Page 3: Table Of Contents
Contents Introduction Energy Star®..................1-4 What is an Energy Star® product? ..........1-4 Trademarks and registered trademarks......... 1-5 License information................ 1-5 OpenSSL Statement ..............1-6 Software licence agreement............1-9 Explanation of manual conventions..........1-11 Safety advices................1-11 Sequence of action ..............1-11 Tips ....................
Page 4 CDRH regulations ................. 2-15 For European users............... 2-16 For Denmark users ............... 2-16 For Finland, Sweden users ............2-16 For Norway users................2-17 Laser safety label ................2-18 Ozone release ................2-19 Acoustic noise (for European users only) ........2-19 For EU member states only ............
Page 5 Setting up the printer driver About the provided printer drivers..........3-3 Printer drivers and supported operating systems......3-3 System requirements ..............3-4 Setting up the system ..............3-5 Installing the printer driver .............. 3-6 When used with Windows.............. 3-6 Installing the printer driver using the Add Printer Wizard ....3-8 For Windows XP/Server 2003 ............
Page 6 Printer driver settings (For Windows 2000/XP/Server 2003) ..3-42 Printer driver settings (For Windows NT 4.0) ........ 3-43 Port 9100 printing (Windows 98SE/Me/2000/XP/Server 2003) ..3-44 Operations on this machine ............3-44 Printer driver settings (Windows 2000/XP/server 2003) ....3-45 Installing the Peer to Peer Printing Tool to connect using Port 9100 (Windows 98SE/Me).............
Page 7 Stapling ..................4-19 Hole punching ................4-19 Fold & Staple................4-20 Selecting the output method ............4-21 Specifying Account Track settings ..........4-24 Specifying the Per Page Setting tab settings ......4-26 Printing documents with a front cover/back cover ...... 4-26 Printing multiple pages ..............
Page 8 Specifying the Watermark tab settings......... 4-68 Printing a watermark..............4-68 Editing a watermark ..............4-69 Specifying the Quality tab settings ..........4-71 Specifying settings................ 4-72 Font settings ................. 4-73 Specifying the Option tab settings ..........4-74 Specifying settings................ 4-75 Saving the driver settings ............. 4-77 To save the driver settings............
Page 9 Security ..................4-117 Finishing ..................4-120 Quality ..................4-122 Setup..................4-124 Setting options................4-125 Specifying settings..............4-125 Saving the driver settings............4-127 To save the driver settings ............4-127 Viewing the settings ..............4-128 Changing the settings ..............4-128 Control panel settings Control panel..................
Page 10 Loading copy paper Paper ....................6-3 Possible paper sizes ............... 6-3 Paper types and paper capacities ..........6-5 Special paper .................. 6-6 Precautions for paper ..............6-8 Paper storage ................. 6-8 Print area..................6-9 Auto tray switch feature ..............6-9 Order for selecting the paper trays ..........
Page 11 Troubleshooting When the message “Trouble” appears (call technical representative) ............9-3 To call the technical representative ..........9-3 When the message “Paper Misfeed at” appears......9-4 Paper misfeed indications.............. 9-5 To clear a paper misfeed in the bypass tray........9-7 To clear a paper misfeed in the ADU ..........
Page 12 Box tab ..................10-13 Print tab ..................10-14 Administrator mode ..............10-15 Basic operation ................10-15 System tab.................. 10-16 Job tab..................10-17 Box tab ..................10-17 Print tab ..................10-18 Network tab ................10-18 10.2 Box operations................10-20 Available parameters ..............10-20 Opening Boxes ................
Page 13 11 Appendix 11.1 Specifications ................. 11-3 bizhub C352P................11-3 Automatic Duplex Unit ..............11-6 Option specifications ..............11-6 Paper Feed Cabinet PC-103............11-6 Paper Feed Cabinet PC-203............11-7 Paper Feed Cabinet PC-403............11-7 Finisher FS-514................11-8 Punch kit PK-510 ................. 11-9 Saddle stitcher SD-503..............
Page 14: C352P (Phase 3)
Contents-12 C352P (Phase 3)
Page 15: Introduction
Introduction...
Page 17 Introduction Introduction Thank you for choosing this machine. This manual contains details on the operation of the various functions of the machine, precautions on its use, and basic troubleshooting procedures. In order to ensure that this machine is used correctly and efficiently, carefully read this manual before using the machine.
Page 18: Energy Star
Introduction Energy Star® ® As an Energy Star Partner, we have determined that this machine meets the ® Energy Star Guidelines for energy efficiency. What is an Energy Star® product? ® An Energy Star product has a special feature that allows it to automatically ®...
Page 19: Trademarks And Registered Trademarks
Introduction Trademarks and registered trademarks KONICA MINOLTA, KONICA MINOLTA Logo, and The essentials of imaging are registered trademarks or trademarks of KONICA MINOLTA HOLDINGS, INC. PageScope and bizhub are registered trademarks or trademarks of KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. Netscape Communications, the Netscape Communications logo, Netscape Navigator, Netscape Communicator, and Netscape are trademarks of Netscape Communications Corporation.
Page 20: Openssl Statement
Introduction OpenSSL Statement OpenSSL License Copyright © 1998-2000 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Page 21 Introduction Original SSLeay License Copyright © 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved. This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The implementation was written so as to conform with Netscapes SSL. This library is free for commercial and non-commercial use as long as the following conditions are aheared to.
Page 22: C352P (Phase 3)
Introduction (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. The licence and distribution terms for any publically available version or derivative of this code cannot be changed. i.e. this code cannot simply be copied and put under another distribution licence [including the GNU Public Licence.] All other product names mentioned are trademarks or registered trademarks...
Page 23: Software Licence Agreement
Introduction Software licence agreement This package contains the following materials provided by Konica Minolta Business Technologies, Inc. (KMBT): software included as part of the printing system, the digitally-encoded machine-readable outline data encoded in the special format and in the encrypted form ("Font Programs"), other software which runs on a computer system for use in conjunction with the Printing Software ("Host Software"), and related explanatory written materials...
Page 24: C352P (Phase 3)
Introduction 9. You may not rent, lease, sublicense, lend or transfer versions or copies of the Software Licensee does not use, or Software contained on any unused media, except as part of the permanent transfer of all Software and Documentation as described above. 10.
Page 25: Explanation Of Manual Conventions
Introduction Explanation of manual conventions The marks and text formats used in this manual are described below. Safety advices 6 DANGER Failure to observe instructions highlighted in this manner may result in fatal or critical injuries in fact of electrical power. Observe all dangers in order to prevent injuries.
Page 26: Tips
Introduction Tips Note Text highlighted in this manner contains useful information and tips to ensure safe use of the machine. Reminder Text highlighted in this manner contains information that should be reminded. Detail Text highlighted in this manner contains references for more detailed information.
Page 27: Installation And Operation Precautions
Installation and operation precautions...
Page 29: Safety Information
Installation and operation precautions Installation and operation precautions Safety information This section contains detailed instructions on the operation and maintenance of this machine. To achieve optimum utility of this device, all operators should carefully read and follow the instructions in this manual. Please read the following section before connecting the machine to the supply.
Page 30: Meaning Of Symbols
Installation and operation precautions Meaning of Symbols Symbol Meaning Example Meaning A triangle indicates a danger This symbol warns against pos- against which you should take sible causes of burns. precaution. A diagonal line indicates a pro- This symbol warns against dis- hibited course of action.
Page 31: Power Cord
Installation and operation precautions Power cord 7 WARNING Ignoring this warnings could cause serious injury or even death. Do not ignore this safety advices. Warning Symbol • Use only the power cord supplied in the package. If a power cord is not supplied, only use the power cord and plug that is specified in POWER CORD INSTRUCTION.
Page 32: Power Source
Installation and operation precautions Power source 7 WARNING Ignoring this warnings could cause serious injury or even death. Do not ignore this safety advices. Warning Symbol • Use only the specified power source voltage. Failure to do that could result in a fire or electrical shock. •...
Page 33: Power Plug
Installation and operation precautions Power plug 7 WARNING Ignoring this warnings could cause serious injury or even death. Do not ignore this safety advices. Warning Symbol • Do not unplug and plug in the power cord with a wet hand, as an electrical shock could result.
Page 34: Installation
Installation and operation precautions Installation 7 WARNING Ignoring this warnings could cause serious injury or even death. Do not ignore this safety advices. Warning Symbol • Do not place a flower vase or other container that contains water, or metal clips or other small metallic objects on this product.
Page 35: Ventilation
Installation and operation precautions Ventilation 7 CAUTION Ignoring this cautions could cause injury or damage to property. Do not ignore this safety advices. Caution Symbol • Always use this product in a well ventilated location. Operat- ing the product in a poorly ventilated room for an extended period of time could injure your health.
Page 36: Consumables
Installation and operation precautions 7 CAUTION Ignoring this cautions could cause injury or damage to property. Do not ignore this safety advices. Caution Symbol • The inside of this product has areas subject to high temper- ature, which may cause burns. When checking the inside of the unit for malfunctions such as a paper misfeed, do not touch the locations (around the fus- ing unit, etc.) which are indicated by a "Caution HOT"...
Page 37: When Moving The Machine
Installation and operation precautions When moving the machine 7 CAUTION Ignoring this cautions could cause injury or damage to property. Do not ignore this safety advices. Caution Symbol • Whenever moving this product, be sure to disconnect the power cord and other cables. Failure to do this could damage the cord or cable, resulting in a fire, electrical shock, or breakdown.
Page 38: Regulation Notices
Installation and operation precautions Regulation notices CE Marking (Declaration of conformity) for users of the European Union (EU) This product complies with the following EU directives: 89/336/EEC, 73/23/EEC and 93/68/EEC directives. This declaration is valid for the area of the European Union. This device must be used with a shielded network (10 Base-T/100 Base-TX) cable and a shielded parallel cable.
Page 39: Interference-Causing Equipment Standard (Ices-003 Issue 4) (For Canada Users)
Installation and operation precautions INTERFERENCE-CAUSING EQUIPMENT STANDARD (ICES-003 ISSUE 4) (for Canada users) This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. For users in countries not subject to class B regulations 7 WARNING Interference with radio communications.
Page 40: Internal Laser Radiation
Installation and operation precautions Internal laser radiation Specification Maximum Average Radia- 11.6 μW at the laser aperture of the print head unit tion Power Wavelength 775-800 nm 7 WARNING This product employs a Class 3B laser diode that emits an invisible laser beam.
Page 41: Cdrh Regulations
Installation and operation precautions CDRH regulations This machine is certified as a Class 1 Laser product under Radiation Performance Standard according to the Food, Drug and Cosmetic Act of 1990. Compliance is mandatory for Laser products marketed in the United States and is reported to the Center for Devices and Radiological Health (CDRH) of the U.S.
Page 42: For European Users
Installation and operation precautions For European users 7 CAUTION Use of controls, adjustments or performance of procedures other than those specified in this manual may result in hazardous radiation exposure. This is a semiconductor laser. The maximum power of the laser diode is 10 mW and the wavelength is 775-800 nm.
Page 43: For Norway Users
Installation and operation precautions 7 VARNING Det här är en halvledarlaser. Om apparaten används på annat sätt än i denna bruksanvisning specificerats, kan användaren utsättas för osynlig laserstrålning, som överskrider gränsen för laserklass 1. Det här är en halvledarlaser. Den maximala effekten för laserdioden är 10 mW och våglängden är 775-800 nm.
Page 44: Laser Safety Label
Installation and operation precautions Laser safety label A laser safety label is attached to the outside of the machine, as shown below. 2-18 C352P (Phase 3)
Page 45: Ozone Release
Installation and operation precautions Ozone release 7 CAUTION Locate the Machine in a Well Ventilated Room A negligible amount of ozone is generated during normal operation of this machine. An unpleasant odor may, however, be created in poorly ventilated rooms during extensive machine operations. For a comfortable, healthy, and safe operating environment, it is recommended that the room well ventilated.
Page 46: Caution Notations And Labels
Installation and operation precautions Caution notations and labels Safety precaution notations and labels appear on this machine at the following positions. Be very careful that an accident does not occur when operations such as removing paper misfeeds are performed. WARNING Do not burn used toner cartridges.
Page 47: Space Requirements
Installation and operation precautions Space requirements To ensure that machine operation, consumables replenishing, part replacement, and regular maintenance can easily be performed, adhere to the recommended space requirements detailed below. (17-1/4) (28) 1212 (7-1/2) (47-3/4) (13-1/2) Unit: mm (inch) C352P+FS-514+PC-403+SD-503+OT-601 Reminder Be sure to allow a clearance of 100 mm (4 inch) or more at the back of this machine for the ventilation duct.
Page 48: Operation Precautions
Installation and operation precautions Operation precautions To ensure the optimum performance of this machine, observe the precautions described below. Power source The power source requirements are as follows. - Voltage fluctuation: Maximum ± 10% (at 110 V/120 to 127 V/220 to 240 V AC) - Frequency fluctuation: Maximum ±...
Page 49: Part Names And Their Functions
Installation and operation precautions Part names and their functions Options * In order to maintain the functionality and quality of the machine, be sure to use the paper feed cabinet when installing the machine on the floor. C352P (Phase 3) 2-23...
Page 50 Installation and operation precautions Part Name Description Main unit The data sent from the computer is printed. Referred to as the "machine", the "main unit", or the "C352P" throughout the manual. Paper Feed Cabinet PC-103 The top tray can be loaded with up to 500 sheets of paper, and the bottom tray can be used as storage.
Page 51 Installation and operation precautions Reminder In order to maintain the functionality and quality of the machine, be sure to use the paper feed cabinet when installing the machine on the floor. C352P (Phase 3) 2-25...
Page 52: Outside Of Machine
Installation and operation precautions Outside of machine * The illustration above shows the main unit with the optional LCT installed. 2-26 C352P (Phase 3)
Page 53 Installation and operation precautions Part Name Description Turns over the paper for double-sided printing Bypass tray Used when printing onto paper with a size not load- ed into a paper tray or onto thick paper, OHP trans- parencies, postcards, envelopes or labels Holds up to 100 sheets of normal paper, 20 sheets of thick paper, OHP transparencies, postcards or label sheets, or 10 envelopes.
Page 54 Installation and operation precautions * The illustration above shows the main unit with the optional double paper feed cabinet installed. 2-28 C352P (Phase 3)
Page 55 Installation and operation precautions Part Name Description ADU release lever Used to open the ADU door when clearing paper misfeeds ADU door Opened when clearing paper misfeeds within the Upper right-side door release le- Used to open the upper right-side door Center right-side door Opened when clearing paper misfeeds from the tray 2...
Page 56 Installation and operation precautions 2-30 C352P (Phase 3)
Page 57 Installation and operation precautions Part Name Description Filter 2 Collects the toner dust generated in the machine Power connector Used for connecting the power cord Dehumidifier heater power switch Used to turn dehumidifier heater on and off. Turning on the dehumidifier heater reduces mois- ture in the paper.
Page 58: Inside Of Machine
Installation and operation precautions Inside of machine 2-32 C352P (Phase 3)
Page 59 Installation and operation precautions Part Name Description Fusing unit cover Opened when clearing paper misfeeds in the fusing unit Release levers Used when clearing paper misfeeds in the fusing unit. Fusing unit cover release button Pressed to open the fusing unit cover Upper right-side door Opened when clearing paper misfeeds from inside the main unit...
Page 60: Saddle Stitcher Sd-503/Mailbin Kit Mt-501
Installation and operation precautions Saddle stitcher SD-503/mailbin kit MT-501 Saddle stitcher SD-503 Part name Description Print output tray Collects printed pages. Misfeed-clearing door Opened when clearing paper misfeeds within the finisher Mailbin kit MT-501 Part name Description Mailbins Collects printed pages Misfeed-clearing door Opened when clearing paper misfeeds Lever [FN7]...
Page 61: Finisher Fs-514/Output Tray Ot-601/Punch Kit Pk-510
Installation and operation precautions Finisher FS-514/output tray OT-601/punch kit PK-510 C352P (Phase 3) 2-35...
