If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING
1. Do not store spare liquid propane
cylinder within 10 feet (3m) of this
appliance.
2. Do not store or use gasoline or other
flammable liquids or vapors within 25
feet (8m) of this appliance.
WARNING: Follow all leak-check
procedures carefully in this manual prior to
barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading the "Lighting"
Instructions section of this manual
S U M M I T
O
G
WNERS
UIDE
DANGER
®
LP Gas Grill Owners Guide
#
A400_LP.g
Ba401.c
B400_LP.c
C400_LP.d
D400_LP.f
E400.c
41995
41995 US 03/27/03
LP
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Weber Summit Gold D LP
Summary of Contents for Weber Summit Gold D LP
- Page 1 ® S U M M I T LP Gas Grill Owners Guide OU MUST READ THIS WNERS UIDE 41995 BEFORE OPERATING YOUR GAS GRILL DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flames. 3.
-
Page 2: Danger & Warnings
Should the burners go out while in operation, turn all gas valves off. Open the lid and wait five minutes before attempting to relight, using the lighting instructions. Do not use charcoal or lava rock in your Weber ® gas barbecue. -
Page 3: Table Of Contents
Contents Danger & Warnings ..................A-2 Warranty ....................A-4 General Instructions .................A-5 Grilling Methods ..................A-6 Cleaning ....................A-6 Exploded View ..................A-7 Parts List ....................A-9 Assembly Instructions ................B-a Gas Instructions ..................C-1 Leak Checking ..................C-4 Operating ....................D-1 Grilling Methods ..................D-1 Lighting ....................D-3 Manual Lighting ..................D-4 Lighting the Side Burner ................D-5 Lighting the Smoker... -
Page 4: Warranty
This Limited Warranty does not cover any failures or attached to the cylinder. If the cylinder manufacturer has operating difficulties due to accident, abuse, misuse, not resolved the issue to your satisfaction, then call Weber- alteration, misapplication, vandalism, improper installation Stephen Products Co., Customer Service Center. -
Page 5: General Instructions
National Fuel Gas Code: ANSI Z 223.1/NFPA54. Operating ® • The pressure regulator supplied with the Weber barbecue must be used. This regulator is set for 10.5 WARNING: Only use this barbecue outdoors in a inches of water column (pressure). -
Page 6: Grilling Methods
NOTE: If grill looses heat while cooking refer to the WARNING: Turn your Weber gas barbecue OFF and troubleshooting section of this manual. wait for it to cool before cleaning. WARNING: Do not move the Weber ® gas barbecue CAUTION: Do not clean your Flavorizer ®... -
Page 7: Exploded View
Exploded View Summit ® Gold D LP 032103... -
Page 8: Exploded View List
Exploded View List Hinge Pin 47. Plastic Plug Thermometer Hardware 48. Right Door Thermometer Bezel 49. Hair Cotter Pin ™ Warm-Up Basket 50. Lid Assembly 8 inch Cooking Grate 51. 1/4 - 20 x 1 1/4 inch Bolt Smoker Assembly 52. -
Page 9: Parts List
Parts List Lid - 1 Bottom Shelf - 1 Left Door - 1 Cookbox - 1 Right Door - 1 Front Frame Rail - 1 Rear Frame Rail - 1 Side Table - 1 Left Frame Side Burner - 1 Assembly - 1 Right Frame Assembly - 1 Warming Rack - 1... - Page 10 Parts List ® Flavorizor Bars - 2 Sets Hinge Pin- 2 Hair Pin Cotter- 2 1-1/4 inch Bolts (1/4 x 20 x 1-1/4 inch Bolt) - 2 Stainless Steel Cooking Grates - 3 Nut Hex (1/4 x 20 Blk Zinc) - 2 1/2 inch Bolts Bottom Tray - 1 (1/4 x 20 x 1/2 inch Bolt) - 8...
- Page 11 Place corregated from each side of the Cookbox under the Caster and Wheel Frame Assembly to level the frames for Frame Rail Assembly. CAUTION: Before proceeding to the next step check that frame rail (2) is on the side with the swing tables (3).
- Page 12 ATTENTION! Only start these bolts. Do not tighten yet.
- Page 14 ATTENTION! Completely remove both partially started bolts from top rear frame rail ATTENTION! Reinstall both bolts through rear panel and into rear frame rail.
