Preparing to Install the Cisco 7401ASR Router

Figure 2-1
1
1
2
Table 2-1
Table 2-1
Cisco 7401ASR
Dimensions (H x W x D)
Weight

Tools and Parts Required

Your Cisco 7401ASR chassis is fully assembled at the factory; no assembly is required. However, you
need the following tools and equipment to install the chassis and the rack-mount and cable-management
kit:
•
•
•
•
The rack-mount and cable-management kit includes the following parts:
•
•
•
•
•
•
Cisco 7401ASR Installation and Configuration Guide
2-2
Dimensions of Cisco 7401ASR Router
12.875 in. (32.7cm)
17.3 in. (43.9 cm)
provides dimensions and weight information.
Cisco 7401ASR Dimensions and Weight
Number 2 Phillips screwdriver
A 3/16-inch flat-blade screwdriver
Tape measure (optional)
Level (optional)
Two rack-mount brackets for mounting the chassis in the rack
One cable-management bracket
Four 12-24 x 0.5-in. screws to secure the rack-mount brackets to the chassis
Four 8-18 x .37-in. screws to secure the rack-mount brackets to a 19-inch rack
Four 8 x .375-in. screws to secure the rack-mount brackets to a 21–23-inch rack
One M4 x 20-mm screw to attach the cable-management bracket to the rack-mount bracket
Chapter 2
2
3
1.72 in. x 17.3 in. x 11.80 in. (4.37 cm x 43.9 cm x 30 cm)
Chassis fully configured with a port adapter ~ 10.5 lb (4.76 kg)
Rack-Mounting, Tabletop Installation, and Cabling
3
11.8 in. (30 cm)
