DIR-620 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in Switch
User Manual
Parameter
Source
Destination
Source
Destination
Click the Change button.
To edit a rule for IP filtering, click the link to the relevant rule. On the opened page, change the
needed parameters and click the Change button.
To remove a rule for IP filtering, click the link to the relevant rule. On the opened page, click the
Delete button.
The source host/subnet IP address.
If the IP address range checkbox is selected, specify the starting
IP address of the range in the Source (first) field and the ending IP
address in the Source (last) field.
If the IP address range checkbox is not selected, specify the IP
address of the host or subnet in the Source field. To specify an IP
address add /32.
To choose a device connected to the router's LAN at the moment,
select the relevant IP address from the drop-down list (the field will
be filled in automatically).
The destination host/subnet IP address.
If the IP address range checkbox is selected, specify the starting
IP address of the range in the Destination (first) field and the
ending IP address in the Destination (last) field.
If the IP address range checkbox is not selected, specify the
starting IP address of the host or subnet in the Destination field. To
specify an IP address add /32.
To choose a device connected to the router's LAN at the moment,
select the relevant IP address from the drop-down list (the field will
be filled in automatically).
Ports
A port of the source IP address. You can specify one port, several
ports separated by a comma, or a range of ports separated by a colon.
A port of the destination IP address. You can specify one port,
several ports separated by a comma, or a range of ports separated by
a colon.
Page 162 of 202
Configuring via Web-based Interface
Description
