  • Page 1 ™ AVENGER UNDERCOUNTER DISHMACHINE SERIES INSTALLATION/OPERATION & TECHNICAL MANUAL FOR JACKSON MODELS: ™ ™ Avenger ™ ™ Avenger Jackson MSC LLC. P.O. BOX 1060 HWY. 25E BARBOURVILLE, KY. 40906 September 18, 2009 PHONE (606) 523-9795 FAX (606) 523-9196 P/N 7610-003-34-01 (Revision D)

  • Page 2: Manufacturers Warranty

    The warranty registration card supplied with the machine must be returned to Jackson MSC within 30 days to validate the warranty. REPLACEMENT PARTS WARRANTY Jackson replacement parts are warranted for a period of 90 days from the date of installation or 180 days from the date of shipment from the factory, which ever occurs first.
  • Page 3 STOP! PARE! ARRET! CALL 1-888-800-5672 TO REGISTER THIS PRODUCT! FAILURE TO DO SO WILL VOID THE WARRANTY! LLAME AL 1-888-800-5672 PARA REGISTRAR ESTE PRODUCTO! AL NO HACERLO LA GARANTIA SERA ANULADA! S.V.P . APPELER 1-888-800-5672 POUR ENREGISTRER CE PRODUIT, LA GARANTIE SERA ANNULEE POUR TOUT PRODUIT NON- ENREGISTREE...
  • Page 4 Changed schematics to new color scheme 08-06-07 7930 Updated AvengerHT Incoming plumbing assembly. 10-07-07 PROCESS Added Avenger LTH designation. Added 480 Volt Avenger HT. 11-20-07 Process Corrected 480 Volt Avenger HT components. Updated installation instructions. Replaced LTH with LT designa- PG 47 & 48...
  • Page 5 Detergent & rinse aid chemical feeder pumps. Avenger™LT = Low temperature, chemical sanitizing, no booster tank. Detergent, rinse aid & sanitizer chemical feeder pumps. Jackson MSC LLC. provides technical support for all Model: of the dishmachines detailed in this manual. We strongly recommend that you refer to this manual Serial No.:...

  • Page 6: Table Of Contents

    Stands, 6” & 18” HTS-11 Scale Prevention and Corrosion Control Device Go*Box Kit Vacuum Switch Assembly SCHEMATICS Avenger™HT 208-230V, 60 HZ, single phase Avenger™HT 460V, 60 HZ, single phase Avenger™LT 115V, 60 HZ, single phase VII. JACKSON MAINTENANCE & REPAIR CENTERS...

  • Page 7: Specification Information

    SECTION 1: SPECIFICATION INFORMATION...
  • Page 8 SECTION 1: SPECIFICATION INFORMATION SPECIFICATIONS of the AVENGER™HT PERFORMANCE/CAPABILITIES ELECTRICAL REQUIREMENTS OPERATING CAPACITY (RACKS/HOUR) WASH MOTOR HP RACKS PER HOUR NOTE: Typical Electrical Circuit is based upon (1) 125% of the DISHES PER HOUR full amperage load of the machine and (2) typical fixed-trip cir- cuit breaker sizes as listed in the NEC 2002 Edition.

  • Page 9: Specifications Avenger™Lt

    SECTION 1: SPECIFICATION INFORMATION SPECIFICATIONS of the AVENGER™LT ELECTRICAL REQUIREMENTS PERFORMANCE/CAPABILITIES WASH MOTOR HP OPERATING CAPACITY (RACKS/HOUR) RACKS PER HOUR NOTE: Typical Electrical Circuit is based upon (1) 125% of the DISHES PER HOUR full amperage load of the machine and (2) typical fixed-trip cir- cuit breaker sizes as listed in the NEC 2002 Edition.

  • Page 10: Dimensions Avenger™Ht

    SECTION 1: SPECIFICATION INFORMATION Avenger™HT DIMENSIONS WALL LEGEND: 1 9 16 [40mm] 4 [6mm] A - Water Inlet - 1/2" Female Pipe Thread, 2 1/2" AFF (Connect to a true 1/2" ID 1 1 4 [32mm] water line) Minimum Wall Clearance B - Electrical Connection 25 3 8 [644mm] 23 3 4 [604mm]...

