Chapter 2—Installation

Display

The display window contains an LCD (Liquid Crystal Display) with
background illumination and two lines of text, each with 16 characters.
It shows a message when certain errors occur and guides the operator
through upgrading, startup, and setup. The following errors are reported:
Error
Empty/Paused
Out of media
Out of ribbon
Printhead lifted
Cutter error
Ribbon fi tted
Paper fault
Power supply error
Power supply too hot
Printhead too hot

Keyboard

The keyboard is of the membrane-switch type and has 7 keys. The key-
board is supplemented by a large "Feed/Pause" button. Some keys have
hard-coded functions in the startup and setup modes.
Feed/Pause button
Keyboard Color Code
Yellow
Green
White
14
Displayed message
PAUSE
PAPER OUT
RIBBON OUT
PRINT HEAD UP/PRESS FEED
OPEN&SHUT CUTTER
RIBBON FITTED
PAPER FAULT
PSU ERROR
PSU OVER TEMP
PRINTHEAD HOT
Feed/Pause a print job. Repeat last printed label.
Enter the Setup Mode (see Chapter 7).
Display error messages and communication channel information.
Scroll between various types of information after pressing the <i>
key. Possible error messages and information on active communi-
cation channels are shown in a loop.
Operation of the printer (operator level)
Setup or service (site or service technician level)
Data input to printer (operator or technician level)
