Vertex Standard VXR-7000 Service Manual page 106

Display Unit
Parts List
REF. DESCRIPTION
R 5009 CHIP RES.
R 5010 CHIP RES.
R 5011 CHIP RES.
R 5012 CHIP RES.
R 5013 CHIP RES.
R 5014 CHIP RES.
R 5015 CHIP RES.
R 5016 CHIP RES.
R 5017 CHIP RES.
S 5001 TACT SWITCH
S 5002 TACT SWITCH
X 5001 XTAL HC-49/U.2S
LCD HOLDER
LIGHT GUIDE
REFLECTOR SHEET
DIFFUSER SHEET
INTER CONNECTOR
SPONGE RUBBER
LED SPACER
LED SPACER
106
VALUE V/W TOL.
1M 1/16W 5%
47k 1/16W 5%
470 1/4W 5%
470 1/4W 5%
330 1/16W 5%
10k 1/16W 5%
47k 1/16W 5%
10 1W 5%
10k 1/16W 5%
2.4576MHz
MFR'S DESIG VXSTD P/N
RMC1/16 105JATP J24185105
RMC1/16 473JATP J24185473
RMC1/4 471JATP J24245471
RMC1/4 471JATP J24245471
RMC1/16 331JATP J24185331
RMC1/16 103JATP J24185103
RMC1/16 473JATP J24185473
RMC1 100JTE J24305100
RMC1/16 103JATP J24185103
EVQ-333 H=5.0(TAPE) N5090046
EVQ-333 H=5.0(TAPE) N5090046
2.4576MHZ H0103166
RA0014900
RA0013200
RA0013500
RA0013600
RA0013700
R7130200
LH-5-4 S6000237
LH-5-2 S6000235
VERS. LOT. SIDE LAYADR
1- B d1
1- A C1
1- B e1
1- B e1
1- B d2
1- B d2
1- B c2
1- B e2
1- B c2
1- A E1
1- A E2
1- B d1
1-
1-
1-
1-
1-
1-
1-
1-