Page 62: Output Tray Ot
Installation and operation precautions Finisher FS-514 Part name Description Output tray 1 Collects prints that are fed out Output tray 2 Collects prints that are fed out Dial [FN6] Turned when clearing paper misfeeds within the finisher Dial [FN5] Turned when clearing paper misfeeds within the finisher Dial [FN4] Turned when clearing paper misfeeds within the...
Page 63 Installation and operation precautions Precautions for using the finisher: - Do not place objects on top of the saddle stitcher or mailbin kit. - Do not place objects below the output trays of the finisher. C352P (Phase 3) 2-37...
Page 64: Control Panel
Installation and operation precautions Control panel Part Name Description Ready indicator Lights up when printing is possible and flashes when data is being received. Error indicator Lights up when an error occurs. [Cancel] key Press to cancel printing and other operations. [Menu/Select] key Press to display the menu and select settings.
Page 65: Basic Operations
Installation and operation precautions Basic operations Turning on the machine Set the power switch to [ n ]. Check that the control panel is turned on. Detail When the machine is turned on, the printer starts up and the message "Now warming-up."...
Page 66: Turning Off The Machine
Installation and operation precautions Turning off the machine Set the power switch to [o]. Reminder When the power switch is turned off, then on again, wait at least 10 seconds to turn it on after turning it off. If there is no wait period between turning the power switch off, then on again, the machine may not function properly.
Page 67: Automatically Canceling The Settings (Automatic Panel Reset)
Installation and operation precautions Automatically canceling the settings (automatic panel reset) If no operation is performed for a specified length of time while settings are being changed, settings that have not been programmed are cleared and return to their defaults. This is the automatic panel reset operation.
Page 68: Automatically Conserving Energy (Sleep Mode)
Installation and operation precautions Automatically conserving energy (Sleep mode) If no operation is performed for a specified length of time, the machine automatically enters a mode where it conserves energy. Although the machine conserves more energy in Sleep mode than in Low Power mode, the machine must warm up when Sleep mode is canceled to begin printing again, therefore taking more preparation time than Low Power mode.
Page 69: Power Supply
Installation and operation precautions Power supply Be sure to turn off the machine if it is not to be used for a long period of time, for example, overnight. In order to ensure that no energy is being consumed, unplug the machine. C352P (Phase 3) 2-43...
Page 70: Connecting To A Computer
Installation and operation precautions Connecting to a computer Compatible interfaces The various interfaces that can be used to connect this printer to a computer are described below. Ethernet interface Connect when using this printing system as a network printer. Supports 10Base-T and 100Base-TX standards. In addition, the Ethernet interface supports the TCP/IP (LDP/LPR, peer-to-peer), IPX/SPX (NetWare), and AppleTalk (EtherTalk) protocols.
Page 71: Connection Diagram
Installation and operation precautions Connection diagram The printer cables can be connected to each port at the back of this machine. Ethernet (10Base-T or 100 Base-TX) USB port Parallel port C352P (Phase 3) 2-45...
Page 72 Installation and operation precautions 2-46 C352P (Phase 3)
Page 73: Setting Up The Printer Driver
Setting up the printer driver...
Page 75: About The Provided Printer Drivers
The printer drivers included on the CD and the supported computer operat- ing systems are listed below. Install the required printer driver. - PCL (PCL XL) Konica Minolta Driver: Windows 98SE, Windows Me, Windows NT 4.0 (SP6a), Windows 2000 Professional (SP4 or later), Windows XP Home Edition, Windows XP...
Page 76: System Requirements
Setting up the printer driver System requirements Check that the computer being connected meets the following conditions. Windows - Operating System: Windows 98SE, Windows Me, Windows NT 4.0 (SP6a or later), Windows 2000 Professional (SP4 or later), Windows XP Home Edition (SP2 or later), Windows XP Professional (SP2 or later), or Windows Server 2003 - Processor: Pentium or higher - Memory: Capacity recommended for the operating system...
Page 77: Setting Up The System
Setting up the printer driver Setting up the system In order to use this printing system, it must first be set up. Setup consists of connecting this machine to a computer and installing the printer driver onto the computer being used. Setup the printing system as described below.
Page 78: Installing The Printer Driver
Setting up the printer driver Installing the printer driver When used with Windows The installation procedure of the Windows printer driver differs depending on how this machine is connected to the computer and depending on which printer driver is used. The installation method also differs depending on the version of Windows that you are using.
Page 79 Setting up the printer driver Note To install the printer driver on a computer running Windows XP, Windows Server 2003, Windows 2000, or Windows NT 4.0, log on with a user name registered with Administrator privileges. To connect this machine to a computer using a parallel connection or a USB connection, the optional local interface kit is required.
Page 80: Installing The Printer Driver Using The Add Printer Wizard
– Konica Minolta PCL driver: User Software CD-ROM – Konica Minolta PostScript driver: PostScript Printer Driver CD- Click the [Start] button, and then click "Printers and Faxes". – If "Printers and Faxes" does not appear in the Start menu, click Control Panel in the Start menu, click "Printers and Other...
Page 81 Specify the folder on the CD-ROM that contains the printer driver for the operating system being used, and then click the [OK] button. – Konica Minolta PCL driver: Folder at Driver\bizhubC352 on the User Software CD-ROM – Konica Minolta PostScript driver: Folder at Driver\bizhubC352 on the PostScript Printer Driver CD-ROM Click the [OK] button.
Page 82: For Windows 98Se/Me/2000/Nt 4.0
Specify the folder on the CD-ROM that contains the printer driver for the operating system being used, and then click the [OK] button. – For Windows 98SE/Me Konica Minolta PCL driver: Folder at Driver\bizhubC352 on the User Software CD-ROM PostScript PPD driver: Folder at Driver\PS-PPD on the PostScript Printer Driver CD-ROM –...
Page 83 Setting up the printer driver Click the [OK] button. The "Printers" list appears. Click the [Next] button. Specify the connection port. Select "LPT1" here. Follow the on-screen instructions. – When using a network connection, perform a test print after the net- work settings have been specified.
Page 84: Installing The Printer Driver Using Plug And Play
Specify the folder on the CD-ROM that contains the printer driver for the operating system being used, and then click the [OK] button. – Konica Minolta PCL driver: Folder at Driver\bizhubC352 on the User Software CD-ROM – PostScript PPD driver: Folder at Driver\PS-PPD on the PostScript Printer Driver CD-ROM Click the [Next] button, and then follow the on-screen instructions.
Page 85: For Windows Me/2000
[OK] button. Printer drivers that are available: – For Windows Me Konica Minolta PCL driver: Folder at Driver\bizhubC352 on the User Software CD-ROM Postscript PPD: Folder at Driver\PS-PPD on the PostScript Printer Driver CD-ROM –...
Page 86 Setting up the printer driver Click the [OK] button (for Windows Me, click the [Next] button), and then follow the on-screen instructions. Click the [Finish] button. When installation is complete, make sure that the icon of the installed printer appears in the Printers window. Remove the CD-ROM from the CD-ROM drive.
Page 87: For Windows Xp/Server 2003
Specify the folder on the CD-ROM that contains the printer driver for the operating system being used, and then click the [OK] button. – Konica Minolta PCL driver: Folder at Driver\bizhubC352 on the User Software CD-ROM – Konica Minolta PostScript driver: Folder at Driver\bizhubC352 on the PostScript Printer Driver CD-ROM Click the [Next] button, and then follow the on-screen instructions.
Page 88 Setting up the printer driver Click the [Finish] button. When installation is complete, make sure that the icon of the installed printer appears in the Printers and Faxes window. Remove the CD-ROM from the CD-ROM drive. This completes the printer driver installation. 3-16 C352P (Phase 3)
Page 89: Uninstalling The Printer Driver
Check the “C:\WINDOWS\system32\spool\drivers\w32x86” folder and delete the folder of the corresponding model if it is available. If the Konica Minolta PCL driver and Konica Minolta PostScript driver are both installed, the model information of both drivers is deleted. If one driver is remaining, do not delete it.
Page 90 Setting up the printer driver Delete the “oem*.inf” and “oem*.PNF” files in the “C:\WINDOWS\inf” folder. (The asterisk (*) in the file name displays a number, and the number varies according to the environment of the computer.) Before deleting the files, open the INF file, check that the model name is described in the last several lines, and then check that the file of the corresponding model is available.
Page 91: When Used With Macintosh
Setting up the printer driver When used with Macintosh The installation procedure for the Macintosh printer driver differs depending on the Mac OS version and printer driver being used. Refer to the table below for the appropriate procedure for installing the printer driver on your Macin- tosh computer.
Page 92: Installing The Printer Driver
Setting up the printer driver Installing the printer driver For Mac OS X Turn the Macintosh computer on. – Quit all running applications that may have started when the Mac- intosh computer was turned on. Insert the Macintosh printer driver CD-ROM into the Macintosh com- puter’s CD-ROM drive.
Page 93: Selecting A Printer
If this machine appears as a printer of a Bonjour connection, select "KONICA MINOLTA" from the "Print Using" drop-down list, select "KONICA MINOLTA C352/C300 PS(P)" in the model list, and then click the [Add] button. –...
Page 94 For Mac OS 10.4, enter "ipp" in the queue name text box. Select "KONICA MINOLTA" from the "Printer Model" drop-down list. Select "KONICA MINOLTA C352/C300 PS(P)", and then click the [Add] button. The selected printer is registered in the printer list.
Page 95 Setting up the printer driver For Mac OS 9.2 After connecting this machine, it can be used as a printer by selecting the PostScript printer from the Chooser and by specifying the printer description (PPD) file. First, copy the printer description (PPD) file onto the Macintosh computer. Insert the Macintosh printer driver CD-ROM into the Macintosh com- puter’s CD-ROM drive.
Page 96: Uninstalling The Printer Driver
Drag the following file, which is located on the hard disk in Library\Printers\PPDs\Contents\Resources\en.lproj, to the "Trash" icon. – KONICA MINOLTA C352.gz Delete the unnecessary files from Library\Printers. For Mac OS 10.3 and Mac OS 10.4, drag the "***c352" file, which is located in Library\Printers\ KONICAMINOLTA\filter, and the following files, which are located in Library\Printers\KONICAMINOLTA\PDEs, to the "Trash"...
Page 97: For Mac Os 9.2
Setting up the printer driver For Mac OS 10.2, drag the following files, which are located in Library\Printer\PPD Plugins, to the "Trash" icon. – KONICAMINOLTAC352 Finishing.plugin – KONICAMINOLTAC352 ImageLayout.plugin – KONICAMINOLTAC352 Security.plugin – KONICAMINOLTAC352 Setup.plugin Enter "/usr" in Go\Go folder to open to the "/usr" folder, and then drag the "***c352"...
Page 98: Printing Operations
Setting up the printer driver Printing operations For Windows Printing is possible when the printer driver is installed and the network set- tings have been specified. Print jobs are specified from the application soft- ware. Printing operation Open the data in the application, click "File", and then click "Print". Check that the printer name has been selected in "Printer Name"...
Page 99: Test Printing
Setting up the printer driver Test printing Printing is possible when the printer driver is installed and the network set- tings have been specified. To check that a connection has been made prop- erly, you can print the standard Windows test page. Print a test page from the printer driver Properties dialog box.
Page 100: For Macintosh
Setting up the printer driver For Macintosh Printing is possible when the printer driver is installed and the network set- tings have been specified. Print jobs are specified from the application soft- ware. Printing operation Open the data in the application, click "File", and then click "Print". The Print dialog box differs depending on the application.
Page 101: Setting Up Network Printing
Setting up the printer driver Setting up network printing Overview of network functions Network functions By connecting this machine to a network through the Ethernet port, this printing system can be used as a network printer. This printing system supports 10Base-T and 100Base-TX standards. In addition, the Ethernet interface supports the TCP/IP (LDP/LPR, IPP, SMB), NetBEUI (SMB), IPX/SPX (NetWare), and AppleTalk (EtherTalk) protocols.
Page 102: Features Of The Network Functions
Setting up the printer driver Features of the network functions This printing system is equipped with the following network functions to flex- ibly support various network environments. - Automatic selection of 10Base-T or 100Base-TX (Fast Ethernet) - Obtains the IP address automatically from DHCP or BOOTP - Printing with SMB printing (Windows 98SE/Me/2000/XP/Server 2003) You can print in Windows 98SE, Windows Me, Windows 2000, Windows XP, or Windows Server 2003 using SMB.
Page 103 Setting up the printer driver With NetWare The Novell NetWare 4.x—6 print server functions are supported. You can connect this printing system to a network using Novell NetWare 4.x—6 as the network operating system and send print jobs from the client to the print server (network controller).
Page 104: Network Connection Methods That Can Be Selected In Each Windows Operating System
Setting up the printer driver Network connection methods that can be selected in each Windows operating system This chapter describes the settings that must be specified for network print- ing. Setting procedures differ depending on the method of networking printing used (SMB, LPR, or IPP printing).
Page 105 Windows 2000/XP/2003 Driver type Using installer Not using in- Using installer Not using in- staller staller Konica Minolta Not required Required Not required Konica Minolta PostScript PostScript PPD Required If the printer driver is installed using the installer while this machine is connected to the network, the required Peer to Peer Printing Tool is also installed automatically, and Port 9100 is created.
Page 106 Setting up the printer driver Network printing in a NetWare environment NetWare Version Protocol Used Emulation Service Mode NetWare 4.x NDS/Bindery Pserver/Nprinter NetWare 5.x/6 Pserver TCP/IP NDPS(lpr) 3-34 C352P (Phase 3)
Page 107: Specifying The Tcp/Ip Settings
Setting up the printer driver Specifying the TCP/IP settings First, assign the IP address from the machine’s control panel. Press the [Menu/Select] key on this machine’s control panel, touch [+] or [,] to display the Admin. Setting screen, and then touch [)]. Enter the administrator password, and then press the [Menu/Select] key.
Page 108 Setting up the printer driver – IP Address: Select whether the "Auto Input" or "Manual Input" method is used to specify the IP address. If "Manual Input" is selected, specify settings for "IP Address", "Subnet Mask", and "Default Gateway". 3-36 C352P (Phase 3)
Page 109 Setting up the printer driver To apply the settings, restart this machine (turn it off, then on again). – When the machine is turned off, then on again, wait at least 10 sec- onds to turn the machine on after turning it off. The machine may not operate correctly if it is turned on immediately after being turned off.
Page 110: Accessing Pagescope Web Connection
Setting up the printer driver Accessing PageScope Web Connection Setting the IP address for this machine enables you to access PageScope Web Connection. Use your Web browser to directly access PageScope Web Connection. Start up the Web browser. In the "Address" bar, enter the IP address for this machine as shown below, and then press the [Enter] key.
Page 111: Smb Printing
Setting up the printer driver SMB printing You can use SMB printing (Windows printing) to print directly over the Micro- soft network from computers running Windows 98SE or Windows Me. Operations on this machine Set the IP address for this machine. For the setting procedure, refer to "Specifying the TCP/IP settings"...
Page 112 Setting up the printer driver Specify settings for the following: – SMB Print: Set whether to use the SMB printing service. Select "ON" here. – NetBIOS Name: Specify the NetBIOS name (up to 15 characters, including the following: -). – Print Service Name: Specify the printing service name (up to 12 characters, excluding the following: / \).
Page 113: Printer Driver Settings (For Windows 98Se/Me)
Setting up the printer driver Printer driver settings (For Windows 98SE/Me) Click the [Start] button, point to "Settings", and then click "Printers". Right-click the icon of the installed printer, and then click "Properties". On the Details tab, click the [Add Port] button. Select "Network", and then click the [Browse] button.
Page 114: Lpr Printing
Setting up the printer driver LPR printing The LPR print service is supported as a standard in Windows 2000, Windows XP, Windows NT 4.0, and Windows Server 2003. TCP/IP is used as the net- work protocol. Operations on this machine Set the IP address for this machine.
Page 115: Printer Driver Settings (For Windows Nt 4.0)
Setting up the printer driver Printer driver settings (For Windows NT 4.0) Click the [Start] button, point to "Settings", and then click "Printers". Right-click the icon of the installed printer, and then click "Properties". On the Ports tab, click the [Add Port] button. In the "Available Printer Ports"...
