Heronhill - for all your Toshiba requirements
FILE NO. A90-0031
TOSHIBA
SERVICE MANUAL
AIR-CONDITIONER
SPLIT TYPE, HEAT PUMP
COOLING ONLY
2 WAY CASSETTE TYPE
RAV-104TUH-1-PE
RAV-134TUH-1-PE/RAV-134AH-PE
RAV-164TUH-1-PE/RAV-164AH-PE
RAV-134TU-1-PE/RAV-134A-PE
RAV-164TU-1-PE/RAV-164A-PE
Printed in UK NOVEMBER 2000
Tel: 01823 665660
www.heronhill.co.uk
Fax: 01823 665807
Advertisement
Related Manuals for Toshiba RAV-104TUH-1-PE
Summary of Contents for Toshiba RAV-104TUH-1-PE
- Page 1 Heronhill - for all your Toshiba requirements FILE NO. A90-0031 TOSHIBA SERVICE MANUAL AIR-CONDITIONER SPLIT TYPE, HEAT PUMP COOLING ONLY 2 WAY CASSETTE TYPE RAV-104TUH-1-PE RAV-134TUH-1-PE/RAV-134AH-PE RAV-164TUH-1-PE/RAV-164AH-PE RAV-134TU-1-PE/RAV-134A-PE RAV-164TU-1-PE/RAV-164A-PE Printed in UK NOVEMBER 2000 Tel: 01823 665660 www.heronhill.co.uk Fax: 01823 665807...
-
Page 2: Table Of Contents
Heronhill - for all your Toshiba requirements CONTENTS SPECIFICATIONS CONSTRUCTIONS VIEWS WIRING DIAGRAMS SPECIFICATIONS OF ELECTRICAL PARTS REFRIGERANT PIPING DIAGRAMS PERFORMANCE CHARACTERISTICS EXPLODED VIEWS AND PARTS LISTS SUMMARY The units referred to within this Manual conform with the protection requirements of Directives 89/336/EEC Electromagnetic Compatibility and 73/23/EEC Low Voltage. -
Page 3: Specifications
Heronhill - for all your Toshiba requirements 1. SPECIFICATIONS Item Model RAV-104TUH-1-PE Cooling capacity Heating capacity Phase 220-240 Power source 0.07 Power consumption Power factor 0.33 Running current Starting current 40/36/34 Operating noise (SPL) Indoor Unit (High/Med/Low) dB(A) Refrigerant Name of Refrigerant... - Page 4 Heronhill - for all your Toshiba requirements 1. SPECIFICATIONS RAV-134TUH-1-PE RAV-164TUH-1-PE Item Model Cooling capacity Heating capacity Phase Power source 220-240 220-240 COOLING HEATING COOLING HEATING Power consumption 2.15 Power factor 10.4 Running current 10.6 10.7 Starting current Operating noise...
- Page 5 Heronhill - for all your Toshiba requirements 1. SPECIFICATIONS Item Model RAV-134TU-1-PE RAV-164TU-1-PE Cooling capacity Phase Power source 220-240 220-240 COOLING COOLING Power consumption Power factor Running current 10.6 Starting current Operating noise 40/36/34 41/37/35 Indoor Unit (High, Med, Low)
-
Page 6: Constructions Views
Heronhill - for all your Toshiba requirements 2. CONSTRUCTION VIEWS 2.1 Indoor Unit RAV-104TUH-1-PE RAV-134TUH-1-PE RAV-164TUH-1-PE RAV-134TU-1-PE RAV-164TU-1-PE Refrigerant piping joint Drain pipe joint (Liquid ø6.4) (outer ø25.5) Hanger bolt (4-M10) Refrigerant piping joint (Gas ø12.7) Wiring connection Panel outer dimension 1050... - Page 7 Heronhill - for all your Toshiba requirements 2. CONSTRUCTION VIEWS 2.2 Outdoor Unit RAV-134AH-PE RAV-164AH-PE RAV-134A-PE RAV-164A-PE Knock-out hole for drain (2-20x60 slots) Hole for drain (2xø19 hole) Refrigerant pipe connection (Gas ø12.7) Refrigerant pipe connection (Liquid ø6.4) Earth screw (M6)
-
Page 8: Wiring Diagrams
Heronhill - for all your Toshiba requirements 3. WIRING DIAGRAMS 3.1 RAV-104TUH-1-PE RAV-134TUH-1-PE RAV-164TUH-1-PE CN05 CN04 (TC) (TA) CN15 (LAN) CN07 (FAN) RY04 CN02 RY03 CN12 RY02 RY01 CN01 (output) (TRANS) CN21 CN09 (WHI) (LOUVER) Interface RY07 RY01 RY06 CN03... - Page 9 Heronhill - for all your Toshiba requirements 3. WIRING DIAGRAMS 3.2 RAV-134TU-1-PE RAV-164TU-1-PE CN04 CN05 (TA) (TC) CN07 (FAN) RY02 CN02 RY03 CN12 CN01 (TRANS) RY01 CN09 (output) (WHI) (LOUVER) Interface RY07 RY14 RY01 RY11 CN11 CN10 (L1) (N) (FLOAT)
- Page 10 Heronhill - for all your Toshiba requirements 3. WIRING DIAGRAMS 3.3 RAV-134AH-PE RAV-164AH-PE Indoor unit Outdoor unit Earth Screw Earth RY05 Wave Control RY07 Circuit 26HD 20SF 20SR Power Supply 220/240V~50Hz Shows terminal block and figures show terminal numbers. Broken lines show wiring at site.
