Summary of Contents for Salus VS30W

  • Page 1 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:38 Digital Thermostat Models: VS30W and VS30B I N S TA L L E R / U S E R M A N U A L...
  • Page 2 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:38 Contents Contents Icons used in this manual: For latest PDF installation guide please go to Box Contents www.salus-controls.com Safety Introduction Product Compliance Installation Important info User Guide Parameter Settings...
  • Page 3 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:38 Product Compliance & Safety Information INTRODUCTION Safety Information Use in accordance with the regulations. Thank you for purchasing the room thermostat The VS30 is to be used for room VS30.
  • Page 4 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:38 Product Compliance & Safety Information Sources of danger Installer parameter settings The thermostat must be disconnected from mains The VS30 is equipped with installer parameter section. supply before removing the cover.
  • Page 5 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:38 Installation – Terminal Connections Understanding your terminal connections Power Terminals 230 Vac Used for supplying power to the Rear of VS30 unit and switched output. NSB (Night Set Back) Connection Used for a 230V output to other thermostat.
  • Page 6 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:38 Installation – Thermostat Mounting Gently remove front housing. Gently remove front housing. Wall Mounting For wall mounting, mark and mount the rear case to the wall. The VS30 is suitable for wall boxes...
  • Page 7 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:38 Installation – Thermostat Mounting Mounting position and installation To ensure trouble free operation and efficient control, the VS30 room thermostat is best positioned in a draft free area, and at 130cm from the floor. Do not position the thermostat near any heat source, behind curtains, direct sunlight or an area of high humidity.
  • Page 8 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:38 Installation – Terminal Connections Sensor Terminal (optional) Sensor Terminal (optional) Night set back output Optional SALUS Sensor Load (Thermal Actuators) NSB for other Live 230V AC 50Hz thermostats...
  • Page 9 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:38 Installation – Terminal Connections Check that the wiring is completed for: Power Terminals NSB (Night Set Back) Connection Sensor Terminals (if applicable) You are ready to secure the rear housing to the wall box...
  • Page 10 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 Installation – Thermostat Mounting Fit the front housing to the rear housing Ensure the pin connections are aligned Align the front housing Lightly press until you hear a positive click.
  • Page 11 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 Installation – LCD Graphics VS30W and VS30B Installer Manual...
  • Page 12 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 Installation – LCD Graphics ICON FUNCTION BOX means to select the mode e.g. means the current setpoint is Hi temp, means the Hi temp is not selected. Sunny: Hi comfortable temperature.
  • Page 13 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 Installation – LCD Graphics ICON FUNCTION Heat indicator: Indicates heat is required. Cool mode indicator: Indicates cooling is required (if applicable). Temperature indicator: Display the room temperature. Display the set-temp.
  • Page 14 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 Installation – User Interface ICON FUNCTION Floor sensor probe indicator: Show only when Air + Floor sensor is connected. Setting indicator: Indicates the unit is in setting mode when program setting.
  • Page 15 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 Installation – User Interface FUNCTION 1. Increase or decrease setpoint temperature. 2. Increase or decrease Day, Clock, Timer, Party and Holiday. 3. Select installer parameter value. 1. Mode selection.
  • Page 16 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 Installation – First Power Up VS30W and VS30B Installer Manual...
  • Page 17 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 Installation - Graphics Key Press once Press x amount of times Hold for five seconds Flashing ON first power up. Proceed to page 19 Short press to save and...
  • Page 18 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Setting time and date VS30W and VS30B Installer Manual...
  • Page 19 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Setting time and date Use left to select 12 hour and right to select 24 hour. Hour Minutes Adjust the time using the up or down arrow key.
  • Page 20 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide – Understanding Temperature Levels - Heating Highest Temperature typically used for early morning and early evening. Typically 20 Deg C Mid Temperature typically used for times of day when you are active around the home.
  • Page 21 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Understanding Temperature Levels - Cooling See device setting D18, section on page 44 Occupied Temperature. Typically 22ºC Unoccupied Temperature Typically 40ºC This avoids cooling being active when the property is unoccupied.
  • Page 22 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Default Heating Schedule .1 Monday to Friday 12.00 6.00 9.00 16.00 23.00 Saturday to Sunday 12.00 7.00 23.00 VS30W and VS30B Installer Manual...
  • Page 23 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Optional Heating Schedule .2 Monday to Friday 12.00 6.00 22.30 Saturday to Sunday 12.00 7.00 23.00 VS30W and VS30B Installer Manual...
  • Page 24 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Optional Heating Schedule .3 Monday to Friday 12.00 5.00 8.00 14.00 22.00 Saturday to Sunday 12.00 7.30 22.30 VS30W and VS30B Installer Manual...
  • Page 25 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Optional Heating Schedule .4 Monday to Friday 12.00 6.00 9.00 15.00 22.30 Saturday to Sunday 12.00 7.30 23.00 VS30W and VS30B Installer Manual...
