Smeg Hob Instructions For The Installer

Advertisement

1. INSTRUCTIONS FOR USE ................................................................ 4
2. SAFETY PRECAUTIONS ................................................................... 6
3. ENVIRONMENTAL CARE................................................................... 8
4. USING THE HOB................................................................................ 9
5. CLEANING AND MAINTENANCE.................................................... 11
6. POSITIONING IN THE COUNTER TOP .......................................... 12
7. ADAPTATION TO DIFFERENT TYPES OF GAS ............................ 20
8. FINAL OPERATIONS ....................................................................... 22
INSTRUCTIONS FOR THE USER: these contain user advice, the description
of the controls and the correct procedures for cleaning and maintenance of
the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the
authorized person who must install the appliance, set it functioning and
carry out an inspection test.
@
Further information about the products can be found at www.smeg.com
Contents
3

Advertisement

Table of Contents
loading

Summary of Contents for Smeg Hob

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR THE INSTALLER: these are intended for the authorized person who must install the appliance, set it functioning and carry out an inspection test. Further information about the products can be found at www.smeg.com...
  • Page 2: Instructions For Use

    FATS AND OILS MAY CATCH FIRE. ALWAYS CHECK THAT THE CONTROL KNOBS ARE IN THE (OFF) POSITION WHEN YOU FINISH USING THE APPLIANCE NEVER PLACE PANS WITH BOTTOMS WHICH ARE NOT PERFECTLY FLAT AND SMOOTH ON THE COOKING HOB PAN STANDS.
  • Page 3: General Instructions

    General instructions NEVER USE PANS OR GRIDDLE PLATES WHICH PROJECT BEYOND THE OUTSIDE EDGE OF THE HOB. SUITABLE HEAT-PROOF GLOVES SHOULD BE WORN FOR ALL OPERATIONS. DO NOT USE OR STORE FLAMMABLE MATERIALS IN THE APPLIANCE STORAGE DRAWER OR NEAR THIS APPLIANCE.
  • Page 4: Safety Precautions

    General instructions 2. SAFETY PRECAUTIONS REFER TO THE INSTALLATION INSTRUCTIONS FOR THE SAFETY REGULATIONS FOR ELECTRIC OR GAS APPLIANCES AND VENTILATION FUNCTIONS. IN YOUR INTERESTS AND FOR YOUR SAFETY THE LAW REQUIRES THAT THE INSTALLATION AND SERVICING OF ALL ELECTRICAL APPLIANCES IS CARRIED OUT BY QUALIFIED PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN FORCE.
  • Page 5 General instructions THIS APPLIANCE MAY NOT BE USED BY PEOPLE (INCLUDING CHILDREN) OF REDUCED PHYSICAL AND MENTAL CAPACITY, OR LACKING IN EXPERIENCE IN THE USE OF ELECTRICAL APPLIANCES, UNLESS THEY ARE SUPERVISED OR INSTRUCTED BY ADULTS RESPONSIBLE FOR THEIR SAFETY. DO NOT LET CHILDREN GO NEAR THE APPLIANCE WHEN IT IS IN OPERATION OR PLAY WITH IT AT ANY TIME.
  • Page 6: Environmental Care

    Instructions for disposal 3. ENVIRONMENTAL CARE Our products packing is made of non-polluting materials, which are therefore compatible with the environment and recyclable. Please help by disposing of the packaging correctly. You can obtain the addresses of collection, recycling and disposal centres from your retailer or from the competent local organisations.
  • Page 7: Using The Hob

    3 and thermocouples 2. To prevent damage to the work top, the hob comes complete with a raised pan stand 4: This must be placed under pans with a diameter greater than those indicated in the table in point "4.3 Cookware diameters".
  • Page 8 Once the contents come to the boil, turn down the flame far enough to prevent the liquid from boiling over. To prevent burns or damage to the hob during cooking, all cookware must be placed inside the perimeter of the hob.
  • Page 9: Cleaning And Maintenance

    Replace the burner caps on their corresponding crowns as indicated in “4.1 Lighting the hob burners”. For correct operation the igniters and thermocouples must always be perfectly clean.
  • Page 10: Positioning In The Counter Top

    The brackets shown in the figure should be placed only after the hob has been built in.
  • Page 11 Instructions for the installer Carefully trim the surplus away from edge beyond the seal. The dimensions given in figure 2 refer from the hole to the inside of the seal. Dimensions: Gas and electrical connection location (measurements in mm).
  • Page 12 IMPORTANT: if the appliance is mounted on a unit, make sure that a separating shelf is installed, as shown in the figure. If the appliance is instead on an oven installed under the hob, there is no need to install a separating shelf.
  • Page 13: Clearances Above And Around Domestic Appliances

    Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s instructions. However, in no case shall the clearance between the highest part of the hob of the cooking appliance and a range hood be less than 600 mm or, for an overhead exhaust fan, 750 mm.
  • Page 14 For definition of hob, see Clause 1.4.64. For definition of trivet, see Clause 1.4.109. Consideration is to be given to window treatments when located near cooking appliances.
  • Page 15 If installed over an oven, make sure that the cables (oven and hob) follow the optimal path, so as to avoid any contact with the oven.
  • Page 16 Instructions for the installer Gas connection This appliance is suitable for installation with Natural Gas or ULPG (propane/butane). Refer to page 21 for the relevant burner pressure and appropriate injector sizes. When the appliance is to be connected to Natural Gas then the pressure regulator supplied must be fitted to the gas inlet.
  • Page 17 “9.2 Burner and nozzle characteristics table”. Room ventilation Caution – This hob shall be installed in rooms with natural ventilation, as required by standards regulations AS/NZS5601. Combustion gas discharge Combustion gases may be discharged by means of hoods connected to a flue with reliable natural draught, or a fan extraction system.
  • Page 18: Adaptation To Different Types Of Gas

    To change the nozzles, proceed as described in the following paragraphs. Replacing the hob nozzles 7 Extract the pan stands and remove all caps and flame-spreader crowns; 8 Unscrew the burner nozzles with a 7 mm socket spanner;...
  • Page 19 0.94 + 0.46 Burner NG – 1.0 kPa Nominal gas Injector Consumption (MJ/h) (mm) Auxiliary (1) 0.90 Semi-rapid (2) 1.20 UR2 (3) 15.2 1.65 + 0.80 Arrangement of the burners on the hob BURNERS 1 Auxiliary 2 Semi-rapid 3 UR2...
  • Page 20: Final Operations

    After making the adjustments described above, reassemble the appliance by following in reverse the instructions reported in paragraph "7.1 Replacement of the cooking hob nozzles". After adjustment with a gas other than the preset one, replace the label on the casing of the appliance with the label corresponding to the new gas.
