- Page 1 Oper ator ′ s manual Please read the oper ator’s manual carefully and make sure you understand the instructions before using the machine. FR 2218A 4X4 FR 2216MA 4X4 FR2216A2 4X4...
-
Page 2: Table Of Contents
CONTENTS Contents Ignition system ............. Check the safety system ..........CONTENTS Main fuse ..............Contents ..............Checking the tyre pressure .......... INTR ODUCTION Checking the engine’s cooling air intake ...... Dear Customer , ............Checking and adjustment of the cutting unit’s ground Driving and transport on public roads ...... -
Page 3: Intr Oduction
Dear Customer , Thank y ou for choosing a Jonsered Frontrider. Jonsered Frontriders are built to a unique design with a front-mounted cutting unit and a patented rear-wheel steering system. FrontRiders are designed for maximum efficiency even in small or confined areas. The closely grouped controls and pedal-operated hydrostatic transmission also contribute to the performance of this machine. -
Page 4: Good Service
INTR ODUCTION Good ser vice Jonsereds products are sold all o ver the world and only through servicing dealers. This is to ensure that you, the customer, get the best support and service. For example, before this machine was delivered it was inspected and adjusted by your dealer. See the certificate in the Service Journal in this manual. -
Page 5: Ser Vice Journal
Ser vice journal Pre-deliver y service 1 1a. Dry-charged battery (506788801) Fill the battery with battery acid and charge for 4 hours at max. 6 amp. 1b. Wet-charged battery (510138501) Charge the battery for 4 hours at max. 3 amp. 2 Fit steering wheel, seat and any optional equipment. -
Page 6: Key To Symbols
KEY T O SYMBOLS Symbols Ignition These symbols are on the machine and in the instr uctions. Hydrostatic freewheel WARNING! Careless or incorrect use can result in serious or fatal injury to the operator or others. Clutch in Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. - Page 7 KEY T O SYMBOLS Star ting instructions Check the engine’s oil level Check the hydrostat’s oil level Lift up the cutting unit Apply and lock the parking brake. If the engine is cold, use the choke Release the parking brake before driving Switch off the engine and take off the ignition cable before repairs or maintenance –...
-
Page 8: Safety Instr Uctions
SAFETY INSTR UCTIONS Saf ety instructions • Look out for the ejector and do not direct it towards anyone. These instr uctions are for your safety. Read them carefully. • Stop the engine and prevent it from starting before you clean the cutting unit. -
Page 9: Driving On Slopes
SAFETY INSTR UCTIONS This is what y ou do • Never allow children or other persons not trained in the use of the machine to use or service it. Local laws may • Remove obstacles such as stones, branches, etc. regulate the age of the user. -
Page 10: Children
SAFETY INSTR UCTIONS • Follow the manufacturer’s recommendations regarding • Petrol and petrol fumes are poisonous and extremely wheel weights or counterbalance weights to increase flammable. Be especially careful when handling petrol, as machine stability. carelessness can result in personal injury or fire. •... -
Page 11: Transport
SAFETY INSTRUCTIONS Transport • Make sure all nuts and bolts are tightened correctly and that the equipment is in good condition. • Do not modify safety equipment. Check regularly to be IMPORTANT INFORMATION sure it works properly. The machine must not be driven if protective plates, protective covers, safety switches or The parking brake is not sufficient to lock the machine other protective devices are not fitted or are defective. -
Page 12: What Is What
WHAT IS WHAT? Location of the controls 1 Choke control, FR2216 A2 4X4 9 Lock button for parking brake 2 Throttle control/choke control 10 Seat adjustment. FR 2216MA 4X4, FR 2218A 4X4 3 Ignition lock 11 Seat adjustment. FR 2216A2 4X4 4 Cutting height adjustment lever 12 Lever to disengage the driving front axle 5 Lifting lever for the cutting unit... -
Page 13: Presentation
PRESENTATION Presentation Choke control, FR2216 A2 4X4 Congratulations on your choice of an excellent quality product The choke lever is used for cold starting and to give the that will give you great pleasure for many years. Three models engine a richer fuel mixture. equipped with four-wheel drive and engines from Briggs &... -
Page 14: Cutting Unit
PRESENTATION Cutting unit Seat The machines have a 3-blade Combi-unit The seat has a jointed attachment on the front edge and can be tipped forward. The seat can also be adjusted lengthways. FR 2216MA 4X4, FR 2218A 4X4 Loosen the handles under the seat and adjust it forwards or backwards to the desired position. -
Page 15: Release Lever
PRESENTATION Release lever The release control must be pulled out in order for the machine to be moved when the engine is shutoff. Should you attempt to drive the machine with the clutch controls pulled out it will not move. The drive on the axle is disengaged when one of the controls is pulled out. -
Page 16: Driving
Driving Before starting FR 2216MA 4X4, FR 2218A 4X4 Move the throttle to position 3 (choke position). In this position the engine is fed with a richer mixture, which IMPORTANT INFORMATION The air intake grille in the means the engine is easier to start. engine cover behind the driver’s seat must not be blocked by, for example, clothing, leaves, grass or dirt. -
Page 17: Starting The Engine With A Weak Battery
Driving Starting the engine with a weak FR 2216A2 4X4 Move the throttle control to the middle position. battery WARNING! Lead-acid batteries produce explosive gases. Avoid sparks, open flames and smoking close to batteries. Always wear protective glasses in the vicinity of batteries. If the battery is too weak to start the engine, it should be recharged. -
Page 18: Driving The Rider
Driving Driving the Rider Cutting tips 1 Release the parking brake by first pressing down the parking brake pedal and then releasing it. • Localise and mark stones and other fixed objects to avoid collision. • Start with a high cutting height and reduce down until the required mowing results are obtained. -
Page 19: Stop The Engine
Driving Stop the engine Clutch control, front axle The control is positioned on the inside of the left front wheel. Preferably allow the engine to idle for a minute to obtain normal working temperature before stopping it if it has been working hard. -
Page 20: Maintenance
Maintenance Maintenance schedule The following is a list of the maintenance which should be conducted on the machine. For those points not described in this manual, visit an authorised service workshop. Daily maintenance At least once Maintenance Maintenance before starting a year interval in hours 100 200... -
Page 21: Cleaning
Maintenance Cleaning Front cover Release the clip on the front hood and lift off the fender. Clean the machine directly after use. It is much easier to wash off grass cuttings before they dry. Oily dirt can be removed using a cold degreasing agent. Spray on a thin layer. -
Page 22: Checking And Adjusting The Steering Wires
Maintenance Temperature variations and vibrations can mean that the 3 If necessary, the wires can be adjusted by tightening the tightening torque for the screws drops. The screws should be adjuster nuts on each side of the steering collar. Do not checked when servicing to guarantee the correct torque. -
Page 23: Checking And Adjusting The Choke Wire
Maintenance Checking and adjusting the choke FR 2216MA 4X4, FR 2218A 4X4 1 Loosen the clamping screw for the cable’s outer casing wire and move the throttle to the full throttle position. FR 2216A2 4X4 If the engine is producing black smoke or is difficult to start then the choke wire (upper wire) may be incorrectly adjusted. - Page 24 Maintenance FR 2216MA 4X4, FR 2218A 4X4 8 Pull the handle outwards. Secure the handle in the air filter cover and close the cover by pressing it inwards. 1 Open the engine cover. 2 Pull up the handle on the air filter cover, unhook and turn towards the engine.
