705i(G) cover_cover.qxp 2010-11-25 오후 4:20 페이지 1
OPERATING INSTRUCTIONS
RD-705i
NETWORK AV RECEIVER

Advertisement

Table of Contents
loading

Related Manuals for Sherwood RD-705i

Summary of Contents for Sherwood RD-705i

  • Page 1 705i(G) cover_cover.qxp 2010-11-25 오후 4:20 페이지 1 OPERATING INSTRUCTIONS RD-705i NETWORK AV RECEIVER...

  • Page 2: Introduction

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지2 Introduction READ THIS BEFORE OPERATING YOUR UNIT This symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 3: Table Of Contents

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지3 CONTENTS Introduction • READ THIS BEFORE OPERATING YOUR UNIT System Connections Front Panel Controls Remote Controls • REMOTE CONTROL OPERATION RANGE • LOADING BATTERIES Operations • LISTENING TO A PROGRAM SOURCE • SURROUND SOUND • ENJOYING SURROUND SOUND • LISTENING TO RADIO BROADCASTS •...

  • Page 4: System Connections

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지4 System Connections • Please be certain that this unit is unplugged from the AC outlet before making any connections. • Since different components often have different terminal names, carefully read the operating instructions of the component connected. • Be sure to observe the color coding when connecting audio, video and speaker cords.
  • Page 5 BD player, DVD player, etc. • You can connect Apple iPod to this receiver via Sherwood iPod dock. If Sherwood iPod dock is connected to DIGILINK-i jack for system control, you should connect its video and audio jacks to the “VIDEO 2” jacks of this receiver. Because, when you control your iPod with the unit’s remote control, the VIDEO 2/iPod is automatically selected as an input source and the...
  • Page 6 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지6 Continued ■hDmI (high Definition multimedia Interface) connection : (*) • You can connect the source component (DVD player, etc.) to the display component (TV, projector, etc.) through this receiver with using a commercially available HDMI cord. • The HDMI connection can carry uncompressed digital video signals and digital audio signals.
  • Page 7 • To emphasize the deep bass sounds, connect a powered subwoofer. SUBWOOFER PREOUT CONNECTING FOR SYSTEm CONTROL • Connect this jack to the DIGILINK-i jack of Sherwood iPod dock that allows you to control the iPod with the unit’s remote control. DIGILINK-i...
  • Page 8 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지8 CONNECTING SPEAkERS • Be sure to connect speakers firmly and correctly according to the channel(left and right) and the polarity(+ and -). If the connections are faulty, no sound will be heard from the speakers, and if the polarity of the speaker connection is incorrect, the sound will be unnatural and lack bass.
  • Page 9 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지9 Continued ■ Connecting speaker wire 1. Strip away approx. 10 mm 2. Loosen by turning the 3. Insert the bare part of the 4. Tighten by turning it (3/8 inch) of wire insulation, speaker terminal counter- wire. clockwise. then twist the wire ends clockwise.
  • Page 10 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지10 CONNECTING ROOm 2 OUT JACkS OR ROOm 2 SPEAkER TERmINALS • ROOM 2 playback feature allows you to play a Another room(Room 2) different program source in another room as well as one source in the main room at the same time.

  • Page 11: Front Panel Controls

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지11 Front Panel Controls RD-705i NETWORK AV RECEIVER MASTER VOLUME STANDBY SOUND INPUT POWER ON / STANDBY AUTO / MANUAL SURROUND STEREO VIDEO AUDIO VIDEO 4 5V / 1A VIDEO AUDIO PHONES SETUP MIC F.AUX SPEAKER AUDIO ASSIGN TONE CH.LEVEL...
  • Page 12 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지12 ■SETUP mIC JACk • To use Auto Setup function, connect the supplied microphone to the SETUP MIC jack.(For details, refer to "When selecting the AUTO SETUP" on page 47.) ■Notes: • Because the microphone for Auto Setup is designed for use with this receiver, do not use a microphone other than the one supplied with this receiver.

  • Page 13: Remote Controls

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지13 Remote Controls CURSOR CONTROL( , , , ), ENTER buttons ROOM 2 button NETWORK CONTROL (NETWORK, RATING ( PAUSE( ), PLAY( ), STOP( REPEAT( ), SHUFFLE( BACKWARD SKIP( FORWARD SKIP( )) buttons...

  • Page 14: Remote Control Operation Range

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지14 REMOTE CONTROL OPERATION RANGE RD-705i NETWORK AV RECEIVER MASTER VOLUME STANDBY SOUND INPUT POWER ON / STANDBY AUTO / MANUAL SURROUND STEREO VIDEO AUDIO VIDEO 4 5V / 1A VIDEO AUDIO PHONES SETUP MIC F.AUX SPEAKER AUDIO ASSIGN TONE CH.LEVEL...

