Chapter 1
Overview and Parts Installation
System Management Functions
The Cisco 7401ASR processor performs the following system management functions:
•
•
•
•
•
•
•
Note
For a chassis footprint, additional dimensions, and clearance requirements for the Cisco 7401ASR
router, see the
"Rack-Mounting, Tabletop Installation, and Cabling."
The Cisco 7401ASR router supports multiprotocol, multimedia routing and bridging with a wide variety
of protocols and port adapters.
Checking the Shipping Container Contents
Use the
container. Do not discard the shipping container. You need the container if you move or ship the Cisco
7401ASR router in the future.
Table 1-1
Cisco 7401ASR Components List
Component
Description
Chassis
Cisco 7401ASR chassis configured with an AC or DC power supply, a port adapter
filler plate, and a CompactFlash Disk
Accessories:
The following accessories might arrive in separate shipping containers:
Rack-mount and
Two rack-mount brackets, one cable-management bracket,
•
cable-management
four 12-24 x 0.5-in. screws to secure the rack-mount brackets to the chassis, four 8-18
kit
x .37-in. screws to secure the rack-mount brackets to a 19-inch rack, four 8 x .375-in.
screws to secure the rack-mount brackets to a 21–23-inch rack, and one M4 x 20-mm
•
Power cables
screw to attach the cable-management bracket to the rack-mount bracket
Documentation
•
An AC power cable, if an AC power supply was ordered
If ordered, router hardware and software documentation set and the Cisco
Documentation CD-ROM package
Optional Equipment
Examples: Network interface cables, transceivers, special connectors
1. Titles and quantities of documents will vary. You must order the type and quantity of documentation sets when you order the hardware.
OL-5419-01 B0
Sending and receiving routing protocol updates
Managing tables, caches, and buffers
Monitoring interface and environmental status
Providing Simple Network Management Protocol (SNMP) management through the console and
Telnet interface
Accounting for and switching of data traffic
Booting and reloading images
Managing the port adapter (including recognition and initialization during online insertion and
removal)
"Preparing to Install the Cisco 7401ASR Router" section on page 2-1
Cisco 7401ASR Components List
to check the contents of the Cisco 7401ASR router shipping
1
Cisco 7401ASR Installation and Configuration Guide
Checking the Shipping Container Contents
in
Chapter 2,
Received
1-5
