DIR-620 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in Switch
User Manual
You can specify the following parameters:
Parameter
Name
Enable
Type
Figure 120. The page for editing a group of ports for VLAN.
Main settings
A name for the port for easier identification.
Select the checkbox to allow using this group of ports.
The type of the VLAN which identifier is specified in the VLAN ID
field.
Local. The group of this type is a channel used to connect local
clients to the router. It is mostly used to connect different types of
clients, which require separate connection settings.
NAT. The group of this type is an external connection with address
translation. It is mostly used to connect to the Internet. Later the
VLAN which identifier is specified in the VLAN ID field is used to
create a WAN connection (on the Net / WAN page).
Transparent. The group of this type is a transparent connection
between an internal port and an external connection. It is mostly
used to connect IPTV set-top boxes.
Page 149 of 202
Configuring via Web-based Interface
Description
