PL-PRO POWER CONDITIONER AND LIGHT MODULE
PL-PRO, PL-PRO-E SPECIFICATIONS
Note: Where different, PL-PRO-E specs are in parentheses.
Current rating:
20 Amps, 2400 watts at 120 VAC
(16 Amps, 3600 watts at 230 VAC)
Input Voltage Range:
0 to 280 VAC without damage
Meter Accuracy:
Voltmeter: ± 2 (±4) VAC; Ammeter: ± 2 amps,
calibrated with trimpot adjustments
Spike Protection Modes:
Line to neutral, neutral to ground, line to ground
Clamping Voltage, all modes: TVSS rating 400V peak, L-N, L-G, N-G, tested
to UL 1449 (TVSS rating 400V peak, L-N; 680V
peak, L-G, N-G)
Response time:
1 nanosecond
Maximum surge current:
11,000 amps (8 x 20mS pulse)
Maximum spike energy:
550 joules total
Noise attenuation:
Differential mode: Greater than 40 dB;
Common mode: greater than 60 dB;
both 1 to 200 MHz
Dimensions:
1.75" (4.45 cm) H x 19" (48.25 cm) W
x 8" (25 cm) D.
Weight:
6 lbs (2.7 kg).
Construction:
Steel chassis, zinc chromate plating;
brushed and black anodized aluminum
front panel; glass epoxy printed circuit boards.
Power consumption:
32 watts
Safety Information:
PL-PRO: UL listed. CUL listed.
PL-PRO-E: CE
Options:
"-G" Suffix (PL-PRO only): provides "super
spec", isolated ground 120V outlets for special
applications. Please consult factory before
ordering to determine suitability in your
application.
The Furman PL-PRO is made in the U.S.A.
Furman Sound, Inc.
1997 South McDowell Blvd.
Petaluma, California 94954-6919
Phone: (707) 763-1010
Fax: (707) 763-1310
Web: www.furmansound.com
E-mail: info@furmansound.com
PL-PRO POWER CONDITIONER AND LIGHT MODULE
PRO SERIES
Power Conditioner
and Light Module
Owner's Manual
3-9918
© 1997 FURMAN SOUND, INC.
MODEL PL-PRO
MODEL PL-PRO-E
960110-1405
1
