First Alert FA142C Installation Instructions Manual

Security systems
Hide thumbs Also See for FA142C:
Table of Contents

Advertisement

Quick Links

See also: User Manual
INSTALLATION
INSTRUCTIONS
F F F F A A A A 1 1 1 1 4 4 4 4 2 2 2 2 C C C C S S S S E E E E C C C C U U U U R R R R I I I I T T T T Y Y Y Y S S S S Y Y Y Y S S S S T T T T E E E E M M M M
N7227–1V1 Rev B 4/99

Advertisement

Table of Contents
loading

Related Manuals for First Alert FA142C

Summary of Contents for First Alert FA142C

  • Page 1 INSTALLATION INSTRUCTIONS F F F F A A A A 1 1 1 1 4 4 4 4 2 2 2 2 C C C C S S S S E E E E C C C C U U U U R R R R I I I I T T T T Y Y Y Y S S S S Y Y Y Y S S S S T T T T E E E E M M M M N7227–1V1 Rev B 4/99...

  • Page 2: Recommendations For Proper Protection

    RECOMMENDATIONS FOR PROPER PROTECTION The following recommendations for the location of fire and burglary detection devices help provide proper coverage for the protected premises. Recommendations For Smoke And Heat Detectors With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Section 1. GENERAL DESCRIPTION .................... 9 Section 2. INSTALLING THE CONTROL ..................11 Mounting the Cabinet ....................... 11 Installing the Lock (if used) ....................11 Installing the Control's Circuit Board Alone or (if used), With a 4204, 4219, or 4229 Module................12 Installing Control and RF Receiver Circuit Boards Together in the Cabinet.....
  • Page 4 Section 6. WIRELESS (RF) ZONE EXPANSION (5700 & 5800 RF SYSTEMS), CONT’D Zone Programming for 5700 Series Transmitters ............33 Go/NoGo Test......................35 5800 Series Transmitter Setup ..................36 5800 Series Transmitter Input Loops ................ 36 5800 Series Transmitter Input Types ................ 36 Compatible 5800 Series Transmitters ................
  • Page 5 Accessories (Compatible Devices) .................. 85 REGULATORY AGENCY STATEMENTS....................89 LIMITATIONS OF THIS ALARM SYSTEM ....................92 FA142C SUMMARY OF CONNECTIONS DIAGRAM ............. Inside Back Cover LIMITED WARRANTY ........................ Back Cover NOTE: A Programming Guide is supplied in addition to this manual.
  • Page 6 Figure 15. Connection of AAV Unit When Not Using an FA4285 Phone Module ....59 Figure 16. Connection of AAV Unit When Also Using an FA4285 Phone Module ....59 Figure 17. FA142C Summary of Connections Diagram ......Inside Back Cover – 6 –...

  • Page 7: How To Use This Manual

    “Data Field Descriptions” in the separate Programming Guide that has been supplied. If you are an experienced user of First Alert Professional products, you may choose to wire and then program the entire system at one time. If so, refer to “Mechanics of Programming”...

  • Page 8: Conventions Used In This Manual

    CONVENTIONS USED IN THIS MANUAL MAIN SECTION TITLES ARE SHOWN IN REVERSE TYPE These notes include specific information which must be followed if you are installing this system for a UL Listed application. These notes include information that you should be aware of before continuing with the installation, and which, if not observed, could result in operational difficulties.

  • Page 9: Section 1. General Description

    Section 1. GENERAL DESCRIPTION The FA142C is a control that supports up to 36 zones, using basic hard-wired, wired expansion, and/or wireless, plus remote keypads. Basic Hardwired Zones Provides 6 basic hardwired zones having the following characteristics: • Zones 1–6 response time is 300–500 milliseconds.
  • Page 10 • The system can be uploaded, downloaded, or controlled via an IBM compatible computer, First Alert’s FADL downloading software (or Compass Windows downloading software), and a HAYES modem specified by First Alert (see the separate Programming Guide).

  • Page 11: Section 2. Installing The Control

    Section 2. INSTALLING THE CONTROL This section provides instructions for mounting the control cabinet, and installing the cabinet lock (if used). Also included in this section are instructions for the following: • Installing the main PC board. • If used, optional mounting one of the following in the cabinet with the main PC board: RF Receiver board, 4204 Relay unit, 4219 Wired Expansion unit, or 4229 Wired Expansion/Relay unit.