Page 116: Port 9100 Printing (Windows 98Se/Me/2000/Xp/Server 2003)
Setting up the printer driver Port 9100 printing (Windows 98SE/Me/2000/XP/Server 2003) The Port 9100 print service is supported as a standard in Windows 2000, Windows XP, and Windows Server 2003. TCP/IP is used as the network protocol. When using Port 9100 printing under Windows 98SE or Windows Me, it may be necessary to install the Peer to Peer Printing Tool.
Page 117: Printer Driver Settings (Windows 2000/Xp/Server 2003)
Setting up the printer driver Printer driver settings (Windows 2000/XP/server 2003) When using Port 9100 to print, change the printer driver port to "9100". For Windows 2000, click the [Start] button, point to "Settings", and then click "Printers". For Windows XP/Server 2003, click the [Start] button, and then click "Printers and Faxes".
Page 118: Installing The Peer To Peer Printing Tool To Connect Using Port 9100 (Windows 98Se/Me)
Setting up the printer driver Installing the Peer to Peer Printing Tool to connect using Port 9100 (Win- dows 98SE/Me) To obtain the Peer to Peer Printing Tool in order to install it for connecting using Port 9100 under Windows 98SE or Windows Me, consult the dealer where you purchased this machine.
Page 119: Printer Driver Settings When The Peer To Peer Printing Tool Is Installed To Connect Using Port 9100 (Windows 98Se/Me)
Right-click the icon of the installed printer, and then click "Properties". On the Details tab, click the [Add Port] button. Click "Others", select "KONICA MINOLTA Peer to Peer Port" from the list, and then click the [OK] button. The Peer to Peer setup dialog box appears. The printer connected to the network is automatically detected.
Page 120: Ipp Printing (Windows 2000/Xp/Server 2003)
Setting up the printer driver IPP printing (Windows 2000/XP/Server 2003) The IPP (Internet Printing Protocol) print service is supported as a standard in Windows 2000, Windows XP, and Windows Server 2003. TCP/IP is used as the network protocol. Operations on this machine Set the IP address for this machine.
Page 121 Setting up the printer driver On the Network tab, click "IPP Setting". Specify settings for the following: – IPP Setting: Set whether to perform IPP printing. Select "ON" here. – Printer Name: Specify the printer name (up to 127 alphanumeric characters).
Page 122: Installing The Printer Driver
– Konica Minolta PCL driver: User Software CD-ROM – Konica Minolta PostScript driver: PostScript Printer Driver CD- For Windows 2000, click the [Start] button, point to "Settings", and then click "Printers". For Windows XP/Server 2003, click the [Start] button, and then click "Printers and Faxes".
Page 123 Click the [Browse] button, specify the folder on the CD-ROM that contains the printer driver, and then click the "OK" button. – Konica Minolta PCL driver: Folder at Driver\bizhubC352 on the User Software CD-ROM – Konica Minolta PostScript driver: Folder at Driver\bizhubC352 on the PostScript Printer Driver CD-ROM Check that the printer name is displayed in the "Printers"...
Page 124: Printing With Netware
Setting up the printer driver Printing with NetWare The printer controller supports the following environments. Network printing in a NetWare environment NetWare Version Protocol Used Emulation Service Mode NetWare 4.x NDS/Bindery Pserver/Nprinter NetWare 5.x/6 Pserver TCP/IP NDPS(lpr) For remote printer mode with NetWare 4.x Bindery Emulation Before using bindery emulation, check that bindery emulation is compatible with the NetWare server.
Page 125 Setting up the printer driver Use the NetWare server console to load PSERVER.NLM. In Administrator mode of PageScope Web Connection, select "NetWare Setting" from the Network tab, and then specify the following settings. – IPX Setting: Select "ON". – Ethernet Frame Type: Select "Auto Detect". (Select the frame type according to the network environment.) –...
Page 126 Setting up the printer driver Note For queue user privileges, the printer notification option, assignment of multiple queues, and passwords, refer to the NetWare documentation, and specify settings as necessary. Reminder When the machine is turned off, then on again, wait at least 10 seconds to turn the machine on after turning it off.
Page 127: For Print Server Mode With Netware 4.X Bindery Emulation
Setting up the printer driver For print server mode with NetWare 4.x Bindery Emulation Before using bindery emulation, check that bindery emulation is compatible with the NetWare server. From a client computer, log on with Supervisor permissions to access the NetWare server where the Pserver is registered. Start up Pconsole.
Page 128 Setting up the printer driver Click the [Esc] button to quit Pconsole. In Administrator mode of PageScope Web Connection, select "NetWare Setting" from the Network tab, and then specify the following settings. – IPX Setting: Select "ON". – Ethernet Frame Type: Select "Auto Detect". (Select the frame type according to the network environment.) –...
Page 129 Setting up the printer driver Select the connection information and, in the active connection col- umn, check that the created Pserver is connected. Reminder When the machine is turned off, then on again, wait at least 10 seconds to turn the machine on after turning it off. The machine may not operate correctly if it is turned on immediately after being turned off.
Page 130: For Netware 4.X Remote Printer Mode (Nds)
Setting up the printer driver For NetWare 4.x remote printer mode (NDS) Log on to NetWare as an administrator from a client computer. Start up NWadmin. Select either the organization or organizational unit container that offers the print service, and then click "Print Services Quick Setup" on the "Tools"...
Page 131 Setting up the printer driver – Ethernet Frame Type: Select "Auto Detect". (Select the frame type according to the network environment.) – NetWare Print Mode: Select "Nprinter/Rprinter". – Printer Name: Specify the printer name. – Printer Number: Specify the printer number (0-255). When 255 is specified, the setting is "Auto".
Page 132: For Netware 4.X/5.X/6 Print Server Mode (Nds)
Setting up the printer driver For NetWare 4.x/5.x/6 Print Server mode (NDS) To use the Print Server mode, the IPX protocol must be loaded on the Net- Ware server. Log on to NetWare as an administrator from a client computer. Start up NWadmin.
Page 133 Setting up the printer driver – IPX Setting: Select "ON". – Ethernet Frame Type: Select "Auto Detect". (Select the frame type according to the network environment.) – NetWare Print Mode: Select "Pserver". – Print Server Name: Specify the print server name created in step 4. –...
Page 134: For Netware 5.X/6 Novell Distributed Print Services (Ndps)
Setting up the printer driver For NetWare 5.x/6 Novell Distributed Print Services (NDPS) Before specifying settings for NDPS, check that the NDPS broker and NDPS manager have been created and loaded. Also, before performing the following procedure, check that the TCP/IP pro- tocol has been set in the NetWare server, and check that the IP address has been set for this machine and that this machine is on.
Page 135: Specifying Client (Windows) Settings When Using The Netware Server
In the "Printer Model" list, specify the folder on the CD-ROM that contains the desired printer driver for the operating system being used. – For Windows 98SE/Me Konica Minolta PCL driver: Folder at Driver\bizhubC352 on the User Software CD-ROM PostScript driver: Folder at Driver\PS PPD on the PostScript Printer Driver CD-ROM –...
Page 136: Printing With Macintosh
Setting up the printer driver Printing with Macintosh This section describes this machine’s settings and the Macintosh network settings. Specify the printer network port settings after installing the printer driver and when selecting a printer. To select a printer, refer to "Selecting a printer" on page 3-21.
Page 137 Setting up the printer driver Enter the administrator password, and log in to the Administrator mode. On the Network tab, click "AppleTalk Setting". Specify settings for the following: AppleTalk: Set whether to use AppleTalk. Select "ON" here. Printer Name: Specify the printer name (up to 31 alphanumeric characters).
Page 138: Specifying The Bonjour Settings
Setting up the printer driver Specifying the Bonjour settings When connecting this machine to a Macintosh computer using Bonjour/Ren- dezvous, the Bonjour settings must be specified. Start up PageScope Web Connection. – To log out if the login page does not appear, click the [Logout] button.
Page 139 Setting up the printer driver To apply the settings, restart this machine (turn it off, then on again). Note The Bonjour connection is a Mac OS X 10.4 function, it is the same func- tion as the Rendezvous connection in Mac OS 10.3 or earlier. Reminder When the machine is turned off, then on again, wait at least 10 seconds to turn the machine on after turning it off.
Page 140: Specifying Macintosh Settings
Setting up the printer driver Specifying Macintosh settings Use the Macintosh computer that is connected to specify the TCP/IP and AppleTalk settings. Reminder For network settings, consult the network administrator. For printer driver installation, refer to "Installing the printer driver" on page 3-20.
Page 141: For Mac Os 9.2
Setting up the printer driver For Mac OS 9.2 On the Apple menu, point to "Control Panel", and then click "AppleTalk". From the "Connect via" drop-down list, select "Ethernet". On the Apple menu, point to "Control Panel", and then click "TCP/IP". From the "Connect via"...
Page 142 Setting up the printer driver 3-70 C352P (Phase 3)
Page 143: Specifying Printer Driver Settings
Specifying printer driver settings...
Page 145: Specifying The Printer Driver Basic Settings
For the settings that can be specified with each printer driver, refer to the following: - Konica Minolta PCL Driver: "Setting up the PCL driver" on page 4-5 - Konica Minolta PostScript Driver: "Setting up the PostScript driver (Windows)" on page 4-47 - PostScript PPD Driver: "Setting up the PPD driver (Windows)"...
Page 146: For Macintosh
Specifying printer driver settings For details on saving settings, refer to the following pages. Konica Minolta PCL driver: "Saving the driver settings" on page 4-44 Konica Minolta PostScript driver: "Saving the driver settings" on page 4-77 To specify custom settings, click the [Properties] button or the [Preferences] button in the Print dialog box, which appears when "Print"...
Page 147: Setting Up The Pcl Driver
Specifying printer driver settings Setting up the PCL driver Selecting the printer Before printing, specify the model name for this machine. For Windows 98SE/Me/2000/NT 4.0, click the [Start] button, point to "Settings", and then click "Printers". For Windows XP/Server 2003, click the [Start] button, and then click "Printers and Faxes".
Page 148: Settings
Specifying printer driver settings Settings Common settings The following describes the common settings and buttons that are displayed on all tabs. Common setting items Button Function Click this button to close the dialog box and apply any settings that have been changed. Cancel Click this button to cancel any settings that have been changed and close the dialog box.
Page 149 Specifying printer driver settings Button Function View When "Paper" is selected, a preview of the page layout as specified in the current settings is displayed and a preview im- age of the print job can be checked. When "Printer" is selected, a printer figure is displayed showing any options, such as the paper tray, that are installed on this machine.
Page 150: Specifying Printer Driver Settings
Specifying printer driver settings Setup tab Item Function Paper Specifies the orientation of the original document, original size, output size, paper source, and paper type. Binding Specifies the folding format such as the binding position, double-sided printing, booklet printing, printing multiple pages on one page, file margin, stapling, or hole punching.
Page 151 Specifying printer driver settings Quality tab Item Function Select Color Specifies the color for printing. Original Image Type Specifies the contents of the original document. Prints with a quality suitable for the original document. Quality Adjustment Adjusts the image quality. You can select "Simple" to ad- just entire documents and "Detailed"...
Page 152: Specifying The Setup Tab Settings
Specifying printer driver settings Specifying the Setup tab settings Printing to suit the paper size You can enlarge or reduce documents created when printing to match the output paper size. Click the Setup tab. From the "Original Size" and "Output Size" drop-down lists, select the desired settings.
Page 153 Specifying printer driver settings To print, load A3 paper in the tray ("Tray 1" or "Bypass Tray") that is specified in the printer driver, and then select "Paper Tray" in the control panel and follow the steps described below to specify the paper size for the paper tray that is used.
Page 154: Specifying A Custom Size
Specifying printer driver settings Specifying a custom size A custom size can be specified and saved in advance as described below. From the "Original Size" or "Output Size" drop-down list, select "Custom Size Settings". The Custom Size Settings dialog box appears. Specify settings for the following: –...
Page 155 Specifying printer driver settings Note The custom size settings can only be specified from the printer driver setup dialog box, which can be displayed from the Printers window (Printers and Faxes window for Windows XP/Server 2003). If using long paper, specify the size of the long paper in Custom Size. For details, refer to "Printing on Banner Paper"...
Page 156: Selecting The Paper Source
Specifying printer driver settings Selecting the paper source When changing the paper type, you can specify it for an paper tray and select the paper tray according to the desired paper type. Click the Setup tab. From the "Paper Source" drop-down list, select the paper tray that contains the paper to be used.
Page 157 Specifying printer driver settings Select the desired setting from the "Paper Type" drop-down list, and then click the [OK] button. Only the paper types that can be selected for each paper tray are displayed. – If "Transparency" is selected as the paper type, you can specify transparency interleaving.
Page 158: Specifying Double-Sided/Booklet Printing
Specifying printer driver settings Specifying Double-sided/Booklet printing You can print a document onto both sides of a page or in a booklet format (two facing pages). This comes in handy when you want to bind multiple- page documents. Click the Setup tab. From the "Print Type"...
Page 159: Printing Multiple Pages On One Page (N In 1)
Specifying printer driver settings Printing multiple pages on one page (N in 1) You can print multiple document pages on one page. This comes in handy when you want to reduce the number of output pages. Click the Setup tab. Select the "Combination"...
Page 160: Setting The File Margin
Specifying printer driver settings Setting the file margin File margins are added to the document before it is printed. Click the Setup tab. Select the "File Margin" check box. To set the width of the file margin, click the [Details] button, and then specify the desired settings in the File Margin Details dialog box that appears.
Page 161: Stapling
Specifying printer driver settings Stapling Multiple-page documents can be stapled. Click the Setup tab. Select the "Staple" check box. From the drop-down list, select the number of staples and the stapling position. Note The "Staple" check box is available only if the optional finisher is installed.
Page 162: Fold & Staple
Specifying printer driver settings Fold & Staple You can select if printed documents will be folded or stapled at the center. Click the Setup tab. Select the "Fold & Staple" check box. To specify the settings in "Fold & Staple", click the [Details] button, and then specify the desired setting in the Fold &...
Page 163: Selecting The Output Method
Specifying printer driver settings Selecting the output method Not only can you print directly, but you can select "Secure Print", which requires a password to print, or "Save in User Box", which saves documents in the HDD. Click the Setup tab. From the "Output Method"...
Page 164 Specifying printer driver settings Secured Printing If "Secure Print" was selected, enter the secure print ID and password in the dialog box that appeared. Note To print the document, select "Secure Print" in the Job Operation menu of the machine’s control panel, and then enter the ID and password. For details, refer to "Managing print jobs"...
Page 165 Specifying printer driver settings Save in User Box When "Save in User Box" or "Save in User Box and Print" is selected, specify the file name and user box number in the dialog box that appears for entering the file name and user box number. Note To print the document, enter the box number and password in the Job Operation menu of the machine’s control panel.
Page 166: Specifying Account Track Settings
Specifying printer driver settings Specifying Account Track settings If account track settings have been specified on this machine, you must enter department name and password. Click the Setup tab. Click the [User Authentication/Account Track] button. Select the "Account Track" check box, and then enter the department name and password.
Page 167 Specifying printer driver settings Note If a print job is sent using a department name or password that is not registered with the account track settings of the machine or if a job is sent without the "Account Track" check box selected, the job is deleted without being authenticated by this machine.
Page 168: Specifying The Per Page Setting Tab Settings
Specifying printer driver settings Specifying the Per Page Setting tab settings Printing documents with a front cover/back cover Click the Per Page Setting tab. Select the "Front Cover Page" and "Back Cover Page" check boxes. To print on the front cover and back cover, select "Printed". To only add a blank page, select "Blank".
Page 169: Printing Multiple Pages
Specifying printer driver settings Printing multiple pages The "Per Page Setting" function comes in handy when you want to change the paper tray during a print job when printing multiple pages. In addition, the "Chapter" function can be used to specify that certain pages are printed on the front side of the paper.
Page 170: Per Page Setting
Specifying printer driver settings Per Page setting You can specify the print type and paper tray for each page. Click the Per Page Setting tab. Select the "Per Page Setting" check box. From the "List Name" drop-down list, select the name of the desired list.
Page 171: Specifying The Overlay Tab Settings
Specifying printer driver settings Specifying the Overlay tab settings Printing different original documents together (Overlay) An original document can be printed on top of form data that was created separately. This function is handy for fax cover letters and form letters. Create the print data using any application.