- Page 15 ATTENTION! Remove packing tape holding the gas line and bracket(1). When installing cookbox route the gas line and bracket(1) inside the frame rails(2).
- Page 18 Matchlight Holder...
- Page 21 NOTE: Igniter Wire(1) is located up under right side of control panel. B400_LP.c...
- Page 22 CAUTION: Hold burner cap(1) down while pushing side burner ignition wire(2) on.
-
Page 27: Gas Instructions
NEVER fill the tank beyond 80% full. WARNING: Make sure that the LP cylinder valve is closed. Close by turning valve clockwise. ® Your Weber gas grill is equipped with a cylinder supply system designed for vapor withdrawal. DANGER WARNING: Only use this grill outdoors in a well- Do not use an open flame to check for gas ventilated area. - Page 28 6) Turn on the cylinder valve. 1) Turn the LP cylinder so the opening of the valve is ® either to the front, side or rear of the Weber barbecue. Lift and hook the cylinder onto the fuel gauge. 7) Check for leaks by wetting the fitting with the soap and water solution and watching for bubbles.
- Page 29 Gas Instructions Completely remove the control panel (4) from the cooking ® WARNING : The gas connections of your Summit box assembly exposing the valves, burners, igniter, and gas grill have been factory tesated. We do however manifold. recommend that you leak check all gas connections before operating your Summit ®...
-
Page 30: Leak Checking
Note - All factory-made connections have been thoroughly checked for gas leaks. The burners have been flame-tested. As a safety precaution however, you should recheck all fittings for leaks before using your Weber Gas Barbecue. Shipping and handling may loosen or damage a gas fitting. - Page 31 Gas Instructions Reinstall control panel Parts required: control panel, screws, and burner control knobs. Place the control panel back onto the control panel brackets on either side of the front of the cooking box. Line up screws with screw holes on both the control panel and control panel brackets.
-
Page 32: Refilling The Liquid Propane Cylinder
Gas Instructions Checking the fuel level in your tank Liquid Propane Cylinder Check the fuel level by viewing the color indicator level The liquid propane cylinder manufacturer is responsible line on the side of the tank scale. for the materials, workmanship and performance of the 1) Empty tank. -
Page 33: Safe Handling Tips For Liquid Propane Gas Cylinders
LP gas is a liquid. As the pressure is Liquid Propane Cylinder requirements released, the liquid readily vaporizes and becomes gas. Replacement LP cylinders supplied by Weber satisfy LP gas has an odor similar to natural gas. You should the above requirements. Check to be sure other be aware of this odor. -
Page 34: Operating
Operating Instructions Grilling Methods Direct cooking The Direct Method, similar to broiling, means the food is NOTE: If grill looses heat while cooking refer to the cooked directly over the heat source. For even cooking, troubleshooting section of this manual. food should be turned once halfway through the grilling You can adjust the Left and Right burners in each burner time. -
Page 35: Operating Instructions
Operating Instructions Indirect cooking Grilling Tips & Helpful Hints The Indirect Method is similar to roasting, but with the • Always preheat the grill before cooking. Set all burners added benefits of that grilled texture, flavor, and on HIGH heat and close lid; heat for 10 minutes, or until appearance you can’t get from an oven. -
Page 36: Lighting
Failure to do so may result in an ® use the barbecue. Replace using only Weber explosive flame-up, which can cause serious bodily authorized replacement hose. Contact the injury or death. -
Page 37: Manual Lighting
Operating Instructions Manual Lighting 3) Turn the cylinder on by turning the cylinder valve counterclockwise. 4) Put match in the match holder and strike match. DANGER WARNING: Do not lean over open barbecue. Failure to open the lid while igniting the 5) Push LEFT burner control knob down and turn to barbecue’s burners, or not waiting 5 minutes START/HI. -
Page 38: Lighting The Side Burner
Operating Instructions Lighting the side burner if the main burners are lit. Side Burner Lighting Instructions 1) Open the side burner lid. 2) Push down and turn the side burner control to START/ DANGER Failure to open the lid while igniting the side 3) Push igniter button and hold until burner ignites. -
Page 39: Using The Smoker
