Capacity Air Flow [m „ Heating Capacity Air Flow [m - (01-113) -...
Page 118  G14LLTA, AR  G14LLTB „ „ MODELS : AR Hi (SP mode09) SP mode09 upper limit Quiet (SP mode09) Normal SP upper limit SP mode09 lower limit Quiet (Normal SP) Hi (Normal SP) SP mode00 upper limit Hi (SP mode00) Quiet (SP mode00) 1000...
Page 119 „ Cooling Capacity 1000 Air Flow [m „ Heating Capacity 1000 Air Flow [m - (01-115) -...
Page 120  G18LLTA, AR  G18LLTB „ „ MODELS : AR Hi (SP mode09) SP mode09 upper limit Quiet (SP mode09) SP mode09 Normal SP lower limit upper limit Quiet (Normal SP) Hi (Normal SP) SP mode00 upper limit Hi (SP mode00) Quiet (SP mode00) 1000...
Page 121 „ Cooling Capacity 1000 1100 Air Flow [m „ Heating Capacity 1000 1100 Air Flow [m - (01-117) -...
Page 122: Airflow
AIRFLOW Air flow Air flow Operation Operation Type Model Type Model mode speed mode speed High High Cooling Cooling Quiet Quiet AU  G07LVLA AS  G07LJCA AU  G09LVLA High High Heating Heating Quiet Quiet High High Cooling Cooling Quiet Quiet AU ...
Page 123 Airflow Airflow Operation Operation Type Model Type Model mode speed mode speed High High Cooling Cooling Quiet Quiet AB  G14LVTA AS  G07LMCA High High Heating Heating Quiet Quiet Floor / Ceiling High High Cooling Cooling Quiet Quiet AB  G18LVTA AS ...
Page 124: Noise Level Curve
NOISE LEVEL CURVE 9-1. COMPACT CASSETTE TYPE  G07LVLA „ „ MODEL : AU z Heating „ Cooling NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 HIGH NC-40 HIGH NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET QUIET NC-20 NC-20 NC-15...
Page 125  G12LVLA, AU  G12LVLB „ „ MODELS : AU z Heating „ Cooling N C -65 N C -65 N C -60 N C -60 N C -55 N C -55 N C -50 N C -50 H igh N C -45 N C -45 H igh...
Page 126  G18LVLA, AU  G18LVLB „ „ MODELS : AU z Heating „ Cooling N C -65 N C -65 N C -60 N C -60 N C -55 N C -55 H igh N C -50 N C -50 H igh N C -45 N C -45...
Page 127: Slim Duct Type
9-2. SLIM DUCT TYPE  G07LLTA „ „ MODEL : AR z Heating „ Cooling NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 HIGH HIGH NC-30 NC-30 NC-25 NC-25 QUIET QUIET NC-20 NC-20 NC-15 NC-15 1,000 2,000...
Page 128  G12LLTA, AR  G12LLTB „ „ MODELS : AR z Heating „ Cooling N C -65 N C -65 N C -60 N C -60 N C -55 N C -55 N C -50 N C -50 N C -45 N C -45 N C -40 N C -40...
Page 129  G18LLTA, AR  G18LLTB „ „ MODELS : AR z Heating „ Cooling N C -65 N C -65 N C -60 N C -60 N C -55 N C -55 N C -50 N C -50 N C -45 N C -45 N C -40 N C -40...
Page 130: Wall Mounted Type
9-3. WALL MOUNTED TYPE  G07LJCA „ „ MODEL : AS z Heating „ Cooling NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 H igh HIGH NC-40 HIGH NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 QUIET QUIET NC-15 NC-15...
Page 131  G12LJCA „ „ MODEL : AS z Heating „ Cooling NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH NC-45 NC-45 HIGH NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 QUIET QUIET NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000...
Page 132  G07LUCA „ „ MODEL : AS z Heating „ Cooling N C-6 5 N C-6 5 N C-6 0 N C-6 0 N C-5 5 N C-5 5 N C-5 0 N C-5 0 N C-4 5 N C - 4 5 N C-4 0 N C-4 0 HIGH...
Page 133  G12LUCA „ „ MODEL : AS z Heating „ Cooling N C-6 5 N C-6 5 N C-6 0 N C-6 0 N C-5 5 N C-5 5 N C-5 0 N C-5 0 N C-4 5 N C-4 5 HIGH N C-4 0 N C-4 0...
Page 134 „ „ G07LMCA MODEL : AS „ „ Cooling Heating N C -6 5 N C -6 5 N C -6 0 N C -6 0 N C -5 5 N C -5 5 N C -5 0 N C -5 0 N C -4 5 N C -4 5 HIGH...
Page 135 „ „ G12LMCA MODEL : AS „ „ Cooling Heating N C -6 5 N C -6 5 N C -6 0 N C -6 0 N C -5 5 N C -5 5 N C -5 0 N C -5 0 HIGH N C -4 5 N C -4 5...
Page 136  G18LFCA „ „ MODEL : AS z Heating „ Cooling NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH HIGH NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET QUIET NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000...
Page 137: Floor / Ceiling Type
9-4. FLOOR / CEILING TYPE NOTE:  G14LVTA „ „ MODEL : AB Installation : Under ceiling z Heating „ Cooling NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 HIGH HIGH NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET QUIET...
Page 138: Floor Type
9-5. FLOOR TYPE  G09LVCA „ „ MODEL : AG z Heating „ Cooling NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 High High NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 Quiet Quiet NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000...
Page 139  G14LVCA „ „ MODEL : AG z Heating „ Cooling NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 High NC-50 NC-50 High NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 Quiet NC-25 Quiet NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000...
Page 140: Sound Level Check Point
9-6. SOUND LEVEL CHECK POINT „ „ COMPACT CASSETTE TYPE Microphone Microphone - (01-136) -...
Page 141 „ „ SLIM DUCT TYPE Measuring duct Measuring duct Microphone Microphone Center Center Side view Front view „ „ WALL MOUNTED TYPE Microphone Microphone - (01-137) -...
Page 142 „ „ FLOOR / CEILING TYPE „ Floor console Microphone Microphone „ Under ceiling Microphone Microphone CENTER „ „ FLOOR TYPE Microphone Microphone ● ● Air Flow Air Flow - (01-138) -...
Page 143: Electrical Characteristics
ELECTRICAL CHARACTERISTICS Power Supply Indoor Rated Voltage Input Power Type Model name AU  G07LVLA 0.19 0.15 AU  G09LVLA 0.19 0.15 AU  G12LVLA 0.24 0.19 AU  G12LVLB Compact Cassette AU  G14LVLA 0.28 0.22 AU  G14LVLB AU ...
Page 144: Safety Devices
SAFETY DEVICES Fan motor Terminal Float Model and type PCB fuse thermal thermal fuse switch protector AU  G07LVLA AU  G09LVLA AU  G12LVLA AU  G12LVLB 130 +17°C ○ Compact Cassette ― 250V 3.15A -9°C AU  G14LVLA AU ...
Page 145: External Input & Output
EXTERNAL INPUT & OUTPUT EXTERNAL INPUT EXTERNAL OUTPUT Indoor unit type Operation status Fresh air control Auxiliary heater Error status output Control input output output output Compact ● ● ● Cassette ● ● ● ● Slim Duct ● ● ● Wall Mounted (LU / LM types) ●...
Page 146 ● When function setting is in "Operation/Stop" mode Input signal Operation Indoor unit Stop ● When function setting is in "Forced stop" mode Input signal Forced stop Command Normal Operation Indoor unit Stop Remote controller Remote control operation invalidity „ Parts (Optional) Wall Mounted Compact...
Page 147: External Output
12-2. EXTERNAL OUTPUT „ „ OPERATION STATUS OUTPUT Wall Mounted Compact Floor / Slim Duct Floor Cassette Ceiling LU / LM Connector CNB01 CN103 CN103 CN304 CN16 CN103 CN20 An air conditioner operation status signal can be output. „ Circuit diagram example Indoor unit Connected unit control PC board *1...
Page 148 „ „ FRESH AIR CONTROL OUTPUT Compact Cassette Slim Duct Wall Mounted Floor / Ceiling Floor Connector A signal linked to air conditioner indoor fan ON can be output. * However, signal becomes OFF during cold air prevention control operation. „...
Page 149 „ „ AUXILIARY HEATER OUTPUT Compact Cassette Slim Duct Wall Mounted Floor / Ceiling Floor Connector CN10 A signal is outputed from Connector when indoor fan and compressor turn on under heating operation. Tr-Ts * Signal output performance specifications are as Tr-Ts = -1°C shown on the right Tr-Ts = -3°C...
Page 150 „ „ ERROR STATUS OUTPUT Wall Mounted Compact Floor / Slim Duct Floor Cassette Ceiling LU / LM Connector CNB02 An air conditioner error status signal can be output. „ Circuit diagram example Indoor unit Connected unit control PC board *1 Connector Ex.)Relay unit Ex.)Display...
Page 151: Function Settings