  • Page 11: Dimensions Avenger™Lt

    SECTION 1: SPECIFICATION INFORMATION Avenger™LT DIMENSIONS WALL LEGEND: [40mm] 4 [6mm] A - Water Inlet - 1/2" Female Pipe Thread, 2 1/2" AFF (Connect to a true 1/2" ID 1 1 4 [32mm] water line) Minimum Wall Clearance B - Electrical Connection 25 3 23 3 4 [604mm] [644mm]...

  • Page 12: Installation/Operation Instructions

    SECTION 2: INSTALLATION/OPERATION INSTRUCTIONS...

  • Page 13: Installation Instructions

    UNPACKING THE DISHMACHINE: Once the machine has been removed from the container, ensure that there are no miss- ing parts from the machine. This may not be obvious at first. If it is discovered that an item is missing, contact Jackson imme- diately to have the missing item shipped to you.

  • Page 14: Electrical Installation Instructions

    ELECTRICAL INSTALLATION INSTRUCTIONS PRESSURE REGULATOR: Jackson has provided a water pressure regulator due to areas where the water pressure fluctu- ates or is lower than the recommended pressure. In some cases, you many not need the regulator and in those cases, the reg- ulator may be removed.

  • Page 15: Chemical Dispensing Equipment

    SECTION 2: INSTALLATION/OPERATION INSTRUCTIONS CHEMICAL DISPENSING EQUIPMENT WARNING: CHLORINE-BASED SANITIZERS CAN BE DETRIMENTAL TO YOUR MACHINE IF THE CHEMICAL SOLUTION IS TOO STRONG. SEE YOUR CHEMICAL PROFESSIONAL TO ENSURE YOUR DISPENSER IS SET UP CORRECTLY. This equipment is not recommend for use with deionized water or other aggressive fluids. Use of deionized water or other aggressive fluids will result in corrosion and failure of materials and components.

  • Page 16: Programming Instructions For Chemical Feeder Pumps

    SECTION 2: INSTALLATION/OPERATION INSTRUCTIONS PROGRAMMING INSTRUCTIONS FOR CHEMICAL FEEDER PUMPS (FOR INSTALLATION TECHNICIAN ONLY) To access the programming mode, the machine must be ON, and idle (between cycles). On the timer board, press and hold both the MOVE and ENTER buttons on the timer board simultaneously for two seconds. The PROGRAM (PGM) light and light A will illuminate.

  • Page 17: Detergent Control

    If the water cannot get hot enough, your results may not be satisfactory. This is why Jackson recommends that if you have installed the machine in an area with hard water, that you also install some type of water treatment equipment to help remove the dissolved solids from the water before it gets to the dishmachine.

  • Page 18: Operation Instructions

    SECTION 2: INSTALLATION/OPERATION INSTRUCTIONS OPERATION INSTRUCTIONS PREPARATION: Before proceeding with the start-up of the unit, verify the following: 1. The strainer is in place and is clean. 2. That the wash and rinse arms are screwed securely into place and that their endcaps are tight. The wash and rinse arms should rotate freely.
  • Page 19 NOTE: If this machine is equipped with a HTS-11, scale prevention and corrosion control device, and lime is becoming a fre- quent problem, the cartridge needs to be replaced. To order a replacement cartridge, call Jackson immediately to have one shipped to you.

  • Page 20: Preventative Maintenance

    SECTION 3: PREVENTATIVE MAINTENANCE...

  • Page 21: Preventative Maintenance

    The dishmachines covered in this manual are designed to operate with a minimum of interaction with the operator. However, this does not mean that some items will not wear out in time. Jackson highly recommends that any maintenance and repairs not specifically discussed in this manual should be performed by QUALIFIED SERVICE PERSONNEL ONLY.