- Page 11 Heronhill - for all your Toshiba requirements 3. WIRING DIAGRAMS 3.4 RAV-134A-PE RAV-164A-PE Indoor unit Outdoor unit Earth screw RC c 6 3 F 6 3 F RC o Surge Absorber Power Supply 220/240V~50Hz Shows terminal block and figures show terminal numbers. Broken lines show wiring at site.
-
Page 12: Specifications Of Electrical Parts
Heronhill - for all your Toshiba requirements 4. SPECIFICATIONS OF ELECTRICAL PARTS RAV-104TUH-1-PE PARTS NAME TYPE SPECIFICATIONS Output (rated) 7W, 4 pole, 230V, 1 Phase, 50Hz Indoor unit fan motor (x2) PAF-230-7-4 Running capacitor for EVM45M504UF AC 450V, 0.5µF indoor fan motor (x2) - Page 13 Heronhill - for all your Toshiba requirements 4. SPECIFICATIONS OF ELECTRICAL PARTS RAV-134TU-1-PE PARTS NAME TYPE SPECIFICATIONS Indoor unit fan motor (x2) PAF-230-7-4 Output (rated) 7W, 4 pole, 230V, 1 Phase, 50Hz Running capacitor for EEP2H105HQA105 AC 500V, 1.0µF indoor fan motor (x2)
- Page 14 Heronhill - for all your Toshiba requirements 4. SPECIFICATIONS OF ELECTRICAL PARTS RAV-134AH-PE PARTS NAME TYPE SPECIFICATIONS Compressor PG330X3F-4LS Output (rated) 1.5kW, 2 pole, 220/240V, 1 Phase, 50Hz Outdoor unit fan motor Output (rated) 39W, 6 pole, 230V, 1 Phase, 50Hz...
- Page 15 Heronhill - for all your Toshiba requirements 4. SPECIFICATIONS OF ELECTRICAL PARTS RAV-164AH-PE PARTS NAME TYPE SPECIFICATIONS Compressor PG350X3F-4LS Output (rated) 1.5kW, 2 pole, 220/240V, 1 Phase, 50Hz Outdoor unit fan motor Output (rated) 39W, 6 pole, 230V, 1 Phase, 50Hz...
- Page 16 Heronhill - for all your Toshiba requirements 4. SPECIFICATIONS OF ELECTRICAL PARTS RAV-134A-PE PARTS NAME TYPE SPECIFICATIONS Compressor PG330X3F-4LS Output (rated) 1.5kW, 2 pole, 220/240V, 1 Phase, 50Hz Outdoor unit fan motor SMF-230-39N-3 Output (rated) 39W, 6 pole, 230V, 1 Phase, 50Hz...
