S-Video Connections

_______ To adapt S-VHS to BNC, use Extron cable 26-353-01.
_______ When connecting Y and C cables, be sure to use the same input numbers on
Input Connections
Output Connections
_______ A Matrix 100 can be configured with RGsB (sync on green) and S-Video.
2-7
S-Video (S-VHS) is typically the output from the AV source on a 4-pin miniature
din-type connector and must be converted to 2 BNC type connectors - one for
Chrominance (C) and the other for Luminance (Y).
To connect S-Video to the Matrix 100, the Matrix must be ordered with two
composite video modules. Use one for Luminance (Y) and the other for
Chrominance (C). The Y and C signal lines are then connected to the two video
modules. See illustration on facing page.
the two video modules for each source. This example uses number 2 inputs.
Also use the same output number pair for each destination. This example uses
number 2 outputs, but we could have used outputs number 1, or 3, etc.
Choose which input number to use to connect the S-Video source device to the
Matrix 100. Connect the Luminance (Y) to the input connector on the first (left)
Video module and the Chrominance (C) to the same input number on the
second (right) Video module.
If audio is used, connect the right and left audio source outputs to the right and
left inputs on the back of the Matrix 100. See page 2-9 for details on audio
connections.
Choose which Matrix 100 output number to use for the S-Video destination unit.
Connect the Luminance (Y) output from the first (left) Video module to the
Luminance input of the destination unit. Connect the Chrominance (C) from the
same output number on the second (right) Video module to the Chrominance
input of the Video destination unit.
If audio is used, connect the right and left audio output from the Matrix
connector to the right and left inputs of the audio destination unit. See page 2-9
for details on audio connections.
