1. INSTRUCTIONS FOR USE ................................................................ 4
2. SAFETY PRECAUTIONS ................................................................... 6
3. ENVIRONMENTAL RESPONSIBILITY ............................................... 8
4. DESCRIPTION OF CONTROLS......................................................... 9
5. USING THE HOB.............................................................................. 10
6. CLEANING AND MAINTENANCE.................................................... 13
7. POSITIONING ON THE HOB TOP................................................... 15
8. ELECTRICAL CONNECTION........................................................... 19
9. GAS CONNECTION ......................................................................... 20
10. ADAPTATION TO DIFFERENT TYPES OF GAS ........................... 22
INSTRUCTIONS FOR THE USER: these instructions contain user
recommendations, a description of the controls and the correct
procedures for cleaning and maintenance of the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the
authorised person who must install the appliance, set it functioning and
carry out an inspection test.
@
Further information about the products can be found at www.smeg.com
Contents
3

Advertisement

Table of Contents
loading

Summary of Contents for Smeg Hob

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR THE INSTALLER: these are intended for the authorised person who must install the appliance, set it functioning and carry out an inspection test. Further information about the products can be found at www.smeg.com...
  • Page 2: Instructions For Use

    THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. IT MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE HOB. WE ADVISE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT CONTAINS CAREFULLY BEFORE USING THE HOB. ALSO KEEP THE SERIES OF NOZZLES PROVIDED.
  • Page 3: General Instructions

    ALWAYS CHECK THAT THE CONTROL KNOBS ARE IN THE (OFF) POSITION WHEN YOU FINISH USING THE HOB. NEVER PLACE PANS WITH BOTTOMS WHICH ARE NOT PERFECTLY FLAT AND SMOOTH ON THE COOKING HOB PAN STANDS. NEVER USE PANS WHICH PROJECT BEYOND THE OUTSIDE EDGE OF THE HOB.
  • Page 4: Safety Precautions

    General instructions 2. SAFETY PRECAUTIONS REFER TO THE INSTALLATION INSTRUCTIONS FOR THE SAFETY REGULATIONS FOR ELECTRIC OR GAS APPLIANCES AND VENTILATION FUNCTIONS. IN YOUR INTERESTS AND FOR YOUR SAFETY THE LAW REQUIRES THAT THE INSTALLATION AND SERVICING OF ALL ELECTRICAL APPLIANCES IS CARRIED OUT BY QUALIFIED PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN FORCE.
  • Page 5 General instructions DO NOT LET CHILDREN GO NEAR THE APPLIANCE WHEN IT IS IN OPERATION OR PLAY WITH IT AT ANY TIME. DO NOT INSERT POINTED METAL OBJECTS (CUTLERY OR UTENSILS) INTO THE SLITS IN THE APPLIANCE. DO NOT USE STEAM JETS FOR CLEANING THE APPLIANCE. THE STEAM COULD REACH THE ELECTRONICS, DAMAGING THEM AND CAUSING SHORT-CIRCUITS.
  • Page 6: Environmental Responsibility

    Instructions for disposal 3. ENVIRONMENTAL RESPONSIBILITY Our environmental responsibility Adequate differentiated collection for the subsequent forwarding of the decommissioned product to recycling, processing and ecologically compatible disposal contributes to avoiding possible negative effects on the environment and on health, and promotes recycling of the appliance's constituent materials. Illicit disposal of the product by the user will lead to the application of administrative sanctions.
  • Page 7: Description Of Controls

    Instructions for the user 4. DESCRIPTION OF CONTROLS Control area All the hob controls are grouped together on the front central area. CONTROL ZONE KNOB DESCRIPTION To light the flame, press the knob and, at the same time, turn it...
  • Page 8: Using The Hob

    Positioning the racks The racks are provided separate unassembled on the hob. To position each rack correctly on its burner, follow the instructions below: Each rack must be positioned on the corresponding burner in order to guarantee proper operation.
  • Page 9 (1) and (2) and then lower it until onto the matching fixing pins on the hob. it is resting on the hob. When properly positioned, the legs of the racks must not be suspended above the hob but should rest on top of it.
  • Page 10: Pan Diameters

