- Page 1 Oper ator ′ s manual Please read the oper ator’s manual carefully and make sure you understand the instructions before using the machine. FR 2213 RA FR 2215 MA FR 2215 MA 4X4...
-
Page 2: Table Of Contents
Removing of the machine hoods ......... Muffler ................Checking and adjusting the steering wires ....Adjusting the parking brake, FR 2213 RA, FR 2213 MA, FR 2215 MA ..............Adjusting the parking brake, FR 2215 MA 4X4 .... Adjusting the throttle wire .......... -
Page 3: Intr Oduction
Dear Customer , Thank y ou for choosing a Jonsered Frontrider. Jonsered Frontriders are built to a unique design with a front-mounted cutting unit and a patented rear-wheel steering system. FrontRiders are designed for maximum efficiency even in small or confined areas. The closely grouped controls and pedal-operated hydrostatic transmission also contribute to the performance of this machine. -
Page 4: Ser Vice Journal
Ser vice journal Pre-deliver y service 12 Tell customer about: Needs and benefits of following the service 1 Charge the battery for 4 hours at max. 3 amp. schedule. 2 Fit steering wheel, seat and any optional The transmission guarantee is only valid if the equipment. -
Page 5: Key To Symbols
KEY T O SYMBOLS Symbols Ignition These symbols are on the machine and in the instr uctions. Hydrostatic freewheel WARNING! Careless or incorrect use can result in serious or fatal injury to the operator or others. Warning: rotating parts. Keep hands and feet clear. - Page 6 KEY T O SYMBOLS The cutting dec k must be fitted at full speed. Starting instructions Check the engine’s oil level Check the hydrostat’s oil level Lift up the cutting unit Apply and lock the parking brake. If the engine is cold, use the choke Release the parking brake before driving Switch off the engine and take off the ignition cable before repairs or maintenance...
-
Page 7: Safety Instr Uctions
SAFETY INSTR UCTIONS Saf ety instructions • Stop the engine and prevent the engine from being started until you have cleaned the outlet channel. These instr uctions are for your safety. Read them carefully. • Look out for the ejector and do not direct it towards anyone. -
Page 8: Driving On Slopes
SAFETY INSTR UCTIONS This is what y ou do • Never allow children or other persons not trained in the use of the machine to use or service it. Local laws may • Remove obstacles such as stones, branches, etc. regulate the age of the user. -
Page 9: Children
SAFETY INSTR UCTIONS • Follow the manufacturer’s recommendations regarding • Petrol and petrol fumes are poisonous and extremely wheel weights or counterbalance weights to increase flammable. Be especially careful when handling petrol, as machine stability. carelessness can result in personal injury or fire. •... -
Page 10: Transport
SAFETY INSTR UCTIONS • Do not change the setting of governors. If you run too fast, Engage the parking brake and tie the tension belts around you risk damaging the machine components. See chapter stable parts on the machine, e.g. frame or rear wagon. on Technical data for highest permitted engine speed. -
Page 11: What Is What
WHAT IS WHAT? Location of the controls 1 Throttle control/choke control 9 Product and serial number plate 2 Ignition lock 10 Seat adjustment. 3 Cutting height adjustment lever 11 Lever to disengage the driving front axle, FR2215MA 4X4 4 Lifting lever for the cutting unit 12 Fuel cap 5 Speed limiter for reversing 13 Cover lock... -
Page 12: Presentation
PRESENTATION Presentation Cutting unit Congratulations on your choice of an excellent quality product FR 2213RA has a cutting unit with rear ejection, i.e. clippings that will give you great pleasure for many years. Four models are thrown behind the cutting unit. equipped with engines from Briggs &... -
Page 13: Seat
PRESENTATION Seat Release lever FR 2213 RA, FR 2213 MA, FR 2215 MA The seat has a jointed attachment on the front edge and can be tipped forward. The release control must be pulled out in order for the The seat can also be adjusted lengthways. -
Page 14: Driving
Driving Before starting • Release the brake pedal while holding the button pressed. The parking brake lock disengages automatically when the brake pedal is pressed. IMPORTANT INFORMATION The air intake grille in the engine cover behind the driver’s seat must not be blocked 4 With a cold engine: by, for example, clothing, leaves, grass or dirt. -
Page 15: Starting The Engine With A Weak Battery
Driving Remove the cables in the reverse order Let the engine run at moderate speed or half throttle for 3- 5 minutes before subjecting it to heavy load. When • The BLACK cable is removed from the chassis and then mowing, use 3/4 to full throttle. -
Page 16: Cutting Tips
Driving Cutting tips 1 Lift up the cutting unit by pulling the lever backwards to its locked position. • Localise and mark stones and other fixed objects to avoid collision. 2 Pull back the throttle and turn the ignition key to the •... -
