- Page 1 CARPET EXTRACTOR Operating Instructions (ENG) MODEL: D250 (115V) D250IE (230V) Prior to Serial No. 1000054536 Read these instructions before operating the machine 98637 04/25/02...
-
Page 2: Important Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precaution must always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. This machine is for commercial use. WARNING: To reduce the risk of fire, electric shock, or injury: Connect to a properly grounded outlet. -
Page 3: Grounding Instructions
GROUNDING INSTRUCTIONS THIS PRODUCT IS FOR COMMERCIAL USE ONLY. PROPER GROUNDING (115V) ELECTRICAL: Grounding Pin Metal Screw The amp, hertz, and voltage are listed on the data label found on each machine. Using voltages above or below those indicated on the Grounded Adaptor data label will cause serious damage to the... -
Page 4: Carpet Inspection
ACCESSORIES: The D-250 can be used with the following For hose fitting lubrication, use a light Windsor equipment: Deluxe Hand Tool silicone lubricant which will not damage o- (DHT), Pile Jogger(PJ2A), Standard Floor rings. Wands(SFW, SW, SW-PRO, PROW), &... -
Page 5: Equipment Set-Up
OPERATIONS EQUIPMENT SET-UP: NOTES:____________________________ Plug power cable from machine into ___________________________________ properly grounded wall outlet. ___________________________________ ___________________________________ Turn vacuum motor switch on and off ___________________________________ to make sure there is electrical power at ___________________________________ machine. ___________________________________ ___________________________________ Connect vac hose to machine. Slide ___________________________________ the swivel cuff over the outlet on the tank. -
Page 6: Daily Maintenance
MAINTENANCE DAILY MAINTENANCE: (At the end of each working day) : Flush the entire system, including floor tool, hand tool, etc., with 1 to 3 gallons of clean, hot water. Vacuum out the solution tank . Rinse tank with fresh water. Periodically inspect the recovery tank and decontaminate if necessary, using a Hospital Grade Virucide or a 1-10 bleach to water solution. -
Page 7: Vacuum Motor Replacement
MAINTENANCE ONLY QUALIFIED MAINTENANCE PERSONNEL ARE TO PERFORM WARNING: THE FOLLOWING REPAIRS. Vac Motor Carbon Brushes Replacement End Cap VACUUM MOTOR REPLACEMENT 1. Turn off all switches and unplug machine. Carbon Brushes WARNING: The green 2. Remove recovery tank. ground wire must be 3. -
Page 8: Maintenance And Troubleshooting
3.) 1000 hours-kit 55250752 valve assembly and o-rings. NOTE: Maintenance and repairs must be done by qualified personnel. Using non- Windsor parts to repair this machine will void the warranty. Contact an authorized Windsor dealer for complete details. TROUBLE SHOOTING CHART :... -
Page 9: Technical Specifications
TROUBLESHOOTING CONT. Solution hose Corrosion on fittings Clean with steel wool. fitting hard to Soak in acetic acid (white vinegar). connect Lubricate lightly with silicone base lubricant. Carpet not Severe soil conditions Make several passes at right angles to getting clean. other. -
Page 10: 115V Wiring Diagram
115V WIRING DIAGRAM D-250 98637 11/07/00... -
Page 11: 230V Wiring Diagram
230V WIRING DIAGRAM D250 98637 06/19/00... - Page 12 THIS PAGE LEFT BLANK INTENTIONALLY D250 98637 06/19/00...
-
Page 13: Recovery Tank Assembly
RECOVERY TANK ASSEMBLY 19AB D-250 98637 11/07/00... - Page 14 RECOVERY TANK ASSEMBLY SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 05151 TUBE ASM, RECOVERY TANK 500009 LABEL, WARNING 260-64A ACCESS COVER CLEAR 6” W/RIM 70546 SCR, 8 X 3/4 PFHT/S BLK ZINC 090-12A FLOAT CAGE ASSY COMPLETE SLIP 240-46 FLOAT SCREEN ADAPTER 30 DEGREE 300-08 FL HD WD SCREW PH 6 X 1/2 SS 78460...
-
Page 15: Solution Tank Assembly
SOLUTION TANK ASSEMBLY 230V D-250 98637 11/07/00... - Page 16 SOLUTION TANK ASSEMBLY SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 360-04A VACUUM 110V TWO STAGE 116392-0 360-06 VACUUM 116213 220V SM 2 STG 05152 TUBE ASM, VAC EXHAUST 50009 PAN HD SH MTL SCREW 10 X 1/2 SS 88208 WIRE, 21” GRN/14 76001 X 76010 87016 WASHER, #10 LOCK EXT STAR SS 70335...
- Page 17 SOLUTION TANK ASSEMBLY CONT'. SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 065-28A PLATE, PUMP MOUNT 40013 HOSEBARB, 3/8 MPT X 1/2 DL 31026 ELBOW, 3/8NPT STREET 70232 SCR, 10-32 X 3/8 PPHMS SS 57196 NUT, 1/2 PUSH-ON DOME CAP 040-06 WHEEL 8”...
-
Page 18: Suggested Spare Parts
SUGGESTED SPARE PARTS SUGGESTED SPARE PARTS DESCRIPTION PART NUMBER PAGE/REF FUSE 55100041 15/203 BPR KIT 55250331 15/191 THERMOSTAT 55130149 THERMOSTAT 55130143 KIT, PACKING PUMP 55250751 KIT, BEARING PUMP 55250752 KIT, VALVE PUMP 55250753 CARBON BRUSHES, VAC MOTOR 115V 140370 VAC MOTOR ASM, 115V UPPER 5536032 13/111A VAC MOTOR ASM, 115V LOWER... -
Page 19: Limited Warranty
If proof of purchase cannot be identified, the warranty start date is 90 days after date of sale to an authorized Windsor distributor. Parts replaced or repaired under warranty are guaranteed for the remainder of the original warranty period.