Page 172 Specifying printer driver settings From the list, select the form that you want to print. Select the file name, and then click the [OK] button. The Print dialog box appears again. Click the [OK] button. Overlay printing is performed. Note You must pre-register forms to be printed.
Page 173: Editing Forms
Specifying printer driver settings Editing forms To use forms, the data for using forms must be registered in advance. To register a form, select "Create Overlay", and then specify the document that you want to register. Create the form data using any application. From the "File"...
Page 174 Specifying printer driver settings Specify the storage location for the form data, and then enter the file name in the "File name" box. Click the [Save] button. Select the file, and then click the [OK] button. The Print dialog box appears again. Click the [OK] button.
Page 175: Specifying The Watermark Tab Settings
Specifying printer driver settings Specifying the Watermark tab settings Printing a watermark You can print specific text in the background as a watermark. Click the Watermark tab. Select the "Watermark" check box. From the drop-down list, select the watermark that you want to print. Specify the desired settings for "Type"...
Page 176: Editing A Watermark
Specifying printer driver settings Editing a watermark You can change the fonts and position of the watermark, and you can register a new watermark. Click the Watermark tab. Select the "Watermark" check box. Click the [Edit] button. Specify settings for the following: –...
Page 177: Printing The Document Number
Specifying printer driver settings Printing the document number When printing multiple copies, you can print the number of each document. Click the Watermark tab. Select the "Distribution Number Stamping" check box. Specify settings for the following: – Pages to Print: Specify the pages where the numbering is to be printed.
Page 178: Copy Protect
Specifying printer driver settings Copy protect You can print a special pattern on an entire page while printing. When copying a printed page, the characters embedded in the pattern appear to prevent an illegal copy. Click the Watermark tab. Select the "Copy Protect" check box. Click the [Edit] button.
Page 179 Specifying printer driver settings Detail Settings: Specifies the color and density pattern to be embedded with copy protection, and specifies the embedding method. - Color: Select the pattern print color. - Density: Select the pattern print density. - Pattern: Select the pattern. - Pattern Contrast: Select the pattern contrast.
Page 180: Specifying The Quality Tab Settings
Specifying printer driver settings Specifying the Quality tab settings Quality tab parameters Item Function Select Color Select the color for printing. Color: Select this setting to print in color. Grayscale: Select this setting to print in grayscale. 2 Color: Select this setting to print the two colors selected from the drop-down list.
Page 181: Specifying Settings
Specifying printer driver settings Specifying settings Click the Quality tab. Specify each setting. To adjust the quality, select "Simple" or "Detailed", and then click the [Settings] button beside the desired setting. In the Quality Adjustment Settings dialog box that appears, specify the brightness and color balance. To adjust the quality, select "Detailed", and then click the [Settings] button beside "Figure/Table/Graph".
Page 182: Specifying The Font Tab Settings
Specifying printer driver settings Specifying the Font tab settings Replacing fonts You can replace the TrueType fonts used in Windows with the printer fonts of this machine. Click the "Font" tab. Select the "Use Printer Fonts" check box. Select the TrueType font that you want to replace. From the "Printer Font to Use"...
Page 183: Specifying The Option Tab Settings
Specifying printer driver settings Specifying the Option tab settings You can specify the options installed on this machine so that they can be used from the printer driver. Note If the installed options are not set from the Option tab, the function for the option cannot be used with the printer driver.
Page 184: Selecting Options
Specifying printer driver settings Selecting options For Windows 98SE/Me/2000/NT 4.0, click the [Start] button, point to "Settings", and then click "Printers". For Windows XP/Server 2003, click the [Start] button, and then click "Printers and Faxes". – If "Printers and Faxes" does not appear in the Start menu, click Control Panel in the Start menu, click "Printers and Other Hardware", and then click "Printers and Faxes".
Page 185 Specifying printer driver settings Note To automatically set the installed options, enter the printer name or IP address of this machine in the "Printer Name or IP Address" box under "Option Information", and then click the [Gather Option Information] button. The [Gather Option Information] button can only be used when the SNMP setting is enabled on this machine and the SNMP v1/v2c (IP) setting check box is selected.
Page 186: Saving The Driver Settings
Specifying printer driver settings Saving the driver settings With PCL drivers, you can save the new settings of the driver and recall them as necessary. To save the driver settings Change the driver settings in the Setup tab and the Per Page Setting tab.
Page 187 Specifying printer driver settings Enter the file name in the "Name" text box. Enter a message in the "Comment" text box as necessary. Specify a folder in the "Save Location" box, and then click the [OK] button. The settings are registered in a library. Note The file extension is ".ksf".
Page 188: Viewing The Settings
Specifying printer driver settings Viewing the settings Click the [Save/Restore Setting] button on the Printing Preferences dialog box, and then select "Restore Saved Setting". From the "Library" list, select the desired settings file. Click the [OK] button. The settings are recalled and displayed in the Printing Preferences dialog box.
Page 189: Setting Up The Postscript Driver (Windows)
Specifying printer driver settings Setting up the PostScript driver (Windows) Selecting the printer Before printing, specify the model name for this machine. For Windows 2000/NT 4.0, click the [Start] button, point to "Settings", and then click "Printers". For Windows XP/Server 2003, click the [Start] button, and then click "Printers and Faxes".
Page 190 Specifying printer driver settings Note If the model name for this machine is not specified from the Option tab, the appropriate printer driver functions cannot be used. Be sure to specify the settings before printing. 4-48 C352P (Phase 3)
Page 191: Settings
Specifying printer driver settings Settings Common settings The following describes the common settings and buttons that are displayed on all tabs. C352P (Phase 3) 4-49...
Page 192 Specifying printer driver settings Common setting items Button Function Click this button to close the dialog box and apply any settings that have been changed. Cancel Click this button to cancel any settings that have been changed and close the dialog box. Help Click this button to display the help for each item on the current- ly displayed dialog box.
Page 193: Layout Tab
Specifying printer driver settings Setup tab Item Function Orientation Specifies the orientation of the image being printed on the paper. Original Size Specifies the size of the original document. Output Size Specifies the output paper size. Automatically enlarges or reduces when the Original Size setting is changed.
Page 194: Quality Tab
Specifying printer driver settings Per Page Setting tab Item Function Front Cover Page Attaches a front cover page. Paper Source Selects the paper tray for the front cover. Back Cover Page Attaches a back cover page. Paper Source Selects the paper tray for the back cover. Transparency Interleave Outputs and inserts interleaves when printing OHP transparencies.
Page 195: Advanced Tab
Specifying printer driver settings Advanced tab Item Function Advanced Printing Specifies whether to enable detailed print functions (booklet). Features PostScript Output Op- Specifies the PostScript file output format. tions Send PostScript Error Specifies whether to print an error report when a PostScript error oc- Handler curs.
Page 196 Specifying printer driver settings Note To display the Device Settings tab in Windows 2000/XP/NT 4.0/Server 2003, right-click the icon of the installed printer, and then click "Properties". Option tab Item Function Option Specifies the options that are installed on this machine. Gather Option Informa- Communicates with this machine and reads the status of the in- tion...
Page 197: Specifying The Setup Tab Settings
Specifying printer driver settings Specifying the Setup tab settings C352P (Phase 3) 4-55...
Page 198: Printing To Suit The Paper Size
Specifying printer driver settings Printing to suit the paper size You can enlarge or reduce documents created when printing to match the output paper size. Click the Setup tab. From the "Original Size" and "Output Size" drop-down lists, select the desired settings.
Page 199: Saving A Custom Sizes
Specifying printer driver settings Saving a custom sizes A custom size can be specified and saved in advance as described below. From the "Original Size" and "Output Size" drop-down lists, select "Custom Size". The Custom Size Settings dialog box appears. Specify settings for the following: –...
Page 200: Selecting The Output Method
Specifying printer driver settings Selecting the output method Not only can you print directly, but you can select "Secure Print", which requires a password to print, or "Save in User Box", which saves documents in the HDD. Click the Setup tab. From the "Output Method"...
Page 201 Specifying printer driver settings Secured printing If "Secure Print" was selected, enter the secure print ID and password in the dialog box that appeared. Note To print the document, select "Secure Print" in the Job Operation menu of the machine’s control panel, and then enter the ID and password. For details, refer to "Managing print jobs"...
Page 202 Specifying printer driver settings Save in User Box When "Save in User Box" or "Save in User Box and Print" is selected, specify the file name and user box number in the dialog box that appears for entering the file name and user box number. Note To print the document, enter the box number and password in the Job Operation menu of the machine’s control panel.
Page 203: Specifying Account Track Settings
Specifying printer driver settings Specifying Account Track settings If account track settings have been specified on this machine, you must enter an department name and password in order to print a job. Click the Setup tab. Click the User Authentication/Account Track button. Select the "Account Track"...
Page 204 Specifying printer driver settings Note If a print job is sent using a department name or password that is not registered with the account track settings of the machine or if a job is sent without the "Account Track" check box selected, the job is deleted without being authenticated by this machine.
Page 205: Specifying The Layout Tab Settings
Specifying printer driver settings Specifying the Layout tab settings C352P (Phase 3) 4-63...
Page 206: Printing Multiple Pages On One Page (N In 1)
Specifying printer driver settings Printing multiple pages on one page (N in 1) You can print multiple document pages on one page. You can also specify the "Booklet" setting to fold the printouts in two to make a booklet. Click the Layout tab. From the "Combination"...
Page 207: Double-Sided Printing
Specifying printer driver settings Double-sided printing You can print a document onto both sides of a page. This comes in handy when you want to bind multiple-page documents. Click the Layout tab. From the "Double Sides" drop-down list, select "Double-Sided". Note The binding orientation can be specified from the "Binding Position"...
Page 208: Fold & Staple
Specifying printer driver settings Fold & Staple You can select if printed documents will be folded or stapled at the center. Click the Layout tab. From the drop-down list, select the folding method. – In addition to "Fold & Staple" for folding copies in half and stapling them, "Center Staple"...
Page 209: Specifying The Per Page Setting Tab Settings
Specifying printer driver settings Specifying the Per Page Setting tab settings Printing documents with a front cover/back cover Click the Per Page Setting tab. From the "Front Cover Page" and "Back Cover Page" drop-down lists, select the desired printing settings. –...
Page 210: Specifying The Watermark Tab Settings
Specifying printer driver settings Specifying the Watermark tab settings Printing a watermark You can print specific text in the background as a watermark. Click the Watermark tab. From the drop-down list, select the watermark that you want to print. Specify settings for the following: –...
Page 211: Editing A Watermark
Specifying printer driver settings Editing a watermark You can change the fonts and position of the watermark, and you can register a new watermark. Click the Watermark tab. To create a watermark, click the [Add] button. – To change a watermark, select the watermark to be changed, and then click the [Edit] button.
Page 212 Specifying printer driver settings Note Only the administrator can select a setting under "Sharing". 4-70 C352P (Phase 3)
Page 213: Specifying The Quality Tab Settings
Specifying printer driver settings Specifying the Quality tab settings C352P (Phase 3) 4-71...
Page 214: Specifying Settings
Specifying printer driver settings Specifying settings Click the Quality tab. Specify settings for the following: Item Function Original Image Type Select the contents of the original document to print with a quality suitable for the original document. Document: Select this setting to print with a quality suitable for doc- uments containing mostly text.
Page 215: Font Settings
Specifying printer driver settings Font settings You can replace the TrueType fonts used in Windows with the printer fonts of this machine. Click the [Font Settings] button. Specify settings for the following: – Download Font Format: Select the TrueType font type to download when downloading the TrueType fonts and not using the printer fonts.
Page 216: Specifying The Option Tab Settings
Specifying printer driver settings Specifying the Option tab settings You can specify the options installed on this machine so that they can be used from the printer driver. Note If the installed options are not set from the Option tab, the function for the option cannot be used with the printer driver.
Page 217: Specifying Settings
Specifying printer driver settings Specifying settings For Windows 2000/NT 4.0, click the [Start] button, point to "Settings", and then click "Printers". For Windows XP/Server 2003, click the [Start] button, and then click "Printers and Faxes". – If "Printers and Faxes" does not appear in the Start menu, click Control Panel in the Start menu, click "Printers and Other Hardware", and then click "Printers and Faxes".
Page 218 Specifying printer driver settings Note To automatically register the installed options in the "Option" list, click the [Gather Option Information] button when connected to the machine. The [Gather Option Information] button can only be used when the SNMP setting is enabled on this machine and the SNMP v1/v2c (IP) setting check box is selected.
Page 219: Saving The Driver Settings
Specifying printer driver settings Saving the driver settings With PostScript drivers, you can save the new settings of the driver and recall them as necessary. To save the driver settings Change the driver settings in the Setup tab and the Layout tab. Click the [Save] button.
Page 220 Specifying printer driver settings Enter the file name in the "Name" text box. Enter a message in the "Comment" text box as necessary. Specify whether to share the driver settings being saved with other users. Click the [OK] button. The settings are registered in a library. Note The file extension is ".ksf".
Page 221: Viewing The Settings
Specifying printer driver settings Viewing the settings Select the settings to restore from the "Easy Set" drop-down list on the Printing Preferences dialog box. The setting values are recalled, and the Printing Preferences dialog box appears again. Changing the settings On the Printing Preferences dialog box, click the [Edit] button.
Page 222: Setting Up The Ppd Driver (Windows)
Specifying printer driver settings Setting up the PPD driver (Windows) Settings Paper tab Item Function Paper size Specifies the paper size. Layout Specifies the number of pages printed on one page. Orientation Specifies the orientation. Rotated Rotates the paper. Paper source Selects the paper tray.
Page 223 Specifying printer driver settings Graphics tab Item Function Resolution Specifies the print resolution. Color Control Specifies whether to adjust the color to that on the screen. Halftoning Specifies the halftone number of lines and the pattern angle. Special Prints a negative or mirror image. Scaling Specifies the enlargement and reduction ratio.
Page 224 Specifying printer driver settings Item Function Screen (Text) Specifies screening of the text in a document. Color Matching (Photo) Adjusts the color quality of photos in a document. Pure Black (Photo) Specifies whether to print the photos in a document in grayscale. Screen (Photo) Specifies screening of photos in a document.
Page 225 Specifying printer driver settings Fonts tabs Item Function Send TrueType fonts to Prints the font specified in the Font Substitution Table with printer printer according to the fonts. fonts Substitution Table The Font Substitution Table can be edited by clicking the [Edit the Table] button.
Page 226: Specifying The Paper Tab Settings
Specifying printer driver settings Specifying the Paper tab settings You can specify the orientation and number of pages to be printed on one page when printing. Specifying settings Click the Paper tab. Specify settings for the following: – Paper size: Select the paper size. –...
Page 227: Specifying The Device Options Tab Settings
Specifying printer driver settings Specifying the Device Options tab settings From the Device Options tab, you can specify advanced functions, such as finishing functions and color adjustments. Specifying settings Click the Device Options tab. Select a function, and then select the setting from the "Change setting for"...
Page 228 Specifying printer driver settings Note For the functions and settings that can be specified, refer to "Settings" on page 4-80. Note The Staple function is available only if the optional finisher is installed. The punch function is available only if optional finisher FS-514 and punch kit PK-510 are installed.
Page 229: Specifying The Options
Specifying printer driver settings Specifying the options You can specify the options installed on this machine so that they can be used from the printer driver. Note If the installed options are not set from the Device Options tab, the function for the option cannot be used with the printer driver.
Page 230 Specifying printer driver settings Note For the functions and settings that can be specified, refer to "Settings" on page 4-80. 4-88 C352P (Phase 3)
Page 231: Setting Up The Ppd Driver (Mac Os 9.2)
Specifying printer driver settings Setting up the PPD driver (Mac OS 9.2) Settings The functions of this machine can be specified on the Paper Setup and Print dialog boxes displayed from an application. The settings can only be applied while using the application. When the application is exited, the settings return to their defaults.
Page 232 Specifying printer driver settings Page Setup items Menu Item Function Page Attributes Paper Specifies the paper size. Orientation Specifies the orientation. Scale Specifies the enlargement and reduction ratio. PostScript Options Flip Horizontal Prints the image flipped horizontally. Flip Vertical Prints the image flipped vertically. Invert Image Prints a negative image.