FUNCTION SETTINGS 13-1. INDOOR UNIT (setting by jumper wire) Note: This function is Slim Duct type only. „ „ SWITCH POSITION „ Slim Duct type „ „ JUMPER WIRE SETTING „ Drainage function setting (JM1) (u...Factory setting) Drainage function Connect Enable Disconnect Disable...
Page 152: Indoor Unit (Setting By Wireless Remote Controller)
13-2. INDOOR UNIT (setting by wireless remote controller) The function settings of the control of the indoor unit can be changed by this procedure ● „ according to the installation conditions. Incorrect settings can cause the indoor unit to malfunction. After the power is turned on, perform the "FUNCTION SETTING"...
Page 153: Ar-Rah2E / Ar-Rah1E
13-2-1. AR-RAH2E / AR-RAH1E „ „ SWITCHING SELECTION OF FUNCTION SETTING MODE (2) Press and hold the “FAN” and the “ SET TEMP. ” buttons. While holding these 2 buttons, press the "RESET" button. SET TEMP. ( ) RESET Function setting mode display „...
Page 154 „ „ BUTTON NAME AND FUNCTION ● During address setting mode, indoor unit rejects any operation command from remote controller. Function number Refer to FUNCTION DETAILS MODE button Setting number - Start the function setting mode Refer to FUNCTION DETAILS - Changes the display digits FAN button START/STOP button...
Page 155 „ „ FUNCTION SETTING (5) Press the “MODE” button to access the (6) Press the “ ” or the “ ” buttons to select function setting mode. the function number. Press the "MODE" button to switch between the left and right digits. Change digit (7) Press the "FAN"...
Page 156: Reset Power After Setting Up Function
„ „ COMPLETION OF FUNCTION SETTING MODE (11) Press the “RESET” button. RESET „ „ SETTING UP EACH INDOOR UNIT Repeat steps (1) through to (11). „ „ RESET THE POWER AFTER SETTING UP FUNCTION OF ALL INDOOR UNITS Important ●...
Page 157: Remote Controller Custom Code Setting
„ „ REMOTE CONTROLLER CUSTOM CODE SETTING According to the following instructions, please set the custom code setting of the Wireless remote controller to match any changes in the custom code setting of the indoor unit. (Note that the air conditioner cannot receive a signal if the air conditioner has not been set for the matching custom code.) 1.
Page 158: Ar-Rea2E
13-2-2. AR-REA2E „ „ CONFIRMATION OF CUSTOM CODE (2) Prior to entering the function setting mode, adjust the custom code of the remote controller to match the custom code of the indoor unit as specified in Remote Controller Custom Code Setting „...
Page 159 „ „ BUTTON NAME AND FUNCTION ● During the function setting mode, indoor unit will reject any operation command from remote controller. Function number Refer to FUNCTION DETAILS Setting number Refer to FUNCTION DETAILS 10°C HEAT button POWERFUL button Changes the displayed digits Switches between the setting number (bottom line) and function number (top line)
Page 160 „ „ FUNCTION SETTING (4) Press the "TEMP. " or "TEMP. " buttons to select the function number. Press the "10°C HEAT" button to switch between left and right digits. Change digit Change digit (5) Press the "POWERFUL" button to proceed (6) Press the "TEMP.
Page 161: Indoor Units
„ „ COMPLETION OF FUNCTION SETTING MODE (9) Press the "RESET" button. RESET „ „ SETTING UP EACH INDOOR UNIT Repeat steps (1) through to (9). „ „ RESET THE POWER AFTER SETTING UP FUNCTION OF ALL INDOOR UNITS Important ●...
Page 162 „ „ REMOTE CONTROLLER CUSTOM CODE SETTING According to the following instructions, please set the custom code setting of the Wireless remote controller to match any changes in the custom code setting of the indoor unit. (Note that the air conditioner cannot receive a signal if the air conditioner has not been set for the matching custom code.) 1.
Page 163: Ar-Reb1E
13-2-3. AR-REB1E „ „ SWITCHING SELECTION OF FUNCTION SETTING MODE " buttons. While holding these 2 buttons, (2) Press and hold the "POWERFUL" and "TEMP. press the "RESET" button. POWERFUL TEMP. ( RESET Function setting mode display „ „ CONFIRMATION OF CUSTOM CODE (3) Press the “TEMP.
Page 164 „ „ BUTTON NAME AND FUNCTION ● During the function setting mode, indoor unit will reject any operation command from remote controller. Function number Refer to FUNCTION DETAILS Setting number Refer to FUNCTION DETAILS 10°C HEAT button POWERFUL button Changes the displayed digits Switches between the setting number (bottom line) and function number (top line)
Page 165 „ „ FUNCTION SETTING (5) Press the "10°C HEAT" button to access (6) Press the "TEMP. " or "TEMP. " the fuction setting mode. buttons to select the function number. Press the "10°C HEAT" button to switch between left and right digits. Change digit (7) Press the "POWERFUL"...
Page 166 „ „ COMPLETION OF FUNCTION SETTING MODE (11) Press the "RESET" button. RESET „ „ SETTING UP EACH INDOOR UNIT Repeat steps (1) through to (11). „ „ RESET THE POWER AFTER SETTING UP FUNCTION OF ALL INDOOR UNITS Important ●...
Page 167 „ „ REMOTE CONTROLLER CUSTOM CODE SETTING According to the following instructions, please set the custom code setting of the Wireless remote controller to match any changes in the custom code setting of the indoor unit. (Note that the air conditioner cannot receive a signal if the air conditioner has not been set for the matching custom code.) 1.
Page 168: Indoor Unit (Setting By Wired Remote Controller)
13-3. INDOOR UNIT (setting by wired remote controller) The function settings of the control of the indoor unit can be changed by this procedure ● „ according to the installation conditions. Incorrect settings can cause the indoor unit malfunction. After the power is turned on, perform the "FUNCTION SETTING" according to the ●...
Page 169: Model: Uty-Rnn  M
 M 13-3-1. MODEL: UTY-RNN „ „ SWITCHING SELECTION OF FUNCTION SETTING MODE 2) To activate the function setting mode, hold down the three buttons "SET TEMP. V", "SET TEMP. Λ" and "FAN" at the same time for 5 seconds or longer. Function setting mode initial display „...
Page 170 „ „ FUNCTION SETTING 3) Press the "Set Time <" button or the "Set Time >" button, to select the function number. Function number 4) Press the "SET TEMP. V" button or the "SET TEMP. Λ" button, to select the setting number. The display flashes during setting number selection.
Page 171 „ „ COMPLETION OF FUNCTION SETTING MODE 6) To clear the function setting mode and return to the regular display, hold down the three buttons "SET TEMP. V", "SET TEMP. Λ" and "FAN" at the same time. Normal mode display * If no key entry is made for 60 seconds, even though none of the above buttons is pressed, the function setting mode will automatically be cleared.
Page 172: Model: Uty-RvnM
 M 13-3-2. MODEL: UTY-RVN „ „ SWITCHING SELECTION OF FUNCTION SETTING MODE 2) When [Menu button] is pressed twice while “Monitor” screen is displayed, it switches to the “Submenu” screen. If [Menu button] is pressed while the “Submenu” screen is displayed, the display returns to the “Monitor”...
Page 173 „ „ FUNCTION SETTING 3) Select the [Function No.] by pressing the [Cursor button (Left/Right)], and select the Function No. to be set by pressing the [Cursor button (Up/Down)]. Function setting Mo 10:00AM R.C. Function Setting address Cancel: Version Error history 4) Select the [Setting No.] by pressing the [Cursor button (Left/Right)], and select the Setting No.
Page 174 „ „ COMPLETION OF FUNCTION SETTING MODE 6) When [Cancel button] is pressed twice while “Function setting” screen is displayed, it switches to the “Submenu” screen. Function setting Mo 10:00AM R.C. Function Setting Submenu Mo 10:00AM address Date and time Screen Cancel: Filter sign...
Page 175: Indoor Unit (Setting By Simple Remote Controller)
