1. INSTRUCTIONS FOR USE ................................................................ 4
2. SAFETY PRECAUTIONS ................................................................... 6
3. ENVIRONMENTAL RESPONSIBILITY ............................................... 8
4. DESCRIPTION OF CONTROLS......................................................... 9
5. USING THE HOB.............................................................................. 10
6. CLEANING AND MAINTENANCE.................................................... 14
7. POSITIONING IN THE COUNTER TOP .......................................... 16
8. ELECTRICAL CONNECTION........................................................... 20
9. GAS CONNECTION ......................................................................... 21
10. REPLACEMENT OF NOZZLES ...................................................... 23
INSTRUCTIONS FOR THE USER: these instructions contain user
recommendations, a description of the controls and the correct
procedures for cleaning and maintenance of the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the
authorised person who must install the appliance, set it functioning and
carry out an inspection test.
@
Further information about the products can be found at www.smeg.com
Contents
3

Advertisement

Table of Contents
loading

Summary of Contents for Smeg Hob

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR THE INSTALLER: these are intended for the authorised person who must install the appliance, set it functioning and carry out an inspection test. Further information about the products can be found at www.smeg.com...
  • Page 2: Instructions For Use

    THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. IT MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE HOB. WE ADVISE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT CONTAINS CAREFULLY BEFORE USING THE HOB. ALSO KEEP THE SERIES OF NOZZLES PROVIDED.
  • Page 3: General Instructions

    General instructions ALWAYS CHECK THAT THE CONTROL KNOBS ARE IN THE (OFF) POSITION WHEN YOU FINISH USING THE HOB. NEVER PLACE PANS WITH BOTTOMS WHICH ARE NOT PERFECTLY FLAT AND SMOOTH ON THE COOKING HOB RACKS. NEVER USE CONTAINERS WHICH PROJECT BEYOND THE OUTSIDE EDGE OF THE...
  • Page 4: Safety Precautions

    General instructions 2. SAFETY PRECAUTIONS REFER TO THE INSTALLATION INSTRUCTIONS FOR THE SAFETY REGULATIONS FOR ELECTRIC OR GAS APPLIANCES AND VENTILATION FUNCTIONS. IN YOUR INTERESTS AND FOR YOUR SAFETY IT HAS BEEN ESTABLISHED BY LAW THAT THE INSTALLATION AND SERVICING OF ALL ELECTRICAL APPLIANCES IS TO BE CARRIED OUT BY QUALIFIED PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN FORCE.
  • Page 5 General instructions DO NOT LET CHILDREN GO NEAR THE APPLIANCE WHEN IT IS IN OPERATION OR PLAY WITH IT AT ANY TIME. DO NOT INSERT POINTED METAL OBJECTS (CUTLERY OR UTENSILS) INTO THE SLITS IN THE APPLIANCE. DO NOT USE STEAM JETS FOR CLEANING THE APPLIANCE. THE STEAM COULD REACH THE ELECTRONICS, DAMAGING THEM AND CAUSING SHORT-CIRCUITS.
  • Page 6: Environmental Responsibility

    Instructions for disposal 3. ENVIRONMENTAL RESPONSIBILITY Our environmental responsibility Adequate differentiated collection for the subsequent forwarding of the decommissioned product to recycling, processing and ecologically compatible disposal contributes to avoiding possible negative effects on the environment and on health, and promotes recycling of the appliance's constituent materials. Illicit disposal of the product by the user will lead to the application of administrative sanctions.
  • Page 7: Description Of Controls

    Instructions for the user 4. DESCRIPTION OF CONTROLS Control zone All the hob controls are grouped together at the centre front. CONTROL ZONE KNOB DESCRIPTION To light the flame, press the knob and, at the same time, turn it anticlockwise to the maximum flame symbol...
  • Page 8: Using The Hob

