R button
Press to dial an outside telephone number when the unit is connected through
a switchboard (PBX).
LCD display
Displays messages and prompts during operation. Displays selections, text,
and names when registering information.
FINE/STANDARD button
Use to set resolution for the type of document you want to send.
MANUAL FEED lamp
Flashes to alert you to add paper or other media to the manual feed tray.
Lights when there is print media in the manual feed tray.
One-touch speed dial/Special Function buttons
Use these buttons for one-touch speed dialling and to perform special
operations.
Numeric buttons
Use the numeric buttons to enter phone numbers when dialling. These
buttons also enter text, numbers, and symbols when registering names and
numbers.
(REDIAL) button
Press to dial the previous number dialled with the numeric buttons.
CODED DIAL button
Press this button and then press a 2-digit number code under which you have
previously registered a facsimile or telephone number for coded speed
dialling.
(HOOK) button
Press to dial with the numeric buttons when using manual sending.
(START/COPY) button
Press to start sending, receiving, copying, and other operations.
ANS HOOK UP/MANUAL button
When both lamps are off, the fax is set for automatic receiving. Press and light
ANS HOOK UP when an answering machine is connected. Press and light
MANUAL for manual document receiving.
(STOP) button
Press to cancel sending, receiving, or registering data, or to cancel any other
operation.
2-12
Getting Started
Chapter 2