13-4. INDOOR UNIT (setting by simple remote controller) The function settings of the control of the indoor unit can be changed by this procedure ● „ according to the installation conditions. Incorrect settings can cause the indoor unit to malfunction. After the power is turned on, perform the "FUNCTION SETTING"...
Page 176 „ „ SWITCHING SELECTION OF FUNCTION SETTING MODE 2) To activate the function setting mode, hold down the three buttons "Set Temp. q", "Set Temp. p" and "Fan" at the same time for 5 seconds or longer. Function setting mode initial display „...
Page 177: Function Details
„ „ FUNCTION SETTING 3) Press the "Fan" button so that the “Function number” display flashes. Then, press either the "Set Temp. p" button or the "Set Temp. q" button to set up the function number. Function number 4) Press the Fan button so that the “Setting number” display flashes. Then, press either the Set Temp.
Page 178 „ „ COMPLETION OF FUNCTION SETTING MODE 6) Press the three buttons "Set Temp. p", "Set Temp. q" and "Fan" at the same time for 5 seconds or longer. The function setting mode will be cleared and the regular display will be restored.
Page 179 13-5. FUNCTION DETAILS Compact Functions Slim duct Wall mounted Floor / Ceiling Floor cassette 1) Filter sign 2) Ceiling height 3) Outlet directions 4) Vertical airflow direction range control 5) Static pressure 6) Room temperature sensor control for cooling 7) Room temperature sensor control for heating 8) Auto restart 9) Room temperature sensor switching 10) Remote controller custom code...
Page 180 3) Outlet directions Select the appropriate number of outlet directions according to the installation conditions. (  ... Factory setting) Function number Setting value Setting description 4-way  3-way 4) Vertical airflow direction range control In a concealed installation, change the setting to "Fixed" (02) to restrict the movement of the upper air outlet so that the airflow is only towards the horizontal direction.
Page 181 8) Auto restart Enable or disable automatic restart after a power interruption. (  ... Factory setting) Function number Setting value Setting description Enable  Disable * Auto restart is an emergency function such as for power outage etc. Do not attempt to use this function in normal operation. Be sure to operate the unit by remote controller or external device.
Page 182 13) Indoor unit fan control for energy saving for cooling Enable or disables the power-saving function by controlling the indoor unit fan rotation when the outdoor unit is stopped during cooling operation. (  ... Factory setting) Function number Setting value Setting description Disable Enable...
Page 183: Wired Remote Controller
13-6. WIRED REMOTE CONTROLLER  M 13-6-1. MODEL: UTY-RNN Prohibited Dual remote controller setting Prohibited Switch 1 °F / °C switch Prohibited Memory backup setting * Do not use DIP Switch 2 „ „ SWITCH POSITION „ Wired remote controller Front case (back side) DIP Switch 2 DIP Switch 1...
Page 184 „ „ DIP SWITCH 1 SETTING „ SW2 setting ● Dual remote controller setting Set the remote controller SW2 according to the following table. Indoor unit (u...Factory setting) Secondary Primary unit Number Remote controller cable unit 1 2 3 of remote controller 1 (Normal) 2 (Dual)
Page 185: Model: Uty-RvnM
 M 13-6-2. MODEL: UTY-RVN Memory backup setting Switch Dual remote controller setting „ „ SWITCH POSITION „ Wired remote controller „ „ DIP SWITCH SETTING „ Memory backup setting Set to ON to use batteries for the memory backup. If batteries are not used, all of settings stored in memory will be deleted if there is a power failure.
Page 186: Simple Remote Controller
13-7. SIMPLE REMOTE CONTROLLER Prohibited Dual remote controller setting °F / °C switch Switch Prohibited Prohibited Prohibited „ „ SWITCH POSITION „ Simple remote controller DIP Switch - (01-182) -...
Page 187 „ „ DIP SWITCH SETTING „ SW2 setting ● Dual remote controller setting Set the remote controller SW2 according to the following table. (u...Factory setting) Indoor unit Secondary Primary unit Number unit Remote controller cable of remote 1 2 3 controller 1 (Normal) 2 (Dual)
Page 188: Optional Parts
OPTIONAL PARTS 14-1. CONTROLLER „ „ LINE UP Indoor units Type Model Wall mounted Compact Floor / Slim Duct Floor Cassette Ceiling UTY-RVN  M    *1  *2  *3    Wired Remote Controller UTY-RNN  M ...
Page 189: Others
14-2. OTHERS „ „ LINE UP Indoor units Type Model Wall mounted Compact Slim Floor / Floor Cassette Duct Ceiling Cassette grille  UTG-UF  D-W Air outlet shutter plate UTR-YDZB  Insulation kit for high UTZ-KXGC  humidity Fresh air intake kit UTZ-VXAA ...
Page 190 „ „ PARTS Cassette grille Air outlet shutter plate Model : UTG-UF  D-W Models : UTR-YDZB For Compact Cassette type For Compact Cassette type Insulation kit for high humidity Fresh air intake kit Model : UTZ-KXGC Model : UTZ-VXAA Insulation For Compact Cassette type For Compact Cassette type...
Page 191 „ „ PARTS Communication kit Communication kit Model : UTY-XCBXZ2 Model : UTY-TWBXF For Wall Mounted (LM) type For Wall mounted (LU) type Half concealed kit Model : UTR-STA For Floor type - (01-187) -...
Page 192: Installation Precautions
INSTALLATION PRECAUTIONS 15-1. INDOOR UNIT INSTALLATION PRECAUTIONS Note: The information listed below are general precautions. Some models also include items that do not apply. „ „ PLACES WHERE USE IS PROHIBITED •Places where there is danger of combustible gas leakage. •Places where sulfur gas, chlorine gas, acid, alkali, or other matter which effects equipment is generated •Places where there is a lot of oil splash and steam (kitchen, machinery room, etc.)
Page 193 [Installation precautions] Contents Countermeasures (Reference) When the When the indoor unit is installed where the inside of the ceiling Add heat insulating material to temperature and is 30°C (86°F) RH80% or greater, the dew point temperature the outside of the indoor unit humidity inside of the outer perimeter may become higher than the cabinet cabinet.
Page 194 [Installation precautions] Contents Countermeasures (Reference) When the When the Wall mounted type is installed in a bedroom, living Plan installation of a model installation room, or other quiet places, the sound of the refrigerant flow with external expansion valve. environment is may be sensed as noise and must be taken into account.
Page 195 2. OUTDOOR UNIT (2 ROOMS TYPE) MULTI TYPE : AOG14LAC2 AOG18LAC2 DTR_AO082E_07 2014.05.30...
Page 196 CONTENTS 2. OUTDOOR UNIT (2 ROOMS TYPE) SPECIFICATIONS ................... 02 - 01 DIMENSIONS ...................... 02 - 03 REFRIGERANT CIRCUIT ................02 - 05 WIRING DIAGRAMS ..................02 - 07 CAPACITY TABLE ..................02 - 09 5-1. COMBINATIONS ....................02 - 09 5-2.
Page 197: Outdoor Unit (2 Rooms Type)
SPECIFICATIONS The following performance is a value at standard combinations. „ „ STANDARD COMBINATION AO  G14LAC2 : AS  G07LMCA + AS  G07LMCA AO  G18LAC2 : AS  G09LMCA + AS  G09LMCA INVERTER MULTI MODELS Type HEAT PUMP TYPE Model name AOG14LAC2...
Page 198 Model name AOG14LAC2 AOG18LAC2 Cooling Energy efficiency class Heating (Average) 4.0 (35˚C) 5.0 (35˚C) Cooling Pdesign 3.8 (-10˚C) 4.2 (-10˚C) Heating (Average) SEER Cooling 6.70 6.60 kWh/kWh SCOP Heating (Average) 4.10 4.10 Annual energy kWh/a consumption QHE (Average) 1296 1434 Cooling Sound power level High...
Page 199: Dimensions
DIMENSIONS „ „ MODEL : AOG14L2, AOG18L2 (Unit : mm) - (02 - 03) -...