-
Page 25: Checking The Fuel Pump's Air Filter
Maintenance Checking the fuel pump’s air filter WARNING! Procedures on contact with acid Check regularly that the fuel pump’s air filter is free from dirt. External: Rinse well with plenty of water. FR 2216MA 4X4, FR 2218A 4X4 Internal: Drink large quantities of water or The filter can when necessary be cleaned with a brush. -
Page 26: Check The Safety System
Maintenance Check the safety system Start motor The machine is equipped with a safety system that prevents starting or driving under the following conditions. Ignition system The engine should only be possible to start when the cutting unit is in its raised position and the gear shift lever or hydrostat pedals are in the neutral position. -
Page 27: Main Fuse
Maintenance Main fuse Checking the engine’s cooling air intake The main fuse is placed in a detachable holder under the battery case’s cover, in front of the battery. Clean the air intake grille in the engine cover behind the Type: Flat pin, 15 A. driver’s seat. -
Page 28: Checking The Cutting Unit's Parallelism
Maintenance 3 Adjust the unit’s ground pressure by screwing in or out the 6 On completion of the adjustment the unit’s parallelism adjusting screws located behind the front wheels on both should be re-checked. sides. 7 Fit the right-hand fender and the front hood. The ground pressure should be between 12 and 15 kg (26.5- 33 lb). -
Page 29: Checking The Blades
Maintenance 4 Grasp the front edge of the cutting unit, pull out and raise WARNING! into the service position. Wear protective glasses when dismantling the cutting unit. The spring which tensions up the belt may break and cause personal injury. 5 Disengage the spring for the drive belt tensioning wheel. -
Page 30: Removing The Mulching Plug
Maintenance Removing the Mulching plug To change a Combi unit from Mulching function to cutting unit with rear ejection, remove the Mulching plug located under the unit with three screws. 1 Put the unit in the service position, see Placing in the service position. -
Page 31: Lubrication
Lubrication Checking the engine’s oil level. 2 Remove the dipstick. Remove the drain plug from the engine’s left side. Check the oil level in the engine when the Rider stands horizontal with the engine switched off. Open the engine cover. Loosen the dipstick, pull it up and wipe it off. -
Page 32: Checking The Transmission Oil Level
Lubrication Checking the transmission oil level *Grease from well-known brand names (petrochemical companies, etc.) usually maintains a good quality. The most important property is that the grease provides good 1 Remove the transmission cover. Undo the two screws protection against corrosion. (one on each side) and lift off the transmission cover. -
Page 33: Troubleshooting Schedule
Troubleshooting schedule Problem Procedure Engine does not start There is no fuel in the fuel tank Spark plug defective Faulty spark plug connections or interchanged cables Dirt in the carburettor or fuel line Dirt in the carburettor or fuel line Starter motor does not turn over the engine Battery flat Bad contact between the cable and battery... -
Page 34: Storage
Storage Winter storage Guard At the end of the season, or if the machine is going to stand There is a cover to protect your machine during storage or idle for more than 30 days, it should immediately be made transport. -
Page 35: Technical Data
TECHNICAL DATA FR 2216MA 4X4 FR 2218A 4X4 FR 2216A2 4X4 Dimensions Length without cutting unit, mm/ft 2010/6,58 2010/6,58 2060/6.75 Length with cutting unit, mm/ft 2220/7,29 2220/7,29 2260/7.41 Width without cutting unit, mm/ft 880/2,89 880/2,89 880/2,89 Width with cutting unit, mm/ft 1140/3.74 1230/4.04 1230/4.04... -
Page 36: Ec-Declar Ation Of Conformity
EC-declaration of conformity (Applies to Europe only) Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel.: +46-36-146500, hereby declares that Jonsered FR 2216 MA 4X4, FR 2218 A 4X4 and FR 2216 A2 4X4 from 2009’s serial numbers and onwards (the year is clearly stated in plain text on the rating plate with subsequent serial number), complies with the requirements of the COUNCIL’S DIRECTIVE:... - Page 38 ´®z+SH6¶6q¨ ´®z+SH6¶6q¨...
