Thank you for choosing our product.
We advise you to read this manual carefully. It contains all necessary
instructions for maintaining unaltered the appearance and functional
qualities of the hob.
NSTRUCTIONS FOR THE INSTALLER: these are for the authorised
persons who must carry out a suitable check of the gas system, install
the appliance, set it functioning and carry out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice,
description of the commands and the correct procedures for cleaning
and maintenance of the appliance.
Contents
3

Advertisement

Table of Contents
loading

Related Manuals for Smeg CIR574X

Summary of Contents for Smeg CIR574X

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR SAFE AND PROPER USE ______________________ 4 POSITIONING OF THE HOB ______________________________________ 6 GAS CONNECTION ____________________________________________ 10 ELECTRICAL CONNECTION _____________________________________ 11 ADAPTATION TO DIFFERENT TYPES OF GAS______________________ 12 FINAL OPERATIONS ___________________________________________ 14 USING THE HOB ______________________________________________ 16 CLEANING AND MAINTENANCE _________________________________ 18 PROBLEMS AND CAUSES ______________________________________ 22 Thank you for choosing our product.

  • Page 2: Instructions For Safe And Proper Use

    Introduction 1. INSTRUCTIONS FOR SAFE AND PROPER USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE HOB. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE HOB.
  • Page 3 Introduction THE IDENTIFICATION PLATE, WITH TECHNICAL DATA, SERIAL NUMBER AND MARKING IS CLEARLY VISIBLE UNDER THE CASING. THE PLATE ON THE CASING MUST NOT BE REMOVED. BEFORE CONNECTING THE DEVICE, MAKE SURE THAT IT HAS BEEN REGULATED FOR THE TYPE OF GAS THAT WILL FEED IT, CHECKING THE LABEL UNDER THE CASING.

  • Page 4: Positioning Of The Hob

    Instructions for the installer 2. POSITIONING OF THE HOB It is the law that all gas appliances are installed by authorised persons. Clearance around the appliance must comply with the requirements of AS5601. The following operation requires building and/or carpentry work so must be carried out by a competent tradesman.

  • Page 5: Instructions For The Installer

    Instructions for the installer Overall dimensions: location of gas and electrical connection points (all measures in mm). 2.2 Clearance above and around domestic appliances Extract from AS5601 30 CM 70 CM...
  • Page 6 Instructions for the installer REQUIREMENTS 1 Overhead clearances – (Measurement A) Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s instructions. However, in no case shall the clearance between the highest part of the hob of the cooking appliance and a range hood be less than 600 mm or, for an overhead exhaust fan, 750 mm.
  • Page 7 Instructions for the installer 2.3 Room ventilation Caution – This hob may only be installed and operated in rooms permanently ventilated in accordance with current regulations. For proper operation of a gas appliance it is essential for the air necessary for combustion of the gas to be able to flow naturally into the room.

  • Page 8: Gas Connection

    Instructions for the installer 3. GAS CONNECTION This appliance is suitable for installation with Natural Gas or ULPG (propane). Refer to page 12 for the relevant burner pressure and appropriate injector sizes. When the appliance is to be connected to Natural Gas then the pressure regulator supplied must be fitted to the gas inlet.

  • Page 9: Electrical Connection

    Instructions for the installer 4. ELECTRICAL CONNECTION Make sure that the voltage and capacity of the power line conform to the data shown on the plate located under the casing. Do not remove this plate for any reason. The plug on the end of the supply cable and the wall socket must be the same type and conform to the current electrical system regulations.

  • Page 10: Adaptation To Different Types Of Gas

    Instructions for the installer 5. ADAPTATION TO DIFFERENT TYPES OF GAS Before performing any cleaning or maintenance work, detach the appliance from the electrical socket. The hob has been adjusted for natural gas at a pressure of 1.0kPa. For functioning with other types of gas the nozzles must be replaced and the primary air adjusted.
  • Page 11 Instructions for the installer 5.2 Adjustment for LPG Loosen screw A and push support B all the way. Use a double head wrench to remove nozzle C and assemble the suitable one, following the instructions indicated in the reference charts, with respect to the type of gas to use.

  • Page 12: Final Operations

    Instructions for the installer 5.3 Adjustment for natural gas The hob has been adjusted for natural gas at a pressure of 1.0kPa. To allow the unit to work back with this type of gas, after it has been adjusted for LPG, perform the same operations described in paragraph “5.2 Adjustment for LPG”, but refer to the following table for the proper injectors.
  • Page 13 Instructions for the installer 6.2 Arrangement of burners on the hob Burners Auxiliary Semi rapid 3 - 6 Rapid Wok (dual control) 6.3 Lubrication of gas taps With time it may happen that the gas taps get blocked and hard to turn. Clean them inside and re-grease them.

  • Page 14: Using The Hob

    7. USING THE HOB Before turning on the burners, make sure that the burner rings, caps and grids have been fitted correctly. In the wok burner, notch A must be aligned with pin B. Grid C provided is intended for use with woks (Chinese pans). Adapter D comes only with open grids models and is intended for use with small sized vessels.
  • Page 15 Instructions for the user 7.2 Practical advice for using the burners For better use of the burners and lower gas consumption, use covered containers that are proportional in size to the burner to prevent the flame from licking the sides (see paragraph “7.3 Diameter of containers”).
  • Page 16 7.4 Electric elements 7.4.1 Turning on electric elements Hobs may be fitted with an electric element of varying diameter. The electric element is controlled by a switch and is turned on by rotating the appropriate knob to the desired position. Raised indicators make for easier and clearer reading and use of the controls, each knob being connected to its corresponding electric element by a rib.
  • Page 17 Instructions for the user WARNING When switching on the electric element for the first time, or if the electric element has not been used for a long time, to remove any humidity from the insulating material it should be dried out by placing the electric element on position 1 for 30 minutes.

  • Page 18: Cleaning And Maintenance

    8. CLEANING AND MAINTENANCE Before any intervention, disconnect the power supply of the device. 8.1 Cleaning Clean the top regularly every time you use it, obviously after it has cooled. 8.1.1 Regular daily cleaning of the hob In order to clean and preserve the surface, always use specific products only, which do not contain abrasive substances or chlorine-based acid substances.

  • Page 19: Preventive Maintenance

    Instructions for the user 8.3 Preventive maintenance This appliance does not need any special maintenance. However, a few simple operations have to be carried out periodically to prevent malfunctioning: Burners: the burners must be cleaned after every use to ensure correct combustion;...

  • Page 20: Problems And Causes

    9. PROBLEMS AND CAUSES Each of the following cases is caused by an abnormal operation of the appliance and should be dealt with by a authorised persons: please contact your local dealer or Service Center in case you detect any of these malfunctioning.