  • Page 12: Installing The Control's Circuit Board Alone Or (If Used), With A 4204, 4219, Or 4229 Module

    Installing the Control's Circuit Board Alone, or (if used), with a 4204, 4219 or 4229 Module Installing the Control's Circuit Board in the Cabinet 1. Hang two long Red mounting clips (provided) on the raised cabinet tabs (see Detail B in Fig. 2). 2.

  • Page 13: Figure 3. Installing The Pc Board & Rf Receiver (If Used) Together In The Cabinet

    4. Insert the top of the control's board into the slot in the clips and position two long (red) clips at the lower edge of the board (see Detail C). 5. Swing this board into place and secure it with two additional screws. 6.

  • Page 14: Standard Phone Line Connections

    Standard Phone Line Connections The wiring connections shown here are not applicable if the FA4285 Phone Module is used. Refer to the FA4285 Phone Module section for information regarding phone line connections, which are different than those shown here. Incoming phone line and handset wiring is connected to the main terminal block via a RJ31X jack (CA38A jack in Canada), as indicated below and shown in Figure 4.

  • Page 15: Earth Ground Connections

    2. Attach Red and Black wires on the battery connector cable to the control board as follows: a. Red to the positive ( +) battery tab on the control board † (see Summary of Connections Diagram for location, if necessary). b.

  • Page 16: Section 3. Installing Remote Keypads

    Section 3. INSTALLING REMOTE KEYPADS This section lists the wired keypads that may be used and provides instructions for wiring and mounting the keypads. A preliminary check-out procedure is also provided to ensure that the connected keypads are functioning properly in the system. Keypads That May Be Used •...

  • Page 17: Using A Supplementary Power Supply To Power Additional Keypads

    Mounting the Keypads 1. Make sure keypads are set to non-addressable mode (address 31), which is the factory default setting. Refer to the instructions provided with the keypad for address setting procedure. 2. Mount the keypads at a height that is convenient for the user. Refer to the instructions provided with the keypad for mounting procedure.

  • Page 18: Preliminary Check-Out Procedure

    Preliminary Check-out Procedure If you want to check that the system is working before connecting field wiring from zones and devices, do the following: 1. Temporarily connect a 1000 ohm end-of-line resistor across each of the basic hard-wire zones 1–6, as shown in the Summary of Connections diagram.

  • Page 19: Basic Hard-Wired Zones 1-6

    Section 4. BASIC HARD-WIRED ZONES 1–6 This section provides general information for the hard-wired zones in the system, plus specific instructions for installing 4-wire smoke/combustion detectors. Also included is a procedure for programming the hard-wired zones. Installing the Hard-Wired Zones Common •...

  • Page 20: Compatible 4-Wire Smoke/Combustion Detectors

    Compatible System Sensor 4-Wire Smoke/Combustion Detectors 1412 4-wire ionization products of combustion detector. 2412 4-wire photoelectric smoke detector. 2412TH 4-wire photoelectric smoke detector w/135º F (57º C) heat detector. A77–716B EOL relay module (supervisory module for wired 4-wire fire zone). 2112/24T Low-profile 4-wire photoelectric smoke detector w/135º...
  • Page 21 Zone Types 00 = Zone Not Used 08 = 24 Hr Aux 01 = Entry/Exit #1 09 = Fire 02 = Not used 10 = Interior w/Delay 03 = Perimeter 20 = Arm Stay * 04 = Interior Follower 21 = Arm-Away * 05 = Trouble Day/Alarm Night 22 = Disarm* 06 = 24 Hr Silent...

  • Page 22: Check-Out Procedure For Hard-Wired Zones

    When you have programmed all the hard-wired zones and Panic keys satisfactorily, exit 56 interactive mode at the Enter Zn Num. prompt by entering [ 0] [ 0] as the next zone number. Then exit the programming mode by keying 99. See the special notes below, then proceed to the check-out procedure that follows.