Page 200 „ „ INSTALLATION PLACE (Unit : mm) When there are obstacles at the When there are obstacles at the back back side. or front sides. When there are obstacles at the back, side(s), and top. When there are obstacles at the back, side with the installation of more than one unit.
Page 201: Refrigerant Circuit
REFRIGERANT CIRCUIT „ „ MODEL : AOG14L2 - (02 - 05) -...
Page 202 „ „ MODEL : AOG18L2 - (02 - 06) -...
Page 203: Wiring Diagrams
WIRING DIAGRAMS „ „ MODEL : AOG14L2 - (02 - 07) -...
Page 204 „ „ MODEL : AOG18L2 - (02 - 08) -...
Page 205: Capacity Table
CAPACITY TABLE 5-1. COMBINATIONS „ „ MODEL : AOG14L2 „ Cooling COOLING OPERATION Cooling Capacity Seasonal Data Combination Input Power Total Capacity Energy of Indoor Unit Room 1 Room 2 (min-max) Pdesign Efficiency (min-max) SEER Class 2.00 2.00 4.00 ( 1.4 - 4.4 ) 1.09 ( 0.35 - 1.40 ) 3.67 1.95...
Page 206 „ „ G18L2 MODEL: AO „ Cooling COOLING OPERATION Cooling Capacity Seasonal Data Combination Input Power Total Capacity Energy of Indoor Unit Room 1 Room 2 (min-max) Pdesign Efficiency (min-max) SEER Class 2.10 2.10 4.20 ( 1.7 - 5.2 ) 1.24 ( 0.35 - 1.68 ) 3.39 2.10...
Page 207: Cooling Capacity
5-2. COOLING CAPACITY This table is created using the maximum capacity. Note: 2 or more indoor units should be connected. „ „ MODEL : AOG14L2 „ Indoor unit : 7000Btu Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB...
Page 208 „ Indoor unit : 7000Btu + 9000Btu Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 3.39 0.86 3.78 0.87 3.91 0.88 4.16 0.88 4.29 0.89 4.55 0.90 4.68 0.90 4.81...
Page 209 Note: 2 or more indoor units should be connected. „ „ MODEL: AOG18L2 „ Indoor unit : 7000Btu Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 2.04 0.35 2.27 0.35...
Page 210 „ Indoor unit : 7000Btu + 7000Btu Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 3.65 0.57 4.07 0.58 4.21 0.58 4.49 0.59 4.62 0.59 4.90 0.60 5.04 0.60 5.18...
Page 211 „ Indoor unit : 9000Btu + 9000Btu Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 3.96 0.86 4.41 0.88 4.56 0.88 4.86 0.89 5.01 0.89 5.31 0.90 5.46 0.91 5.61...
Page 212: Heating Capacity
5-3. HEATING CAPACITY This table is created using the maximum capacity. Note: 2 or more indoor units should be connected. „ „ MODEL : AOG14L2 „ Indoor unit : 7000Btu Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 2.13 0.92 2.08 0.93...
Page 213 „ Indoor unit : 7000Btu + 9000Btu Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 3.08 1.34 3.01 1.37 2.94 1.40 2.86 1.42 2.79 1.45 3.57 1.44 3.49 1.47 3.40 1.49 3.32 1.52 3.23 1.55 3.99 1.52 3.90 1.55 3.80 1.58 3.71...
Page 214 Note: 2 or more indoor units should be connected. „ „ MODEL: A OG18L2 „ Indoor unit : 7000Btu Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 2.15 1.03 2.10 1.06 2.05 1.08 2.00 1.10 1.95 1.12 2.51 1.11 2.45 1.13 2.39...
Page 215 „ Indoor unit : 7000Btu + 7000Btu Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 3.58 1.65 3.50 1.69 3.41 1.72 3.33 1.75 3.24 1.79 4.20 1.72 4.10 1.76 4.00 1.79 3.90 1.83 3.80 1.86 4.55 1.69 4.44 1.72 4.34 1.76 4.23...
Page 216 „ Indoor unit : 9000Btu + 9000Btu Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 3.60 1.83 3.51 1.87 3.43 1.91 3.34 1.95 3.26 1.99 4.48 1.92 4.37 1.96 4.27 2.00 4.16 2.04 4.05 2.08 4.88 1.90 4.76 1.94 4.64 1.98 4.53...
Page 217: Capacity Compensation Rate For Pipe Length And Height Defference
CAPACITY COMPENSATION RATE FOR PIPE LENGTH AND HEIGHT DEFFERENCE „ „ G14L2) INDOOR UNIT : 7000Btu (AO Pipe length (m) COOLING 0.936 0.908 Û 1 0.969 0.943 0.915 Indoor unit is higher than 0.988 0.973 0.947 0.919 outdoor unit. 0.992 0.992 0.977 0.951...
Page 218 „ „ G18L2) INDOOR UNIT : 7000Btu (AO Pipe length (m) COOLING 0.940 0.914 Û 1 0.973 0.948 0.921 Indoor unit is higher than 0.988 0.977 0.952 0.925 outdoor unit. 0.992 0.992 0.981 0.956 0.929 Height difference H 1.000 1.000 0.989 0.963 0.936...
Page 219 „ „ G14L2) INDOOR UNIT : 9000Btu (AO Pipe length (m) COOLING 0.924 0.891 Û 1 0.962 0.931 0.899 Indoor unit is higher than 0.988 0.966 0.935 0.902 outdoor unit. 0.992 0.992 0.969 0.939 0.906 Height difference H 1.000 1.000 0.977 0.946 0.913...
Page 220 „ „ G18L2) INDOOR UNIT : 9000Btu (AO Pipe length (m) COOLING 0.928 0.898 Û 1 0.966 0.936 0.905 Indoor unit is higher than 0.988 0.969 0.940 0.909 outdoor unit. 0.992 0.992 0.973 0.943 0.912 Height difference H 1.000 1.000 0.981 0.951 0.920...
Page 221 „ „ G14L2) INDOOR UNIT : 12000Btu (AO Pipe length (m) COOLING 0.914 0.877 Û 1 0.959 0.921 0.884 Indoor unit is higher than 0.988 0.962 0.925 0.888 outdoor unit. 0.992 0.992 0.966 0.929 0.891 Height difference H 1.000 1.000 0.974 0.936 0.899...
Page 222 „ „ G18L2) INDOOR UNIT : 12000Btu (AO Pipe length (m) COOLING 0.919 0.883 Û 1 0.962 0.926 0.891 Indoor unit is higher than 0.988 0.966 0.930 0.894 outdoor unit. 0.992 0.992 0.970 0.934 0.898 Height difference H 1.000 1.000 0.978 0.941 0.905...
Page 223 „ „ G18L2) INDOOR UNIT : 14000Btu (AO Pipe length (m) COOLING 0.947 0.927 Û 1 0.974 0.955 0.935 Indoor unit is higher than 0.988 0.978 0.959 0.939 outdoor unit. 0.992 0.992 0.982 0.963 0.942 Height difference H 1.000 1.000 0.990 0.971 0.950...
Page 224: Additional Charge Calculation
ADDITIONAL CHARGE CALCULATION „ „ MODEL : AOG14L2 Refrigerant type R410A Refrigerant amount 1250 „ Refrigerant charge Total pipe length 20 or less 30 (MAX.) 10 g/m Additional charge G18L2 „ „ MODEL: AO Refrigerant type R410A Refrigerant amount 1300 „...
Page 225: Airflow
AIRFLOW „ „ MODEL : AOG14L2 „ Cooling Number of Airflow rotations (r.p.m.) 1850 1089 „ Heating Number of Airflow rotations (r.p.m.) 1850 1089  G18L2 „ „ MODEL: AO „ Cooling Number of Airflow rotations (r.p.m.) 2050 1206 „ Heating Number of Airflow...
Page 226: Operation Noise (Sound Pressure)
OPERATION NOISE (SOUND PRESSURE) 9-1. NOISE LEVEL CURVE „ „ MODEL : AOG14L2 „ „ Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000...
Page 227: Sound Level Check Point
9-2. SOUND LEVEL CHECK POINT - (02 - 31) -...
Page 228: Electric Characteristics
ELECTRIC CHARACTERISTICS Model name AOÛG14L2 AOÛG18L2 Voltage 230 ~ Power supply Frequency Max. operating current Starting current Main fuse (Circuit breaker) current *1) Wiring spec. Power cable *2) Limited wiring length *1) Wiring spec. Selected sample (Selected based on Japan Electrotechnical Standard and Codes Committee E0005) *2) Limited wiring length : This is the wiring length in case voltage descent is less than 2%.
Page 229: Safety Devices
SAFETY DEVICES Model Protection form AO Û G14L2 AO Û G18L2 15A 250V Current fuse (MAIN PCB) 10A 250V Circuit protection 3.15A 250V Current fuse 20A 250V (NEAR THE TERMINAL) OFF :100 °C Fan motor protection Thermal protector ON : 95 °C Thermal protection program OFF : 110°C...
Page 230: Installation Precautions
INSTALLATION PRECAUTIONS 12-1. OUTDOOR UNIT INSTALLATION PRECAUTIONS Note: The information listed below are general precautions. Some models also include items that do not apply. „ „ PLACES WHERE USE PROHIBITED • Places where there is the danger of combustible gas leakage •...
Page 231 3. OUTDOOR UNIT (3 ROOMS TYPE) MULTI TYPE : AOG18LAT3 AOG24LAT3 DTR_AO083E_07 2014.05.30...
Page 232 CONTENTS 3. OUTDOOR UNIT (3 ROOMS TYPE) SPECIFICATIONS ................... 03 - 01 DIMENSIONS ...................... 03 - 03 REFRIGERANT CIRCUIT ................03 - 04 WIRING DIAGRAMS ..................03 - 05 CAPACITY TABLE ..................03 - 06 5-1. COMBINATIONS ....................03 - 06 5-2.
Page 233: Outdoor Unit (3 Rooms Type)
