D-Link User ManualDIR-620 User Manual page 113

DIR-620 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in Switch
User Manual
Parameter
Primary DNS server/
Secondary DNS server
Authorization in the
ISP's network via
802.1x protocol
Authentication method
Username
Password
Figure 94. The page for creating a new connection. The Miscellaneous section.
Parameter
Enable RIP
Enable IGMP Multicast
NAT
Firewall
Ping
Enter addresses of the primary and secondary DNS servers in the
relevant fields.
Authorization via 802.1x protocol
Select the checkbox to allow authorization in the ISP's network via
the 802.1x protocol.
Select a needed authentication method from the drop-down list.
Enter the username provided by your ISP.
Enter the password provided by your ISP.
Miscellaneous
Select the checkbox to allow using RIP for this connection.
Select the checkbox to allow multicast traffic from the external
network (e.g. video streaming) to be received.
Select the checkbox if you want one WAN IP address to be used for
all computers of your LAN.
Select the checkbox to enable protection against ARP and DDoS
attacks.
Select the checkbox to allow the router to answer ping requests from
the external network through this connection. For security reasons,
it is recommended not to select this checkbox.
Page 113 of 202
Configuring via Web-based Interface
Description
Description