  • Page 23: Wired Zone Expansion (4219, 4229)

    Section 5. WIRED ZONE EXPANSION This section provides information regarding the use of expansion modules (4219 or 4229) for expanding the number of wired zones in the system, describes the modules that can be used and their wiring connections, plus a procedure for programming the wired expansion zones. Installing Zone Expansion Units You can add an additional 8 wired expansion EOLR zones to the basic control's 8 hardwired zones, for a total of 14 wired zones, by using a No.

  • Page 24: Programming Wired Expansion Zones

    Programming Wired Expansion Zones 1. With at least one 2-line Alpha keypad (FA550KP) connected to the keypad terminals on the control, power up the system temporarily. If you had previously connected the AC transformer to the control panel, you need only plug in the transformer (to 120VAC outlet) to power up the system.

  • Page 25: Check-Out Procedure For Wired Expansion Zones

    At the “INPUT DEVICE” prompt, enter “2” (AUX 10 Input Dev: Wired) as the input device. The display on the AUX WIRED AW: 01 left will appear. Press [ ] to continue. Typical summary display A summary display will appear, showing the Zn ZT RC In data for the zone that was just programmed.
  • Page 26 3. Fault and restore every contact or sensor in each expansion zone individually to ensure that it is being monitored by the system. Each time a zone is faulted, the keypad should display the number of the faulted zone (as programmed by you just previously in 56 mode). When each zone is restored, the READY TO ARM message should appear again.

  • Page 27: Wireless (Rf) Zone Expansion (5700 And 5800 Rf Systems)

    Wireless may not be used in UL Commercial Burglary installations. Wireless Systems Available The FA142C supports wireless zones which may be used exclusively, or in addition to hardwire zones 1 through 6. The system supports two different wireless systems which have many similarities, but notable differences in the programming of the transmitters for each system.

  • Page 28: Transmitter Battery Life

    The supervision for a particular transmitter in the 5800 system may be turned off by entering it as a "UR" (unsupervised RF) type, as described later. 5800 series transmitters have built-in tamper protection and will cause a “CHECK” condition to be annunciated if covers are removed. Each transmitter is also supervised for low battery and will transmit a low bat- tery signal to its receiver, with the battery having at least 30 days of life remain- ing.

  • Page 29: Installing The 5800Tm Module

    Terminal 7 BLUE: Not Used Do not cut any of the jumpers on the 5800TM when using it with the FA142C. For additional information, refer to the 5800TM’s instructions. 5700 Series Transmitter Setup Each 5700 series transmitter has DIP switches to set both the transmitter's zone number (Transmitter zone/ID) and the system House ID.

  • Page 30: Setting The Dip Switches On 5700 Series Wireless Transmitters

    Setting the DIP Switches Set the DIP switches on each 5700 series transmitter to the appropriate on 5700 Series zone/ID number and House ID. Refer to the Compatible 5700 Series Transmitters Transmitters table on a following page in this section for zone numbers and programming information for each particular transmitter.

  • Page 31: Dip Switch Tables For 5700 Rf System Wireless Devices

    DIP SWITCH TABLES FOR 5700 RF SYSTEM WIRELESS DEVICES DIP SWITCH TABLES FOR 5700 RF SYSTEM WIRELESS DEVICES 5775 PIR HOUSE ID 5701 PANIC TRANSMITTER 5706/5707 SMOKE DETECTOR/TRANSMITTER SWITCH SETTING FOR ALL DETECTORTRANSMITTER DEVICES EXCEPT 5716 MIRROR HOUSE ID (1 SHOWN) DIP SWITCH POSITION DEVICE SIDE...

  • Page 32: Compatible 5700 Series Transmitters

    Compatible 5700 Series Transmitters Model Product Zone/ID # Description 5701 Panic Transmitter 62 or 63 • Programmable for either silent or audible 24-hour alarm. 5706 Photoelectric Smoke 48–55 • One-piece smoke detector with Detector built-in transmitter. • Built-in UL Listed 85dB piezo electric alarm sounder and audible low battery warning.

  • Page 33: Programming The Control For A 5700 Wireless System

    Programming the Control For a 5700 Wireless System 1. With at least one two-line Custom English keypad wired and set to address 31 (default), power up the system temporarily by plugging the AC transformer (previously wired to the control) into a 120VAC outlet. 2.
  • Page 34 Data field 22 RF SYSTEM TYPE, must have been programmed for a 5700 RF system (“1”). Also, the House ID should have been entered in field 24, and all 5700 transmitters set to the same House ID. 4. Press 56. (Zone Programming Mode) Use this mode to program zone numbers, zone types, and alarm report codes for all 5700 wireless zones that are going to be used in the system.

