Specifications - Toshiba RAV-182B-PE Service Manual

ITEM
Cooling capacity
Power source
Power consumption
Power Factor
Running current
Starting current
Indoor unit
(High/Med./Low)
Operating
noise (SPL)
Outdoor unit
Name of refrigerant
Regrigerant Charge volume
Add. volume (20-30m)
Refrigerant control
Large side size
Coupler style
Smaller side size
Inter- Coupler style
connection
Standard length
pipe
Maximum length
(of one way) * 1
Max. height difference
if indoor unit higher
Outdoor unit higher
Condensate drain pipe diameter
INDOOR UNIT
Model
Appearance colour
Height
Dimensions Width
Depth
Net Weight
Heat exchanger type
Indoor fan type
Air flow volume
Fan motor output
External Static STANDARD
Pressure
MAX. MOTOR
CEILING PANEL Model
Appearance colour
Height
Dimensions Width
Depth
Net Weight
Air filter
OUTDOOR UNIT
Model
Appearance colour
Height
Dimensions Width
Depth
Net Weight
Heat exchanger type
Outdoor fan type
Air flow volume
Fan motor output
Model
Compressor
Output
Protective device
Flexible duct
Blowout unit
Suction canvas
Long-life filter kit
Built-in duct filter kit
Note 1: These mean actual length.
Tel: 01823 665660
Heronhill - for all your Toshiba requirements

1. SPECIFICATIONS

MODEL
RAV-182B-PE
kW 5.0
Phase 1
V 220 – 240
Hz 50
COOLING
kW 2.24
% 92
A 10.6
A 60
dB(A) 42/39/36
dB(A) 52
R-22
kg 1.45
g/m 35
Capillary tube
mm ø 12.7
Flare
mm ø 6.4
Flare
m 7.5
m 30
m 15
m 30
mm ø 32 (OD)
RAV-182B-PE
mm 345
mm 700
mm 800
kg 39
Finned tube
Multi-blade fan
3
m /h 840
W 60
mmAq 4
mmAq 10
RBC-B161PE(W)
Silky mist (Munsell 1Y8.9/0.5)
mm 40
mm 780
mm 500
kg 4
Washable
RAV-182A-PE
Bronze white (Munsell 6Y7.5/1)
mm 740
mm 880
mm 310
kg 58
Finned tube
Propeller fan
3
m /h 2700
W 39
PH250X3-4LS
kW 2.0
Fuse, Crankcase heater,
Overload relay
RBC-FD202E
RBC-BU1E(W)
RBC-CA161BE
RBC-LK161BE
RBC-DK161BE-P
- 4 -
www.heronhill.co.uk
RAV-242-PE
6.7
1
220 – 240
50
COOLING
2.9
93
13.5
80
43/40/37
53
R-22
1.65
45
Capillary tube
ø 15.9
Flare
ø 6.4
Flare
7.5
30
15
30
ø 32 (OD)
RAV-242B-PE
Black (Zinc galvanized steel + Thermal insulation)
345
1000
800
53
Finned tube
Multi-blade fan
1140
100
4
10
RBC-B260PE(W)
Silky mist (Munsell 1Y8.9/0.5)
40
1080
500
6
Washable
RAV-242A-PE
Bronze white (Munsell 6Y7.5/1)
790
880
310
64
Finned tube
Propeller fan
3000
63
PH330X3-4MS
2.2
Inner overload relay, Fuse,
Crankcase heater
RBC-DK261BE-P
RAV-242B-PE
6.7
3
380 – 415
50
COOLING
2.8
86
4.7
25
43/40/37
53
R-22
1.65
45
Capillary tube
ø 15.9
Flare
ø 6.4
Flare
7.5
30
15
30
ø 32 (OD)
RAV-242B-PE
345
1000
800
53
Finned tube
Multi-blade fan
1140
100
4
10
RBC-B260PE(W)
Silky mist (Munsell 1Y8.9/0.5)
40
1080
500
6
Washable
RAV-242A8-PE
Bronze white (Munsell 6Y7.5/1)
790
880
310
64
Finned tube
Propeller fan
3000
63
YH330X3-MS
2.2
Overload relay, Fuse,
Crankcase heater
RBC-FD202E
RBC-BU1E(W)
RBC-CA260BE
RBC-LK260BE
Fax: 01823 665807