  • Page 26 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Optional Heating Schedule .5 Monday to Friday 12.00 6.00 10.00 16.00 23.00 Saturday to Sunday 12.00 7.30 23.30 VS30W and VS30B Installer Manual...
  • Page 27 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Default Cooling Schedule .1 Monday to Friday 12.00 6.00 9.00 16.00 23.00 Saturday to Sunday 12.00 7.00 23.00 VS30W and VS30B Installer Manual...
  • Page 28 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Optional Cooling Schedule .2 Monday to Friday 12.00 6.00 22.30 Saturday to Sunday 12.00 7.00 23.00 VS30W and VS30B Installer Manual...
  • Page 29 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Optional Cooling Schedule .3 Monday to Friday 12.00 5.00 8.00 14.00 22.00 Saturday to Sunday 12.00 7.30 22.30 VS30W and VS30B Installer Manual...
  • Page 30 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Optional Cooling Schedule .4 Monday to Friday 12.00 6.00 9.00 15.00 22.30 Saturday to Sunday 12.00 7.30 23.00 VS30W and VS30B Installer Manual...
  • Page 31 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:39 User Guide - Optional Cooling Schedule .5 Monday to Friday 12.00 6.00 10.00 16.00 23.00 Saturday to Sunday 12.00 7.30 23.30 VS30W and VS30B Installer Manual...
  • Page 32 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:40 User Guide – Setting the Temperature Schedule Use right and left to select the day of the programs. 7 Days Individual VS30W and VS30B Installer Manual...
  • Page 33 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:40 User Guide – Setting the Temperature Schedule Adjust the time using the up or down arrow key. Use right and left to select the Hi/Mid or low temp.
  • Page 34 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:40 User Guide – Setting the Temperature Schedule Repeat through to program 4. If you require a 5th or 6th program enter a time and select your temperature To remove a program out set the time to --:--.
  • Page 35 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:40 User Guide - Temporary Override Use the up or down arrow key to view your program set temperature. Temporary override allows you to increase the temperature or decrease it to the desired setting until it reverts back on the next program time.
  • Page 36 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:40 User Guide - Temporary Override Confirm the temporary set temperature. To cancel temporary override press See below. VS30W and VS30B Installer Manual...
  • Page 37 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:40 User Guide - Permanent Override Setting permanent low temperature Move from Use the up or down arrow key to view your set temperature. See page 35. To cancel permanent override select...
  • Page 38 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:40 User Guide - Party Mode Use the right arrow to select The party mode is an the party mode. option that enables temperature for a period of time.
  • Page 39 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:40 User Guide - Holiday Mode Use the right arrow to select the holiday mode. Use the up arrow to select how many days to be off for. Press tick to confirm and it will start the holiday count down.
  • Page 40 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:40 User Guide - Frost Protection Use the right arrow to select the frost mode. Use the up arrow to select the frost protection temperature. Press tick to confirm...
  • Page 41 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:41 Installation - Entering Device Menu Press all three buttons If you need to simultaneously. change device parameters follow the steps below. Must only be entered by the installer.
  • Page 42 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:41 Installation - Device Parameters FUNCTION SYSTEM SETTING DEFINITION DEFAULT Heating Pulse Width Modulation Control On-Off 0.5 Deg C +/- 0.25 Deg C On-Off 1.0 Deg C +/- 0.5 Deg C Room -3.0 to 3.0...
  • Page 43 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:41 Installation - Device Parameters continued FUNCTION SYSTEM SETTING DEFINITION DEFAULT Frost Set point 5-17 Deg C Required Temperature for frost 5 Deg Temperature protection and holiday mode Hour Format...
  • Page 44 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:41 Installation - Device Parameters continued FUNCTION SYSTEM SETTING DEFINITION DEFAULT Preset program Select 1-5 of the default programs selection Heat/Cool mode 0: heating mode 0 or 1 selection...
  • Page 45 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:41 Installation - Technical Detail Model VS30W/ VS30B Type Electronic programmable room thermostat, digital room thermostat designed for 230V AC applications Programming Modes User selectable for 5/2, ALL and Individual day options...
  • Page 46 VS30W - VS30B Installer - User Manual 014_Layout 1 16/07/2014 14:41 Installation - Notes VS30W and VS30B Installer Manual...
  • Page 47 SALUS Controls warrants that this product will be free from any defect in materials or workmanship, and shall perform in accordance with its specification, for a period of five years from the date of installation. SALUS Controls sole liability for breach of this warranty will be (at its option) to repair or replace the defective product.
  • Page 48 SALUS Controls is a member of the Computime Group Maintaining a policy of continuous product development SALUS Controls plc reserve the right to change specification, design and materials of products listed in this brochure without prior notice. Issue Date: April 2014...
