Summary of Contents for Furman PL-PRO E II
- Page 1 SERIES II 16 AMP POWER CONDITIONERS...
- Page 2 Laboratory precision Digital Voltmeter displays incoming line voltage (± 1.5 VAC) • True RMS Current Meter displays power draw (± 0.5 amp) 2 3 0 2 3 0 00.5 PL-PRO E II front panel PL-PRO DE II front panel PM-PRO E II front panel...
-
Page 3: Safety Information
SERIES II 16 AMP POWER CONDITIONERS I N T R O D U C T I O N Thank you for purchasing a Furman Series II Power Conditioner, and congratulations on choosing the best protection for your electronics. Series II Power Conditioners feature Furman’s revolutionary SMP+ circuitry, as well as our exclusive Linear Filtering Technology (LiFT). - Page 4 3. Do not operate your Series II unit near radiators, heat registers, stoves, or other heat sources. 4. Connect your PL-PRO E II, PL-PRO DE II, or PM-PRO E II only to a 220 – 240 VAC, 50 Hz, 16 amp grounded electrical outlet.
-
Page 5: Additional Features
SERIES II 16 AMP POWER CONDITIONERS ADDITIONAL F E A T U R E S All PL-PRO Series II models include an 8 foot, 1.5mm x 3 gauge heavy-duty power cable. A rear mounted BNC jack accepts any standard (12 VAC 0.5 amp) gooseneck lamp for rear rack illumination. - Page 6 2 3 0 2 3 0 2 3 0 00.5 2 3 0 00.5 BNC Connector for Gooseneck Lamp...
-
Page 7: Operation
O P E R AT I O N Retractable Rack Lights, Rear Panel Lamp and Dimmer Control: The PL-PRO E II, PL-PRO PE II, PL-PRO DE II and PL-PRO PDE II include a dimmer control for the two retractable front panel light tubes. - Page 8 SERIES II 16 AMP POWER CONDITIONERS 2. If all of the LED’s on the voltmeter flash, the input voltage is marginally high. The PL-PRO’s outlets will remain powered unless the incoming voltage rises above the Extreme Voltage Shutdown cutoff voltage of 270 – 280 volts (UK version: 255 –...
- Page 9 The unit must be returned to Furman Sound or to an authorized Furman Service center for repair. NOTE: If the mains power is above the high...
-
Page 10: Three-Year Limited Warranty
50 or 60 Hz AC line, it can be effectively reduced by low-pass filters. THREE YEAR LIMITED WARRANTY Furman Sound, Inc., having its principal place of business at 1997 South McDowell Blvd., Petaluma, CA 94954 (“Manufacturer”) warrants its 16 amp Series II Power Conditioners (the “Product”) as follows:... - Page 11 This warranty shall be cancellable by Manufacturer at its sole discretion if the product is modified in any way without written authorization from Furman Sound. This warranty also does not apply to Products upon which repairs have been affected or attempted by persons other than pursuant to written authorization by Manufacturer.
-
Page 12: Specifications
Over Voltage Shutdown: 280 VAC typically (UK version, 260 VAC) Voltmeter Accuracy: PL-PRO E II / PE II: ±4 VAC, calibrated with internal trimpot adjustments PL-PRO DE II / PDE II & PM-PRO E II / PE II: ±1.5 VAC Current Meter Accuracy: PM-PRO E II / PE II: ±0.5 amp...