  • Page 35: Go/Nogo Test

    10. Mark the zone number on the transmitter. 11. After the transmitter has been entered into the system, press [ ] to continue. Typical summary display A summary of the programmed values for the Zn ZT – RC In: selected zone will now be displayed 20 03 –...

  • Page 36: 5800 Series Transmitter Setup

    3. Mount the transmitter according to the instructions provided with the transmitter. 4. Exit the GO/NO GO test mode by entering Installer Code + (OFF ). You should now proceed to “Check-Out Procedure for Wireless Zones” at the end of this section. 5800 Series Transmitter Setup General 5800 series transmitters have built-in serial numbers that must be entered...

  • Page 37: Compatible 5800 Series Transmitters

    Compatible 5800 Series Transmitters Enter As Input Model Product Device Type Description 5801 Wireless Panic UR or RF • Has four pushbuttons, each with a Transmitter unique input (loop) code. • Programmable responses (e.g., Panic, Arm–Stay, Arm–Away, Disarm, etc. 5802 Pendant BR Only •...

  • Page 38: Programming The Rf Transmitters (5800 Rf Systems)

    Compatible 5800 Series Transmitters (Continued) Enter As Input Model Product Device Type Description 5819 Shock Processor • Connects to externally mounted Transmitter inertia-type shock detector (not supplied). • Has built-in tampered cover switch. • Has 3 unique input (loop) codes: Loop 1: Terminals for a wired, N.C.

  • Page 39: Enrolling 5800 Transmitters Into The System

    24. RF HOUSE ID CODE The House ID identifies a 5827 or 5827BD Wireless keypad if it is used (enter 01–31). The wireless keypads should be set to the same ID. If no wireless keypad is to be used, leave as “00”. Enrolling 5800 Transmitters Into The System There are two methods that may be used to enroll transmitters.
  • Page 40 A display will appear, showing a summary of that zone's programming. ZN ZT – RC I n : L If the zone is not programmed, the display will appear as shown here. If 1 0 0 0 – 0 0 RF: 1 checking a zone's programming, and it is programmed satisfactorily, press [#] to back up one step and enter another zone number, if desired.
  • Page 41 The system will enroll the serial number of the first transmitter heard, 10 Input S/N: add the loop number entered to this serial number, display the serial A002-4064 and loop numbers, and cause the keypad to beep twice. If the serial and loop number combination is already present in the system, a single long beep will be heard from the keypad.

  • Page 42: To Either Temporarily Or Permanently Remove A Zone From The System (5800 System)

    To Either Temporarily Or Permanently Remove A Zone From The System (5800 System). 1. Enter the programming mode: Key Installer Code + 8 + 0 and press [ ][5][6]. 2. Enter the zone number and press [ ]. A summary display will appear. 3.

  • Page 43: Go/No Go Test Mode

    Go/No Go Test Before mounting transmitters permanently, conduct Go/No Go tests to verify (5700/5800 adequate signal strength and reorient or relocate transmitters if necessary. RF Systems) During this mode, wireless receiver gain is reduced by 50%. Testing in this mode assists in determining good mounting locations for the transmitters and verifies that the RF transmission has sufficient signal amplitude margin for the installed system.

  • Page 44: Section 7. Relay Outputs

    Section 7. RELAY OUTPUTS Relay Device Basics Relays are programmable switches that can be used to perform many different functions. They can be used to turn lights on and off, control sounders, or for status indications. In this system, each relay must be programmed as to how to act (ACTION), when to activate (START), and when to deactivate (STOP).

  • Page 45: Programming Options Defined

    4229 4229 RELAY RELAY DIP SWITCH CONNECTOR FOR SETTING ADDRESS AND ZONE “A” RESPONSE EITHER OR BOTH CAN BE USED TERMINALS ON RELAY CONTROL PANEL NO C NC 4-PIN CONSOLE PLUG GRN DATA OUT (TERM 6) TAMPER JUMPER POSITION TO CONTROL 4229 IN CABINET (–) GROUND (TERM 4)
  • Page 46 2. ZONE LIST (ZL) is a group of zones to which the “EVENT” applies in order to activate a particular relay. Note that there are a total of 3 zone lists that can be programmed in field 81 mode; when the selected EVENT (Alarm, Fault or Trouble) occurs in any zone in the selected “Start”...