SPECIFICATIONS The following performance is a value at standard combinations. STANDARD COMBINATION „ „ AO  G18LAT3 : AS  G07LMCA + AS  G07LMCA + AS  G07LMCA AO  G24LAT3 : AS  G07LMCA + AS  G07LMCA + AS  G09LMCA INVERTER MULTI MODELS Type HEAT PUMP TYPE...
Page 234 Model name AO  G18LAT3 AO  G24LAT3 Cooling Energy efficiency class Heating (Average) Cooling 5.4 (35˚C) 6.8 (35˚C) Pdesign Heating (Average) 5.0 (-10˚C) 5.2 (-10˚C) SEER Cooling 6.90 6.40 kWh/kWh SCOP Heating (Average) 4.30 4.20 Annual energy kWh/a consumption QHE (Average) 1627 1730...
Page 235: Dimensions
DIMENSIONS MODEL : AOG18L3, AOG24L3 „ „ (Unit : mm) Top view Front view Side view Bottom view Ø12 Drain cap mounting places Drain pipe mounting places INSTALLATION PLACE „ „ When there are obstacles at the When there are obstacles at When there are obstacles at the back or front sides.
Page 236: Refrigerant Circuit
REFRIGERANT CIRCUIT MODEL : AOG18L3, AOG24L3 „ „ - (03 - 04) -...
Page 237: Wiring Diagrams
WIRING DIAGRAMS MODEL : AOG18L3, AOG24L3 „ „ F4 FUSE T 5A 250V - (03 - 05) -...
Page 238: Capacity Table
CAPACITY TABLE 5-1. COMBINATIONS MODEL : AOG18L3 „ „ Cooling „ COOLING OPERATION Cooling Capacity Seasonal Data Combination Input Power Total Capacity Energy of indoor unit (min-max) Room 1 Room 2 Room 3 Pdesign (min-max) SEER Efficiency Class 2.30 2.30 4.60 ( 1.8 - 5.0 ) 1.22 ( 0.50 - 1.43 ) 3.77...
Page 239 MODEL: AO „ „ G24L3 Cooling „ COOLING OPERATION Cooling Capacity Seasonal Data Combination Input Power Total Capacity Energy of indoor unit (min-max) Room 1 Room 2 Room 3 Pdesign (min-max) SEER Efficiency Class 2.30 2.30 4.60 ( 1.8 - 5.0 ) 1.20 ( 0.50 - 1.40 ) 3.83 2.30...
Page 240 Heating „ HEATING OPERATION Heating Capacity Seasonal Data Combination Input Power Total Capacity Energy of indoor unit (min-max) Room 1 Room 2 Room 3 Pdesign (min-max) SCOP Efficiency Class 2.75 2.75 5.50 ( 2.0 - 6.1 ) 1.55 ( 0.52 - 1.93 ) 3.55 2.80 3.30...
Page 241: Cooling Capacity
5-2. COOLING CAPACITY This table is created using the maximum capacity. Note: 2 or more indoor units should be connected. MODEL : AOG18L3 „ „ Indoor unit : 7000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB...
Page 242 Indoor unit : 7000Btu + 7000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 3.69 2.84 0.49 4.11 2.86 0.49 4.25 3.11 0.50 4.53 3.12 0.50 4.67 3.37 0.50 4.95 3.36...
Page 243 Indoor unit : 9000Btu + 9000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 4.38 3.34 0.64 4.88 3.36 0.65 5.04 3.65 0.65 5.38 3.67 0.66 5.54 3.96 0.66 5.87 3.94...
Page 244 Indoor unit : 12000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 5.93 4.38 1.03 6.61 4.41 1.05 6.83 4.79 1.05 7.29 4.81 1.06 7.51 5.19 1.07 7.96 5.17...
Page 245 Indoor unit : 7000Btu + 7000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 6.36 4.94 1.16 7.09 4.97 1.18 7.33 5.40 1.18 7.81 5.43 1.20 8.05 5.86 1.20...
Page 246 Indoor unit : 9000Btu + 9000Btu + 9000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 5.67 4.53 0.91 6.32 4.56 0.92 6.53 4.95 0.93 6.96 4.97 0.94 7.18 5.37 0.94...
Page 247 Note: 2 or more indoor units should be connected. MODEL: AO „ „ G24L3 Indoor unit : 7000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 2.17 1.64 0.31 2.42 1.65...
Page 248 Note: 2 or more indoor units should be connected. Indoor unit : 18000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 4.17 3.04 0.68 4.64 3.06 0.69 4.80 3.32 0.69 5.12...
Page 249 Indoor unit : 7000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 5.12 3.89 0.78 5.71 3.92 0.79 5.90 4.25 0.79 6.29 4.27 0.80 6.49 4.61 0.80 6.88 4.59...
Page 250 Indoor unit : 9000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 5.45 4.14 0.86 6.07 4.17 0.88 6.28 4.53 0.88 6.69 4.55 0.89 6.90 4.91 0.89 7.31 4.89...
Page 251 Indoor unit : 12000Btu + 18000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 6.36 4.60 1.18 7.09 4.63 1.19 7.33 5.03 1.20 7.81 5.05 1.21 8.05 5.45 1.22 8.54 5.43...
Page 252 Indoor unit : 7000Btu + 7000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 6.77 5.20 1.18 7.54 5.23 1.19 7.79 5.69 1.20 8.31 5.71 1.21 8.56 6.16 1.22...
Page 253 Indoor unit : 7000Btu + 9000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 6.77 5.29 1.18 7.54 5.33 1.19 7.79 5.79 1.20 8.31 5.81 1.21 8.56 6.27 1.22...
Page 254 Indoor unit : 9000Btu + 9000Btu + 9000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 5.89 4.67 0.92 6.56 4.70 0.94 6.78 5.11 0.94 7.23 5.13 0.95 7.45 5.54 0.95...
Page 255 Indoor unit : 9000Btu + 12000Btu + 12000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 23°CWB (°CDB) 6.69 5.18 1.18 7.45 5.21 1.19 7.70 5.66 1.20 8.21 5.68 1.21 8.46 6.14 1.22...
Page 256: Heating Capacity
5-3. HEATING CAPACITY This table is created using the maximum capacity. Note: 2 or more indoor units should be connected. MODEL : AOG18L3 „ „ Indoor unit : 7000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 2.32 1.06 2.27 1.09...
Page 257 Indoor unit : 7000Btu + 7000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 3.78 1.83 3.69 1.87 3.60 1.91 3.51 1.95 3.42 1.99 4.26 1.95 4.16 1.99 4.06 2.03 3.96 2.06 3.86 2.06 4.80 1.91 4.68 1.95 4.57 1.99 4.45...
Page 258 Indoor unit : 9000Btu + 9000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 3.89 1.95 3.80 1.99 3.71 2.03 3.61 2.06 3.52 2.06 4.39 1.98 4.29 2.02 4.19 2.06 4.08 2.06 3.98 2.06 4.95 1.98 4.83 2.02 4.71 2.06 4.59...
Page 259 Indoor unit : 12000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 4.22 1.78 4.12 1.81 4.02 1.85 3.91 1.89 3.81 1.92 4.91 1.85 4.79 1.89 4.67 1.93 4.56 1.97 4.44 2.01 5.56 1.91 5.42 1.95 5.29 1.99 5.16...
Page 260 Indoor unit : 7000Btu + 7000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 4.79 1.82 4.67 1.86 4.56 1.90 4.45 1.93 4.33 1.97 5.54 1.90 5.41 1.94 5.28 1.98 5.15 2.02 5.02 2.06 6.22 1.96 6.07 2.00 5.92...
Page 261 Indoor unit : 9000Btu + 9000Btu + 9000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 4.73 1.80 4.62 1.84 4.50 1.88 4.39 1.91 4.28 1.95 5.47 1.88 5.34 1.92 5.21 1.96 5.08 2.00 4.95 2.04 6.14 1.94 5.99 1.98 5.85...
Page 262 Note: 2 or more indoor units should be connected. MODEL: AO „ „ G24L3 Indoor unit : 7000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 2.32 1.06 2.27 1.09 2.21 1.11 2.16 1.13 2.10 1.15 2.65 1.14 2.59 1.16 2.52...
Page 263 Note: 2 or more indoor units should be connected. Indoor unit : 18000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 4.68 2.30 4.57 2.35 4.46 2.40 4.35 2.45 4.24 2.50 5.32 2.39 5.20 2.44 5.07 2.49 4.94 2.54 4.82 2.59...
Page 264 Indoor unit : 7000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 4.90 2.67 4.78 2.72 4.66 2.78 4.55 2.78 4.43 2.78 5.75 2.67 5.61 2.72 5.47 2.78 5.34 2.78 5.20 2.78 6.51 2.67 6.35 2.72 6.20 2.78 6.04...
Page 265 Indoor unit : 9000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 4.91 2.63 4.79 2.69 4.67 2.74 4.56 2.78 4.44 2.78 5.76 2.67 5.63 2.72 5.49 2.78 5.35 2.78 5.21 2.78 6.53 2.67 6.37 2.72 6.22 2.78 6.06...
Page 266 Indoor unit : 12000Btu + 18000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 5.03 2.45 4.91 2.50 4.79 2.55 4.67 2.60 4.55 2.65 5.91 2.55 5.77 2.61 5.63 2.66 5.49 2.71 5.35 2.78 6.68 2.63 6.52 2.69 6.37 2.74 6.21...
Page 267 Indoor unit : 7000Btu + 7000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 5.31 2.22 5.19 2.27 5.06 2.31 4.93 2.36 4.81 2.41 6.18 2.34 6.04 2.38 5.89 2.43 5.74 2.48 5.59 2.53 7.00 2.42 6.84 2.47 6.67...
Page 268 Indoor unit : 7000Btu + 9000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 5.31 2.22 5.19 2.27 5.06 2.31 4.93 2.36 4.81 2.41 6.18 2.34 6.04 2.38 5.89 2.43 5.74 2.48 5.59 2.53 7.00 2.42 6.84 2.47 6.67...