  • Page 22: Troubleshooting

    SECTION 4: TROUBLESHOOTING...
  • Page 23 SECTION 4: TROUBLESHOOTING SECTION COMMON PROBLEMS WARNING: Inspection, testing and repair of electrical equipment should be performed only by qualified service per- sonnel. Certain procedures in this section require electrical tests or measurements while power is applied to the machine. Exercise extreme caution at all times. If test points are not easily accessible, disconnect power, attach test equipment and reapply power to test.
  • Page 24 SECTION 4: TROUBLESHOOTING SECTION COMMON PROBLEMS WARNING: Inspection, testing and repair of electrical equipment should be performed only by qualified service per- sonnel. Certain procedures in this section require electrical tests or measurements while power is applied to the machine. Exercise extreme caution at all times. If test points are not easily accessible, disconnect power, attach test equipment and reapply power to test.

  • Page 25: Parts Section

    SECTION 5: PARTS SECTION...

  • Page 26: Control Panel Weldment Assemblies

    SECTION 5: PARTS SECTION CONTROL PANEL WELDMENT ASSEMBLIES Avenger™HT Complete Control Panel Assembly Bushing, Snap Complete Control Panel 05975-003-35-21 Weldment Assembly Screw, 10-32 x 1” Avenger™HT Relay, 240V (4 per Asm) 05700-003-31-47 05945-111-89-75 05305-002-19-42 Screw, 6-32 x 3/8 05305-002-25-91 Control Panel Weldment 05700-003-31-48 Locknut, 10-24 w/ P Clamp 1/4”...

  • Page 27: Control Panel Weldment Assemby, Avenger™Ht 460 Volt

    SECTION 5: PARTS SECTION AVENGER™HT 480V CONTROL PANEL ASSEMBLY ITEM DESCRIPTION Mfg. No. Electrical Panel Weldment 05700-003-37-46 Timer Bracket Assembly 05700-003-36-05 Timer, Univeral 05945-003-33-09 Relay 05945-002-47-41 Terminal Board 05940-021-94-85 Track, Terminal Block 05700-003-37-49 Fuse Holder 05920-011-72-89 Fuse, 1/4 AMP 05920-002-75-95 Contactor 05945-111-60-07 Overload...

  • Page 28: Control Panel Assembly/Kick Panel Weldment, Avenger™Ht

    SECTION 5: PARTS SECTION CONTROL PANEL ASSEMBLY/KICK PANEL WELDMENT - AVENGER™HT Complete Control Panel Assembly To order the wire harness use 05700-003-31-64 number: 05999-003-34-61. ITEM DESCRIPTION Mfg. No. Control Panel 09330-003-31-66 Decal, Control Panel 09905-003-31-65 Locknut, 1/4”-20 S/S Hex w/Nylon Insert 05310-374-01-00 Thermometer, 48”...

  • Page 29: Control Panel Assembly/Kick Panel Weldment, Avenger™Lt

    SECTION 5: PARTS SECTION CONTROL PANEL ASSEMBLY/KICK PANEL WELDMENT - AVENGER™LT Complete Control Panel Assembly To order the wire harness use 05700-003-34-23 number: 05999-003-34-62. D - Detergent S - Sanitizer R - Rinse Aid ITEM DESCRIPTION Mfg. No. Control Panel 09330-041-73-90 Decal, Control Panel 09905-031-73-95...

  • Page 30: Terminal Block Box Assembly

    SECTION 5: PARTS SECTION TERMINAL BLOCK BOX ASSEMBLY Terminal Block Track 05700-000-43-60 Decal, Power Connections Locknut, 10-24 S/S Hex w/ 09905-011-47-35 Nylon Insert 05310-373-01-00 Terminal Block Terminal Block Box (2 Per) (3 per 480V) 05700-003-27-69 05940-500-02-19 Terminal Block Box Cover (Not Shown) 05700-003-27-70 Screw, 10-32 x 1/2”...

