DIR-620 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in Switch
User Manual
Figure 29. Configuring PPPoE WAN connection. The expert settings mode. The PPP section.
Parameter
Username
Without authorization
Password
Password confirmation
Service name
Authentication
algorithm
MTU
Keep Alive
PPP
A username (login) to access the Internet.
Select the checkbox if you don't need to enter a username and
password to access the Internet.
A password to access the Internet.
The confirmation of the entered password (to avoid mistypes).
The name of the PPPoE authentication server.
Select a required authentication method from the drop-down list or
leave the AUTO value.
The maximum size of units transmitted by the interface.
Select the checkbox if you want the router to
your ISP even when the connection has been inactive for a specified
period of time. When the checkbox is selected, the LCP interval
and LCP fails fields are available. Specify the required values.
Page 40 of 202
Configuring via Web-based Interface
Description
keep you connected to
