Appendix C: Printer Options
Optional items for the printer include the 250-sheet
second hopper and the SIMM board.

250-Sheet Second Hopper

The optional hopper makes it possible to load extra
paper into the printer. Up to 250 additional sheets of
letter, A4, or executive paper can be loaded into the
paper cassette.

Setting Up the 250-Sheet Hopper

1. Take the 250-sheet hopper out of the shipping
carton. Remove the vinyl bag and peel off the
shipping tape.
2. Press the paper lifting plate down until it locks into
position.
C—2
10 App.C Options* 2
3. Holding both sides of the second paper tray, slightly
bend the tray as shown. Insert the second tray all the
way into the port of the 250-sheet hopper as shown.
4. Fit the paper guide furnished with the unit into the
position corresponding to the paper size you plan to
use.
For executive size paper
For letter or A4 size paper
96.9.24, 1:15 PM
Inside
Outside