  • Page 31: Chemical Feeder Pump Assembly, Avenger™Ht

    SECTION 5: PARTS SECTION CHEMICAL FEEDER PUMP ASSEMBLY - AVENGER™HT Complete Chemical Feeder Pump Assembly 05700-003-32-03 15, 16 See page 39 for indi- vidual peri pump com- ponents. A B C D A B C D Avenger™ Series Technical Manual 7610-003-34-01 Issued: 10-07-2007 Revised: N/A...
  • Page 32 SECTION 5: PARTS SECTION CHEMICAL FEEDER PUMP ASSEMBLY - AVENGER™HT (CONTINUED) ITEM DESCRIPTION Mfg. No. Peri Pump Plate Weldment 05700-003-33-48 Detergent Feeder Pump, (Red Roller) 36RPM, 240V 05700-002-72-49 Motor, 36 RPM 115V (480V Machine) 04320-111-35-14 Rinse Aid Feeder Pump, (Black Roller), 14RPM, 240V 05700-002-72-48 Motor, 14 RPM 115V (480V Machine) 04320-111-35-13...

  • Page 33: Chemical Feeder Pump Assembly, Avenger™Lt

    SECTION 5: PARTS SECTION CHEMICAL FEEDER PUMP ASSEMBLY - AVENGER™LT Avenger™ Series Technical Manual 7610-003-34-01 Issued: 10-07-2007 Revised: N/A...
  • Page 34 SECTION 5: PARTS SECTION CHEMICAL FEEDER PUMP ASSEMBLY - AVENGER™LT (CONTINUED) ITEM DESCRIPTION Mfg. No. Peri Pump Plate Channel 05700-003-53-25 Switch, Pressure 06685-003-36-13 Bracket, Pressure Switch 05700-003-53-03 Locknut, 10-24 W/Nylon Insert 05310-373-01-00 Motor, 36 RPM 115V 04320-111-35-14 Motor, 14 RPM 115V 04320-111-35-13 Peri Pump Kit (Black Roller) 04320-002-87-63...

  • Page 35: Chemical Feeder Pump Components

    SECTION 5: PARTS SECTION CHEMICAL FEEDER PUMP COMPONENTS Rear Housing Screw, 8-32 x 3/8” Phillips Pan Head Screw, 8-32 x 1/2” Phillips Flat Head 04320-111-37-09 2 per 2 per 05305-011-37-07 05305-011-37-06 Screw, 6-32 x 3/4” Phillips Pan Head 4 per 05305-011-37-05 Front Housing 04320-111-37-08...

  • Page 36: Incoming Plumbing Assembly, Avenger™Ht

    SECTION 5: PARTS SECTION PLUMBING ASSEMBLIES - AVENGER™HT Plug, 1/4” Brass Valve, Check Vacuum Plumbing Assembly 2 per machine 04820-111-51-14 05700-003-32-14 04730-209-01-00 Injector Weldment 05700-031-41-83 Fitting, Outlet Elbow 04820-111-51-18 Injector Assembly Nut, P/P for 1/8” Tubing 05700-003-22-01 04730-011-59-45 Vacuum Breaker 04820-003-06-13 Bushing, 1/4 x 1/8 SS (Not Shown)

  • Page 37: Incoming Plumbing Assembly, Avenger™Lt

    SECTION 5: PARTS SECTION PLUMBING ASSEMBLIES - AVENGER™LT Connects to 45 Deg. Elbow Plate, Rinse Weldment Gasket, Rinse Injector Hose, 3/4” x 11” 05700-011-82-73 05330-111-42-81 05700-003-29-68 Clamp, Hose 04730-719-06-09 Locknut, 1/4”-20 S/S Hex w/Nylon Insert 05310-374-01-00 Plate, Deflector 05700-002-62-49 Plate, Rinse 05700-011-82-86 Complete Incoming Plumbing Assembly...

  • Page 38: Solenoid Valve Repair Kit/Vacuum Breaker Repair Kit

    SECTION 5: PARTS SECTION RINSE SOLENOID VALVE & VACUUM BREAKER REPAIR PARTS KITS/WATER HAMMER ARRESTOR KIT OPTION Screw Data Plate Cap Screw Coil & Housing Data Plate Valve Bonnet Spring & Plunger Kit 06401-003-07-40 Spring position is moved for clarity. Goes below the plunger.