Operating Instructions Using the Smoker poultry and fish recipes in the gas grill cookbook. Cook with the lid down according to the times indicated in charts or recipes. The smoker uses presoaked wood chips. For best results with faster cooking foods like steaks, burgers and chops, DANGER etc., we recommend using finer wood chips because they Do not use any flammable fluid in the smoker to... -
Page 40: Lighting The Smoker
If the hose is found 2,3,9 to be damaged in any way, do not use the grill. ® Replace using only Weber authorized replacement hose Contact the Customer Service Representative in your region using the contact information sheet provided with your manual. -
Page 41: Manually Lighting The Smoker Burner
If the hose is found 2,3,10 to be damaged in any way, do not use the grill. ® Replace using only Weber authorized replacement hose. Contact the Customer Service Representative in your region using the contact information sheet provided with your manual. -
Page 42: Rotisserie Assembly
Operating Instructions 3) Put the spit forks on the rotisserie shaft. Rotisserie Assembly Slide a spit fork from each side onto the shaft so that the tines are facing each other. Reverse forks to each Parts required: rotisserie motor bracket(1), rotisserie other so that one fork screw is on top(1) and one is on motor(1), rotisserie shaft(1), spit forks(4) the bottom(2), as shown in illustration. -
Page 43: Using The Rotisserie
Operating Instructions WARNING: Setup up the rotisserie with food before Using the Rotisserie lighting rotisserie burner. Note - Before using your rotisserie, measure your food at Operating the widest point. If it exceeds 9 1/2”, it is too large to fit the rotisserie. -
Page 44: Lighting The Rotisserie
If the hose is found to be damaged in any way, do not use the ® grill. Replace using only a Weber authorized replacement hose. Contact the Customer Service Representative in your region using the contact information sheet provided with your manual. -
Page 45: Manually Lighting The Rotisserie Burner
If the hose is found to be damaged in any way, do not use the ® grill. Replace using only a Weber authorized replacement hose. Contact the Customer Service Representative in your region using the contact information sheet provided with your manual. -
Page 46: Troubleshooting
Main & Smoker Burner Troubleshooting Problem Check Cure ® Burners burn with a yellow or Inspect Weber ® Insect / Spider Clean Weber Insect / Spider orange flame, in conjunction with screens for possible instructions. screens. (See Section “Annual the smell of gas. -
Page 47: Side Burner Troubleshooting
Side Burner Troubleshooting Problem Check Cure Side Burner does not light. Is gas supply off? Turn supply on. Flame is low in HIGH position. Is the fuel hose bent or kinked? Straighten hose. If match lights burner, checkigniter Push button ignition does not Does burner light with a match? (see below). -
Page 48: Rotisserie Troubleshooting
Rotisserie Troubleshooting Problem Check Cure Burner does not light. Did you hold the burner control Try to relight burner by holding knob down and hold down for 20 burner control knob down and seconds until after burner ignited? continue holding down until 20 seconds after burner has ignited. -
Page 49: Maintenance
If the spider/insect screen becomes damaged or cannot be can nest in the venturi section(1) of the burner tubes. This cleaned, call Weber-Stephen Products Customer Service blocks the normal gas flow, and can cause the gas to flow for replacement parts. -
Page 50: Replacing Main Burners
Maintenance Disconnect the Thermocouple from the IR Burner Replacing Main Burners valve. ® Your Summit gas grill must be OFF and cool. Turn gas OFF at source. Disconnect regulator. Remove cooking grates. Remove Smoker box. ® Remove Flavorizer bars. To remove control panel refer to “Remove the control panel”... - Page 51 Maintenance Pull manifold assembly out from the manifold frame. Remove the Crossover ® tube. Pull the selected burner(s) tube(s) from manifold frame and replace with a new burner tube. To reinstall the manifold assembly, reverse steps 7 through 14. CAUTION: The burner openings (1) must be positioned properly over the Lift and twist the burner assembly slightly, to separate valve orifices (2).
-
Page 52: Crossover Ignition System Operations
Maintenance Crossover ® Ignition System Operations Replace Igniter Batteries ® If the Crossover ignition system fails to ignite the LEFT Parts required: 1 AA alkaline battery per igniter. burner in a burner set, light the LEFT burner with a match. If the LEFT burner lights with a match, then check the Unscrew igniter button from top of control panel.