  • Page 15: Operations

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지15 Operations ■Note : Before operating this receiver, first set this unit as desired for optimum performance, doing the system setup procedures. (For details, refer to "System Setup" on page 41.) LISTENING TO A PROGRAM SOURCE Before operation • Each time the “VIDEO” button on the front panel is pressed, the input source changes as follows: →...
  • Page 16 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지16 Adjusting the tone (bass and treble) Operate the selected component for playback. Enter the tone mode. • When playing back the program sources with surround sound, refer to “ENJOYING SURROUND SOUND” on page 19. TONE Adjust the (overall) volume.

  • Page 17: Surround Sound

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지17 SURROUND SOUND • This receiver incorporates a sophisticated Digital Signal Processor that allows you to create optimum sound quality and sound atmosphere in your personal Home Theater. Surround modes ■ ■Dolby Digital DTS Digital Surround Dolby Digital is the multi-channel digital signal format DTS Digital Surround(also called simply DTS) supports up to developed by Dolby Laboratories.
  • Page 18 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지18 ■Classic • The following modes apply conventional 2-channel signals such as digital PCM or analog stereo signals to high This mode provides the acoustic effects of a large concert performance Digital Signal Processor to recreate sound hall for classical music.

  • Page 19: Enjoying Surround Sound

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지19 ENJOYING SURROUND SOUND ■Note: Before surround playback, first perform the speaker setup procedure, etc. on the SETUP menu for optimum performance. (For details, refer to "SETTING THE SPEAKER / ROOM EQ SETUP" on page 47.) Depending on how to select a surround mode, select the auto surround mode or the manual surround mode.
  • Page 20 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지20 Continued ■To cancel the surround mode for stereo operation • Depending on the signal format which is being input, either the STEREO stereo mode or the 2CH downmix mode is selected. • To cancel either the stereo mode or the 2CH downmix mode, select the surround mode with using the SURROUND MODE UP/ DOWN (>/<) buttons.
  • Page 21 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지21 Continue Adjusting each channel level with test tone ■When selecting the "DRC (Dynamic Range Compression)" • The volume level of each channel can be adjusted easily • This function compresses the dynamic range of with the test tone function.
  • Page 22 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지22 Adjusting the current channel level • After adjusting each channel level with test tone, adjust the channel levels either according to the program sources or to suit your tastes. • You can adjust the current channel levels as desired. These adjusted levels are just memorized into user’s memory ("CAL"), not into preset memory("REF 1", "REF 2").
  • Page 23 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지23 memorizing the adjusted channel levels Recalling the memorized channel levels • You can memorize the adjusted channel levels into preset memory("REF 1", "REF 2") and recall the memorized Press the CHANNEL LEVEL button. whenever you want. CH.LEVEL After performing the steps 1 ~ 4 in "Adjusting the current channel level"...

  • Page 24: Listening To Radio Broadcasts

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지24 LISTENING TO RADIO BROADCASTS Auto tuning manual tuning • Manual tuning is useful when you already know the Select the desired band. frequency of the desired station. • After selecting the desired band, press the TUNING UP(+) / DOWN(-) buttons repeatedly until the right frequency has been reached.
  • Page 25 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지25 manual presetting Tuning to preset stations • You can store up to 30 preferred stations in the memory. • After selecting the tuner as an input source, select the desired preset number. Tune in the desired station with auto or manual tuning.

  • Page 26: Listening To Rds Broadcasts(Fm Only)

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지26 RDS Tuner (Regional Option for some countries in Europe, etc.) LISTENING TO RDS BROADCASTS(FM ONLY) RDS(Radio Data System) is a method for sending information signals together with the transmitter signals. Your tuner is capable of translating these signals and putting the information on the display. These codes contain the following information.
  • Page 27 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지27 Displaying RDS information In the FM mode, • Each time this button is pressed, the display mode changes as follows: Program Signal Surround → → → Service name input mode (PS) Program ← ← Radio Type Text (RT) (PTY) * Program Service Name(PS)-The name of the radio station.