Page 233: Print Dialog Box
Specifying printer driver settings Print dialog box Print items Menu Item Function General Copies Specifies the number of copies to print. Collated Prints multiple copies in sets. Pages Specifies the page range to print. Paper Source Selects the paper tray. Color Matching Print Color Specifies the color for printing.
Page 234 Specifying printer driver settings Menu Item Function Layout Pages per sheet Specifies the number of pages to print on one page. Layout direction Specifies the page order for printing multiple pages on one page. Border Specifies the borders around pages. Job Logging If there is a PostScript Specifies the PostScript error report conditions.
Page 235 Specifying printer driver settings Menu Item Function Finishing Options 3 Wait Mode Temporarily stops printing after part of the doc- ument has been printed so that the proof print can be checked. Resolution Specifies the print resolution. Select Color Specifies whether to print in color or grayscale. Glossy Mode Prints with a glossy finish.
Page 236: Page Setup
Specifying printer driver settings Page setup Basic settings (Page Attributes) Select "Paper Setup" or "Page Setup" from the "File" menu. Select "Page Attributes". Specify settings for the following: – Paper: Select the paper size. – Orientation: Select the orientation. – Scale: Specify the enlargement and reduction ratio.
Page 237 Specifying printer driver settings Note The folding function can be selected from the screen that is displayed when "Layout" is selected in the Print dialog box. C352P (Phase 3) 4-95...
Page 238: Custom Page Sizes
Specifying printer driver settings Custom Page Sizes Select "Paper Setup" or "Page Setup" from the "File" menu. Select "Custom Page Sizes". Click the [New] button. Specify settings for the following: – Paper Size: Specify the paper size. – Margins: Specify the paper margins. –...
Page 239: Postscript Options
Specifying printer driver settings PostScript Options Select "Paper Setup" or "Page Setup" from the "File" menu. Select "PostScript Options". Specify settings for the following: – Visual Effects: Select the "Flip Horizontal", "Flip Vertical", or "Invert Image" (nagative image) check box. –...
Page 240: Printing
Specifying printer driver settings Printing Basic settings (General) From the "File" menu, select "Print". Select "General". Specify settings for the following: – Copies: Specify the number of copies to print. – Collated: Select this check box to print multiple copies in sets. –...
Page 241 Specifying printer driver settings – Paper Source: Select the paper tray. C352P (Phase 3) 4-99...
Page 242: Printing Multiple Pages On One Page (Layout)
Specifying printer driver settings Printing multiple pages on one page (Layout) You can specify if multiple pages are printed on one page of paper or if double-sided printing is performed. From the "File" menu, select "Print". Select "Layout". Specify settings for the following: –...
Page 243: Printer-Specific Options (Finishing Options 1 To 4)
Specifying printer driver settings Printer-specific options (Finishing Options 1 to 4) You can specify printer-specific options. You can specify this option when using the staple or hole punch functions of this machine. From the "File" menu, select "Print". Select "Finishing Options 1 to 4". Specify settings for the following: –...
Page 244 Specifying printer driver settings – Screen (Photo): Select if screening of photos in a document is performed. – Smoothing (Photo): Select if smoothing of photos in a document is performed. – Color Setting (Graphic): Adjust the color quality of charts and graphs in a document to the text or photo settings.
Page 245: Setting Options
Specifying printer driver settings Setting options You can specify the options installed on this machine so that they can be used from the printer driver. Reminder If the installed options are not set from the Installable Options screen, the function for the option cannot be used with the printer driver. When installing options, be sure to specify the correct settings.
Page 246 Specifying printer driver settings Note The option settings are displayed automatically the first time the printer driver is selected. For details, refer to "Selecting a printer" on page 3-21. 4-104 C352P (Phase 3)
Page 247: Setting Up The Ppd Driver (Mac Os X)
Specifying printer driver settings Setting up the PPD driver (Mac OS X) Settings The functions of this machine can be specified on the Paper Setup and Print dialog boxes displayed from the application. The settings can only be applied while using the application. When the application is exited, the settings return to their defaults.
Page 248 Specifying printer driver settings Note Depending on the application, "Page Setup" may be displayed as "Paper Setup". In addition, you may have to select "Paper Setup", then "Options" from the "File" menu. The dialog boxes differ depending on the application. To specify the "Custom Paper Size"...
Page 249: Print Dialog Box
Specifying printer driver settings Print dialog box Print items Menu Item Function Copies & Pages Copies Specifies the number of copies to print. Collated Prints multiple copies in sets. Pages Specifies the page range to print. Layout Pages per Sheet Specifies the number of pages to print on one page.
Page 250 Specifying printer driver settings Menu Item Function Cover Page Print Cover Page Specifies whether to attach a cover page. Cover Page Type Selects whether "Confidential" or any other com- ment is printed on the cover page. Billing Info Enter the user information used for the account calculation.
Page 251 Specifying printer driver settings Menu Item Function Quality Resolution Specifies the resolution (this function cannot be selected on this machine). Select Color Selects the color for printing. Glossy Mode Prints with a glossy finish. Original Image Type Prints with a quality suitable for the original docu- ment.
Page 252 Specifying printer driver settings Note The dialog boxes differ depending on the application. The items indicated by "*1" are displayed in Mac OS 10.3 and Mac OS 10.4. The items indicated by "*2" are displayed only in Mac OS 10.3. The items indicated by "*3"...
Page 253: Page Setup
Specifying printer driver settings Page setup Basic settings (Page Attributes) Select "Page Setup" or "Paper Setup" from the "File" menu. Select "Page Attributes". Specify settings for the following: – Paper Size: Select the paper size. – Orientation: Select the orientation. –...
Page 254 Specifying printer driver settings Note If the paper size is other than the custom paper size, select the desired settings after specifying the settings in Custom Size. When "W" is selected for each standard paper size in the printer driver, the data can be centered and printed.
Page 255: Custom Paper Size
Specifying printer driver settings Custom Paper Size Select "Page Setup" or "Paper Setup" from the "File" menu. For Mac OS 10.3, select "Custom Paper Size" from "Settings". For Mac OS 10.4, select "Manage Custom Sizes" from the "Paper Size" dropdown list. Click the [New] (Mac OS 10.3) or [+] (Mac OS 10.4) button.
Page 256: Printing
Specifying printer driver settings Printing Basic settings (Copies & Pages) From the "File" menu, select "Print". Select "Copies & Pages". Specify settings for the following: – Copies: Specify the number of copies to print. – Collated: Select this check box to print multiple copies in sets. –...
Page 257: Printing Multiple Pages On One Page (Layout)
Specifying printer driver settings Printing multiple pages on one page (Layout) You can print multiple pages on one sheet. From the "File" menu, select "Print". Select "Layout". Specify settings for the following: – Pages per Sheet: Select the number of pages to print on one page. –...
Page 258: Paper Feed
Specifying printer driver settings Paper Feed You can specify the paper tray for printing. From the "File" menu, select "Print". Select "Paper Feed". Specify settings for the following: – All pages from: Select the paper tray loaded with the paper to print all pages.
Page 259: Security
Specifying printer driver settings Security Not only can you print directly, but you can select "Secure Print", which requires a password to print, "Save in User Box", which saves documents in a HDD, "Proof and Print", which prints the first set of multiple copies and temporarily stops printing, and "Account Track Settings", which manages the number of printed pages.
Page 260 Specifying printer driver settings – Account Track: Register the department name and password when account track settings have been applied on this machine and when this check box is selected. Note If a print job is sent using a department name or password that is not registered with the account track settings of the machine or if a job is sent without the "Account Track"...
Page 261 Specifying printer driver settings Detail Print the document from the control panel of this machine. For details, refer to "Managing print jobs" on page 10-31. C352P (Phase 3) 4-119...
Page 262: Finishing
Specifying printer driver settings Finishing You can specify the various finishing functions of this machine, such as stapling and hole punching. From the "File" menu, select "Print". Select "Finishing". Specify settings for the following: – Collate: Select this check box to print multiple copies in sets. –...
Page 263 Specifying printer driver settings Note If the password rules have been enabled on the machine, specify a password that contains 8 digits. Note The "Staple" check box is available only if the optional finisher is installed. The "Hole-Punch" check box is available only if optional finisher FS-514 and punch kit PK-510 are installed.
Page 264: Quality
Specifying printer driver settings Quality From the "File" menu, select "Print". Select "Quality". Specify settings for the following: – Resolution: Select the resolution. – Select Color: Select the color for printing. – Glossy Mode: Prints with a glossy finish. – Original Image Type: Select the quality suitable for the original document.
Page 265 Specifying printer driver settings – Smoothing (Graphic): Adjust the smoothing process of charts and graphs in a document to the text or photo settings. C352P (Phase 3) 4-123...
Page 266: Setup
Specifying printer driver settings Setup You can specify the cover settings. From the "File" menu, select "Print". Select "Setup". Specify settings for the following: – Paper Type: Select the paper type. – Front Cover Page: Select if a front cover page is to be attached –...
Page 267: Setting Options
Specifying printer driver settings Setting options You can specify the options installed on this machine so that they can be used from the printer driver. Reminder If the installed options are not set from the Installable Options screen, the function for the option cannot be used with the printer driver. When installing options, be sure to specify the correct settings.
Page 268 Specifying printer driver settings Click the [Apply Changes] button or click [ ] to close the Printer info dialog box. 4-126 C352P (Phase 3)
Page 269: Saving The Driver Settings
Specifying printer driver settings Saving the driver settings With Mac OS X drivers, you can save the new settings of the driver and recall them as necessary. To save the driver settings Change the driver settings in the dialog boxes that appear after "Copies &...
Page 270: Viewing The Settings
Specifying printer driver settings Viewing the settings Select the preset name from the "Presets" drop-down list in the Print dialog box to recall the settings. Changing the settings Select the preset name from the "Presets" drop-down list in the Print dialog box to change the settings.
Page 271: Control Panel Settings
Control panel settings...
Page 273: Control Panel
Control panel settings Control panel settings Control panel Available keys From the control panel, jobs can be printed or deleted, initial settings, for example, for paper, can be specified, or various settings such as network settings can be changed. The following four keys are used to specify settings. Arrow keys Press these keys to choose a different setting.
Page 274: Basic Operations
Control panel settings Basic operations The procedures for changing settings are described below in the following examples. - Basic menu operations % "Specifying the size of the paper in the bypass tray" - User settings % "Specifying the “Sleep Mode” function" - Display the Administrator Setting screen % "Entering the administrator password"...
Page 275 Control panel settings Press the [,] key until "Bypass Size" appears. Press the [Menu/Select] key. The paper size flashes, indicating that the setting can be changed. Press the [+] and [,] keys until the desired paper size appears. Press the [Menu/Select] key. The paper size is changed and the next parameter appears.
Page 276: Sleep Mode
Control panel settings Sleep mode Example: "User Setting" — "Power Save" — "Sleep Mode" Press the [Menu/Select] key. The settings menu appears. Press the [,] key until "User Setting" appears. Press the [)] key. The "User Setting" menu appears. Press the [,] key until "Power Save" appears. Press the [)] key.
Page 277 Control panel settings Press the [,] key until "Sleep Mode" appears. Press the [Menu/Select] key. The setting flashes, indicating that it can be changed. Press the [)] key. The value flashes, indicating that it can be changed. Press the [+] and [,] keys until the desired value appears. Press the [Menu/Select] key.
Page 278: Administrator Password
Control panel settings Administrator password Example: "Admin. Setting" — "Input password." Press the [Menu/Select] key. The settings menu appears. Press the [,] key until "Admin. Setting" appears. Press the [)] key. A screen appears, requesting the administrator password. Press the [+] and [,] keys until the desired value for the first digit of the password appears.
Page 279 Control panel settings Continue pressing the [)] key so that the next digit can be entered and pressing the [+] and [,] keys until the desired value appears. After entering the password, press the [Menu/Select] key. The "Admin. Setting" menu appears. C352P (Phase 3)
Page 280: Overview Of Utility Mode Parameters
Control panel settings Overview of utility mode parameters Settings menu list This section describes the parameters available when the [Menu/Select] key is pressed. Note The parameters and settings that appear differ depending on the selected settings and installed options. Main menu Note The “Meter Count”...
Page 281 Control panel settings Job Operation menu * When "Fold & Staple" is set while printing from a box * When "Center Staple" is set while printing from a box * When "Fold" is set while printing from a box Note The menus that appear may differ depending on the password that is specified, if account track settings have been specified.
Page 282 Control panel settings Paper Tray menu When "Custom Size" is selected When "Oversized Paper" is selected When "Custom Size" is selected When "Oversized Paper" is selected * The paper trays that appear differ depending on the options that are installed. 5-12 C352P (Phase 3)
Page 283 Control panel settings User Setting menu C352P (Phase 3) 5-13...
Page 284 Control panel settings When finisher FS-514 is installed When the mailbin kit is installed When "Tray 1 % Tray 5" is set to "Enable" wihile the optional output tray is installed. 5-14 C352P (Phase 3)
Page 285 Control panel settings C352P (Phase 3) 5-15...
Page 286 Control panel settings Admin. Setting menu At "Manual Input" 5-16 C352P (Phase 3)
Page 287 Control panel settings Note If the entered administrator password is incorrect, the message “Password failure Please wait.” appears, and the “Admin. Setting” menu does not appear. If administrator authentication failed, causing the message “Password is not valid” to appear and preventing any operation from being performed, restart the machine.
Page 288 Control panel settings 5-18 C352P (Phase 3)
Page 289 Control panel settings C352P (Phase 3) 5-19...
Page 290 Control panel settings 5-20 C352P (Phase 3)
Page 291 Control panel settings C352P (Phase 3) 5-21...
Page 292 Control panel settings When "Write Setting" is set to "Enable" Note When “Enhanced Security” is set to “ON”, “Write Setting” cannot be changed. 5-22 C352P (Phase 3)
Page 293 Control panel settings C352P (Phase 3) 5-23...
Page 294 Control panel settings Note When “Enhanced Security” is set to “ON”, “SSL Setting” of “TCP Socket” cannot be changed. 5-24 C352P (Phase 3)
Page 295 Control panel settings When "Auth. System" is set to "basic" or "digest" C352P (Phase 3) 5-25...
Page 296 Control panel settings 5-26 C352P (Phase 3)
Page 297 Control panel settings Screen transitions when documents remain in the box C352P (Phase 3) 5-27...
Page 298 Control panel settings *1 Appears when the HDD is installed. *2 Appears when the security kit is installed. 5-28 C352P (Phase 3)
Page 299 Control panel settings Note If the entered password is incorrect, the message “Password failure Please wait.” appears, and the menu for the function does not appear. If the entered encryption key is incorrect, the message “Encryption Passphrase failure” appears, and the menu for the function does not appear.
Page 300 Control panel settings 5-30 C352P (Phase 3)
Page 301 Control panel settings Note When “Enhanced Security” is set to “ON”, “SSL” of “OpenAPI” and “Data Capture” cannot be changed. If an SSL certificate is not installed, “SSL” and “Port No. (SSL)” of “OpenAPI” cannot be changed. C352P (Phase 3) 5-31...
Page 302 Control panel settings Banner Print menu Printing is finished. With a multi-page job 5-32 C352P (Phase 3)
Page 303: Parameters
Control panel settings Parameters Job Operation This section describes the parameters and main settings that can be specified after pressing the [Menu/Select] key, then selecting "Job Operation". Account Name Parameters Description Initial Setting Account Name Select the name of the account. —...
Page 304: Paper Tray
Control panel settings Paper Tray This section describes the parameters and main settings that can be specified after pressing the [Menu/Select] key, then selecting "Paper Tray". Parameters Description Initial Setting Tray 1 Size Select the size of paper loaded in Tray 1. Tray 1 Type Select the type of paper loaded in Tray 1.
Page 305: User Setting
Control panel settings User Setting This section describes the parameters and main settings that can be specified after pressing the [Menu/Select] key, then selecting "User Setting". Print Reports Parameters Description Initial Setting Meter Count Prints the total checklist. — Check Consumable Prints the checklist for consumables.