  • Page 39: Wash Motor/Drain Plumbing Assembly

    SECTION 5: PARTS SECTION WASH MOTOR/DRAIN PLUMBING/ AVENGER™LT WASH MANIFOLD ASSEMBLY Area within this box is an overall view of the Avenger™LT wash manifold assembly. For the Avenger™LT replace item 1 below with this manifold. See Motor and Pump Assembly Page Ball Valve Assembly AVENGER™LT 115V &...
  • Page 40 SECTION 5: PARTS SECTION WASH MOTOR / DRAIN PLUMBING/ AVENGER™LT WASH MANIFOLD ASSEMBLY ITEM DESCRIPTION Mfg. No. Hub, Discharge Machined (Avenger™HT Shown) 05700-021-37-90 Lower Wash Manifold (Avenger™LT) 05700-021-52-80 Gasket, Manifold 05330-200-23-00 Nut, Jam 1 1/2”-12 NPT 05700-000-86-23 Hose Clamp, 1 5/16" - 2 1/4", #28 04730-719-01-37 Hose,1 1/4”...

  • Page 41: Motor & Pump Assembly

    SECTION 5: PARTS SECTION MOTOR & PUMP ASSEMBLY Complete Pump & Motor Assembly, 480V 60HZ, With Complete Pump & Motor Assembly, 60 HZ, With Bracket Bracket 05700-003-31-57 05700-003-52-80 Complete Pump & Motor Assembly, 60 HZ, No Bracket Complete Pump & Motor Assembly, 480V 60 HZ, No 06105-002-72-75 Bracket 06105-003-52-78...

  • Page 42: Rinse Arm & Wash Arm Assemblies

    SECTION 5: PARTS SECTION RINSE ARM & WASH ARM ASSEMBLIES Plug, Rinse Arm 04730-609-04-00 Rinse Arm Assembly (AVENGER™HT units only) 2 per Asm. 05700-031-39-21 Rinse Arm 05700-031-38-30 Bearing 03120-002-72-24 Bushing, Rinse Head 05700-021-33-84 Washer, Rinse Arm 05330-011-42-10 Ring, Retaining 05340-112-01-11 O-ring (Not Shown) 05330-002-60-69 Wash Arm Assembly...

  • Page 43: Thermostat & Rinse Tank Assembly

    SECTION 5: PARTS SECTION AVENGER™HT THERMOSTAT & RINSE TANK ASSEMBLY Thermostat 05930-003-06-48 Complete Rinse Tank Assembly Rinse Tank Weldment (AVENGER™HT 208-230V) 05700-003-31-95 05700-003-31-94 Complete Rinse Tank Assembly (AVENGER™HT 480V) 05700-003-37-78 Fitting, 1/4” Imperial Brass 05310-924-02-05 Locknut, 1/4”-20 S/S Hex with Nylon Insert Gasket, Heater 05310-374-01-00 05330-011-47-79...
  • Page 44 SECTION 5: PARTS SECTION AVENGER™LT THERMOSTAT & HEATER COMPONENTS Wash Thermostat 05930-003-13-65 Heater, Fire Bar 04540-003-46-27 Insulation Paper, 1/8” 04540-003-46-30 Heater Cover Plate 05700-003-46-37 Hi Limit Thermostat 06685-003-46-77 Avenger™ Series Technical Manual 7610-003-34-01 Issued: 10-07-2007 Revised: N/A...

  • Page 45: Door Assembly

    SECTION 5: PARTS SECTION DOOR ASSEMBLY Complete Door Assembly 05700-003-32-09 Avenger™ Series Technical Manual 7610-003-34-01 Issued: 10-07-2007 Revised: N/A...
  • Page 46 SECTION 5: PARTS SECTION DOOR ASSEMBLY (CONTINUED) ITEM DESCRIPTION Mfg. No. Outer Door Weldment 05700-003-33-37 Inner Door 05700-003-33-21 Door Handle 05700-003-26-62 Bolt, 1/4”-20 x 3/8" Long 05305-274-20-00 Channel, Right Seal 05700-003-33-19 Channel, Left Seal 05700-003-33-20 Channel, Top Seal 05700-003-33-22 Screw, 10-32 x 1/2” Pan Phillips Head 05305-011-44-52 Baffle, door 05700-003-33-38...

