APRILIA RSV 1000 R FACTORY Workshop Manual page 305

RSV 1000 R - RSV 1000 R FACTORY
ADDITIONAL KEY STORE PROCEDURE
The immobilizer system can recognize up to 4 keys. The
storage procedure can only be done at the Dealer's with a
Master Key.
The storage procedure cancels the existing codes, so that if
the client wishes to store new keys he must come to the
Dealer's with all the keys he wishes to use. The storage pro-
cedure is as follows :
1. with a customer key (already stored), turn from key ON
to OFF
2. fit the Master Key within 20 seconds, thus enabling the
storing procedure. The led will stay on continuously
3. insert and run key-ON's in sequence with all the keys to
be stored. The led will switch off for 0.5 seconds after
each key has been successfully stored.
4. After each key has been stored, the system waits for a
new key for 20 seconds (led on continuously) after
which the procedure self-terminates (the led flashes
once for each key and then turns off).
ELECTRICAL SYSTEM
7 - 17