Page 306: Tray Setting
Control panel settings Tray Setting Parameters Description Initial Setting Auto Tray Select Specify the paper trays that are selected T1, T2, T3, T4, BP when the paper tray is automatically changed. Tray Priority Specify the priority for selecting the paper T1, T2, T3, T4, BP trays when the automatic paper-tray-switch- ing operation is performed.
Page 307: Printer Setting
Control panel settings Printer Setting Parameters Description Initial Setting Basic Set- PDL Setting Specify the printer description lan- Auto ting guage as "Auto", "PCL", or "PS". Paper Tray Select the paper tray that is to be Auto used. 2-Sided Print Select whether or not ("ON"...
Page 308: Font List
Control panel settings Parameters Description Initial Setting PCL Set- Typeface Specify the font to be used. ting Refer to the "Font List" below for numbers and their corresponding fonts. Symbol Set Specify the symbol set to be used. Desktop Line/Page Specify the number of lines per 64 lines page.
Page 309 Control panel settings Font Name Font Name Univers Condensed Medium ITC Bookman Light Italic Univers Condensed Bold ITC Bookman Demi Italic Univers Condensed Medium Italic New Century Schoolbook Roman Univers Condensed Bold Italic New Century Schoolbook Bold Antique Olive New Century Schoolbook Italic Antique Olive Bold New Century Schoolbook Bold Italic Antique Olive Italic...
Page 310: Admin. Setting
Control panel settings Admin. Setting This section describes the parameters and main settings that can be specified after pressing the [Menu/Select] key, then selecting "Admin. Setting". Network Setting Parameters Description Initial Setting TCP/IP TCP/IP Setting Select whether or not TCP/IP is used.
Page 311 Control panel settings Parameters Description Initial Setting NetWare IPX Setting Specify the name of the DNS do- — main. IPX Setting Select whether or not IPX is used. Ethernet Frame Select the frame type. — Print Setting Specify the server conditions. —...
Page 312 Control panel settings Parameters Description Initial Setting SNMP SNMP Setting Select whether or not SNMP is used. If it is used, specify whether or not "SNMP v1/v2c (IP)", "SNMP v3 (IP)", or "SNMP v1 (IPX)" is used. UDP Port Number Specify the UDP port number.
Page 313 Control panel settings Parameters Description Initial Setting http Server http Server Set Select whether or not the http server settings are used. PSWC Setting Select whether or not PageScope Web Connection is used. Specify IPP print settings. — IPP Setting Select whether or not IPP printing is used.
Page 314 Control panel settings Time Adjustment Parameters Description Initial Setting NTP Setting Select whether or not the time is obtained through NTP. NTP Server Add. Specify the IP address or DNS name of the — NTP server. Port No. Specify the receiving port number for NTP. System Setting Parameters Description...
Page 315 Control panel settings Call Center Parameters Description Initial Setting Call Center Transmits the status of the machine to the — center. Security Setting Parameters Description Initial Setting Admin. Password Changes the administrator password. — Enhanced Security Select whether or not enhanced security settings are applied.
Page 316 Control panel settings If the encryption settings are changed, the hard disk must be reformatted. Detail For details on the operations available with "Enhanced Security", refer to page 5-47. For details on the operations available with "HDD Setting", refer to page 5-50.
Page 317: Enhanced Security
Control panel settings Enhanced Security When the enhanced security setting is applied on this machine, various linked security settings are set in order to increase security when managing data. Restrictions are applied to user operations, and box operations and print jobs are limited. There are various settings that must first be specified or are forcibly set in order for "Enhanced Security"...
Page 318 Control panel settings Changed settings For increased security, change the following linked settings when "Enhanced Security" is set to "ON". "Admin. Setting" menu Changed settings "Security Setting" – "Security Details" – Set to "Enable". "Password Rules" "Security Setting" – "Security Details" – Set to "Mode 2"...
Page 319: Password Rules
Control panel settings Password Rules If password rules have been applied, the following limitations are applied to the passwords in order to increase security. If password rules are applied and already specified passwords do not meet the password rules, those passwords are not accepted when they are en- tered.
Page 320: Hdd Setting
Control panel settings Confidential document passwords Limitations on the number Limitations on registering/changing of characters 8 alphanumeric characters • A password that consists of a repetition of the same character (case-sensitive) cannot be registered. HDD Setting The following operations can be performed from the HDD Setting screen. HDD Password Changes the password for using the HDD.
Page 321: O.w. Priority
Control panel settings O.W. Priority Select the priority setting for overwriting temporary data when the security kit is installed. Select "Encryption" to perform high-level security encryption processing. However, data overwriting with encryption of the HDD differs depending on whether "Mode 1" or "Mode 2" is selected. Normally, "Encryption"...
Page 322: Encryption Key
Control panel settings Encryption Key Specify encryption of the HDD when the security kit is installed. When a setting is specified, all data written to the HDD is encrypted to protect it. If the encryption key is changed, the HDD must be reformatted. In the Encryption Key screen, type in the encryption key (20 characters long).
Page 323: Banner Printing
Control panel settings OpenAPI Parameters Description Initial Setting Access Setting Select whether or not OpenAPI access is en- Permit abled. Port No. Specify the port number. — Port No. (SSL) Specify the port number (SSL). 50003 Select whether or not SSL is enabled. Authentication Select whether or not user authentication is performed.
Page 324 Control panel settings 5-54 C352P (Phase 3)
Page 325: Loading Copy Paper
Loading copy paper...
Page 327: Paper
Loading copy paper Loading copy paper Paper Use paper that meets the following specifications. Possible paper sizes Non-standard-sized paper: Paper Source Paper Width Paper Length Bypass tray 90.0 mm to 311.1 mm 139.7 mm to 1200 mm Tray 1 90.0 mm to 311.1 mm 139.7 mm to 457.2 mm Tray 2 —...
Page 328 Loading copy paper Standard-sized paper: Paper Source Paper Size Bypass tray A3 w to B6 w, A6 w, A3 Wide (12 × 18 w), 11 × 17 w to 5-1/2 × 8-1/2 w/v, 8 × 13 w Tray 1 A3 w to B6 w, A6 w, A3 Wide (12 × 18 w), 11 × 17 w to 5-1/2 × 8-1/2 w/v, 8 ×...
Page 329: Paper Types And Paper Capacities
Loading copy paper Paper types and paper capacities Paper Type Normal Pa- Thick Paper Thick Paper Thick Paper Weight (g/m 60 g/m 91 g/m 151 g/m 210 g/m 90 g/m 150 g/m 209 g/m 256 g/m Paper Source, Etc. Bypass tray 100 sheets 20 sheets or 20 sheets or...
Page 330: Special Paper
Loading copy paper Special paper Paper other than normal paper, such as OHP and colored paper, is called special paper. Be sure to select a special paper setting for paper trays loaded with media such as OHP and colored paper in order to prevent operating errors.
Page 331: Loading Copy Paper
Loading copy paper Paper Type Description Duplex Normal Select these settings when loading paper that has already been 2nd-Side printed on one side. Thick 1 "Duplex 2nd-Side" can be selected only normal, thick 1, thick 2 or thick 3 paper is loaded in the tray 1 or the bypass tray. Thick 2 Thick 3 C352P (Phase 3)
Page 332: Precautions For Paper
Loading copy paper Precautions for paper The following types of paper should not be used, otherwise decreased print quality, paper misfeeds or damage to the machine may occur. - OHP transparencies that have already been fed through the machine (even if the transparency is still blank) - Paper that has been printed on by a heat-transfer printer or an inkjet printer - Paper that is either extremely thick or extremely thin...
Page 333: Print Area
Loading copy paper Print area Any part of the image within the area indicated below is not copied. - A margin 4.2 mm from the leading edge of the paper (A) - A margin 3 mm from the trailing edge of the paper (B) - A margin 3 mm on both sides of the paper (C) A: 4.2 mm B: 3 mm...
Page 334: Order For Selecting The Paper Trays
Loading copy paper Order for selecting the paper trays As a factory default, when a different paper tray is automatically selected, the next paper tray in the following list is chosen. Tray 2 % Tray 3 % Tray 4 % Tray 1 Detail To change the order in which the paper trays are selected, refer to "User Setting"...
Page 335: Loading Copy Paper
Loading copy paper Loading copy paper Loading paper into the Tray 1 Pull out the tray 1. Press down on the paper-lifting plate Paper-lifting until it locks into place. plate Paper feed roller Slide the lateral guides to fit the size Lateral guide of paper to be loaded.
Page 336 Loading copy paper Load the paper into the tray so that , mark the side of the paper to be printed on (the side facing up when the package was unwrapped) faces up. – Load letterhead paper so that the side to be printed on faces down.
Page 337 Loading copy paper When loading envelopes, load them in the w orientation with the flap side down, as shown in the illustration. If the envelopes are loaded with the flap side up, a paper misfeed may occur. The flap side of envelopes cannot be printed on.
Page 338 Loading copy paper When loading postcards, load them in the w orientation, as shown in the illustration. Do not load postcards in the v orientation. Be sure to load letterhead paper so that the side to be printed on faces down.
Page 339: Loading Paper Into The Tray 2, 3 Or 4
Loading copy paper Loading paper into the tray 2, 3 or 4 Pull out the paper tray. Slide the lateral guides to fit the size of paper to be loaded. Lateral guide Film Load the paper into the tray so that , mark the side of the paper to be printed on (the side facing up when the package...
Page 340 Loading copy paper How is curled paper loaded? % Flatten the paper before loading it. How many sheets of paper can be loaded? % Do not load so many sheets of normal paper that the top of the stack is higher than the , mark. Close the paper tray.
Page 341: Loading Paper Into The Lct
Loading copy paper Loading paper into the LCT 0 If the [Power] is turned off, the LCT cannot be pulled out, even after the tray release button is pressed. Be sure that the machine is turned on with the [Power]. Press the tray release button.
Page 342 Loading copy paper Load the paper into the left side of , mark the LCT so that the side of the paper to be printed on (the side facing up when the package was unwrapped) faces up. – Load letterhead paper so that the side to be printed on faces down. Close the LCT.
Page 343: Loading Paper Into The Bypass Tray
Loading copy paper Loading paper into the bypass tray Paper can be fed manually through the bypass tray if you wish to copy onto paper that is not loaded into a paper tray, or if you wish to copy onto thick paper, postcards, envelopes, OHP transparencies or labels.
Page 344 Loading copy paper A maximum of 20 postcards can be loaded into the bypass tray. When loading OHP transparencies, load them in the v orientation, as shown in the illustration. Do not load OHP transparencies in the w orientation. A maximum of 20 OHP transparencies can be loaded into the bypass tray.
Page 345 Loading copy paper A maximum of 10 envelopes can be loaded into the bypass tray. Flap side When loading labels, load them in the w orientation, as shown in the illustration. Do not load labels in the v orientation. A maximum of 20 labels can be loaded into the bypass tray. Side to be printed on C352P (Phase 3)
Page 346 Loading copy paper Be sure to load letterhead paper so that the side to be printed on faces Note The image will be printed on the surface of the paper facing down when the paper is loaded into the bypass tray. 6-22 C352P (Phase 3)
Page 347: Specifying Finishing Settings
Loading copy paper Specifying finishing settings If the optional finisher is installed, the machine can be set to finish the pages after printing them. The Finishing settings can be specified from the printer driver. Stapling prints (Staple settings) Detail In order for the prints to be stapled, all of the following conditions must be met.
Page 348: Punching Holes In Prints (Punch Settings)
Loading copy paper Punching holes in prints (Punch settings) Holes for filing can be punched in the prints. Detail In order for holes to be punched in the prints, all of the following conditions must be met. - The paper width must be between 182 mm and 297 mm - The paper length must be between 182 mm and 432 mm Note The Punch settings are available only if the optional finisher and punch kit...
Page 349: Specifying Center Binding
Loading copy paper Specifying center binding The paper that is fed out can be folded in half and stapled at two places along the vertical center. Note The Fold & Staple settings are available only if the optional finisher and saddle stitcher are installed.
Page 350 Loading copy paper 6-26 C352P (Phase 3)
Page 351: Replacing Consumables
Replacing consumables...
Page 353: Replacing The Toner Cartridge
Replacing consumables Replacing consumables Replacing the toner cartridge When the toner is about to run out, the advanced warning message shown below appears. Detail About 1000 (A4) pages can be printed after the message "Toner near empty" appears. When the message appears, prepare to replace the toner cartridge according to your maintenance agreement.
Page 354 Replacing consumables Note When the message appears, replace the toner cartridge according to your maintenance agreement. When the message "Toner Empty Call Service." appears, contact the service representative. 7 CAUTION Handling toner and the toner cartridges Do not throw toner or the toner cartridge into a fire. Toner expelled from the fire may cause burns.
Page 355: To Replace The Toner Cartridge
Replacing consumables To replace the toner cartridge The procedure for replacing any of the toner cartridges (yellow (Y), magenta (M), cyan (C) or black (K)) is the same. Example: Replacing the black toner cartridge 0 When replacing the toner cartridge, be sure to replace filter 2. A new filter 2 is included in the package with the black toner cartridge.
Page 356 Replacing consumables Prepare the new toner cartridge. – Make sure that the toner cartridge is the same color as the label in the cartridge compartment. What happens if the toner cartridge of a different color is installed? % The toner cartridge of a color different than the one that was removed cannot be installed.
Page 357 Replacing consumables Note Check that a toner cartridge of the same color as the one to be replaced has been prepared. Reminder Be careful about the installation location of the toner cartridges, since it is different for other colors. The shape of the black toner cartridge is different from the shapes of the toner cartridges for the other colors.
Page 358: Replacing The Staples
Replacing consumables Replacing the staples When there are no more staples, the message shown below appears. Detail Be sure to replace the staple cartridge only after the message appears, otherwise the machine may be damaged. To replace the staple cartridge in the finisher Open the front door.
Page 359 Replacing consumables Remove the empty cartridge from the staple cartridge holder. Load the new staple cartridge into the staple cartridge holder. – Do not remove the remaining staples, otherwise the machine will not be able to staple after the cartridge is replaced. Insert the staple cartridge holder, making sure the tabs on the holder slide along the rails in the...
Page 360: To Replace The Staple Cartridge In Saddle Stitcher
Replacing consumables To replace the staple cartridge in saddle stitcher Raise the print output tray, and then push down the staple cartridge holder and remove it. Press in the area marked "PUSH" to unlock the staple cartridge holder. Remove the empty staple cartridge from the staple cartridge holder.
Page 361 Replacing consumables Load the new staple cartridge into the staple cartridge holder. Slowly pull off the seal. Insert the staple cartridge holder, and then push it up until it locks into place. – When inserting the staple cartridge holder, be sure to insert it so that it faces the correct direction.
Page 362 Replacing consumables Pull the handle of the misfeed- clearing door to open it, and then close it. 7-12 C352P (Phase 3)
Page 363: Replacing The Waste Toner Box
Replacing consumables Replacing the waste toner box When it is almost time to replace the waste toner box (and if it is replaceable by the user), the message shown in the following illustration appears, warning about the replacement period. Reminder When the message appears, replace the specified supplies or part according to your maintenance agreement.
Page 364: To Replace The Waste Toner Box
Replacing consumables To replace the waste toner box Follow the procedure described below to replace the waste toner box. Open the machine’s front door. Pull the waste toner release lever. Remove the waste toner box. Install the new waste toner box. 7-14 C352P (Phase 3)
Page 365 Replacing consumables Remove filter 1, and then install the new filter 1. Close the front door. 7 CAUTION Handling toner and the toner cartridges Do not throw toner or the waste toner box into a fire. Toner expelled from the fire may cause burns. 7 CAUTION Precautions for toner spills Be careful not to spill toner inside the machine or get toner on your...
Page 366 Replacing consumables Reminder Do not tilt the removed waste toner box, otherwise waste toner may spill. Do not throw away used waste toner boxes. Instead, keep them in their boxes to be collected by your technical representative. 7-16 C352P (Phase 3)
Page 367: Maintenance
Maintenance...
Page 369: Cleaning
Maintenance Maintenance Cleaning This section describes the procedures for cleaning each part. Housing Clean the surface of the housing by wiping it with a soft cloth dampened with a mild household detergent. Reminder Be sure to turn off the machine (set the power switch to “o”) before cleaning it.