  • Page 47: Miscellaneous Door Components

    SECTION 5: PARTS SECTION MISCELLANEOUS DOOR COMPONENTS Door Switch & Bracket Assembly 05700-003-32-21 Door Switch Bracket Door Switch 05700-003-31-43 05930-003-31-44 Switch Mounting Plate Assembly 05700-003-33-54 Hardware: Locknut, 6-32 S/S Hex with Nylon Insert Door Spring 05310-373-03-00 05700-003-32-85 Screw, 6-32 x 1/4” Flat Head 05305-171-01-00 HInge Stop Assembly Right (Shown): 05700-003-32-61...

  • Page 48: Frame & Panel Components

    SECTION 5: PARTS SECTION FRAME & PANEL COMPONENTS W-Top Shroud W-Right Shroud 05700-003-37-06 05700-003-37-05 Shroud Plug (2 per unit) 05700-003-32-50 Optional Back Panel Standard Back Panel 05700-003-33-55 05700-003-36-35 W-Left Shroud 05700-003-37-04 Hardware: Nut, 1/4”-20 Serrated Hex (4 per Asm) 05310-011-66-49 Nut, 5/16”-18 Cad Spline (4 per Asm) 05310-959-03-00 The swivel feet used...

  • Page 49: Miscellaneous Parts

    SECTION 5: PARTS SECTION MISCELLANEOUS PARTS Rail, Left Rack 05700-031-37-89 Rail, Right Rack 05700-031-37-88 Components secured with: Locknut, 1/4”-20 S/S Hex with Nylon Insert 05310-374-01-00 Splash Shield 05700-003-33-51 Strainer Weldment Strainer Spacer 05700-003-32-81 05700-001-35-83 Attaches with: Nut, Nylon Wing, 1/4”-20 05310-994-01-00 Avenger™...

  • Page 50: Stands, 6" & 18

    SECTION 5: PARTS SECTION STANDS & COMPONENTS Installation Instructions: To install the stand, first remove the adjustable feet from the machine. Place machine on table and use the square mounting holes to line up the machine. Re-insert adjustable feet through bottom of table top and tighten to lock machine to table.

  • Page 51: Hts-11 Scale Prevention And Corrosion Control Device

    SECTION 5: PARTS SECTION HTS-11 (SCALE PREVENTION & CORROSION CONTROL DEVICE) Replacement Cartridge Kleenware HTS-11 System (Inspect at least every 6 months) 04730-003-28-03 04730-003-28-04 The HTS-11 must be installed vertically. The provided bracket is to be secured to the wall. Observe proper Replacement Test Strip inlet/outlet water directions.

  • Page 52: Go*Box Kit

    SECTION 5: PARTS SECTION GO BOX KIT A GO*Box is a kit of the most needed parts for a particular model or model family to successfully effect a repair in the first call 90% or more of the time. The following components may be ordered together using 06401-003-35-26 ITEM DESCRIPTION Mfg.

  • Page 53: Vacuum Switch Assembly

    SECTION 5: PARTS SECTION VACUUM SWITCH ASSEMBLY 4, 5 ITEM DESCRIPTION Mfg. No. Complete Assembly 05700-003-55-98 Box, Vacuum Switch 05700-003-55-96 Harness, Vacuum Switch 05700-003-55-97 Fitting, .231 x .394 Liquid Tite 05975-011-49-03 Switch, Pressure 06685-003-36-13 Bracket, Pressure Switch 05700-003-53-03 Locknut, 10-32 S/S Hex w/ Nylon Insert 05310-373-02-00 Screw, 10-32 x 3/8”...
  • Page 54 SECTION 5: PARTS SECTION VACUUM SWITCH ASSEMBLY INSTALLATION Remove locknut on plumbing support brkt. and mount switch box over existing stud. Re-install brkt. and route red and white tubes behind blue hose as shown. Route gray cable down back and under tub along inlet plumbing, remove wires from existing pressure switches and connect to gray cable per note below.
  • Page 55 SECTION 6: ELECTRICAL SCHEMATICS...