  • Page 28: Listening To Internet Radio Broadcasts, Music Files

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지28 LISTENING TO INTERNET RADIO BROADCASTS, MUSIC FILES • You can listen to Internet radio broadcasts or music files stored on a USB memory device or a computer (media server). ■Internet Radio ■USB memory Devices • Internet radio refers to radio broadcasts distributed over •...
  • Page 29 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지29 Basic Operation Select the desired item, then press the ENTER button. Make the necessary preparations. ENTER/MEMO PRESET ①Check the network environment, then turn on this unit. (See “CONNECTING TO NETWORK” on page 10.) ②If settings are required, register your accounts and make the network settings, etc.
  • Page 30 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지30 ◆To pause playback ◆To play repeatedly During playback, press the PAUSE( ) button. During playback of the desired music file, press the REPEAT( ) button. • Then “ ” lights up and the music files on the folder are •...
  • Page 31 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지31 When selecting “now playing” ENTER/MEMO • You can display the information on the Internet radio broadcast or music file being played. Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired display mode. Example: When playing an Internet radio broadcast •...
  • Page 32 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지32 ◆When selecting “Create Station” ① While playing a song to be rated, press the RATING( ) button. • Then the name entry menu is displayed. ‘ s o g ’ ① Press the CURSOR UP(▲)/DOWN(▼) buttons to enter the desired character.
  • Page 33 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지33 • While playing a broadcast, each time the CURSOR UP(▲) When selecting “internet radio” or DOWN(▼) button is pressed, the display mode changes as follows. • You can listen to Internet radio broadcasts provided by →station name ↔song title ↔album name ←...
  • Page 34 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:24페이지34 Repeat the above step 3 until the desired music Press the CURSOR UP(▲)/DOWN(▼) buttons to file is selected. select the desired category, then press the ENTER button. Example: When playing a music file Repeat the above step 3 until the desired music...
  • Page 35 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지35 When selecting “settings” When selecting “favorites” • When listening to Internet radio broadcasts or music files • You can listen to Internet radio stations (only provided by for the first time, first make settings for accounts, playback, Shoutcast) or music files registered in the “favorites” list or network, etc.
  • Page 36 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지36 Press the ENTER button. Press the CURSOR UP(▲)/DOWN(▼) buttons to select “OK” or “CANCEL”, then press the ENTER button. • Then the previous status is returned to. • When the “OK” is selected, the playback settings are Visit the Reciva website at www.reciva.com on stored and the previous status is returned to.
  • Page 37 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지37 ■When selecting “General” * In case of selecting “AP List” • This unit searches for all available wireless routers. G e n e r a l S e t t i g F a c t o r y S e t t...

  • Page 38: Recording

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지38 RECORDING • The digital signals from the coaxial, optical digital input or HDMI IN can be heard but cannot be recorded. • When recording the analog signals from CD, AUX, F.AUX, VIDEO 2~4, be sure to select the analog input.

  • Page 39: Other Functions

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지39 OTHER FUNCTIONS Operating the sleep timer • The sleep timer allows the system to continue to operate for a specified period of time before automatically shutting off. • To set the receiver to automatically turn off after the specified period of time.

  • Page 40: Confirming The Hdmi Function

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지40 CONFIRMING THE HDMI FUNCTION To use the HDMI control functions properly, it is recommend to confirm the HDMI control functions usable with each connected component by performing the following operations. ■Note : • Some HDMI control functions may not work with certain components and TV that are not compatible with them.

  • Page 41: System Setup

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지41 System Setup • The setup menu is displayed on the fluorescent display and allows you to perform the setup procedures easily. In most situations, you will only need to set this once during the installation and layout of your home theater, and it rarely needs to be changed later.
  • Page 42 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지42 ■Setup menu flow • The setup menu flow is as follows : SYSTEM SETUP AMP : SURR.BACK / FRONT HEIGHT / ROOM 2 / BI AMP SW MODE : NORM / SW + * : Default setting for AUDIO ASSIGN TONE : OFF / ON varies depending on the input source.

  • Page 43: Setting The System Setup

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지43 SETTING THE SYSTEM SETUP SYSTEM SETUP AMP : SURR.BACK / FRONT HEIGHT / ROOM 2 / BI AMP SW MODE : NORM / SW + TONE : OFF / ON BASS : 0 dB / - 10 ~ + 10...
  • Page 44 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지44 When selecting the TONE OFF : To listen to a program source without the tone effect. ("DIR" lights up.) ↕ ON : To adjust the tone for your taste. ("DIR" goes off.) ■When the TONE is set to ON to adjust the tone (bass and treble) ①...

  • Page 45: Setting The Input Setup

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지45 SETTING THE INPUT SETUP INPUT SETUP VIDEO 1 CONFIG A.MODE : AUTO / HDMI / DIGITAL / ANALOG D.IN : OPT1 / OPT 2 / COX 1 / COX 2 / - - - AUTO : ON / OFF...
  • Page 46 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지46 When selecting the AUDIO mODE • You can select the audio input signal to be played. ■Notes : • Be sure to set the AUDIO MODE to the audio input which is connected and assigned to the selected input source.