Page 370: Paper Take-Up Roller
Maintenance Paper take-up roller Clean the paper take-up rollers by wiping them with a soft, dry cloth. Reminder Never use solvents, such as benzene or thinner, to clean the paper take- up roller. Electrostatic charger wire If the electrostatic charger wire is dirty, streaks will appear though the printed images.
Page 371: Print Head
Maintenance Print head If the print head becomes dirty, decreased print quality may result. If this occurs, clean the print head according to the following procedure. Open the machine’s front door. Remove the cleaning tool from the machine’s front door. Insert the cleaning tool into the print head cleaning opening, pull it out, and then repeat this back and forth...
Page 372: Emptying The Waste Containers
Maintenance Emptying the waste containers If the hole-punch waste container in punch kit installed on finisher becomes full, the message shown below appears (if it can be emptied by the user). Note When the message "Punch Scrap Full Call Service." appears, contact the service representative.
Page 373: To Empty The Hole-Punch Waste Container
Maintenance To empty the hole-punch waste container Follow the procedure described below to empty the hole-punch waste container. Open the front door. Pull out the hole-punch waste container FN3.1. Empty the hole-punch waste container. Insert the hole-punch waste container at its original position. Close the front door.
Page 374: When The Message "Preventive Maintenance Time" Appears
Maintenance When the message “Preventive Maintenance Time” appears If the message "Preventive Maintenance Time" appears, contact your technical representative and request a periodic maintenance inspection. C352P (Phase 3)
Page 375: Troubleshooting
Troubleshooting...
Page 377: When The Message "Trouble" Appears
Troubleshooting Troubleshooting When the message “Trouble” appears (call technical representative) If a malfunction that cannot be corrected by the user occurred, the message "Trouble C-xxxx Call Service." appears. (call technical representative screen) To call the technical representative Write down the malfunction code (for example, C-0001) in the call technical representative screen.
Page 378: When The Message "Paper Misfeed At" Appears
Troubleshooting When the message “Paper Misfeed at” appears If a misfeed occurs during printing, the message "Paper Misfeed at" appears and the location of the misfeed is indicated in the screen. (misfeed screen) At this time, printing cannot continue until the misfeed is adequately cleared. Note The procedure for clearing a misfed paper differs depending on where the misfeed occurs.
Page 379: Paper Misfeed Indications
Troubleshooting Paper misfeed indications Code Description JG, JH A paper misfeed in the fusing unit (p. 9-18) JF, JG A paper misfeed in the main unit (p. 9-15) A paper misfeed in the bypass tray (p. 9-7) A paper misfeed in the LCT (p. 9-14) A paper misfeed in the saddle stitcher (p.
Page 380 Troubleshooting Code Description A paper misfeed in the mailbin (p. 9-30) JJ, JK, JL, JS A paper misfeed in finisher (p. 9-27) C352P (Phase 3)
Page 381: To Clear A Paper Misfeed In The Bypass Tray
Troubleshooting To clear a paper misfeed in the bypass tray Remove all paper from the bypass tray. If the misfed paper could not be removed, open the upper right-side door. Open inside cover M1. Slowly pull out the paper. Close the upper right-side door. C352P (Phase 3)
Page 382 Troubleshooting 7 CAUTION The area around the fusing unit is extremely hot. %Touching anything other than the indicated levers and dials may result in burns. If you get burnt, immediately cool the skin under cold water, and then seek professional medical attention.
Page 383: To Clear A Paper Misfeed In The Adu
Troubleshooting To clear a paper misfeed in the ADU Open the ADU door. Carefully pull out any misfed paper. Close the ADU door. Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 9-5. C352P (Phase 3)
Page 384: To Clear A Paper Misfeed In The Tray 1
Troubleshooting To clear a paper misfeed in the tray 1 Pull up the upper right-side door release lever, and then open the upper right-side door. Open inside cover M1. Slowly pull out the paper. Close the upper right-side door. Pull out the tray 1, and then remove any misfed paper. Close the tray 1.
Page 385 Troubleshooting 7 CAUTION The area around the fusing unit is extremely hot. %Touching anything other than the indicated levers and dials may result in burns. If you get burnt, immediately cool the skin under cold water, and then seek professional medical attention.
Page 386: To Clear A Paper Misfeed In The Tray 2
Troubleshooting To clear a paper misfeed in the tray 2 Pull up the center right-side door release lever, and then open the center right-side door. Carefully pull out any misfed paper. Close the center right-side door. Pull out the tray 2, and then remove any misfed paper. Close the tray 2.
Page 387: To Clear A Paper Misfeed In A Paper Tray (Tray 3 Or 4)
Troubleshooting To clear a paper misfeed in a paper tray (tray 3 or 4) Pull up the lower right-side door release lever, and then open the lower right-side door. Carefully pull out any misfed paper. Close the lower right-side door. Pull out the paper tray, and then remove any misfed paper.
Page 388: To Clear A Paper Misfeed In The Lct
Troubleshooting To clear a paper misfeed in the LCT Pull up the lower right-side door release lever, and then open the lower right-side door. Carefully pull out any misfed paper. Close the lower right-side door. Press the tray release button, pull out the LCT, and then remove any misfed paper.
Page 389: To Clear A Paper Misfeed In The Right-Side Door
Troubleshooting To clear a paper misfeed in the right-side door Pull up the upper right-side door release lever, and then open the upper right-side door. Slowly pull out the paper. If the end of the paper is caught in Timing the timing roller section, open inside roller cover M1.
Page 390 Troubleshooting Pull out the paper tray being used, Paper and then remove any paper feed roller remaining in the tray. Load the paper into the paper tray again, and then close the tray. 7 CAUTION The area around the fusing unit is extremely hot. %Touching anything other than the indicated levers and dials may result in burns.
Page 391 Troubleshooting Reminder If the paper is misfed as described below, contact your technical representative. The paper is wrapped around the timing roller. The paper is folded or shredded by the timing roller. Be careful not to touch the surface of the paper feed roller (in the tray 1) or the film (in the tray 2, 3 and 4 and in the LCT) with your hands.
Page 392: To Clear A Paper Misfeed In The Fusing Unit
Troubleshooting To clear a paper misfeed in the fusing unit Pull up the upper right-side door release lever, and then open the upper right-side door. Push up the fusing unit cover, and then slowly pull out any misfed paper. Press fusing unit cover release button M2, and then open the fusing unit cover.
Page 393 Troubleshooting Slowly pull out any misfed paper. Raise the fusing unit cover lever M3, and then close the fusing unit cover. Close the fusing unit cover. C352P (Phase 3) 9-19...
Page 394 Troubleshooting Close the upper right-side door. 7 CAUTION The area around the fusing unit is extremely hot. %Touching anything other than the indicated levers and dials may result in burns. If you get burnt, immediately cool the skin under cold water, and then seek professional medical attention.
Page 395 Troubleshooting Reminder If the paper is misfed as described below, contact your technical representative. The paper is wrapped around the roller in the fusing unit. The paper is folded or shredded by the roller in the fusing unit. The paper that was removed tore and partly remains in the fusing unit. Decreased print image quality may Image transfer belt result if the surface of the image...
Page 396: To Clear A Banner Paper Misfeed
Troubleshooting To clear a banner paper misfeed Pull up the upper right-side door release lever, and then open the upper right-side door. – If the end of the paper cannot be seen or cannot be grabbed, pull out the paper in the direction of the arrow.
Page 397 Troubleshooting Push up the fusing unit cover, and then pull out any misfed paper. Press fusing unit cover release button M2, and then open the fusing unit cover. – Do not manually return the M2 release levers to their original positions.
Page 398 Troubleshooting Raise fusing unit cover lever M3, and then close the fusing unit cover. Close the fusing unit cover. Close the upper right-side door. 9-24 C352P (Phase 3)
Page 399 Troubleshooting 7 CAUTION The area around the fusing unit is extremely hot. %Touching anything other than the indicated levers and dials may result in burns. If you get burnt, immediately cool the skin under cold water, and then seek professional medical attention.
Page 400 Troubleshooting Reminder Decreased print image quality may Image transfer belt result if the surface of the image transfer belt or image transfer roller is touched. Be careful not to touch the surface of the image transfer belt or the image transfer roller. Transfer roller 9-26 C352P (Phase 3)
Page 401: To Clear A Paper Misfeed In The Finisher
Troubleshooting To clear a paper misfeed in the finisher Pull the finisher release lever 1 to unlock the finisher. Grab the finisher at "2", and then slide the finisher away from the main unit. – To move the finisher away from the main unit, be sure to grab it at "2".
Page 402 Troubleshooting Raise lever FN1, turn dial FN2, and then pull out any paper. Lower guide FN3, and then pull out any paper. – If the punch kit is installed, pull out the hole-punch waste container FN3.1. Return guide FN3 to its original position. –...
Page 403 Troubleshooting Turn dial FN5 or dial FN6, and then pull out any paper. Return the finisher to its original position. – When returning the finisher to its original position, do not grab the handle on the front door, the control panel, the mailbins, or the saddle stitcher.
Page 404: To Clear A Paper Misfeed In The Mailbin
Troubleshooting To clear a paper misfeed in the mailbin Open the front door. Turn dial FN5 or dial FN6 to feed out the paper. While pressing down lever FN7, pull out any paper. Pull handle FN8 to open the misfeed- clearing door.
Page 405 Troubleshooting Pull out any paper in the mailbin. Close the misfeed-clearing door. Close the front door. Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 9-5. C352P (Phase 3) 9-31...
Page 406: To Clear A Paper Misfeed In The Saddle Stitcher
Troubleshooting To clear a paper misfeed in the saddle stitcher Open the front door. Turn dial FN5 or dial FN6 to feed out the paper. Remove all paper from the finishing tray. Open the misfeed-clearing door, and then pull out any paper. 9-32 C352P (Phase 3)
Page 407 Troubleshooting Close the misfeed-clearing door. Close the front door. Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 9-5. C352P (Phase 3) 9-33...
Page 408: When The Message "Replenish Paper" Appears
Troubleshooting When the message “Replenish paper” appears If a tray has run out of paper while printing, the message "Replenish paper." appears. To replenish paper Check which paper tray is indicated, and then load it with paper. xx: Indicates the paper tray sssss: Indicates the size of the paper ttttt: Indicates the code for the paper type NRML (normal paper), 1SIDE (paper only for single-sided printing),...
Page 409: Clearing A Staple Jam
Troubleshooting Clearing a staple jam Reminder Be careful when clearing jammed staples since injuries may result. If the staples become jammed, follow the procedure described below. If the paper is pulled out with too much force, the stapler may be damaged. To clear jammed staples in the finisher Remove all paper from the finisher.
Page 410 Troubleshooting Lower guide FN3, and then pull out any paper. – If the punch kit is installed, pull out the hole-punch waste container FN3.1. Return guide FN3 to its original position. – If the punch kit is installed, insert the hole-punch waste container FN3.1 into its original position.
Page 411 Troubleshooting Turn the dial to the left to move the stapler toward the front. Remove the staple cartridge holder. – Pull the staple cartridge holder toward you to remove it. – Only touch the blue parts of the staple cartridge. Swing open the shutter of the staple cartridge holder, and then pull out one sheet of staples.
Page 412 Troubleshooting Insert the staple cartridge holder, making sure the tabs on the holder slide along the rails in the compartment. – Check that the staple cartridge holder is securely installed. Close the front door. Reminder If stapling still cannot be resumed, even after performing the above procedure, contact your technical representative.
Page 413: To Clear Jammed Staples In The Saddle Stitcher
Troubleshooting To clear jammed staples in the saddle stitcher Open the front door. Raise lever FN1, turn dial FN2, and then pull out any paper. Lower guide FN3, and then pull out any paper. – If the punch kit is installed, pull out the hole-punch waste container FN3.1.
Page 414 Troubleshooting Return guide FN3 to its original position. – If the punch kit is installed, insert the hole-punch waste container FN3.1 into its original position. Turn dial FN4 to feed the paper, open the transport unit cover, and then pull out any paper. Turn dial FN5 or dial FN6, and then pull out any paper.
Page 415 Troubleshooting Raise the finishing tray, and then push down the staple cartridge holder and remove it. Swing open the shutter of the staple cartridge holder, and then pull out one sheet of staples. Return the shutter of the staple cartridge holder to its original position. Insert the staple cartridge holder, and then push it down until it locks into place.
Page 416: When "Near Life Limit" Appears
Troubleshooting When “near life limit” appears When it is almost time to replace supplies or a part within this machine, the message shown in the following illustration appears, warning about the replacement period. Note When the message appears, replace the specified supplies or part according to your maintenance agreement.
Page 417: Simple Troubleshooting
Troubleshooting Simple troubleshooting Main unit Symptom Possible Cause Remedy The machine does not Is no power supplied from the Correctly insert the power supply start up when the power electrical outlet? plug into the electrical outlet. switch is turned on. The machine does not Is the right-side door of the Securely close the right-side door of...
Page 418: Finisher
Troubleshooting Finisher Symptom Possible Cause Remedy The finisher cannot be Is no power supplied to the Check that the cord is correctly in- used. connector? serted into the connector. The pages cannot be Have the staples run out? Replace the staple cartridge. (See stapled.
Page 419: Printer Driver
Troubleshooting Printer driver Symptom Probable Cause Action The message "No The printer driver selected for Check the printer name selected. printers are connect- printing is not compatible with the ed." or "Print error" printer controller. appears. The network cable, parallel cable, Check that the cable is connected or USB cable is disconnected.
Page 420 Troubleshooting Symptom Probable Cause Action A printer driver setting Some functions cannot be com- Do not try to select settings that cannot be selected. bined. are not available. The "Conflicts" mes- An incorrect combination of func- Check the settings and specify sage with "Unable to tions has been specified.
Page 421 Troubleshooting Symptom Probable Cause Action The form is not printed Available computer memory Simplify the form to reduce the properly. space is not sufficient. data size. The image is not print- Available computer memory Simplify the image to reduce the ed properly.
Page 422: Main Messages And Their Remedies
Troubleshooting Main messages and their remedies Main messages Message Cause Remedy Set paper. Paper of a suitable size is not Either select a different size or feed loaded in a paper tray. paper of a suitable size from the by- Check Size pass tray.
Page 423 Troubleshooting Message Cause Remedy Paper Misfeed at xxxx Since a paper misfeed oc- Clear the paper misfeed. curred, the machine is unable (See p. 9-5.) to make prints. HDD Password Error The password is incorrect. Register the correct password. Encryption Key failure The encryption key is incor- Register the correct encryption key, rect.
Page 424 Troubleshooting 9-50 C352P (Phase 3)
Page 425: Additional Settings
Additional settings...
Page 427: Using Pagescope Web Connection
Additional settings Additional settings 10.1 Using PageScope Web Connection PageScope Web Connection is a device management utility supported by the HTTP server integrated into the printer. Using a Web browser on a computer connected to the network, machine set- tings can be specified from PageScope Web Connection. Flash and HTML are available from View Mode in PageScope Web Connection.
Page 428: Accessing Pagescope Web Connection
Additional settings Accessing PageScope Web Connection PageScope Web Connection can be accessed directly from a Web browser. Start up the Web browser. In the Address bar, enter the IP address for this machine, and then press the [Enter] key. http://<IP_address_for_this_machine>/ Example: If the IP address for this machine is 192.168.1.20 http://192.168.1.20/ Detail...
Page 429: Page Structure
Additional settings Page structure The page that appears immediately after PageScope Web Connection is ac- cessed is called the User mode page, and it is displayed when you have logged in as a public user. Note If no operation is performed for the set length of time while logged on, a timeout occurs and you will automatically be logged off.
Page 430 Additional settings Item Description KONICA MINOLTA Logo Click the logo to jump to the following Web site (KONICA MINOLTA Web site). http://konicaminolta.com PageScope Web Connec- Click the PageScope Web Connection logo to display the tion Logo version information of PageScope Web Connection.
Page 431: Cache Function Of Web Browsers
Additional settings Cache function of web browsers The newest information may not appear on the PageScope Web Connection page due to the cache function of the Web browser. In addition, problems can occur when the cache function is used. When using PageScope Web Connection, disable the cache function of the Web browser.