  • Page 47: Programming Output Relays

    Programming Output Relays 1. With at least one 2-line Alpha keypad connected to the keypad terminals on the control, power up the system temporarily. If you had previously connected the AC transformer to the control panel, you need only plug in the transformer (to 120VAC outlet) to power up the system.

  • Page 48: Example Of Output Relay Programming

    CHOICES FOR ZONE TYPES 00 = Not Used 04 = Interior Follower 08 = 24 Hr Aux 01 = Entry/Exit #1 05 = Trouble Day/Alarm Night 09 = Fire 02 = Not used 06 = 24 Hr Silent 10 = Interior w/Delay 03 = Perimeter 07 = 24 Hr Audible CHOICES FOR SYSTEM OPERATION...
  • Page 49 Zone List Displays Upon keying 81, this screen will appear. Enter the Zone List Number 01, 02, Zone List No. or 03 to program (or 00 to end these entries). Press the [ ] key to advance. (00 = Quit) In the following displays, zone list 01 has been selected for programming.

  • Page 50: Section 8. Fa4285 Phone Module

    Phone Module. Installing the Phone Module General Information The FA4285 Phone Module is an add-on accessory for the FA142C that permits access to the security system via a Touch-tone phone (either on premises or by a call-in when away).

  • Page 51: Phone Module Wiring

    1. Make 12V (+) and (–) and data in and data out connections from the Phone Module to the control, using the connector cable supplied with the Phone Module (see Figure 12). Color Lead Terminal On Control * These are the same connections as GREEN DATA IN (terminal 6) those used for remote keypads...

  • Page 52: Figure 12. Fa4285 Phone Module Wiring Connections

    FA4285 WIRING NOTES: 1. Wire the FA4285 Phone Module exactly as shown, using a direct-connect cord and RJ31X jack. 2. If Touch-tones are not heard when pressing keys following phone access to the security system via an on-premises phone , try reversing the pair of wires connected to terminals 3 & 4 on the FA4285, and the pair of wires connected to terminals 17 &...

  • Page 53: Programming The Control For Phone Access

    Programming The Control For Phone Access 1. With at least one keypad (but set to the non-addressable mode, address 31) connected to the keypad terminals on the control, power up the system temporarily. If you had previously connected the AC transformer to the control panel, you need only plug in the transformer (to 120VAC outlet) to power up the system.

  • Page 54: Checking The Operation Of The Fa4285 Phone Module

    Checking the Operation of the FA4285 Phone Module To Check Phone Module Operation From an On-Premises Phone 1. Pick up phone and enter the programmed 2-digit phone code (entered in field 26, . Annunciation of a system status VOICE MODULE ACCESS CODE) report should automatically start.

  • Page 55: Section 9. External Sounders

    Section 9. EXTERNAL SOUNDERS This section provides a list of compatible sounders, connection information for an external sounder and programming procedures for those options that affect the operation of external sounders. Compatible Sounders Ademco AB-12M 10” Motor bell & box. UL Grade A. 100mA current Motorized Bell &...

  • Page 56: Sounder Connections

    This control complies with NFPA requirements for temporal pulse sounding of fire notification appliances. Temporal pulse sounding for a fire alarm consists of the following: 3 pulses – pause – 3 pulses – pause – 3 pulses. . . repeated. Sounder Connections The control provides a 12 VDC output which can power external alarm sounders (bells or sirens, see compatible sounders listed previously).

  • Page 57: Long Range Radio

    Section 11. LONG RANGE RADIO General Information If output to long range radio is selected, all messages that are programmed to go to the primary telephone line receiver will also be sent to the Ademco 7720PLUS or 7820 long range radio. These messages will be in Contact ID format (not affected by entry in field 46).