Page 17: Maintenance
Maintenance Maintenance schedule The following is a list of the maintenance which should be conducted on the machine. For those points not described in this manual, visit an authorised service workshop. Daily maintenance At least once Maintenance Maintenance before starting a year interval in hours 100 200... -
Page 18: Cleaning
Maintenance Cleaning Right-hand fender Dismantle the foot-plate (1), screws (2 and 3), and lift off the Clean the machine directly after use. It is much easier to wash fender. off grass cuttings before they dry. Oily dirt can be removed using a cold degreasing agent. Spray on a thin layer. -
Page 19: Checking And Adjusting The Steering Wires
Maintenance Checking and adjusting the steering Adjusting the parking brake, FR wires 2213 RA, FR 2213 MA, FR 2215 MA The steering is controlled by means of wires. These can in Check that the brake is correctly adjusted by placing the time become slack, which implies that the adjustment of the machine on a slight downhill slope with the clutch disengaged steering becomes altered. -
Page 20: Adjusting The Throttle Wire
Maintenance Adjusting the throttle wire 3 Remove the air filter cover. 4 Lift out the air filter cartridge from the fan housing. The throttle cable may need to be adjusted, if the engine does not respond as it should when accelerating, if it produces black smoke or maximum revs are not reached. -
Page 21: Replacement Of Fuel Filter
Maintenance Replacement of fuel filter Ignition system Replace the fuel filter every 100 running hours (once per The engine is equipped with an electronic ignition system. season) or more frequently if it is clogged. Only the spark plug requires maintenance. For recommended spark plug, see Technical data. -
Page 22: Fuses
Maintenance Fuses Check that the cooling intake is free from leaves, grass and dirt. The main fuse is placed in a detachable holder under the battery case’s cover, in front of the battery. Type: Flat pin, 15 A. Check the air duct, located on the inside of the engine cover, ensure it is clean and does not rub against the cooling air intake. -
Page 23: Checking The Cutting Unit's Parallelism
Maintenance Checking the cutting unit’s Service position for the cutting unit parallelism FR 2213 MA, FR 2215 MA, FR 2215 MA 4x4 Check the cutting unit’s parallelism as follows: The cutting head can be placed in the service position to provide easy access for cleaning, repairs and servicing. -
Page 24: Checking The Blades
Restoring from service position 1 Grip the front edge of the unit and loosen the lock, fold down and slide in the unit. FR 2213 RA • Lift up the cutting unit 2 Replace the cutting height stay and the belt. Tension the belt with the belt adjuster. -
Page 25: Removing The Mulching Plug
Maintenance Removing the Mulching plug FR 2213 MA, FR 2215 MA, FR 2215 MA 4x4 To change a Combi unit from the Mulching function to a cutting unit with rear ejection, remove the Mulching plug, which is located under the unit, attached with a knob. 1 Put the unit in the service position, see Service position for the cutting unit. -
Page 26: Lubrication
2 Check that there is oil in the transmission’s oil tank. The engine oil should be changed the first time after 8 hours FR 2213 RA, FR 2213 MA, FR 2215 MA: Fill if necessary running time. It should then be changed after every 50 hours with engine oil SAE 10W/40 (class SF–CC). -
Page 27: Lubricating The Belt Adjuster
Lubrication Lubricating the belt adjuster The belt adjuster should be lubricated regularly using good quality molybdenum disulphide grease*. • Lubricate using a grease gun, 1 nipple from the right-hand side under the engine’s lower belt pulley, until grease is forced out. With daily use, lubrication should be carried out twice weekly. -
Page 28: Troubleshooting Schedule
Troubleshooting schedule Problem Procedure Engine does not start There is no fuel in the fuel tank Spark plug defective Faulty spark plug connections or interchanged cables Dirt in the carburettor or fuel line Starter motor does not turn over the engine Starter motor does not turn over the engine Battery flat Bad contact between the cable and battery Lift lever for cutting unit in wrong position... -
Page 29: Storage
Storage Winter storage Service At the end of the season, or if the machine is going to stand Low season is the most suitable time to perform a service or idle for more than 30 days, it should immediately be made overhaul of the machine in order to ensure high function ready for storage. -
Page 30: Technical Data
TECHNICAL DATA FR 2213 RA FR 2213 MA FR 2215 MA FR 2215MA 4X4 Dimensions Length without cutting unit, mm/ft 2010/6,58 2010/6,58 2010/6,58 2010/6,58 Length with cutting unit, mm/ft 2230 / 7,32 2230 / 7,32 2230 / 7,32 2230 / 7,32... -
Page 31: Ec-Declar Ation Of Conformity