Page 269 Indoor unit : 9000Btu + 9000Btu + 9000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 5.26 2.34 5.13 2.39 5.01 2.44 4.88 2.49 4.75 2.54 6.12 2.46 5.97 2.52 5.82 2.57 5.68 2.62 5.53 2.67 6.93 2.55 6.76 2.61 6.60...
Page 270 Indoor unit : 9000Btu + 12000Btu + 12000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 5.31 2.29 5.19 2.33 5.06 2.38 4.93 2.43 4.81 2.48 6.18 2.40 6.04 2.45 5.89 2.50 5.74 2.55 5.59 2.60 7.00 2.49 6.84 2.54 6.67...
Page 271: Capacity Compensation Rate For Pipe Length And Height Defference
CAPACITY COMPENSATION RATE FOR PIPE LENGTH AND HEIGHT DEFFERENCE INDOOR UNIT : 7000Btu (AO G18L3, AOG24L3) „ „ Pipe length (m) COOLING 0.956 0.942 0.928 1 0.977 0.963 0.950 0.936 Indoor unit is higher than 0.988 0.981 0.967 0.953 0.940 outdoor unit.
Page 272 INDOOR UNIT : 9000Btu (AO G18L3, AOG24L3) „ „ Pipe length (m) COOLING 0.956 0.942 0.928 1 0.977 0.963 0.950 0.936 Indoor unit is higher than 0.988 0.981 0.967 0.953 0.940 outdoor unit. 0.992 0.992 0.985 0.971 0.957 0.943 Height difference H 1.000 1.000...
Page 273 INDOOR UNIT : 12000Btu (AO G18L3, AOG24L3) „ „ Pipe length (m) COOLING 0.933 0.899 0.859 1 0.970 0.940 0.906 0.866 Indoor unit is higher than 0.988 0.974 0.944 0.910 0.869 outdoor unit. 0.992 0.992 0.978 0.948 0.913 0.873 Height difference H 1.000 1.000...
Page 274 INDOOR UNIT : 14000Btu (AO G18L3, AOG24L3) „ „ Pipe length (m) COOLING 0.969 0.962 0.953 1 0.982 0.977 0.970 0.961 Indoor unit is higher than 0.988 0.986 0.981 0.973 0.965 outdoor unit. 0.992 0.992 0.990 0.985 0.977 0.968 Height difference H 1.000 1.000...
Page 275 INDOOR UNIT : 18000Btu (AO „ „ G24L3) Pipe length (m) COOLING 0.977 0.968 0.953 1 0.986 0.985 0.976 0.960 Indoor unit is higher than 0.988 0.990 0.989 0.980 0.964 outdoor unit. 0.992 0.992 0.994 0.993 0.984 0.968 Height difference H 1.000 1.000 1.002...
Page 276: Additional Charge Calculation
ADDITIONAL CHARGE CALCULATION MODEL : AOG18L3, AOG24L3 „ „ Refrigerant type R410A Refrigerant amount 2200 Refrigerant charge „ Total pipe length 30 or less 50 (MAX.) 20g/m Additional charge - (03 - 44) -...
Page 277: Airflow
AIRFLOW MODEL : AOG18L3 „ „ Cooling „ Number of rotations Airflow (r.p.m.) 3050 1795 Heating „ Number of rotations Airflow (r.p.m.) 2750 1618 MODEL : AOG24L3 „ „ Cooling „ Number of rotations Airflow (r.p.m.) 3300 1942 Heating „ Number of rotations Airflow...
Page 278: Operation Noise (Sound Pressure)
OPERATION NOISE (SOUND PRESSURE) 9-1. NOISE LEVEL CURVE MODEL : AOG18L3 „ „ Cooling Heating „ „ NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000...
Page 279: Sound Level Check Point
9-2. SOUND LEVEL CHECK POINT - (03 - 47) -...
Page 280: Electric Characteristics
ELECTRIC CHARACTERISTICS Model name AOG18L3 AOG24L3 Voltage 230 ~ Power supply Frequency Max. operating current 12.5 Starting current Main fuse (Circuit breaker) current *1) Wiring spec. Power cable *2) Limited wiring length *1) Wiring spec. : Selected sample (Selected based on Japan Electrotechnical Standard and Codes Committee E0005) *2) Limited wiring length : This is the wiring length in case voltage descent is less than 2%.
Page 281: Safety Devices
SAFETY DEVICES Model Protection form AOG18L3 AOG24L3 5A 250V Current fuse (MAIN PCB) 3.15A 250V Current fuse Circuit protection 25A 250V (NEAR THE TERMINAL TO POWER SUPPLY) Current fuse 10A 250V (NEAR THE TERMINAL TO INDOOR UNIT) OFF :130±20°C Fan motor protection Thermal protector ON : 100±20°C OFF : 110°C...
Page 282: Installation Precautions
INSTALLATION PRECAUTIONS 12-1. OUTDOOR UNIT INSTALLATION PRECAUTIONS Note: The information listed below are general precautions. Some models also include items that do not apply. PLACES WHERE USE PROHIBITED „ „ • Places where there is the danger of combustible gas leakage •...
Page 283 4. OUTDOOR UNIT (4 ROOMS TYPE) MULTI TYPE : AOG30LAT4 DTR_AO078E_08 2014.05.30...
Page 284 CONTENTS 4. OUTDOOR UNIT (4 ROOMS TYPE) SPECIFICATIONS ................... 04 - 01 DIMENSIONS ...................... 04 - 03 REFRIGERANT CIRCUIT ................04 - 04 WIRING DIAGRAMS ..................04 - 05 CAPACITY TABLE ..................04 - 06 5-1. COMBINATIONS ....................04 - 06 5-2.
Page 285: Specifications
SPECIFICATIONS The following performance is a value at standard combinations. STANDARD COMBINATION „ „ AO  G30LAT4 : AS  G09LMCA + AS  G09LMCA + AS  G09LMCA + AS  G09LMCA INVERTER MULTI MODELS Type HEAT PUMP TYPE Model name AOG30LAT4 Power source...
Page 286 Model name AO  G30LAT4 Cooling Energy efficiency class Heating (Average) Cooling 8.0 (35˚C) Pdesign Heating (Average) 6.2 (-10˚C) SEER Cooling 6.20 kWh/kWh SCOP Heating (Average) 4.00 Annual energy consumption kWh/a QHE (Average) 2169 Cooling Sound power level High dB (A) Heating - (04 - 02) -...
Page 287: Dimensions
DIMENSIONS MODEL : AOG30L4 „ „ (Unit : mm) Top view Front view Side view Bottom view MOUNTING POSITION „ „ When there are obstacles at the When there are obstacles at When there are obstacles at the back or front sides. the back, side(s), and top.
Page 288: Refrigerant Circuit
REFRIGERANT CIRCUIT MODEL : AOG30L4 „ „ Outdoor unit CAPILLARY CONDENSER TUBE RECEIVER TANK OIL BACK CAPILLARY CONDENSER PRESSURE SWITCH(1) STRAINER PRESSURE SWITCH(2) DISTRIBUTOR MUFFLER EXPANSION EXPANSION EXPANSION EXPANSION VALVE VALVE VALVE VALVE STRAINER STRAINER STRAINER STRAINER CHARGING CHARGING CHARGING CHARGING VALVE VALVE...
Page 289: Wiring Diagrams
WIRING DIAGRAMS MODEL : AOG30L4 „ „ - (04 - 05) -...
Page 290: Capacity Table
CAPACITY TABLE 5-1. COMBINATIONS MODEL : AOG30L4 „ „ Cooling „ COOLING OPERATION Cooling Capacity Seasonal Data Combination Input Power Total Capacity Energy of indoor unit (min-max) Room 1 Room 2 Room 3 Room 4 Pdesign (min-max) SEER Efficiency Class 1.96 1.96 3.27...
Page 291 COOLING OPERATION Cooling Capacity Seasonal Data Combination Input Power Total Capacity Energy of indoor unit Room 1 Room 2 Room 3 Room 4 (min-max) Pdesign (min-max) SEER Efficiency Class 1.93 1.93 1.93 1.93 7.70 ( 1.6 - 9.6 ) 2.20 ( 0.68 - 3.41 ) 3.50 1.89 1.89...
Page 292 Heating „ HEATING OPERATION Heating Capacity Seasonal Data Combination Input Power Total Capacity Energy of indoor unit (min-max) Room 1 Room 2 Room 3 Room 4 Pdesign (min-max) SCOP Efficiency Class 2.42 2.42 4.15 9.00 ( 1.8 - 10.1 ) 2.66 ( 0.58 - 3.53 ) 3.38 2.27...
Page 293 HEATING OPERATION Heating Capacity Seasonal Data Combination Input Power Total Capacity Energy of indoor unit Room 1 Room 2 Room 3 Room 4 (min-max) Pdesign (min-max) SCOP Efficiency Class 2.35 2.35 2.35 2.35 9.40 ( 1.8 - 10.8 ) 2.43 ( 0.58 - 3.47 ) 3.87 2.27 2.27...
Page 294: Cooling Capacity
5-2. COOLING CAPACITY This table is created using the maximum capacity. Note: 3 or more indoor units should be connected. MODEL : AOG30L4 „ „ Indoor unit : 7000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB...
Page 295 Note:3 or more indoor units should be connected. Indoor unit : 18000Btu Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 4.21 3.26 0.75 4.69 3.29 0.76 4.85 3.57 0.76 5.17 3.58 0.77 5.33 3.87...
Page 296 Note: 3 or more indoor units should be connected. Indoor unit : 7000Btu + 12000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 4.58 3.50 0.84 5.11 3.52 0.86 5.28 3.83 0.86 5.63 3.84 0.87 5.80 4.15...
Page 297 Note: 3 or more indoor units should be connected. Indoor unit : 9000Btu + 9000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 4.06 3.23 0.76 4.53 3.25 0.77 4.68 3.53 0.77 4.99 3.55 0.78 5.14...
Page 298 Note: 3 or more indoor units should be connected. Indoor unit : 9000Btu + 24000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 7.07 5.54 1.26 7.88 5.58 1.28 8.15...
