Power management module board error codes
LED code: 7-1, 7-2, 7-3, 7-4, 7-5, 7-6, 7-7, 7-8, 7-9, 7-10, 7-11, 7-12, or 7-13
Location: Power management board
Action: Perform the following steps to resolve the problem. Stop when the problem is resolved.
Reseat the power management module.
1.
Replace the power management module.
2.
Power management module backplane error codes
LED code: 8-1, 8-2, 8-3, 8-4, 8-5, 8-6, 8-7, or 8-8
Location: Power management backplane
Action: Perform the following steps to resolve the problem. Stop when the problem is resolved.
Press the power management module reset button.
1.
Unknown power management module error code
LED code: 19-1
Location: Unknown
Action: Perform the following steps to resolve the problem. Stop when the problem is resolved.
Press the power management module reset button.
1.

Port 85 codes and iLO messages

Troubleshooting the system using port 85 codes

Locate the port 85 code display.
1.
IMPORTANT: Be sure the port 84/85 switch is set to display port 85 codes.
Locate the code in the following table.
2.
For example, if the port 85 code displays "31h," see "Processor-related port 85 codes (on page
131)" for more information.
Port 85 code
3xh
4xh
6xh
All other codes,
including 00h, 01h,
and 5xh
Reference the designated section in this guide for the appropriate troubleshooting steps.
3.

Processor-related port 85 codes

Processor-related port 85 codes display in the format 3xh.
Description
Port 85 codes in this format indicate processor-related errors. See "Processor-
related port 85 codes (on page 131)" for more information.
Port 85 codes in this format indicate memory-related errors. See "Memory-related
port 85 codes (on page 132)" for more information.
Port 85 codes in this format indicate expansion board-related errors. See
"Expansion board-related port 85 codes (on page 133)" for more information.
Port 85 codes in this range cover several areas. See the section "Miscellaneous
port 85 codes (on page 133)" for more information.
Error messages 131
