1.
2.
INSTALLATION OF THE APPLIANCE_________________________ 6
3.
GAS CONNECTION _______________________________________ 8
4.
5.
FINAL OPERATIONS _____________________________________ 13
6.
USE OF THE COOKING HOB ______________________________ 14
7.
CLEANING AND MAINTENANCE ___________________________ 16
8.
PROBLEMS AND CAUSES ________________________________ 18
Thank you for choosing our product.
We advise you to read this manual carefully. It contains all necessary
instructions for maintaining unaltered the appearance and functional
qualities of the hob.
INSTRUCTIONS FOR THE INSTALLER: these are for the authorised
persons who must carry out a suitable check of the gas system, install
the appliance, set it functioning and carry out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice,
description of the commands and the correct procedures for cleaning
and maintenance of the appliance.
Contents
3

Advertisement

Table of Contents
loading

Related Manuals for Smeg Hob

Summary of Contents for Smeg Hob

  • Page 1: Table Of Contents

    INSTALLATION OF THE APPLIANCE_________________________ 6 GAS CONNECTION _______________________________________ 8 ADAPTATION TO DIFFERENT TYPES OF GAS _______________ 11 FINAL OPERATIONS _____________________________________ 13 USE OF THE COOKING HOB ______________________________ 14 CLEANING AND MAINTENANCE ___________________________ 16 PROBLEMS AND CAUSES ________________________________ 18 Thank you for choosing our product.

  • Page 2: Instructions For Safe And Proper Use

    THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE COOKING HOB. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE COOKING HOB. ALSO KEEP THE SERIES OF NOZZLES SUPPLIED. INSTALLATION...
  • Page 3 DO NOT USE RECIPIENTS OR GRIDDLE PLATES THAT EXTEND BEYOND THE EXTERNAL PERIMETER OF THE HOB. THE HOB IS TO BE USED BY ADULTS ONLY. DO NOT LET UNSUPERVISED CHILDREN PLAY WITH THE HOB. REPLACED APPLIANCES MUST BE TAKEN TO A SPECIAL GARBAGE COLLECTION CENTRE.

  • Page 4: Installation Of The Appliance

    Instructions for the installer 2. INSTALLATION OF THE APPLIANCE It is the law that all gas appliances are installed by an authorised persons. Clearance around the appliance must comply with the requirements of AS5601. (see 2.6) Positioning The following operation requires building and/or carpentry work so must be carried out by a competent tradesman.

  • Page 5: Electrical Connection

    0.75 mm (3 x 0.75 cable), keeping in mind that the end to be connected to the hob must have the ground wire (yellow-green) longer by at least 20 mm. Use only H05V2V2-F cable or similar which has a maximum temperature of 90°C.

  • Page 6: Gas Connection

    Instructions for the installer 3. GAS CONNECTION This appliance is suitable for installation with Natural Gas or ULPG (propane). Refer to page 12 for the relevant burner pressure and appropriate injector sizes. When the appliance is to be connected to Natural Gas then the pressure regulator supplied must be fitted to the gas inlet.
  • Page 7 750 mm. Any other downward facing combustible surface less than 600 mm above the highest part of the hob shall be protected for the full width and depth of the cooking surface area in accordance with Clause 5.12.1.2. However, in no case shall this clearance to any surface be...

  • Page 8: Room Ventilation

    200 mm, the surface shall be protected in accordance with Clause 5.12.1.2 to a height C of not less than 150 mm above the hob for the full dimension (width or depth) of the cooking surface area. Where the cooking appliance is fitted with a ‘splashback’, protection of the rear wall is not required.

  • Page 9: Adaptation To Different Types Of Gas

    Before performing any cleaning or maintenance work, detach the appliance from the electrical socket. The cooker hob is set for natural gas NG (2H) at a pressure of 1.0 kPa. In the case of functioning with other types of gas the burner nozzles must be changed and the minimum flame adjusted on the gas taps.

  • Page 10: Burner And Nozzle Characteristics Table

    0.88 WOK (4) 13.5 1.00 Burner NG – 1.0 kPa Nominal gas Injector consumption (mm) (MJ/h) Auxiliary (1) 0.90 Semi rapid (2) 1.20 Rapid (3) 1.55 WOK (4) 1.75 Arrangement of burners on cooking hob BURNERS Auxiliary Semi rapid Rapid...

  • Page 11: Final Operations

    Instructions for the installer 5. FINAL OPERATIONS Having carried out the above adjustments, reassemble the appliance following, backwards, the instructions in paragraph “3.2 Burner and nozzle characteristics table”. After adjustment to a different kind of gas from the one for which the cooker has been tested, replace the plate inside the heating compartment with one corresponding to the new kind of gas.

  • Page 12: Use Of The Cooking Hob

    USE OF THE COOKING HOB Lighting the burners Before lighting the hob burners check that the flame caps are in the correct position and that their burner caps are in place, making sure that the holes A in the flame caps correspond to the spark plugs and thermocouples.

  • Page 13: Practical Advice For Using The Burners

    When water reaches the boiling point, lower the flame so that it doesn’t overflow. To avoid burns or damage to the hob, all recipients or griddle plates must be placed within the perimeter of the cooking hob. When using fats or oils, be extremely careful that they don’t overheat and catch fire.

  • Page 14: Cleaning And Maintenance

    Use normal non-abrasive products for steel, and a wooden or plastic tool if necessary. Rinse thoroughly and dry with a soft cloth or deerskin. 7.2 Cleaning of cooking hob components Grids, caps, flame cap crowns and burners can be removed for ease of cleaning. Wash them in warm water using a non-abrasive detergent, taking care to remove all tough spots.
  • Page 15 Instructions for the user Preventive maintenance This appliance does not need any special maintenance. However, a few simple operations have to be carried out periodically to prevent malfunctioning: Burners: the burners must be cleaned periodically to ensure correct combustion; make sure that all the openings and flame ports are clean and free of obstacles, and that the burners rest firmly on their supports.

  • Page 16: Problems And Causes

    Instructions for the user 8. PROBLEMS AND CAUSES Each of the following cases is caused by an abnormal operation of the appliance and should be dealt with by a authorised persons: please contact your local dealer or Service Center in case you detect any of these malfunctioning.