Page 299 Note: 3 or more indoor units should be connected. Indoor unit : 12000Btu + 24000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 7.47 5.77 1.43 8.32 5.80 1.45 8.61...
Page 300 Note: 3 or more indoor units should be connected. Indoor unit : 18000Btu + 18000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 7.63 6.14 1.43 8.50 6.18 1.45...
Page 301 Note: The total capacity of connected a indoor unit is up to 49000Btu from 27000Btu. Indoor unit : 7000Btu + 7000Btu + 7000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB...
Page 302 Note: The total capacity of connected a indoor unit is up to 49000Btu from 27000Btu. Indoor unit : 7000Btu + 7000Btu + 18000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB...
Page 303 Indoor unit : 7000Btu + 9000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 6.79 5.29 1.68 7.56 5.33 1.71 7.82 5.79 1.72 8.33 5.81 1.73 8.59 6.27...
Page 304 Indoor unit : 7000Btu + 12000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 6.92 5.63 1.27 7.71 5.66 1.29 7.97 6.15 1.30 8.49 6.18 1.31 8.76...
Page 305 Indoor unit : 7000Btu + 14000Btu + 18000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.17 6.60 1.62 9.10 6.64 1.64 9.41 7.22 1.65 10.03 7.25 1.67 10.34 7.82 1.67 10.96 7.80 1.69 11.27 7.78...
Page 306 Indoor unit : 9000Btu + 9000Btu + 9000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 5.55 4.75 1.32 6.19 4.78 1.34 6.40 5.19 1.34 6.82 5.21 1.36 7.03...
Page 307 Indoor unit : 9000Btu + 9000Btu + 24000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.82 7.09 1.82 9.82 7.13 1.85 10.16 7.75 1.86 10.83 7.78 1.88 11.16 8.40 1.88 11.83 8.37 1.90 12.17 8.35...
Page 308 Indoor unit : 9000Btu + 12000Btu + 24000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.77 7.18 1.93 9.77 7.23 1.96 10.10 7.85 1.97 10.77 7.88 1.99 11.10 8.51 2.00 11.77 8.48 2.02 12.10 8.46 2.03 12.44 9.03...
Page 309 Indoor unit : 9000Btu + 18000Btu + 18000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.77 7.36 1.94 9.77 7.41 1.97 10.10 8.05 1.98 10.77 8.08 2.00 11.10 8.72 2.01 11.77 8.69 2.03 12.10 8.68 2.04 12.44 9.26 2.05 8.58...
Page 310 Indoor unit : 12000Btu + 12000Btu + 24000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.75 7.17 2.01 9.74 7.22 2.05 10.08 7.84 2.06 10.74 7.88 2.08 11.07 8.50 2.09 11.74 8.47 2.11 12.07 8.45 2.12 12.40 9.02...
Page 311 Indoor unit : 7000Btu + 7000Btu + 7000Btu + 7000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 7.51 5.98 1.68 8.37 6.02 1.70 8.65 6.54 1.71 9.22 6.57 1.73...
Page 312 Indoor unit : 7000Btu + 7000Btu + 7000Btu + 18000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.25 6.98 1.60 9.19 7.02 1.63 9.50 7.63 1.64 10.13 7.66 1.65 10.44 8.27 1.66 11.07 8.24...
Page 313 Indoor unit : 7000Btu + 7000Btu + 9000Btu + 18000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.84 7.01 1.79 9.84 7.06 1.82 10.18 7.67 1.83 10.85 7.70 1.85 11.19 8.31 1.86 11.86 8.28...
Page 314 Indoor unit : 7000Btu + 7000Btu + 14000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.82 7.05 1.84 9.82 7.10 1.87 10.16 7.71 1.88 10.83 7.74 1.90 11.16 8.36 1.91 11.83 8.33...
Page 315 Indoor unit : 7000Btu + 9000Btu + 9000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.25 6.67 1.62 9.19 6.71 1.64 9.50 7.29 1.65 10.13 7.32 1.67 10.44 7.90 1.67 11.07 7.87...
Page 316 Indoor unit : 7000Btu + 9000Btu + 12000Btu + 18000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.76 7.45 1.96 9.76 7.50 1.99 10.09 8.15 2.00 10.76 8.18 2.02 11.09 8.83 2.03 11.76 8.80 2.05 12.09 8.79 2.06 12.42 9.37...
Page 317 Indoor unit : 7000Btu + 12000Btu + 12000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.77 7.18 1.94 9.77 7.23 1.97 10.10 7.85 1.98 10.77 7.88 2.00 11.10 8.51 2.01 11.77 8.48 2.03 12.10 8.46 2.04 12.44 9.03...
Page 318 Indoor unit : 9000Btu + 9000Btu + 9000Btu + 12000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.17 6.60 1.61 9.10 6.64 1.64 9.41 7.22 1.65 10.03 7.25 1.66 10.34 7.82 1.67 10.96 7.80...
Page 319 Indoor unit : 9000Btu + 9000Btu + 12000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.79 7.14 1.91 9.79 7.18 1.93 10.12 7.80 1.94 10.79 7.83 1.96 11.12 8.46 1.97 11.79 8.43...
Page 320 Indoor unit : 9000Btu + 12000Btu + 12000Btu + 14000Btu „ Indoor temperature °CDB 18°CDB 21°CDB 23°CDB 25°CDB 27°CDB 29°CDB 30°CDB 32°CDB °CWB 12°CWB 15°CWB 16°CWB 18°CWB 19°CWB 21°CWB 22°CWB 23°CWB (°CDB) 8.75 7.28 2.00 9.75 7.32 2.04 10.08 7.96 2.05 10.75 7.99 2.07 11.08 8.63 2.08 11.75 8.59 2.10 12.08 8.58...
Page 321: Heating Capacity
5-3. HEATING CAPACITY This table is created using the maximum capacity. Note: 3 or more indoor units should be connected. MODEL : AOG30L4 „ „ Indoor unit : 7000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 2.46 1.26 2.40 1.29...
Page 322 Note: 3 or more indoor units should be connected. Indoor unit : 18000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 5.29 2.48 5.17 2.53 5.04 2.58 4.91 2.63 4.79 2.69 5.74 2.43 5.60 2.48 5.47 2.53 5.33 2.58 5.19 2.64...
Page 323 Note: 3 or more indoor units should be connected. Indoor unit : 7000Btu + 12000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 5.44 2.47 5.31 2.52 5.18 2.57 5.05 2.62 4.92 2.68 5.90 2.42 5.76 2.47 5.62 2.52 5.48 2.57...
Page 324 Note: 3 or more indoor units should be connected. Indoor unit : 9000Btu + 9000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 5.52 2.52 5.39 2.57 5.25 2.63 5.12 2.68 4.99 2.73 5.98 2.47 5.84 2.52 5.70 2.58 5.56 2.63...
Page 325 Note: 3 or more indoor units should be connected. Indoor unit : 9000Btu + 24000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.74 3.19 7.55 3.26 7.37 3.33 7.19 3.39 7.00 3.46 8.55 3.29 8.34 3.36 8.14 3.43 7.94 3.50...
Page 326 Note: 3 or more indoor units should be connected. Indoor unit : 12000Btu + 24000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.74 3.19 7.55 3.26 7.37 3.33 7.19 3.39 7.00 3.46 8.55 3.29 8.34 3.36 8.14 3.43 7.94 3.50...
Page 327 Note: 3 or more indoor units should be connected. Indoor unit : 18000Btu + 18000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 8.09 3.19 7.90 3.26 7.71 3.33 7.51 3.39 7.32 3.46 8.94 3.29 8.72 3.36 8.51 3.43 8.30 3.50...
Page 328 Note: The total capacity of connected a indoor unit is up to 49000Btu from 27000Btu. Indoor unit : 7000Btu + 7000Btu + 7000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 6.65 2.67 6.49 2.73 6.34 2.78 6.18 2.84 6.02 2.89...
Page 329 Note: The total capacity of connected a indoor unit is up to 49000Btu from 27000Btu. Indoor unit : 7000Btu + 7000Btu + 18000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.88 3.21 7.69 3.28 7.50 3.34 7.32 3.41 7.13 3.48...
Page 330 Indoor unit : 7000Btu + 9000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.14 3.23 6.97 3.30 6.80 3.37 6.63 3.44 6.46 3.50 7.88 3.34 7.69 3.41 7.50 3.47 7.31 3.54 7.13 3.58 8.82 3.27 8.61 3.34 8.40...
Page 331 Indoor unit : 7000Btu + 12000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.25 3.17 7.07 3.24 6.90 3.31 6.73 3.37 6.56 3.44 8.00 3.27 7.81 3.34 7.62 3.41 7.43 3.48 7.24 3.55 9.08 3.34 8.87 3.41 8.65...
Page 332 Indoor unit : 7000Btu + 14000Btu + 18000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.73 3.08 7.54 3.14 7.36 3.20 7.18 3.27 6.99 3.33 8.69 3.21 8.49 3.28 8.28 3.34 8.07 3.41 7.87 3.48 10.02 3.38 9.78 3.45 9.55...
Page 333 Indoor unit : 9000Btu + 9000Btu + 9000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.14 3.23 6.97 3.30 6.80 3.37 6.63 3.44 6.46 3.50 7.88 3.34 7.69 3.41 7.50 3.47 7.31 3.54 7.13 3.58 8.82 3.27 8.61 3.34 8.40...