-
Page 17: Refrigerant Piping Diagrams
Heronhill - for all your Toshiba requirements 5. REFRIGERANT PIPING DIAGRAMS Indoor Unit RAV-104TUH-1-PE Cooling Heating Indoor unit Heat exchanger Distributor strainer Strainer capillary tube TC Sensor Refrigerant pipe (Liquid) Refrigerant pipe (Gas) ø6.4mm (1/4") ø12.7mm (1/2") Tel: 01823 665660 www.heronhill.co.uk... - Page 18 Heronhill - for all your Toshiba requirements 5. REFRIGERANT PIPING DIAGRAMS 5.1 Indoor Unit Outdoor Unit RAV-134TUH-1-PE RAV-134AH-PE Cooling Heating Indoor unit Heat exchanger Distributor strainer Strainer capillary tube TC Sensor Refrigerant pipe (Gas) Refrigerant pipe (Liquid) ø6.4mm (1/4") ø12.7mm (1/2")
- Page 19 Heronhill - for all your Toshiba requirements 5. REFRIGERANT PIPING DIAGRAMS 5.2 Indoor Unit Outdoor Unit RAV-164TUH-1-PE RAV-164AH-PE Cooling Heating Indoor unit Heat exchanger Distributor strainer Strainer capillary tube TC Sensor Refrigerant pipe (Gas) Refrigerant pipe (Liquid) ø12.7mm (1/2") ø6.4mm (1/4")
- Page 20 Heronhill - for all your Toshiba requirements 5. REFRIGERANT PIPING DIAGRAMS 5.3 Indoor Unit Outdoor Unit RAV-134TU-1-PE RAV-134A-PE Indoor unit Heat exchanger Distributor strainer & capillary tube Strainer TC Sensor Refrigerant pipe (Smaller side) Refrigerant pipe (Larger side) ø6.4mm (1/4") ø12.7mm (1/2")
- Page 21 Heronhill - for all your Toshiba requirements 5. REFRIGERANT PIPING DIAGRAMS 5.4 Indoor Unit Outdoor Unit RAV-164TU-1-PE RAV-164A-PE Indoor unit Heat exchanger Distributor strainer & capillary tube Strainer TC Sensor Refrigerant pipe (Smaller side) Refrigerant pipe (Larger side) ø6.4mm (1/4") ø12.7mm (1/2")
-
Page 22: Performance Characteristics
Heronhill - for all your Toshiba requirements 6. PERFORMANCE CHARACTERISTICS Cooling capacity Capacity Ratio (%) (kW) RAV-134AH-PE RAV-164AH-PE 3.60 2.88 3.82 3.06 4.05 3.24 3.42 4.28 3.60 4.50 3.78 4.73 3.96 4.95 4.14 5.18 4.32 5.40 Room Temp. (Wet Bulb) (°C) - Page 23 Heronhill - for all your Toshiba requirements 6. PERFORMANCE CHARACTERISTICS Cooling capacity RAV-134AH-PE RAV-164AH-PE Heating Capacity Ratio Cooling Capacity Ratio INDOOR UNIT Piping Length L (m) Piping Length L (m) Cooling capacity RAV-134A-PE Cooling Capacity Ratio RAV-164A-PE INDOOR UNIT Piping Length L (m) Tel: 01823 665660 www.heronhill.co.uk...
- Page 24 Heronhill - for all your Toshiba requirements 6. PERFORMANCE CHARACTERISTICS Piping Length/Additional Refrigerant Volume The amount of refrigerant put into the outdoor unit at the factory is sufficient to fill up to 20m of refrigerant pipework. If the length of the refrigerant pipework is 20m or less, addition of refrigerant at the installation site is unnecessary.
-
Page 25: Exploded Views And Parts Lists
Heronhill - for all your Toshiba requirements 7. EXPLODED VIEWS AND PARTS LISTS Indoor Unit RAV-104TUH-1-PE RAV-134TUH-1-PE RAV-164TUH-1-PE RAV-134TU-1-PE RAV-164TU-1-PE 25/24 Part No. Description Model Part No. Description Model 43A22007 Blower Base Assembly 43154141 Relay – LY2F-L RAV-134/164TU-1-PE 43020288 Fan-C-F... - Page 26 Heronhill - for all your Toshiba requirements 7. EXPLODED VIEWS AND PARTS LISTS Outdoor Unit RAV-134AH-PE RAV-164AH-PE Part No. Description Model Part No. Description Model 43120156 Propeller Fan 43A41506 Comp – PG330X3F-4LS RAV-134AH-PE 43A21003 Fan Motor 43A41507 Comp – PG350X3F-4LS...
- Page 27 Heronhill - for all your Toshiba requirements 7. EXPLODED VIEWS AND PARTS LISTS Outdoor Unit RAV-134A-PE RAV-164A-PE Part No. Description Model Part No. Description Model 43120156 Propellor Fan 43A45001 Dryer 43A21012 Fan Motor 43155115 MF Capacitor – Compressor 43A43016 Condensor 43155080 MF Capacitor –...
- Page 28 Heronhill - for all your Toshiba requirements 7. EXPLODED VIEWS AND PARTS LISTS Ceiling Panel RBC-U134PG(W)-E Part No. Description Part No. Description 43080392 Filter 43009503 Grille-L-R 43007108 Plate Connect (Long) 43007124 Support Plate 43009504 ASM-Grille-Out 43009499 ASM-Grille-Out 43007107 Bushing 43421531...
- Page 29 Heronhill - for all your Toshiba requirements NOTES Tel: 01823 665660 www.heronhill.co.uk Fax: 01823 665807...
- Page 30 Heronhill - for all your Toshiba requirements TOSHIBA AIR CONDITIONING www.toshiba-aircon.co.uk MADE IN UK A90-0031 Tel: 01823 665660 www.heronhill.co.uk Fax: 01823 665807...
