Print Area

A margin required by the printer is added with respect to the size of paper loaded in the printer. Except in borderless print-
ing, the actual printing area corresponds to the paper size minus the space for this margin.
Note
• Printable Area: The area that can be printed.
• There is no margin (that is, a margin of 0 mm) during borderless printing on rolls.
• Recommended Print Area: We recommend printing within this area.
• To print so that your original matches the print area exactly, use an oversized paper size that includes the
required margin. (See "Printing on Oversized Paper.")
Top Edge
Sheets 3 mm (0.12 in)
Rolls 0/3 mm (0/0.12
in)
Sheets
• Printable Area
a margin of 3 mm (0.12 in) on top, 23 mm (0.91 in) on bottom, and 3 mm (0.12 in) on left and right sides is required.
• Recommended Print Area
A margin of 20 mm (0.79 in) on top, 23 mm (0.91 in) on bottom, and 5 mm (0.20 in) on left and right sides is required.
Rolls
iPF650
Margins of Printable Area
Bottom Edge Sides
23 mm (0.91 3 mm (0.12 in)
in)
0/3 mm (0/0.12 0/3 mm
in) (0/0.12 in)
Printer Parts
→P.84
Margins of Recommended Print Area
Top Edge Bottom Edge
20 mm (0.79 23 mm (0.91
in) in)
20 mm (0.79 5 mm (0.20 in)
in)
> Printer Specifications >
Sides
5 mm (0.20 in)
5 mm (0.20 in)
Print Area