Page 334 Indoor unit : 9000Btu + 9000Btu + 24000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.86 3.12 7.68 3.18 7.49 3.25 7.30 3.31 7.11 3.38 8.85 3.26 8.63 3.32 8.42 3.39 8.21 3.46 8.00 3.53 10.20 3.43 9.95 3.50 9.71...
Page 335 Indoor unit : 9000Btu + 12000Btu + 24000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.93 3.10 7.74 3.17 7.55 3.23 7.36 3.30 7.17 3.36 8.92 3.24 8.71 3.31 8.50 3.37 8.28 3.44 8.07 3.51 10.28 3.41 10.04 3.48 9.79...
Page 336 Indoor unit : 9000Btu + 18000Btu + 18000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 8.06 3.08 7.87 3.14 7.68 3.20 7.49 3.27 7.30 3.33 9.07 3.21 8.86 3.28 8.64 3.34 8.42 3.41 8.21 3.48 10.46 3.38 10.21 3.45 9.96...
Page 337 Indoor unit : 12000Btu + 12000Btu + 24000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.93 3.09 7.74 3.16 7.55 3.22 7.36 3.29 7.17 3.35 8.92 3.23 8.71 3.30 8.50 3.36 8.28 3.43 8.07 3.50 10.28 3.40 10.04 3.47 9.79...
Page 338 Indoor unit : 7000Btu + 7000Btu + 7000Btu + 7000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.71 3.20 7.53 3.26 7.34 3.33 7.16 3.40 6.98 3.46 8.51 3.30 8.30 3.37 8.10 3.44 7.90 3.50 7.70 3.57 9.53 3.23 9.30...
Page 339 Indoor unit : 7000Btu + 7000Btu + 7000Btu + 18000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 8.06 3.11 7.87 3.17 7.68 3.24 7.49 3.30 7.30 3.37 9.07 3.25 8.86 3.31 8.64 3.38 8.42 3.45 8.21 3.52 10.46 3.42 10.21...
Page 340 Indoor unit : 7000Btu + 7000Btu + 9000Btu + 18000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 8.06 3.10 7.87 3.17 7.68 3.23 7.49 3.30 7.30 3.36 9.07 3.24 8.86 3.31 8.64 3.37 8.42 3.44 8.21 3.51 10.46 3.41 10.21...
Page 341 Indoor unit : 7000Btu + 7000Btu + 14000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.93 3.13 7.74 3.19 7.55 3.26 7.36 3.32 7.17 3.39 8.92 3.26 8.71 3.33 8.50 3.40 8.28 3.47 8.07 3.54 10.28 3.44 10.04...
Page 342 Indoor unit : 7000Btu + 9000Btu + 9000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.73 3.13 7.54 3.19 7.36 3.26 7.18 3.32 6.99 3.39 8.69 3.26 8.49 3.33 8.28 3.40 8.07 3.47 7.87 3.54 10.02 3.44 9.78...
Page 343 Indoor unit : 7000Btu + 9000Btu + 12000Btu + 18000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 8.06 3.13 7.87 3.19 7.68 3.26 7.49 3.32 7.30 3.39 9.07 3.26 8.86 3.33 8.64 3.40 8.42 3.47 8.21 3.54 10.46 3.44 10.21...
Page 344 Indoor unit : 7000Btu + 12000Btu + 12000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.86 3.13 7.68 3.19 7.49 3.26 7.30 3.32 7.11 3.39 8.85 3.26 8.63 3.33 8.42 3.40 8.21 3.47 8.00 3.54 10.20 3.44 9.95...
Page 345 Indoor unit : 9000Btu + 9000Btu + 9000Btu + 12000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.66 3.13 7.48 3.19 7.30 3.26 7.11 3.32 6.93 3.39 8.62 3.26 8.41 3.33 8.21 3.40 8.00 3.47 7.80 3.54 9.94 3.44 9.70...
Page 346 Indoor unit : 9000Btu + 9000Btu + 12000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.86 3.13 7.68 3.19 7.49 3.26 7.30 3.32 7.11 3.39 8.85 3.26 8.63 3.33 8.42 3.40 8.21 3.47 8.00 3.54 10.20 3.44 9.95...
Page 347 Indoor unit : 9000Btu + 12000Btu + 12000Btu + 14000Btu „ Indoor temperature 16°CDB 18°CDB 20°CDB 22°CDB 24°CDB (°CDB) (°CWB) 7.93 3.13 7.74 3.19 7.55 3.26 7.36 3.32 7.17 3.39 8.92 3.26 8.71 3.33 8.50 3.40 8.28 3.47 8.07 3.54 10.28 3.44 10.04...
Page 348: Capacity Compensation Rate For Pipe Length
CAPACITY COMPENSATION RATE FOR PIPE LENGTH AND HEIGHT DEFFERENCE INDOOR UNIT : 7000Btu (AO „ „ G30L4) Pipe length (m) COOLING 0.955 0.941 0.927  1 0.976 0.962 0.949 0.935 Indoor unit is higher than 0.988 0.980 0.966 0.952 0.939 outdoor unit.
Page 349 INDOOR UNIT : 9000Btu (AO „ „ G30L4) Pipe length (m) COOLING 0.956 0.942 0.928  1 0.977 0.963 0.950 0.936 Indoor unit is higher than 0.988 0.981 0.967 0.954 0.940 outdoor unit. 0.992 0.992 0.985 0.971 0.957 0.943 Height difference H 1.000 1.000...
Page 350 INDOOR UNIT : 12000Btu (AO  G30L4) „ „ Pipe length (m) COOLING 0.937 0.912 0.888  1 0.970 0.944 0.919 0.896 Indoor unit is higher than 0.988 0.974 0.948 0.923 0.899 outdoor unit. 0.992 0.992 0.978 0.952 0.927 0.903 Height difference H 1.000...
Page 351 INDOOR UNIT : 14000Btu (AO  G30L4) „ „ Pipe length (m) COOLING 0.955 0.937 0.922  1 0.974 0.962 0.945 0.930 Indoor unit is higher than 0.988 0.978 0.966 0.948 0.934 outdoor unit. 0.992 0.992 0.982 0.970 0.952 0.937 Height difference H 1.000...
Page 352 INDOOR UNIT : 18000Btu (AO „ „ G30L4) Pipe length (m) COOLING 0.968 0.961 0.954  1 0.982 0.976 0.969 0.962 Indoor unit is higher than 0.988 0.986 0.980 0.973 0.966 outdoor unit. 0.992 0.992 0.990 0.984 0.977 0.970 Height difference H 1.000 1.000...
Page 353 INDOOR UNIT : 24000Btu (AO „ „ G30L4) Pipe length (m) COOLING 0.978 0.969 0.953  1 0.986 0.986 0.977 0.961 Indoor unit is higher than 0.988 0.990 0.990 0.981 0.965 outdoor unit. 0.992 0.992 0.994 0.994 0.984 0.968 Height difference H 1.000 1.000...
Page 354: Additional Charge Calculation
ADDITIONAL CHARGE CALCULATION MODEL : AOG30L4 „ „ Refrigerant type R410A Refrigerant amount 3300 Refrigerant charge „ Total pipe length 50 or less 70 (MAX.) 25g/m Additional charge - (04 - 70) -...
Page 355: Airflow
AIRFLOW MODEL : AOG30L4 „ „ Cooling „ Number of rotations Airflow (r.p.m.) 3500 2060 Heating „ Number of rotations Airflow (r.p.m.) 3300 1942 - (04 - 71) -...
Page 356: Operation Noise (Sound Pressure)
OPERATION NOISE (SOUND PRESSURE) 9-1. NOISE LEVEL CURVE MODEL : AOG30L4 „ „ Cooling Heating „ „ NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000...
Page 357: Sound Level Check Point
9-2. SOUND LEVEL CHECK POINT - (04 - 73) -...
Page 358: Electric Characteristics
ELECTRIC CHARACTERISTICS Model name AOG30L4 Voltage 230 ~ Power supply Frequency Max. operating current 15.7 Starting current 10.5 Main fuse (Circuit breaker) current *1) Wiring spec. Power cable *2) Limited wiring length *1) Wiring spec. Selected sample (Selected based on Japan Electrotechnical Standard and Codes Committee E0005) *2) Limited wiring length : This is the wiring length in case voltage descent is less than 2%.
Page 359: Safety Devices
SAFETY DEVICES Model Protection form AO  G30L4 5A 250V Current fuse (MAIN PCB) 3.15A 250V Current fuse Circuit protection (NEAR THE TERMINAL TO 25A 250V POWER SUPPLY) Current fuse (NEAR THE TERMINAL TO 15A 250V INDOOR UNIT) OFF :130±20°C Fan motor protection Thermal protector ON : 100±20°C...
Page 360: Installation Precautions
INSTALLATION PRECAUTIONS 12-1. OUTDOOR UNIT INSTALLATION PRECAUTIONS Note: The information listed below are general precautions. Some models also include items that do not apply. PLACES WHERE USE PROHIBITED „ „ • Places where there is the danger of combustible gas leakage •...

Fujitsu AU*G07LVLA Technical Manual

Table of Contents

1 Features

2 Remote Controller

4 Dimensions

5 Wiring Diagrams

6 Air Velocity and Temperature Distributions

 G09Llta (Utd-Gxsa-W) &#X84; &#X84; Model : Ar

7 Fan Performance Curve

8 Airflow

9 Noise Level Curve

10 Electrical Characteristics

11 Safety Devices

12 External Input & Output

13 Function Settings

14 Optional Parts

15 Installation Precautions

2. Outdoor Unit (2 Rooms Type)

3. Outdoor Unit (3 Rooms Type)

4. Outdoor Unit (4 Rooms Type)

1 Specifications

2 Dimensions

3 Refrigerant Circuit

4 Wiring Diagrams

5 Capacity Table

6 Capacity Compensation Rate for Pipe Length

7 Additional Charge Calculation

8 Airflow

9 Operation Noise (Sound Pressure)

10 Electric Characteristics

11 Safety Devices

12 Installation Precautions

Quick Links

AIR CONDITIONER

Chapters

Related Manuals for Fujitsu AU*G07LVLA

Summary of Contents for Fujitsu AU*G07LVLA