  • Page 56: Avenger™Ht 208-230V, 60 Hz, Single Phase

    SECTION 6: ELECTRICAL SCHEMATICS Avenger ™ HT 208-230 VOLT - 60 HERTZ - SINGLE PHASE Avenger™ Series Technical Manual 7610-003-34-01 Issued: 10-07-2007 Revised: N/A...

  • Page 57: Avenger™Ht 460V, 60 Hz, Single Phase

    SECTION 6: ELECTRICAL SCHEMATICS Avenger ™ HT 480 VOLT - 60 HERTZ - THREE PHASE Avenger™ Series Technical Manual 7610-003-34-01 Issued: 05-02-2007 Revised: 10-07-2007...

  • Page 58: Avenger™Lt 115V, 60 Hz, Single Phase

    SECTION 6: ELECTRICAL SCHEMATICS Avenger ™ LT 115 VOLT - 60 HERTZ - SINGLE PHASE Avenger™ Series Technical Manual 7610-003-34-01 Issued: 05-02-2007 Revised: 10-07-2007...
  • Page 59 SECTION 7: JACKSON MAINTENANCE & REPAIR CENTERS...

  • Page 60: Jackson Maintenance & Repair Centers

    SECTION 7: JACKSON MAINTENANCE & REPAIR CENTERS ALABAMA TO FLORIDA ALABAMA CALIFORNIA P & D APPLIANCE GCS SERVICE INC. 4220-C ROSEVILLE ROAD PHILADELPHIA, PA JONES-McLEOD APPLIANCE BARKERS FOOD MACHINERY NORTH HIGHLANDS, CA (215)925-6217 SERVICES 95660 800-441-9115 1616 7TH AVE. NORTH...
  • Page 61 SECTION 7: JACKSON MAINTENANCE & REPAIR CENTERS FLORIDA TO MARYLAND JONES-McLEOD APPLIANCE HAWAII INDIANA CERTIFIED SERVICE CENTER 854 LAKESIDE DRIVE FOOD EQMT. PARTS & GCS SERVICE INC. 1051 GOODWIN DRIVE MOBILE, AL 36693 SERVICE CO. INDIANAPOLIS, IN LEXINGTON, KY 40505 (251) 666-7278 300 PUUHALE RD.
  • Page 62 SECTION 7: JACKSON MAINTENANCE & REPAIR CENTERS MARYLAND TO NEW YORK EMR SERVICE DIVISION MICHIGAN GCS SERVICE INC. NEW HAMPSHIRE 106 WILLIAMSPORT CIRCLE ST. LOUIS, MO SALISBURY, MD 21804 GCS SERVICE INC. (314) 638-7444 GCS SERVICE INC. (410) 543-8197 LIVONIA, MI...
  • Page 63 SECTION 7: JACKSON MAINTENANCE & REPAIR CENTERS NEW YORK TO PENNSYLVANIA B.E.S.T. INC. AUTHORIZED APPLIANCE OHIO OREGON 3003 GENESEE STREET SERVICECENTER BUFFALO, NY 14225 904 S. MARSHALL ST. CERTIFIED SERVICE CENTER RON'S SERVICE (716) 893-6464 WINSTON-SALEM, NC 27403 890 REDNA TERRACE...
  • Page 64 SECTION 7: JACKSON MAINTENANCE & REPAIR CENTERS RHODE ISLAND TO WISCONSIN RHODE ISLAND WHALEY FOODSERVICE GCS SERVICE INC. GCS SERVICE INC. REPAIRS HOUSTON, TX VIRGINIA BEACH, VA GCS SERVICE INC. 4740-A FRANCHISE STREET (713)785-9187 (757) 464-3500 EAST PROVIDENCE, RI N. CHARLESTON, SC 29418...
  • Page 65 SECTION 7: JACKSON MAINTENANCE & REPAIR CENTERS WISCONSIN TO WYOMING/INTERNATIONAL GENERAL PARTS, INC. W223 N735 SARATOGA DRIVE WAUKESHA, WI 53186 (262) 650-6666 (800) 279-9946 (262) 650-6660 FAX WYOMING HAWKINS COMMERCIAL APPLIANCE SERVICE 3000 S. WYANDOT ST. ENGLEWOOD, CO 80110 (303) 781-5548...