  • Page 58: Audio Alarm Verification (Aav) Unit

    Section 11. AUDIO ALARM VERIFICATION (AAV) UNIT General Information An Audio Alarm Verification (AAV) module, such as the Eagle 1241, is an add- on accessory that permits voice dialog between an operator at a central station and a person at the alarm installation, for the purpose of alarm verification. For UL installations, the AAV option cannot be used.

  • Page 59: Figure 15. Connection Of Aav Unit When Not Using An Fa4285 Phone Module

    INCOMING TELCO LINE DIRECT CONNECT CORD RJ31X RING PREMISES JACK ANSWERING MACHINE AND PLUG PHONES ANSWERING TERMINALS MACHINE ON CONTROL EARTH GROUND REFER TO AAV MODULE INSTRUCTIONS FOR CONNEC- TIONS TO AUDIO SPEAKERS AND MICROPHONE INPUT TRIGGER RING 4204 MODULE NOTE: DO NOT USE RELAY 1 FOR...

  • Page 60: Section 12. Final Power Up

    Section 12. FINAL POWER UP In previous sections, you made temporary power connections for the purpose of programming and testing. This section provides information about final power-up procedures and battery size calculations. Earth Ground Connections The designated earth ground terminal (21) must be terminated in a good earth ground for the lightning transient protective devices in this product to be effective.

  • Page 61: Auxiliary Device Current Draw Worksheet

    2. Attach the Red and Black wires on the battery connector cable as follows: a) Red to the positive (+) battery tab on the control board.* b) Black to the negative (–) battery tab on the control board.* This not required if wires were previously connected to the battery tabs on the control.

  • Page 62: Alpha Descriptor Programming

    Vocabulary list (on a following page) shown in boldface type. The Phone Module will not provide annunciation of the other words. If an FA4285 Phone Module is added to an existing FA142C system, the Alpha descriptors presently in the system should be re-programmed, selecting from those words shown in boldface type in the Alpha Vocabulary list.
  • Page 63 4. Press “0” (No).* Default Descriptor If a descriptor was not entered previously for zone 1, the default ZN 0 1 ZO NE 0 1 descriptor for zone 1 will be displayed. The procedure for adding custom words to the built-in vocabulary will be found later under “Adding Custom Words”.

  • Page 64: Adding Custom Words

    Press “6” to accept the selected ZN 0 1 B A CK word. DO O R Note: If these are the only words you are using for the descriptor, press “8” instead of “6” to save them Flashing Cursor if “6” is in memory.
  • Page 65 When adding Custom Words in steps 3–6, the keypad’s keys perform the following functions: [4] Moves cursor one space to left. [6] Selects desired letter; moves cursor one space to right. [8] Saves the new word in the system's memory. 3.

  • Page 66: Alpha Vocabulary List (For Entering Zone Descriptors)

    ALPHA VOCABULARY LIST (For Entering Zone Descriptors) NOTE : Some rarely-used words appearing in previously published lists have been deleted from this list. Use only this list for selecting zone descriptors. (Word Space) • 057 DOOR • 106 LAUNDRY • 059 DOWN RADIO VALVE...

  • Page 67: Sequential Mode (For 5800 Transmitters)

    Section 14. SEQUENTIAL MODE (for 5800 Series Wireless Transmitters) Use this mode only after all other zone information has been programmed, including transmitter loop numbers. There are two methods of enrolling – you can enroll each transmitter into the system as you are entering the zone information in field 56 (the procedure will be found in the WIRELESS (RF) ZONE EXPANSION section), or you can enroll all the transmitters in 83 menu mode after all other zone...
  • Page 68 5. This prompt is displayed when the system has found the next zone 10 Input S/N: which needs to be enrolled. Axxx xxxx The system will respond to the first serial number transmitted. A serial number may be enrolled by one of two methods: a) Enter the 7 digit serial number printed on the transmitter b) Activate the transmitter by faulting or restoring the input you wish to use for that zone (e.g., press a button, open or close a door, etc.).
  • Page 69 7. The system will search for the next zone that does not have a serial number associated with it. If one is found, the prompt in step 5, along with the appropriate zone number, will be displayed. Follow steps 5 and 6 for the remaining wireless zones.

