Operating Manual
Summit 425 LP
WARNING: F o l l ow all leak ch e ck pro c e d u r e s
carefully in this manual prior to barbecue
operation. Do this even if barbecue was
dealer assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this appliance
without reading "Lighting" instructions
section of this manual.
SUMMIT 425 & 450
Summit 450 LP
FOR YOUR SAFETY
1. Do not store or use gasoline or other
2. An LP tank not connected for use shall
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call your
LP Gas Barbecues
Step-By-Step Guide
flammable vapors and liquids in the
vicinity of this or any other appliance.
not be stored in the vicinity of this or
any other appliance.
gas supplier or your fire department.
97464
3/97
