Page 1: Service Manual
Heronhill - for all your Toshiba requirements FILE No. A90-9612 SERVICE MANUAL AIR CONDITIONER SPLIT TYPE 2 WAY CASSETTE TYPE RAV-133TU-PE/RAV-132A-PE RAV-163TU-PE/RAV-182A-PE Printed in UK Dec 1996 s Tel: 01823 665660 www.heronhill.co.uk Fax: 01823 665807... -
Page 2: Table Of Contents
Heronhill - for all your Toshiba requirements CONTENTS 1. SPECIFICATION............................3 2. CONSTRUCTION VIEWS.........................5 3. WIRING DIAGRAM.............................7 4. SPECIFICATIONS OF ELECTRICAL PARTS...................9 5. INTERFACE PCB............................11 6. REFRIGERANT PIPING DIAGRAM......................12 7. PERFORMANCE CHARACTER.......................13 8. EXPLODED VIEWS AND PARTS LISTS....................15 SUMMARY • The units referred to within this manual conform with the protection requirements of Directives 89/336/EEC Electromagnetic Compatibility and 73/23/EEC Low Voltage. -
Page 3: Specification
Heronhill - for all your Toshiba requirements 1. SPECIFICATIONS MODEL RAV-133TU-PE ITEM Cooling capacity Phase Power source 220-240 COOLING Power consumption Power factor Running current 10.3 Starting current Indoor unit dB(A) 40/36/34 (High, Med, Low) Operating noise (SPL) Outdoor unit... - Page 4 Heronhill - for all your Toshiba requirements ITEM MODEL RAV-163TU-PE Cooling capacity Phase 220-240 Power source COOLING Power consumption Power factor Running current 11.1 Starting current 41/37/35 Operating Indoor unit (high/med/low)dB (A) noise (SPL) Outdoor unit dB (A) Name of refrigerant...
-
Page 5: Construction Views
Heronhill - for all your Toshiba requirements CONSTRUCTION VIEWS 2.1 Indoor unit RAV-133TU-PE RAV-163TU-PE (Unit: mm) Tel: 01823 665660 www.heronhill.co.uk Fax: 01823 665807... -
Page 6: Outdoor Unit
Heronhill - for all your Toshiba requirements 2.2 Outdoor unit RAV-132A-PE RAV-182A-PE Knock - out hole for drain (2-(20 x 60) slots) Hole for drain (2-ø19 hole) Refrigerant piping joint (Gas side ∅ 12.7) Refrigerant piping joint (Liquid side ∅ 6.4) -
Page 7: Wiring Diagram
Heronhill - for all your Toshiba requirements 3. WIRING DIAGRAM Tel: 01823 665660 www.heronhill.co.uk Fax: 01823 665807... - Page 8 Heronhill - for all your Toshiba requirements RAV-132A-PE RAV-182A-PE Indoor Unit Outdoor Unit Earth Screw Surge Absorber Power supply 220-240V 50Hz shows terminal block and figures show terminal numbers. Broken lines show wiring at site. Do not operate the units with the magnetic contactor pushed in.
-
Page 9: Specifications Of Electrical Parts
Heronhill - for all your Toshiba requirements 4. SPECIFICATION OF ELECTRICAL PARTS 4.1 RAV-133TU-PE PARTS NAME TYPE SPECIFICATIONS Indoor unit fan motor (x2) PAF-230-7-4 Output (Rated) 7W, 4 pole, 1 phase, 230V, 50Hz Running capacitor for EVM45M504UF AC 450V, 0.5µF... - Page 10 Heronhill - for all your Toshiba requirements 4.3 RAV-132A-PE PARTS NAME TYPE SPECIFICATIONS Compressor PH230X3-4LS Output (Rated) 1.5kW, 2 pole, 220/240V, 1 phase, 50Hz Outdoor unit fan motor S M F - 2 3 0 - 3 9 N - 3...
-
Page 11: Interface Pcb
Heronhill - for all your Toshiba requirements 5. INTERFACE PCB FOR LOUVER OPERATION An additional PCB, referred to as the Interface PCB, is fitted to this unit to operate the dc stepper motors, which drive the louvers. The power supply to the interface PCB is via relay RY11 on the indoor PCB. -
Page 12: Refrigerant Piping Diagram
Heronhill - for all your Toshiba requirements 6. REFRIGERANT PIPING DIAGRAM 6.1 Indoor unit Outdoor unit RAV-133TU-PE RAV-132A-PE RAV-163TU-PE RAV-182A-PE Indoor unit Distributor strainer capillary Evaporator TC sensor Refrigerant pipe Refrigerant pipe (Larger side) (Smaller side) ø 12.7 mm ø 6.4 mm... -
Page 13: Performance Character
Heronhill - for all your Toshiba requirements 7. PERFORMANCE CHARACTER 7.1 Cooling capacity (KW) Capacity Ratio (%) RAV-133TU-PE RAV-163TU-PE RAV-132A-PE RAV-182A-PE 2.88 3.60 3.06 3.82 3.24 4.05 3.42 4.28 3.60 4.50 3.78 4.73 3.96 4.95 4.14 5.18 4.32 5.40 -2 ~ Room Temp. - Page 14 Heronhill - for all your Toshiba requirements 7.2 Cooling capacity RAV-133TU-PE / RAV-132A-PE RAV-163TU-PE / RAV-182A-PE Cooling Capacity Ratio Indoor Unit Outdoor Unit Piping Length (m) 7.3 Piping length/additional refrigerant volume Additional amount of refrigerant Piping length Recharge quantity (kg)
-
Page 15: Exploded Views And Parts Lists
Heronhill - for all your Toshiba requirements 8. EXPLODED VIEWS AND PARTS LIST 8.1 Indoor unit RAV-133TU-PE RAV-163TU-PE 225 226 2 1 5 Location Location Part No Description Part No Description 43039240 Canoe Clip 43A22001 Casing Assembly 43A72001 Drain Pan... - Page 16 Heronhill - for all your Toshiba requirements 8.2 Ceiling panel RBC-U133PG(W)-PE Location Part Location Part Description Description number Number number Number 43080392 Filter 43009503 Grille-L-R 43007108 Plate connect (long) 43007124 Support plate 43009504 ASM-Grille-Out 43009499 ASM-Grille-Out 43007107 Bushing 43A26001 ASM-Motor...
- Page 17 Heronhill - for all your Toshiba requirements 8.3 Outdoor Unit RAV-132A-PE RAV-182A-PE Location Location Part No. Description Part No. Description 43120156 Fan, Propeller 43155080 Capacitor, Plastic Film 43A21012 Motor, Fan 43162027 Cover, Electric Parts 43143642 Condenser 43145098 Dryer 43049132 Base, Spring, B...
- Page 18 Heronhill - for all your Toshiba requirements -89- Tel: 01823 665660 www.heronhill.co.uk Fax: 01823 665807...