  • Page 70: Section 15. System Communication

    Section 15. SYSTEM COMMUNICATION This section provides an explanation of formats this system accommodates for reporting alarms and other system conditions to the central station. The process of a successful transmission consists of both the method of communication between the control panel and the central station receiver and the actual way the information is sent and displayed at the central station.
  • Page 71 3+1/4+1 3+1/4+1 Report Standard Expanded Alarm SSS(S) A SSS(S) A SSSS AZ AAA(A) Z Trouble SSS(S) T SSS(S) T SSSS Tt TTT(T) t Bypass SSS(S) B SSS(S) B SSSS Bb BBB(B) b AC Loss SSS(S) E SSS(S) E SSSS EA C EEE(E) A C Low Batt SSS(S) L...

  • Page 72: Table Of Contact Id Event Codes

    TABLE OF CONTACT ID EVENT CODES Code Definition Code Definition Fire Alarm Exit Error Alarm Duress Trouble (Global) Alarm, 24-hour Silent RF Sensor Tamper Alarm, 24-hour Audible Panic RF Sensor Low Battery Alarm, Perimeter, Burg. O/C by User Alarm, Interior, Burg. Cancel by User Alarm, Entry/Exit, Burg.
  • Page 73 Press 45 PHONE SYSTEM SELECT Enter 1 digit (default = 0) If Central Station Receiver is not on WATS line: 0 = Pulse Dial, 1 = Tone Dial. If Central Station Receiver is on WATS line: 2 = Pulse Dial, 3 = Tone Dial. Press 46 REPORT FORMAT, PRIMARY/SECONDARY Determines which format is to be used to report to the central...
  • Page 74 1 2 3 4 – 9 1 1 – 0 0 4   Example 1. Pager displays: This indicates that Subscriber No. 1234’s system is reporting an Alarm (911), due to zone 4 being faulted (004). 1 2 3 4 – 0 0 1 – 0 0 5 Example 2.
  • Page 75 Press 62 AC LOSS REPORT CODE Reports with Subscriber No. Timing of this report is random with up to a 48-minute delay. The Restore report has a random delay of up to about 12 minutes. If AC restores before the report goes out, there is no AC restore report.
  • Page 76 Press 94 DOWNLOAD PHONE NUMBER Enter up to 12 digits; 0–9, # + 11 for “ ”, # + 12 for “#”, # + 13 for a pause. Do not fill unused spaces. End field by entering “ ”. To clear entries, press 94 .

  • Page 77: Section 16. Testing The System

    Section 16. TESTING THE SYSTEM Test Procedure After installation is completed, the System should be carefully tested, as follows: 1. With the System in the disarmed state, check that all zones are intact. If a NOT READY message is displayed, press the [ ] key to display the faulted zone(s).

  • Page 78: To The Installer

    TRANSMITTER SNIFFER MODE Make sure the system is disarmed before trying to enter this mode. Key Installer code + # + 3. This initiates a procedure that will check that all 5700 series transmitters have been properly programmed. Note: If the communicator is in the process of sending a report to the Central Station, the system will not go into the Sniffer mode.

  • Page 79: Section 17. System Operation

    Section 17. SYSTEM OPERATION Security Codes Installer Code The installer programs the 4-digit Installer Code initially as part of the programming procedure. The factory default Installer code is "4-1-1-1", but may be changed in field 20. Note: The Installer Code is defined as User #1. The Installer code is the only code that can allow re-entry into programming mode.

  • Page 80: Keypad Functions

    Keypad Functions General Note that if you enabled QUICK ARM (field 21), the [#] key can be pressed Information instead of entering the security code, for any of the arming procedures (Away, Stay, Instant, Maximum, etc.). The security code is always required, however, when disarming the system.

  • Page 81: Panic Keys

    Panic keys READY (shown lettered) AWAY STAY MAXIMUM TEST BYPASS INSTANT CODE CHIME First Alert READY Professional KP ALPHA KEYPAD The panic functions are identified by the system as follows: Important: Keys Displayed as Zone Notes: Silent Panic [1] &...

  • Page 82: Trouble Conditions

    Exit Alarm Displays • The " " display, etc. will also result if an alarm from an exit or EXIT ALARM (Continued) interior zone occurs within two minutes after the end of an exit delay. In any of the previous cases, use a second OFF sequence (code plus OFF key) to clear the keypad display.

