10 Maintenance and service
Lamp replacement - direction
indicators front
The direction indicator lamp is fitted inside
the headlamp's smaller cover.
10
1. Detach the headlamp (p. 353).
2. Detach the cover by pulling it straight out.
3. Pull the bulb holder in order to extract the
bulb.
4. Press and simultaneously turn the bulb to
detach it.
Reinstall the parts in reverse order.
Related information
•
Lamps - specifications (p. 358)
356
Lamp replacement - rear lamp
Rear direction indicators, rear fog lamp and
reversing lamp are replaced from inside the
cargo area.
Lamp housing, rear
The bulbs for reversing lamp, fog lamp and
direction indicator in the rear lamp cluster are
replaced from inside the cargo area.
1. Open the panel.
2. Remove the insulation that is fitted in
front of the bulb holder by pulling it
straight out.
3. Press down the catch and pull out the
bulb holder.
4. Remove the blown bulb by pressing it in
and turning anticlockwise.
5. Fit a new bulb, press down and turn
clockwise.
6. Press down the catch when the bulb
holder is refitted.
7. Refit the insulation and panel.
Related information
•
Lamp replacement - location of rear
lamps (p. 357)
•
Lamps - specifications (p. 358)