    (see “5.5 Pan diameters”). During cooking, in order to avoid burns or damage to the hob top, all pans or griddles must be positioned inside the outer edge of the hob and at a minimum distance of 5-7 cm must be maintained from the knobs.
  • Page 11: Cleaning And Maintenance

    Before performing any operations requiring access to powered parts, switch off the power supply to the appliance Cleaning the hob To keep the hob in good condition it should be cleaned regularly after use. Let it cool first. 6.1.1 Ordinary daily cleaning To clean and preserve the glass and brass surfaces, always use only specific products that do not contain abrasives or chlorine-based acids.
  • Page 12 Scotch bright sponge or with a brass brush, rinse and dry with a microfibre cloth and put it back on the hob. WARNING: never wash in the dishwasher.
  • Page 13: Positioning On The Hob Top

    In case of installation on an empty kitchen unit with doors, a separation panel must be placed under the hob. Keep a minimum distance of 10 mm between the bottom of the hob and the surface of the panel, which must be easily extractable to allow sufficient access for...
  • Page 14 The figure to the side shows the exact holes to be used to correctly attach the hob to the work surface with brackets. IMPORTANT: If the hob is to be installed on top of an oven, ensure that the latter is equipped with a cooling fan.
  • Page 15: Clearances Above And Around Domestic Appliances

    Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s instructions. However, in no case shall the clearance between the highest part of the hob of the cooking appliance and a range hood be less than 600 mm or, for an overhead exhaust fan, 750 mm.
  • Page 16: Combustion Gas Discharge

    For definition of hob, see Clause 1.4.64. For definition of trivet, see Clause 1.4.109. Consideration is to be given to window treatments when located near cooking appliances.
  • Page 17: Electrical Connection

    Make sure that the supply line is suitably earthed. Pass the power supply cable through the back of the unit, taking care that it does not touch the bottom casing of the hob or the oven (if any) installed underneath it.
  • Page 18: Gas Connection

    Instructions for the installer 9. GAS CONNECTION Gas connection This appliance is suitable for installation with Natural Gas or ULPG (propane/butane). Refer to page 25 for the relevant burner pressure and appropriate injector sizes. When the appliance is to be connected to Natural Gas then the pressure regulator supplied must be fitted to the gas inlet.
  • Page 19 The room where the appliance is installed must have enough air flow needed for the regular combustion of gas and the necessary air change in the room itself. The hob shall be installed in rooms with natural ventilation, as required by Standards regulations AS/NZS560.
  • Page 20: Adaptation To Different Types Of Gas

    In order to replace the nozzles and adjust the burners, the hob top must be removed as described below. 10.1 Removing the hob top...
  • Page 21 Instructions for the installer 10.2 Replacement of nozzles on the cooker hob Caution: The maximum torque of the screw C should not exceed 1 Nm. Unscrew screw C and push air regulator D as far as it will go. Using a 7-mm wrench, remove nozzle E and replace...
  • Page 22 Instructions for the installer 10.3 Burner and nozzle characteristics table Burner ULPG - 2.75 kPa Nominal gas consumption Injector (MJ/h) (1/100 mm) Auxiliary Semi-Rapid Medium-Rapid Large-Rapid 11.5 Burner Natural Gas - 1.0 kPa Nominal gas consumption Injector (MJ/h) (1/100 mm) Auxiliary Semi-Rapid Medium-Rapid...
  • Page 23: Auxiliary Semi-Rapid Medium-Rapid Large-Rapid

    Semi-Rapid Medium-Rapid Large-Rapid To identify the burners on your hob, please refer to the illustrations in “10.7 Arrangement of the burners on the hob”. If after adjusting the air the flame is in the modes shown in the diagram: the following changes need to be made: A: the flame is noisy, unstable and is separated from the burner: the primary air is too open.
  • Page 24: Auxiliary

    After adjustment with a gas other than the preset one, replace the label on the casing with the label corresponding to the new gas. The label is in the bag with the nozzles provided. 10.7 Arrangement of the burners on the hob Type of burner 1 Auxiliary...
