- Page 1 CARPET EXTRACTOR Operating Instructions (ENG) MODEL: D250 (115V) 10070100 Beginning with Serial No. 1000054537 Read these instructions before operating the machine 86038570 05/11/07 PRV NO. 98828...
-
Page 2: Table Of Contents
TABLE OF CONTENTS MODEL ____________________________________________ DATE OF PURCHASE ________________________________ SERIAL NUMBER __________________________________ SALES REPRESENTATIVE # _________________________ DEALER NAME ____________________________________ Data Log/Table of Contents ....1 Technical Specifications…………...……..11 Safety Instructions........2 Parts Lists..........13-22 Grounding Instructions ......3 Spare Parts..........23 Operations..........4 Wiring Diagram........24 Maintenance …………………………..6-9 Warranty ..........25 Troubleshooting ........10 INSPECTION... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precaution must always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. This machine is for commercial use. WARNING: To reduce the risk of fire, electric shock, or injury: Connect to a properly grounded outlet. -
Page 4: Grounding Instructions
GROUNDING INSTRUCTIONS THIS PRODUCT IS FOR COMMERCIAL USE ONLY. PROPER GROUNDING (115V) Grounding Pin Metal Screw ELECTRICAL: The amp, hertz, and voltage are listed on the data label found on each machine. Using voltages above Grounded Adaptor or below those indicated on the data label will cause Outlet Grounded Outlet Box serious damage to the motors. -
Page 5: Operations
ACCESSORIES: 5. Pour clean, hot water into the solution tank. The D-250 can be used with the following Windsor To avoid possible tank distortion, water equipment: Deluxe Hand Tool (86000020 – PRV temperature must not exceed 140 F (60C). - Page 6 OPERATION HEATER OPERATION 3. When cleaning, keep the working opening (wand mouth) flat on the surface being cleaned. Keep The disconnect fittings on the the wand moving when the valve is open. heater will become extremely 4. The shutoff float inside the recovery tank will hot during operation.
-
Page 7: Maintenance
MAINTENANCE DAILY MAINTENANCE: 2. Check hoses for wear, blockages, or damage. Frayed or cracked hoses should be repaired or (At the end of each working day): replaced to eliminate vacuum or solution pressure loss. 1. Flush the entire system, including floor tool, hand tool, etc., with 1 to 3 gallons of clean, hot 3. - Page 8 MAINTENANCE SERVICE SCHEDULE MAINTENANCE DAILY WEEKLY QUARTERLY Check machine for cord damage Check recovery dome and gasket for damage and cleanliness Check hoses for wear, blockages, or damage Check handles, switches, and knobs for damage Check vac motor intake filter and clean Run one gallon of water through system Clean out recovery tank and check...
- Page 9 3. Remove solution hoses from fittings in pump. 4. Remove the (2) screws that fasten the pump to the frame. 5. Reverse process to install pump. Note: Vacuum Motor Carbon Brushes Replacement (Windsor) Place End Cap stop in groove. WARNING: The green...
- Page 10 1000 hours-kit 86201090 – PRV NO. 250-75B valve assembly and o-rings. NOTE: Maintenance and repairs must be done by qualified personnel. Using non-Windsor parts to repair this machine will void the warranty. Contact an authorized Windsor dealer for complete details.
-
Page 11: Troubleshooting
TROUBLESHOOTING TROUBLE SHOOTING CHART PROBLEM POSSIBLE CAUSE SOLUTION No power to machine Dead electrical circuit Check building circuit breaker or fuse box. Electrical shock Faulty power cord Replace. Electrical shock Equipment not grounding Follow grounding instructions exactly. Receptacle not grounded Contact an electrician to check building's wiring. -
Page 12: Technical Specifications
TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS ELECTRICAL: 115 V, 60 Hz, 15 Amps per power cable ((D250) 230 V, 50 Hz, 15 Amps (D250IE) ELECTRIC VACUUM MOTOR (1) –2/1.25 HP, 2 stage, Waterlift –150” (381cm) SOLUTION PUMP 250 psi, adj. SOLUTION CAPACITY 17 gallons (64.3ltr) RECOVERY CAPACITY 15 gallons (56.75ltr) - Page 13 NOTES: D-250 86038570 05/11/07...
-
Page 14: Parts Lists
RECOVERY TANK ASSEMBLY D-250 86038570 05/11/07... - Page 15 VAC MTR ASM, D/B RCVRY 115V 2ST 86202070 360-04B BRUSHES, VAC FOR 116392-00 SERVICE ONLY 1000121568 SERVICE ONLY 86135320 140687 BRUSH SET, 120V VAC WINDSOR 86256490 70814 STUD, 1/4-20 X 4.5 86010640 87016 WASHER, #10 LOCK EXT STAR SS 86274980...
- Page 16 CONTROL PANEL GROUP D-250 86038570 05/11/07...
- Page 17 CONTROL PANEL GROUP REF PART NO. PRV NO. QTY DESCRIPTION SERIAL NO. FROM NOTES: 86199650 070-08 1 FAN 105 CFM AXIAL 86090870 61367 1 PANEL ASM, CONT. 3 SW W/HEAT 86276290 70621006 4 SCR, #10 X 3/4 PPHST HI-LO BLK 86199660 070-08A 1 FAN FINGER GUARD 86273810...
- Page 18 VACUUM GROUP (LOWER) D-250 86038570 05/11/07...
- Page 19 VAC MTR ASM, D/B SLTN 115V 2ST 86202070 360-04B BRUSHES, VAC FOR 116392-00 SERVICE ONLY 1000121568 SERVICE ONLY 86135320 140687 BRUSH SET, 120V VAC WINDSOR 86282120 39582 HOSE, VAC EXHAUST X 9” 86002380 20046 CLAMP, 2.25” WORM GEAR 86267480 880292 WIRE, 4”...
- Page 20 PUMP & HEATER GROUP (200 PSI) D-250 86038570 05/11/07...
- Page 21 PUMP & HEATER GROUP (200 PSI) SERIAL NO. PART NO. PRV NO. DESCRIPTION FROM NOTES: 86199640 030-16 ELBOW, 1/4 NPT STREET LONG 90D 86200260 151-50C HOSE, PULSE 47.0 1/4MPT X 1/4 MPT INCLUDED IN 86197370 31017 ELBOW, 1/4 FPT X 1/4 FPT HEATER ASSEMBLY INCLUDED IN 86005590...
-
Page 22: Solution Tank Assembly
SOLUTION TANK ASSEMBLY D-250 86038570 05/11/07... - Page 23 SOLUTION TANK ASSEMBLY SERIAL NO. PART NO. PRV NO. DESCRIPTION FROM NOTES: 86201290 280-02 RIVET AL. 3/16 X 1/2 CLOSED 86201500 260-71 SOLUTION COVER D/B 86002450 22015 COUPLER, 1/4 OD 86005590 56014 NIPPLE, 1/4 CLOSE 86199580 250-35 D/B BPR 200 PSI 86200250 151-50B HOSE, 42”...
-
Page 24: Spare Parts
PUMPTEC 300PSI PUMP KIT 2 86201170 250-79G PUMPTEC 300PSI REBUILD KIT 3 86202070 360-04B BRUSHES, VAC FOR 116392-00 86135320 140687 BRUSH SET, 120V VAC WINDSOR 1000121568 86031620 85047 VAC MOTOR ASM, RCVRY 115V 2ST 86031600 85045 VAC MOTOR ASM, SLTN 115V 2ST 86201130 250-79 PUMPTEC 200PSI PUMP &... -
Page 25: Wiring Diagram
115V WIRING DIAGRAM D-250 86038570 05/11/07...