  • Page 83: Section 18. Troubleshooting Guide

    Section 18. TROUBLESHOOTING GUIDE SYSTEM (including Wireless) SYMPTOM POSSIBLE CAUSE REMEDY 1. Transmitter signal not 1a. Transmitter or 4281/5881 not properly pow- Check or change transmitter's bat tery. received at 4281/5881. ered. Check the control's AC power. 1b. If Transmitter is 5827/5827BD , house ID 1b.

  • Page 84: Troubleshooting Guide

    2b. Telephone connection not secure. 2b. Check all connections. 2c. Digital communicator malfunctioning 2c. Check with a different FA142C. 2d. Telephone number in program needs prefix 2d. Program prefix or access code into the or access code.

  • Page 85: Contacting Technical Support

    (1200 – 9600 Baud, 8 Data Bits, 1 Start/Stop Bit, No Parity) ATLIS FAX – Automated Fax Retrieval System: 1–800–573–0153 1–516–921–6704/Ext. 1667 FIRST ALERT World Wide Web Page: HTTP//: WWW. FIRST ALERT. COM INTERNET E-Mail Address: First Alert_Tech_SPRT @ First Alert–165 . First Alert . com – 85 –...

  • Page 86: Specifications & Accessories

    Section 19. SPECIFICATIONS & ACCESSORIES Specifications FA142C 1. Physical: 12-1/2" W x 14-1/2" H x 3" D (318mm x 368mm x 76mm) SECURITY CONTROL 2. Electrical: VOLTAGE INPUT: 16.5VAC from plug-in 25VA transformer, Ademco No. 1321/TF2 (in U.S.A.) RECHARGEABLE BACK-UP BATTERY: 12VDC, 4AH (Gel type).
  • Page 87 200ft (60m) nominal indoors from wireless transmitters (the (5800 System) actual range to be determined with system in TEST mode). 5. Zones: (With the FA142C) 4281L: accepts up to 4 transmitters. 4281M or 4281H: accepts up to 8 transmitters. 5881L/5882L*: accepts up to 8 transmitters.

  • Page 88: Accessories (Compatible Devices)

    Accessories (Compatible Devices) Sounders Ademco AB-12M 10” Motor bell & box. UL Grade A. 100mA current Motorized Bell & Box draw. Ademco 1011BE12M 10” Motor bell & box. UL Listed. 100mA current Motorized Bell & Box draw. Ademco 702 Outdoor Self-contained 6–12 volt siren (driver built-in) Siren and weatherproof for outdoor use.

  • Page 89: Regulatory Agency Statements

    REGULATORY AGENCY STATEMENTS FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 15 STATEMENT This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your information: This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception.
  • Page 90 UL NOTICES 1. This is a "Grade A" residential system. 2. The 4285 Phone module and 7720PLUS or 7820 Long Range Radios have not been UL tested and cannot, therefore, be used in a UL installation. 3. The Entry Delay (field 38) cannot be greater than 45 seconds (set to 3 or less) for UL installations.
  • Page 91 CANADIAN DEPARTMENT OF COMMUNICATIONS (DOC) STATEMENT NOTICE The Canadian Department of Communications label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company.

  • Page 92: Limitations Of This Alarm System

    WARNING! THE LIMITATIONS OF THIS ALARM SYSTEM While this System is an advanced design security system, it does not offer guaranteed protection against burglary, fire or other emergency. Any alarm system, whether commercial or residential, is sub ject to compromise or failure to warn for a variety of rea sons.
  • Page 93 BATTERY FUSE THESE OPTIONAL ITEMS SET UNIT’S DIP (e.g. ADEMCO No. 90-12) MAY ALSO BE USED GEL LEAD ACID TYPE. ADEMCO No. 4219 SWITCH FOR REPLACEMENT SEE THEIR INSTRUCTIONS WIRED EXPANSION MODULE FOR DEVICE ADDRESS BATTERY NORMALLY NEED NOT BE USE SAME VALUE (8 ADD'L EOLR WIRED ZONES) OF “1”...

  • Page 94: Limited Warranty

    Pittway Corporation, and its divisions, subsidiaries and affiliates ("Seller"), 165 Eileen Way, Syosset, New York 11791, warrants its First Alert Professional products to be in conformance with its own plans and specifications and to be free from defects in materials and workmanship under normal use and...
