DIR-620 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in Switch
User Manual
Parameter
VLAN ID
Port
QoS
Tag
Click the Save changes button.
Click the Delete port button to delete the port highlighted in the table at the bottom of the page.
Click the Delete VLAN button to delete this group of ports form the system.
For further use of groups of ports for VLAN it is required to save the changed settings to
!
the non-volatile memory of the router and reboot it (click the Save&Reboot line in the
top-page menu displayed when the mouse pointer is over the System caption).
An identifier of the VLAN to which this group of ports will be
assigned.
Ports
From the list, select an available value (a physical port of the router,
the wireless interface) to assign it to this group. The port will be
displayed in the table at the bottom of the page.
A priority tag for the traffic transmitted through the port highlighted
in the table at the bottom of the page.
Select a value for the port highlighted in the table at the bottom of
the page:
tagged,
•
untagged.
•
Page 150 of 202
Configuring via Web-based Interface
Description