    2 holes on the burner. Positioning the racks The racks are provided unassembled on the hob. To position each rack correctly on its burner, follow the instructions below: Each rack must be positioned on the corresponding burner in order to guarantee proper operation.
  • Page 9 All the racks have two reference notches (A). To position the racks correctly, align the reference notches (A) with the cavities (B) on the hob. After positioning, check that the rack feet are all resting on the same level. Make sure that the racks are simply centred on their respective burners, without forcing the burners to be raised or tilted.
  • Page 10 During cooking, in order to avoid burns or damage to the hob top, all pans or griddles must be positioned inside the outer edge of the hob and at a minimum distance of 5-7 cm must be maintained from the knobs.
  • Page 11 Instructions for the user Pan diameters BURNERS min. and max. Ø (in cm) 1 Auxiliary 7-18 2. Semi-rapid 10-24 3 Medium Rapid 18-24 4 Large Rapid 20-26...
  • Page 12: Cleaning And Maintenance

    Before performing any operations requiring access to powered parts, disconnect the appliance from the power supply. Cleaning the hob To keep the hob in good condition it should be cleaned regularly after use. Let it cool first. 6.1.1 Ordinary daily cleaning To clean and preserve the stainless steel surfaces, always use only specific products that do not contain abrasives or chlorine-based acids.
  • Page 13 6.2.2 Racks Remove the racks and clean them with lukewarm water and non- abrasive detergent, making sure to remove any encrustations. Replace them on the cooking hob. These components must not be washed in the dishwasher. 6.2.3 Flame-spreader crowns The flame-spreader crowns are removable. Wash them with lukewarm water and non-abrasive detergent, making sure to remove any encrustations.
  • Page 14: Positioning In The Counter Top

    "X" be kept between the appliance and the wall as shown in the figure so as to avoid damage from overheating. Make sure that there is a minimum distance of 750 mm between the hob and any shelf that may be installed directly above it.
  • Page 15 Depending on the hob model being installed refer to the dimensions in the figure, bearing in mind that for both models the long front side must brush against the hole. Fix the hob to the unit using the appropriate brackets A supplied.
  • Page 16: Clearances Above And Around Domestic Appliances

    Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s instructions. However, in no case shall the clearance between the highest part of the hob of the cooking appliance and a range hood be less than 600 mm or, for an overhead exhaust fan, 750 mm.
  • Page 17: Combustion Gas Discharge

    For definition of hob, see Clause 1.4.64. For definition of trivet, see Clause 1.4.109. Consideration is to be given to window treatments when located near cooking appliances.
  • Page 18: Electrical Connection

    Make sure that the supply line is suitably earthed. Pass the power supply cable through the back of the unit, taking care that it does not touch the bottom casing of the hob or the oven (if any) installed underneath it.
  • Page 19: Gas Connection

    Instructions for the installer 9. GAS CONNECTION Gas connection This appliance is suitable for installation with Natural Gas. Refer to “10.3 Burner and nozzle characteristics table” for the relevant burner pressure and appropriate injector sizes. When the appliance is to be connected to Natural Gas then the pressure regulator supplied must be fitted to the gas inlet.
  • Page 20 The room where the appliance is installed must have enough air flow needed for the regular combustion of gas and the necessary air change in the room itself. The hob shall be installed in rooms with natural ventilation, as required by Standards regulations AS/NZS560.
  • Page 21: Replacement Of Nozzles

    Before carrying out the following operations, disconnect the appliance from the power supply. The appliance is tested with NG (Natural Gas) at a pressure of 1kPa. In order to replace the nozzles and adjust the burners, the hob top must be removed as described below. 10.1...
  • Page 22 Instructions for the installer 10.2 Replacement of the cooking hob nozzles Caution: The maximum torque of the screw C should not exceed 1 Nm. Unscrew screw C and push air regulator D as far as it will go. Using a 7-mm wrench, remove nozzle E...
  • Page 23 Semi-rapid Medium Rapid Large Rapid To identify the burners on your hob, please refer to the illustrations in paragraph “10.7 Arrangement of the burners on the hob”. If having adjusted the air the flame appears as illustrated in the figure: the following modifications must be made: A: the flame is "noisy", unstable or "detaches"...
  • Page 24 After adjustment with a gas other than the preset one, replace the label on the casing of the appliance with the label corresponding to the new gas. The label is inserted inside the pack together with the nozzles. 10.7 Arrangement of the burners on the hob Type of burner 1 Auxiliary...