  • Page 47: Setting The Speaker / Room Eq Setup

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지47 SETTING THE SPEAKER / ROOM EQ SETUP • After you have installed this receiver and connected all the components, you should adjust the speaker settings for the optimum sound acoustics according to your environment and speaker layout. • Even when you change speakers, speaker positions, or the layout of your listening environment, you should adjust the speaker settings, too.
  • Page 48 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지48 Continued Place the microphone on a flat level surface at the listening position. • If possible, use a tripod, etc. to attach the microphone at the same height as your ears would be when you are seated in your listening position.
  • Page 49 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지49 When selecting the ROOm EQ • The room EQ is a kind of room equalizer for your speakers. According to the acoustic characteristics of your room measured by the auto setup, the room EQ automatically adjusts the frequency response of your speakers.
  • Page 50 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지50 When selecting the SPEAkER CONFIGURATION Press the CURSOR UP(▲)/DOWN(▼) buttons to select the "SPK CONFIG", then press the ENTER button. RON T Press the CURSOR LEFT(◀)/ RIGHT(▶) buttons to set the selected speaker as desired. • Depending on your speaker type, you can select one of these following speaker types.
  • Page 51 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지51 When selecting the CROSSOVER • When speakers are set to "SMALL", be sure to set their crossover frequency correctly according to their frequency characteristics. ■Note : • Even though performing the AUTO SETUP procedure, you should set the CROSSOVER manually when speakers are set to “SMALL”.
  • Page 52 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지52 When selecting the SPEAkER DISTANCE Press the CURSOR UP(▲)/DOWN(▼) buttons to select the “SPK DISTANCE”, then press the ENTER button. N I T : E ERS Press the CURSOR UP(▲)/DOWN(▼) buttons to select the desired item. ■Note : • You cannot select the speakers set to "NO".

  • Page 53: Setting The Ch Level Setup

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지53 SETTING THE CH LEVEL SETUP CH LVL SETUP MODE : CAL / REF 1 / REF 2 LEFT : 0 dB / -15 ~ + 15 CENTER : 0 dB / -15 ~ + 15 RIGHT : 0 dB / -15 ~ + 15...
  • Page 54 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지54 memorizing the adjusted channel levels Recalling the memorized channel levels • You can memorize the adjusted channel levels into preset Press the CURSOR UP(▲)/DOWN(▼) buttons memory("REF 1", "REF 2") and recall the memorized whenever you want. to select the "MODE ~ ".

  • Page 55: Setting The Multi Room Setup

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지55 SETTING THE MULTI ROOM SETUP • The ROOM 2 function allows enjoying one source in the main room and playing another in a different room at the same time. MULTI ROOM SET ROOM 2 : OFF / ON RETURN IN : MAIN / TUNER / CD / AUX / F.AUX / VIDEO 1 / V2/iPOD / VIDEO 3 / VIDEO 4...

  • Page 56: Setting The Parameter Setup

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지56 SETTING THE PARAMETER SETUP PARAMTER SETUP PANORAMA : OFF / ON C.WIDTH : 3 / 0 ~ 7 DIMENSION : 0 / -3 ~ +3 DRC DD DRC : OFF / MID / MAX RETURN DRC THD DRC : AUTO / OFF / MID / MAX RETURN H.GAIN : LOW / MID / HIGH...
  • Page 57 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지57 When selecting “DRC DD”, “DRC ThD” When selecting “h.GAIN” • You can adjust the front height channel level as desired. • This function compresses the dynamic range of previously ■Note: specified parts of the Dolby Digital or Dolby TrueHD sound •...

  • Page 58: Setting The Hdmi Setup

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지58 SETTING THE HDMI SETUP HDMI SETUP HDMI : AMP / THROUGH CEC : OFF / ON POWER : OFF / ON RETURN • HDMI(HDMI AUDIO OUT) : To output the digital audio signals from the HDMI MONITOR OUT connector.
  • Page 59 RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지59 When selecting the POWER CONTROL • The power control function allows the power status of this unit to be interlocked with the power ON/OFF and start of playback of the connected components. OFF : Not to use the POWER CONTROL function.

  • Page 60: Troubleshooting Guide

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지60 Troubleshooting Guide If a fault occurs, run through the table below before taking your receiver for repair. If the fault persists, attempt to solve it by switching the receiver off and on again. If this fails to resolve the situation, consult your dealer.

  • Page 61: Specifications

    RD-705i(G)_ENG_101206_RD-705i(G)_ENG2010-12-07오전10:25페이지61 Specifications ■AmPLIFIER SECTION • Power output, stereo mode, 6 Ω, THD 0.1 %, 40 Hz~20 kHz | 2× 80 W • Total harmonic distortion at -3 dB, 6 Ω, 1 kHz | 0.02% • Intermodulation distortion 60 Hz : 7 kHz= 4 : 1 SMPTE, 6 Ω, 80 W 0.05%...
  • Page 62 705i(G) cover_cover.qxp 2010-11-25 오후 4:20 페이지 2 RD-705i NETWORK AV RECEIVER 5707-00000-481-0S...
