If there is sufficient space in the stack for all of the
specified registers, PSM operates as follows:
1.
The contents of registers R to R
=
CC - 1 are stored in
ascending sequence, beginning with the location
tion pointed to by the current top-of-stack address
(SPD15_31)t plus 1 and ending with the current top-
of-stack address plus CC.
2.
The current top-of-stack address is incremented by the
value of CC, to point to the new top-of-stack location.
3.
The space count (SPD33-47) is decremented by the
value of CC and the word count is incremented by the
value of CC.
4.
The condition code is set to reflect the new status of
the space count.
Affected: (SPD), (TSA+1) to
(TSA+CC), CC
Trap: Push-down stack limit
(R) -
(SPD)15_31 +
1. ..
(R+CC-l) -
(SPD)t 15-31 + CC
(SPD)15_
31
+C C -SPD
15
_
3
/
(SPD)33_47- CC -SPD 33 _ 47
(SPD) 49-63 +CC -
SPD 49-63
Condition code settings:
0
0
0
2 3
4
Result of PSM
0
0
0
0
0
0
0
0
0
0
o
0
0
0
0
0
0
0
Space count>
o.
Space count
=
O.
Word count + CC > 2 15 _1,
TW
=
1.
Space count
<
CC, TS
=
1.
Space count
<
CC, worq
count
=
0, TS
=
1.
Space count
<
CC, word
count + CC > 2 15 _1
TS
=
1, and TW
=
1.
Space count
=
0, TS
=
1.
Space count
=
0, word
count
=
0, TS
=
1.
Space count
=
0, word
count + CC > 2 15 _1,
TS
=
1, and TW
=
1.
Instruction
completed
Instructi on
aborted
t For real extended mode of addressing this is a 20-bit
field (12-31); for real and virtual addressing modes it is a
17-bit field (15-31).
If the instruction operation extends into a memory page
protected either by the access protection codes or write
locks, the memory protection trap can occur.
If the opera-
tion extends into a memory region"that is physically not
present, the nonexistent memory address trap can occur.
If the address of the elements within the stack (pointed to
by the top-of-stack address) is in the range 0 through -15,
then the registers indi cated by the R field of the PSM in-
struction are stored in the general registers rather than in
main memory. In this case the results wi II be unpredictable if
any source registers are also used as destination registers.
PLM
PULL MULTIPLE
(Doubleword index alignment)
PULL MULTIPLE loads a sequential set of general registers
from the push-down stack defined by the stack pointer
doubleword located at the effective doubleword address of
PLM. The condition code must contain a count of the num-
ber of words to be pulled from the stack.
(An initiaJ value
of 0000 for the condition code specifies that 16 words are
to be pulled from the stack.) The registers are treated as a
circular set (with register 0 following register 15), the first
register to be loaded from the stack is register R+CC-1, and
the contents of the current top-of-stack location becomes
the contents of this register. The last register to be loaded
is register R.
If there is a sufficient number of words in the stack to load
all of the specified registers, PLM operates as toiiows:
1.
Registers R+CC-1 to register R are loaded in descend-
ing sequence, beginning with the contents of the lo-
cation pointed to by the current top-of-stack address
(SPD15-31)t and ending with the contents of the loca-
tion pointed to by the current top-of-stack address
minus CC-1.
2.
The current top-of-stack address is decremented by the
value of CC, to point to the new" top-of-stack location.
3.
The space count (SPD33-47) is incremented by the
value of CC and the word count is decremented by the
value of CC.
4.
The condition code is set to reflect the new status of
the word count.
Affected: (SPD), (R+CC-l)
to (R), CC
((SPDh5_31t-R +CC -1, ... ,
((SPD)15-31
-Icc -
11) -
Rt
(SPD)15-31 - CC- SPD 15-31 t
(SPD)33-47 + CC -
SPD33-47
(SPD)49-63 - CC -
SPD49-63
Trap: Push-down stack limit
push-Down Instructions (Non-Privileged)
99