Page 432: Logging In To The Administrator Mode
Additional settings Logging in to the Administrator mode You can specify the system and network settings by logging in to the Admin- istrator mode. In the login page, select [Administrator], and then click the [Login] button. – If necessary, select the language and the display format. 10-8 C352P (Phase 3)
Page 433 Additional settings Enter the administrator password for this machine, and then click the [OK] button. The page switches to the Administrator mode page. C352P (Phase 3) 10-9...
Page 434 Additional settings Note If the User mode page is displayed, click the [Logout] button to display the login page. When logged in to the Administrator mode, the machine’s control panel is locked and cannot be used. Depending on the status of this machine, you may not be able to log in to the Administrator mode.
Page 435: User Mode
Additional settings User mode The User mode provides functions for checking and operating the machine on a user level. You can select from four tabs (System, Job, User Box, and Print) C352P (Phase 3) 10-11...
Page 436: System Tab
Additional settings System tab On the System tab, information and settings concerning the system configuration are displayed. The System tab is the first page that appears when you access "http://<IP_address_for_this_machine>/" on the Web browser. Menus Description Device In- Consumables Information about consumables for this machine is dis- formation played.
Page 437: Job Tab
Additional settings Job tab From the Job tab, jobs managed by the machine can be checked. Menus Description Current Print The list of print jobs being performed and queued to be per- Jobs formed and their details are displayed. HDD/Memory The list of box jobs being performed and queued to be per- formed and their details are displayed.
Page 438: Print Tab
Additional settings Print tab From the Print tab, the default printer settings can be checked and the vari- ous reports can be printed. Menus Description Default General Setting The default printer settings are displayed. Setting PCL Setting The PCL settings are displayed. PS Setting The PostScript settings are displayed.
Page 439: Administrator Mode
Additional settings Administrator mode In Administrator mode, you can specify system settings for this machine. You can select from five tabs (System, Job, Box, Print, and Network). For details on logging on to Administrator mode, refer to "Logging in to the Administrator mode"...
Page 440: System Tab
Additional settings System tab On the System tab, information and settings concerning the system config- uration of this machine are displayed. Menus Description Import/Export Information from this machine can be saved as a file (ex- ported) or information can be written to this machine (im- ported).
Page 441 Additional settings Note Only text files can be read when importing and exporting. If the settings are cleared by selecting "Network Setting Clear", you will not be able to connect to this machine until the settings are specified again. Job tab From the Job tab, the history of jobs managed by the machine can be checked.
Page 442: Network Tab
Additional settings Print tab From the Print tab, the default print settings can be changed. Menus Description Interface Specify the amount of time until the interface times out. Default Set- General Setting Change the default print settings, such as the paper tray ting and paper size.
Page 443 Additional settings Menus Description SSL/TLS SSL/TLS Specify the settings for SSL/TLS. When SSL is used, trans- missions between this machine and the client computer are encrypted. In order use SSL, a self-signed certificate must first be cre- ated or a certificate issued by a certification authority must be installed.
Page 444: Box Operations
Additional settings 10.2 Box operations Box operations allow document print data to be saved on the HDD and print- ed when desired. Various boxes can be created for specific uses, and data can be saved in a specified box. Available parameters User mode Menu Description...
Page 445: Opening Boxes
Additional settings Opening Boxes The list of boxes currently created and the list of data saved in those boxes can be viewed. Open Public User Box Item Description User Box No. Type in the number of the box to be opened. User Box Password Type in the password if a password has been set for the box.
Page 446 Additional settings Note When logged on to Administrator mode, the settings of boxes can be specified or the boxes can be deleted without the box password being entered. 10-22 C352P (Phase 3)
Page 447 Additional settings To open a box Select the box type, and then click [Next]. In the "User Box No." box, type the box number. For User mode, type the password in the "User Box Password" box. Click [OK]. A list of the documents saved in the specified box is displayed. C352P (Phase 3) 10-23...
Page 448: Checking Box Information
Additional settings Checking box information The basic box information and the list of documents saved in the box can be viewed. In addition, documents can be deleted, renamed or moved/copied. Box Detail Information Item Description Refresh to the new information Click to display the most recent information.
Page 449 Additional settings Document list Item Description Document Name Displays the name of the document. Time Stored Displays the date/time that the document was regis- tered. Click this icon to display detailed information for the document. This item is not available with this machine. Click this icon to delete the document.
Page 450: Changing The Box Settings
Additional settings Changing the box settings To change the box settings, click [User Box Setting] in the Box Detail Information page. 10-26 C352P (Phase 3)
Page 451 Additional settings When changing the box attributes, specify information for the following, and then click [Apply]. Item Description User Box No. Displays the box number. This cannot be changed. User Box Name Type in a box name of a maximum of 20 characters. Index Type in the characters used for indexing.
Page 452: Deleting A Box
Additional settings Deleting a box The currently open box can be deleted. In the Box Detail Information page, click [Delete User Box]. Check the displayed information, and then click [OK] to delete the box. 10-28 C352P (Phase 3)
Page 453: Creating Boxes
Additional settings Creating boxes New boxes can be created. Select the type of box to be created, and then click [Next]. C352P (Phase 3) 10-29...
Page 454 Additional settings Specify the necessary settings, and then click [Apply]. Item Description User Box No. Type in a box number between 1 and 999,999,999. Up to 1,000 boxes can be created. User Box Name Type in a box name of a maximum of 20 characters. User Box Password Type in a password of a maximum of 8 alphanumeric characters.
Page 455: Managing Print Jobs
Settings for these functions can be specified from the following printer drivers. Konica Minolta PCL Printer Driver for Windows Konica Minolta PostScript Printer Driver for Windows 2000/XP/Server 2003 Konica Minolta PPD Printer Driver for Mac OS X C352P (Phase 3) 10-31...
Page 456 Additional settings Setting procedure With Windows, select a function from the "Output Method" drop-down list on the Setup tab. With a Macintosh, select a function from the "Output Method" drop-down list, which is displayed after "Security" is selected. 10-32 C352P (Phase 3)
Page 457: Storing Jobs
Additional settings Storing jobs Depending on the function selected in the "Output Method" drop-down list of the printer driver, the print document may be stored on this machine as a print job. In order to print a stored job, the job must be recalled using the "Job Operation"...
Page 458 Additional settings Enter the account name, and then press the [Menu/Select] key. Enter the account name by pressing the [+] and [,] keys until the desired character appears and pressing the [)] key so that the next character can be entered. When the [Menu/Select] key is pressed, the screen for entering the password appears.
Page 459 Additional settings Press the [+] and [,] keys until the desired job appears. – Secure Print: Select to print a document stored using the "Secure Print" function. – User Box: Select to print a document stored using the "Save in User Box"...
Page 460 Additional settings To print, press the [Menu/Select] key. The print confirmation screen appears. – To specify the number of copies to be printed, press the [)] key, and then specify the desired number of copies in the screen that appears. If "ALL" was selected, the number of copies cannot be specified.
Page 461: Printing When Account Track Settings Have Been Specified
Konica Minolta PCL Printer Driver for Windows Konica Minolta PostScript Printer Driver for Windows 2000/XP/Server 2003 Konica Minolta PPD Printer Driver for Mac OS X Note If the optional HDD is not installed, 100 accounts can be specified. If the optional HDD is installed, 1000 accounts can be managed.
Page 462: Setting Procedure (For Windows)
Additional settings Setting procedure (for Windows) Click the [Properties] or [Preferences] button in the Print dialog box to display the Printing Preferences dialog box. Click the Setup tab. Click the [User Authentication/Account Track] button. Select the "Account Track" check box, and then type in the department name and password.
Page 463: Setting Procedure (For Mac Os X)
Additional settings Setting procedure (for Mac OS X) On the "File" menu, click "Print". Select "Security". Select the "Account Track" check box, and then type in the department name and password. Click the [Print] button to print the document. – If the entered department name and password are accepted by the machine, the job is printed and added to the count for the specified account.
Page 464: Job Operations In Pagescope Web Connection
Additional settings Job operations in PageScope Web Connection From PageScope Web Connection, the status of jobs being performed by this machine can be checked. For details, refer to the following pages. "Job tab" on page 10-13, page 10-17 10-40 C352P (Phase 3)
Page 465: Printing On Banner Paper
Additional settings 10.4 Printing on Banner Paper Paper up to 1200 mm long can be loaded into the bypass tray and printed on using this machine with the appropriate setting specified from the control panel. Loading banner paper and printing on it is referred to as "banner printing" throughout the manual.
Page 466: Printer Drivers And Supported Operating Systems
"Original Size" and "Output Size" drop-down lists on the Setup tab. Note For the Konica Minolta PCL driver, the custom size settings can only be specified from the printer driver setup dialog box, which can be displayed from the Printers window (for Windows XP/Server 2003,Printers and Fax- es window).
Page 467: Printing
Additional settings Printing Press the [Menu/Select] key in the control panel. Press the [,] key until "Banner Print OFF" is displayed. Press the [Menu/Select] key. Press the [+] or [,] key to select "ON", and then press the [Menu/Select] key. From the computer, select the job to be printed, and then click "Print"...
Page 468 Additional settings With the side to be printed on facing down, insert the paper as much as possible into the feed slot. – Before loading the paper, check that the following message appears in the control panel. Slide the lateral guides to fit the size of paper being loaded. –...
Page 469 Additional settings When printing is finished, press the [Cancel] key. Press the [Menu/Select] key. C352P (Phase 3) 10-45...
Page 470 Additional settings 10-46 C352P (Phase 3)
Page 471 Appendix...
Page 473: Specifications
Appendix Appendix 11.1 Specifications bizhub C352P Specifications Type Freestanding printer Photoconductor Developing system Dry-type dual-component HMT developing method Fusing system Belt-fixing Paper Normal paper (60 g/m to 90 g/m ), Banner paper (127 g/m to 160 g/m )**, thick paper 1 (91 g/m...
Page 474 Appendix Specifications Interface Standard: Ethernet (10Base-T or 100Base-TX) Optional: USB 1.1, USB 2.0, or IEEE 1284 Frame Type Ethernet 802.2 Ethernet 802.3 Ethernet II Ethernet SNAP Supported Protocols TCP/IP IPX/SPX NetBEUI AppleTalk (EtherTalk) Print Speed Full color/black: 35 ppm (single-sided), 32 sides/min. (dou- blesided) With special paper or with the "Glossy"...
Page 475 Appendix Specifications Utility PageScope Web Connection Web Browsers: Microsoft Internet Explorer 6 or later recommended (JavaS- cript enabled, Cookies enabled) Microsoft XML Parser MSXML3.X must be installed when us- ing Internet Explorer 5.5. Netscape Navigator 7.02 or later (JavaScript enabled, Cook- ies enabled) ®...
Page 476: Automatic Duplex Unit
Appendix Automatic Duplex Unit Specifications Paper types Normal paper (64 g/m to 90 g/m ), thick paper 1 (91 g/m 150 g/m ), thick paper 2 (151 g/m to 209 g/m thick paper 3 (210 g/m to 256 g/m Paper sizes A3 w to A5 w/v, A3 Wide (12 ×...
Page 477: Paper Feed Cabinet Pc-203
Appendix Paper Feed Cabinet PC-203 Specifications Paper types Normal paper (60 g/m to 90 g/m Paper sizes A3 w to A5 w, 11 × 17 w to 8-1/2 × 11 w/v Tray paper capacity Upper tray (Tray 3): 500 sheets (80 g/m Lower tray (Tray 4): 500 sheets (80 g/m Power requirements Supplied from main unit...
Page 478: Finisher Fs-514
Appendix Finisher FS-514 Specifications Finishing trays Finishing tray 1, finishing tray 2 Feed settings "Sort", "Group", "Sort"/"Offset", "Group"/"Offset", and "Sort" and Staple Paper types Finishing tray 1, finishing tray 2: Normal paper (50 g/m to 90 g/m Thick paper (91 g/m to 256 g/m ), OHP, postcards, enve- lopes, label sheets, letterheads...
Page 479: Punch Kit Pk-510
Appendix Punch kit PK-510 Specifications Punched holes Paper types Normal paper (50 g/m to 209 g/m Paper sizes A3 w, A4 v, B5w Power requirements Supplied from finisher Dimensions 114 mm (W) × 461 mm (D) × 106 mm (H) Weight Approx.
Page 480: Output Tray Ot-601
Appendix Output tray OT-601 Specifications Number of bins 1 bin Paper capacity Normal paper (50 g/m to 90 g/m ): Maximum 200 sheets Thick paper (91 g/m to 256 g/m ), postcards, envelopes, OHP, or label sheets, letterheads: Maximum 20 sheets Dimensions 282 mm (W) ×...
Page 481: Configuration Page
Appendix 11.2 Configuration page C352P (Phase 3) 11-11...
Page 482: Font List
Appendix 11.3 Font list PCL font list 11-12 C352P (Phase 3)
Page 483: Ps Font List
Appendix PS font list C352P (Phase 3) 11-13...
Page 484: Test Page
Appendix 11.4 Test page 11-14 C352P (Phase 3)
Page 485: Glossary
Appendix 11.5 Glossary Term Definition 10Base-T/100Base- An Ethernet standard, which is a cable consisting of twisted copper TX/1000Base-TX wire pairs. The transmission speed of 10Base-T is 10 Mbps, of 100Base-TX is 100 Mbps, and of 1000Base-T is 1000 Mbps. AppleTalk A generic name for the protocol suite developed by Apple Computer for computer networking "Auto Paper Select"...
Page 486 Appendix Term Definition DPI (dpi) Abbreviation for Dots Per Inch. A resolution unit used by printers and scanners. Indicates how many dots per inch are represented in an image. The higher the value, the higher the resolution. Driver Software that works as a bridge between a computer and a periph- eral device.
Page 487 Appendix Term Definition LPR/LPD Abbreviation for Line Printer Request/Line Printer Daemon. A print- ing method over a network in a Windows NT system or UNIX system. Using TCP/IP, you can output print data from Windows or Unix to a printer over a network. MAC Address Abbreviation for Media Access Control address.
Page 488 Appendix Term Definition Abbreviation for Portable Document Format. An electronically for- matted document which uses the .pdf extension. Based on the Post- Script format, you can use the free Adobe Acrobat Reader software to view documents. Abbreviation for Page Description Language. The language for spec- ifying the print image per page to a printer when printing using a page printer.
Page 489 Appendix Term Definition Abbreviation for Red, Green, and Blue. Represents all colors by changing the brightness ratio of the RGB 3 colors using the primary colors used by the color representation in a monitor. Resolution Displays the ability to reproduce the details of images and print mat- ter correctly Samba UNIX server software that uses SMB (Server Message Block) so that...
Page 490: Index
Appendix 11.6 Index Clearing a paper misfeed in the LCT 9-14 Clearing a paper misfeed in the 9-15 right-side door 5-33 Account name 9-35 Clearing a staple jam 4-24 4-61 10-37 Account track 11-11 Configuration page Add Printer Wizard Consumables 2-23 2-38 Control panel...
Page 491 Appendix 5-10 Main menu 2-23 11-3 Main unit 4-98 General Maintenance Glossy mode 4-38 4-52 1-11 4-72 4-81 4-93 4-101 4-109 Manual conventions 4-122 4-18 4-65 Margin 4-81 Graphics Tab Menu operations Grounding Menu/Select 9-48 Messages 9-10 9-13 9-14 Misfeed 4-19 4-66 Hole punching...
Page 492 Appendix 4-84 4-114 Paper Printing Paper capacities Printing functions 4-116 10-31 Paper feed Proof and print 9-10 4-23 4-60 Paper misfeed Proof and printing 9-13 9-14 9-15 9-18 2-35 Punch kit PK-510 Paper misfeed location 6-24 Punch settings 4-94 Paper setup Paper size 4-10 4-56...
Page 493 Appendix 10-33 Storing jobs System requirements 5-35 5-44 System setting 3-35 TCP/IP 11-14 Test page 5-44 Time adjustment Toner cartridge 2-26 6-11 9-10 Tray 1 2-26 6-15 9-12 Tray 2 Tray 3 2-26 6-15 9-13 2-26 6-15 9-13 Tray 4 5-36 Tray setting Trouble...
Page 494 Appendix 11-24 C352P (Phase 3)
